Prediction and identification of gas-bearing properties of tight sandstone reservoirs through simultaneous pre-stack inversion:A case study of block S in Sulige gas field
-
摘要: 苏里格S区块储层与围岩阻抗差异小、气水关系复杂,叠后纵波阻抗反演方法难以区分优质储层,通过研究区岩石物理分析可知,叠前参数纵横波比可以有效区分岩性和含气性。本文首先进行模型正演确定储层地震响应特征;然后通过适用于砂泥岩的Xu-White模型进行岩石物理建模及横波预测,建立岩石物理模板;其次采取线性去噪、剩余振幅补偿等处理方法对CRP道集进行优化;最后通过叠前同时反演定量预测储层厚度及含气性。结果表明:①储层顶界的地震反射特征为强波谷反射,底界反射不明显;②纵横波比小于1.68可有效划分砂岩,联合纵波阻抗小于12 200 g·cm-3·m·s-1预测储层,再由更低的纵横波比小于1.57识别含气性;③储层展布特征与含气性预测范围趋势相似,但在局部上存在差异,储层发育程度与其含气性不一定呈正相关。本文所提方法期望为下一步圈定有利含气储层面积及井位部署提供有力的技术支撑。Abstract: Owing to the small impedance difference with surrounding rock and complex gas-water relationships,it is difficult to identify high-quality reservoirs in block S in the Sulige gas field through the post-stack P-wave impedance inversion.According to the petrophysical analysis of the study area,the pre-stack parameter vp/vs ratio can be used to effectively identify lithology and gas-bearing properties.This study firstly determined the seismic response characteristics of the reservoirs through forward modeling.Secondly,it conducted petrophysical modeling and the prediction of shear-wave velocities using the Xu-White model suitable for sandstone and mudstone and accordingly established a petrophysical model.Thirdly,the CRP gathers were optimized using the processing methods such as linear denoising and residual amplitude compensation.Finally,the thickness and gas-bearing properties of the reservoirs in block S in the Sulige gas field were quantitatively predicted through simultaneous pre-stack inversion.The results are as follows.(1)The top boundary of the reservoirs in the study area shows the seismic reflection characterized by strong trough reflection,while the bottom boundary of the reservoirs shows unapparent seismic reflection;(2)The vp/vs ratio of less than 1.68 can be used to effectively determine sandstone.This combined with the P-wave impedance of less than 12200 g·cm-3·m·s-1 can be used to predict the reservoirs in the study area. Moreover, a vp/vs of less than 1.57 can be used to identify the gas-bearing properties;(3)Reservoir distribution and the predicted gas-bearing range have similar trends but differ locally.The development degree of reservoirs is not necessarily positively correlated with the gas content.The method proposed in this paper is expected to provide strong technical support for delineating the favorable gas-bearing reservoir area and deploying well locations in the future.
-
-
[1] 何自新, 付金华, 席胜利, 等. 苏里格大气田成藏地质特征[J]. 石油学报, 2003, 24(2):6-12.
[2] He Z X, Fu J H, Xi S L, et al. Geological features of reservoir formation of Sulige gas field[J]. Acta Petrolei Sinica, 2003, 24(2):6-12.
[3] 李凌高, 甘利灯, 杜文辉, 等. 叠前地震反演在苏里格气田储层识别和含气性检测中的应用[J]. 天然气地球科学, 2008, 19(2):261-265.
[4] Li L G, Gan L D, Du W H, et al. Pre-stack seismic inversion applied to reservoir prediction and natural gas detection in SLG gas field[J]. Natural Gas Geoscience, 2008, 19(2):261-265.
[5] 高棒棒, 苏海, 段淑远, 等. 苏里格南部地区地震储层预测技术研究——以盒8段为例[J]. 地球物理学进展, 2020, 35(4):1364-1369.
[6] Gao B B, Su H, Duan S Y, et al. Study of seismic reservoir prediction technology in the southern area of Sulige:A case of 8th member of Shihezi formation[J]. Progress in Geophysics, 2020, 35(4):1364-1369.
[7] 郝亚炬, 高君. 基追踪弹性阻抗反演识别含气砂岩[J]. 物探与化探, 2020, 44(6):1329-1335.
[8] Hao Y J, Gao J. Gas sand preciion using basis pursuit elastic impedance inversion[J]. Geophysical and Geochemical Exploration, 2020, 44(6):1329-1335.
[9] 杨森, 吴国忱, 张明振, 等. 基于稀疏表示的增维叠前地震反演方法[J]. 石油地球物理勘探, 2020, 55(2):398-410.
[10] Yang S, Wu G C, Zhang M Z, et al. Multi-dimensional pre-stack seismic inversion based on sparse representation[J]. Oil Geophysical Prospecting, 2020, 55(2):398-410.
[11] 李建华, 刘百红, 张延庆, 等. 叠前AVO反演在储层含油气性预测中的应用[J]. 石油地球物理勘探, 2016, 51(6):1180-1186.
[12] Li J H, Liu B H, Zhang Y Q, et al. Oil-bearing reservoir prediction with prestack AVO inversion[J]. Oil Geophysical Prospecting, 2016, 51(6):1180-1186.
[13] 高云, 朱应科, 赵华, 等. 叠前同时反演技术在砂砾岩体有效储层预测中的应用[J]. 石油物探, 2013, 52(2):223-228.
[14] Gao Y, Zhu Y K, Zhao H, et al. Application of simultaneous pre-stack inversion technology in effective reservoir prediction of glutenite bodies[J]. Geophysical Prospecting for Petroleum, 2013, 52(2):223-228.
[15] 刘浩杰, 陈雨茂, 王延光, 等. 粘弹介质叠前四参数同步反演及应用[J]. 物探与化探, 2021, 45(1):140-148.
[16] Liu H J, Chen Y M, Wang Y G, et al. Prestack four-parameter synchronous inversion method based on viscoelastic medium theory and its applications[J]. Geophysical and Geochemical Exploration, 2021, 45(1):140-148.
[17] 沙志彬, 万晓明, 赵忠泉, 等. 叠前同时反演技术在珠江口盆地西部海域天然气水合物储层预测中的应用[J]. 物探与化探, 2019, 43(3):476-485.
[18] Sha Z B, Wan X M, Zhao Z Q, et al. The application of pre-stack simultaneous inversion to gas hydrates reservoir prediction in the western Pearl River Mouth basin[J]. Geophysical and Geochemical Exploration, 2019, 43(3):476-485.
[19] 黄芸, 梅玲, 关键, 等. 模型正演技术在准噶尔盆地东部地震解释中的应用[J]. 新疆石油地质, 2012, 33(5):554-556,604.
[20] Huang Y, Mei L, Guan J, et al. Application forward modeling technigue to seismic interpretation in Eastern Junggar Basin[J]. Xinjiang Petroleum Geology, 2012, 33(5):554-556,604.
[21] Keys R G, Xu S Y. An approximation for the Xu-White velocity model[J]. Geophysics, 2002, 67(5):1406-1414.
[22] Xu S Y, White R E. A physical model for shearwave velocity prediction[J]. Geophysical Prospecting, 1996, 44(4):687-717.
[23] Gassmann F. Uber die Elastizitat poroser Medien[J]. Veirteljahrss-chrift der Naturforschenden Gesellschaft in Zurich, 1951, 96(1):1-23.
[24] Biot M A. Theory of propagation of elastic waves in a fluid saturated porous solid,Ⅰ-Low frequency range and Ⅱ-Higher-frequency range[J]. Journal of the Acoustical of America, 2005, 28(2):179-191.
[25] Brie A, Pampuri F, Meazza A F, et al. Shear sonic interpretation in gas-bearing sands[C]// Dallas:SPE Annual Technical Conference and Exhibition, 1995:701-710.
[26] 井元帅. 致密砂岩含气储层预测方法优化及应用——以苏53区块为例[J]. 天然气勘探与发, 2019, 42(3):78-85.
[27] Jing Y S. Methods to predict tight sandstone their application to gas-bearing reservoirs and Su 53 block[J]. Natural Gas Exploration and Development, 2019, 42(3):78-85.
[28] 包培楠, 王维红, 李文龙, 等. CRP道集优化处理及其在大庆油田S区的应用[J]. 物探与化探, 2019, 43(5):1030-1037.
[29] Bao P N, Wang W H, Li W L, et al. CRP gather optimization processing and its application in S area of Daqing Oilfield[J]. Geophysical and Geochemical Exploration, 2019, 43(5):1030-1037.
-
