Analysis of tunnel inflow conditions based on the characteristics of typical tight-narrow monoclinic karst water system in the central Yunnan Province, China
-
摘要:
中国西南地区分布着大面积的碳酸盐岩，地层和构造的空间组合结构差异形成了多种复杂而各具特色的岩溶水系统。当隧洞穿越岩溶水系统时，涌水问题表现各异，涌水条件难以识别，这一直是隧洞工程建设面临的重要挑战。滇中引水工程小扑隧洞隧址区发育线状延伸、紧密互层的可溶与非可溶岩地层，构成典型的紧窄单斜岩溶水系统。文章细致梳理研究区岩溶水系统特征的控制性因素，结合地下水监测信息和水化学特征识别小扑隧洞的涌水条件。结果表明：紧窄单斜构造影响了岩溶发育的空间格局和地下水的径流及转换方式，控制着含水层介质发育和地下水补径排分布的特征，进而可将研究区细分为4个特征各异的小尺度岩溶水系统。小扑隧洞不同段穿越的岩溶水系统特征差异较大，隧洞涌水经历的水文地球化学作用过程不尽相同，综合认为隧洞1#洞段涌水来源于暗河管道，2#洞段涌水为揭露岩溶裂隙所致，补给高程分别为2 165.4 m和2 234.69 m，并初步确定各自的充水水源补给范围。研究结果可为后续隧洞防排水工程方案设计以及突涌水灾害防治提供依据。
Abstract:The southwest China is covered by large areas of carbonate rock strata, in which the movement of many terranes results in strong folds and rock fractures. The spatial structure diversity of strata and tectonics has formed various complex and distinctive karst water systems. Therefore, tunnels for traffic lines and water diversion projects are often built in southwest China, but when tunnels cross karst water systems, the tunnel inflow conditions are difficult to be identified due to the complexity of water inflow, which has been a challenge in tunnel construction projects. In the Xiaopu tunnel area of the central Yunnan Province, linear extension and closely interbedded soluble and non-soluble rock strata are developed, forming a typical tight-narrow monoclinic karst water system. Since the tunnel construction, the water inrush has respectively occurred in Section 1 and Section 2 with large and long-lasting water inflow. The complexity of the water inflow brings a great challenge for the tunnel construction. Therefore, it is urgent to find out the source and mode of water inflow in Xiaopu tunnel. Focusing on specific engineering problems, this study carefully sorts out the controlling factors of the characteristics of the tight-narrow monoclinic karst water system in Xiaopu tunnel. The division of the karst water system is reduced to a small scale, and the water inflow conditions of the tunnel are identified according to the groundwater monitoring data as well as the inflow conditions such as the hydrochemical characteristics and hydrogen and oxygen isotopes of water inflow.
The results show that the tight-narrow monoclinic structure affects the spatial pattern of karst development, the runoff and the transformation mode of groundwater. This structure also controls the characteristics of aquifer media development and groundwater recharge, runoff and discharge distribution. Hence, the study area can be subdivided into four small-scale karst water systems with different characteristics, i.e., the bare-covered fissure flow and conduit flow with concentrated discharge, bare conduit flow with concentrated discharge, the bare-covered fissure flow with multiplex discharge, and the bare fissure flow with concentrated discharge. The hydrochemical type of groundwater in the Duimen-Daliyuan-Niuliancun karst water system, which is crossed by the Section 1 of Xiaopu tunnel, is mainly HCO3·SO4-Ca·Mg. And the concentration of Ba2+ in groundwater is higher than that in other karst water systems due to the dissolution of barite minerals in the strata of the Weining group of the middle Carboniferous and the upper Devonian. The hydrochemical type of groundwater in the Piantoushan-Lunacun-Jinxiandong karst water system crossed by Section 2 is HCO3-Ca·Mg, indicating relatively pure karst water. This shows that dolomite dissolution is the main hydrochemical process for controlling water quality. Due to the slow flow of the karstic fracture network, the groundwater has a long residence time in the runoff path, and the water-rock interaction and evaporation are relatively strong, thus the heavy hydrogen and oxygen isotopes are more enriched. Huge differences in hydrogen and oxygen isotope composition also rule out the possibility of surface water flooding into the tunnel. It is concluded that the water inflow in Section 1 is caused by the uncovering of the underground conduit and the interception of the discharge spring of the shallow karst downstream. The karst conduit developed in the contact zone of igneous rock constitutes the main water inflow channel, in which the groundwater in the conduit is the water source with a recharge elevation of 2,165.4 m, mainly located in the karst depression in the north of Wangjiawan. The water inflow in Section 2 is caused by the exposure of karst fissures. The fissure network constitutes the main water flow passage, and the groundwater in Dengying formation is the water source, with a recharge elevation of 2,234.6 m, mainly located in the slope area on the north ridge of Piantou mountain.
The groundwater in different karst water systems has experienced different water-rock interaction and evaporation processes. Therefore, the hydrochemistry and stable hydrogen and oxygen isotopes of groundwater are good natural tracers for tracing the source of water inflows in tunnels crossing different karst water systems. Comprehensive utilization of multiple approaches and information verification can improve the accuracy of identifying tunnel water inflow conditions, which may provide a basis for the subsequent design of tunnel drainage projects and the prevention of water inrush disasters in the tunnel.
-
-
表 1 紧窄单斜小尺度岩溶水系统特征
Table 1. Characteristics of the tight-narrow monoclinic karst water system at a small scale
岩溶水系统名称 对门－大梨园－牛恋村 王家湾－青菜村－干硐村 偏头山－鲁纳村－金线洞 三印村－龙潭村 特征 裸露-覆盖隙-管流集中排泄型 裸露管流集中排泄型 裸露-覆盖隙流复合排泄型 裸露隙流集中排泄型 岩溶含
水系统含水岩组 二叠系阳新组、泥盆系－
石炭系、震旦系灯影组二叠系阳新组、泥盆系－石炭系 震旦系灯影组、陡山沱组 含水介质 溶隙、溶管 溶管 裂隙、溶隙 空间结构 单斜、陡倾 岩溶水
流系统补给方式 集中贯入 分散入渗 补给特点 量大、集中、迅速 连续、面广 径流方式 顺岩层走向集中流 顺岩层走向散流 四周散流 径流面积 25.6 km2 15 km2 23.4 km2 13.9 km2 排泄方式 集中排泄 集中排泄和湖盆排泄
带分散排泄集中排泄 排泄高程 1 886~1 932 m 2 149 m 1 890 m 2 105~2 114 m 泉成因 溢流 溢流 侵蚀 溢流、侵蚀 动态特征 季节性、水文响应快 水量稳定、水文响应滞后 岩溶水系统边界 岩性界线、分水岭、滇池南岸 岩性界线、分水岭 岩性界线、分水岭、滇池南岸 岩性界线、分水岭
下载: 导出CSV
表 2 小扑隧洞区水样的水化学测试结果
Table 2. Hydrogeological test results of water samples in Xiaopu tunnel area
编号 取样位置 Ca2+ Mg2+ Ba2+ ${\rm{HCO}}_3^{-}$ TDS 舒卡列夫水
化学分类mg·L−1 N1 对门－大梨园－牛恋村岩溶水系统 7.67 3.71 0.001 9 18.3 32 HCO3·SO4-Ca·Mg·Na N2 31.65 10.48 0.007 6 48.8 100 HCO3-Ca·Mg N3 143.50 36.19 0.060 0 97.6 385 HCO3·SO4-Ca·Mg J1 偏头山－鲁纳村－金线洞岩溶水系统 10.80 2.46 0.003 3 115.9 222 HCO3-Ca·Na W1 王家湾－青菜村－干硐村岩溶水系统 12.01 4.87 0.012 6 30.5 45 HCO3·SO4-Ca·Mg W2 13.40 8.26 0.003 7 18.3 59 HCO3·SO4·Cl-Mg·Ca W3 − 14.99 0.040 1 − − − W4 43.90 19.33 0.112 2 79.3 147 HCO3·SO4-Ca·Mg L1 三印村－龙潭村岩溶水系统 55.39 20.26 0.003 6 134.2 208 HCO3-Ca·Mg L2 13.49 1.04 0.004 0 51.3 102 HCO3-Ca SD1 1#洞段涌水 51.26 18.22 0.018 5 81.8 172 HCO3·SO4-Ca·Mg SD2 2#洞段涌水 40.34 18.92 0.006 2 85.4 134 HCO3-Ca·Mg 注：“−”未检测。
Note: "−" Not detect.
下载: 导出CSV
表 3 隧洞涌水补给高程计算结果
Table 3. Calculation results of the recharge elevation of tunnel water inflow
项目 δDVSMOW/‰ δ18OVSMOW/‰ 推算补给高程/m 1#洞段涌水 −87.12 −11.8 2165.4 2#洞段涌水 −89.05 −11.98 2234.6
下载: 导出CSV
-
[1] 中国科学院地质研究所岩溶研究组. 中国岩溶研究[M]. 北京: 科学出版社, 1979.
Karst Research Group, Institute of Geology, Chinese Academy of Sciences. Karst research in China[M]. Beijing: Science Press, 1979.
[2] 刘训, 李廷栋, 耿树方, 游国庆. 中国大地构造区划及若干问题[J]. 地质通报, 2012, 31(7):1024-1034.
LIU Xun, LI Tingdong, GENG Shufang, YOU Guoqing. Geotectonic division of China and some related problems[J]. Geological Bulletin of China, 2012, 31(7):1024-1034.
[3] 王宇. 断陷盆地岩溶水赋存规律[M]. 昆明: 云南科技出版社, 2003.
WANG Yu. Storage rule of karst water in fault basin[M]. Kunming: Yunnan Science and Technology Press, 2003.
[4] 蒋忠诚, 夏日元, 时坚, 裴建国, 何师意, 梁彬. 西南岩溶地下水资源开发利用效应与潜力分析[J]. 地球学报, 2006(5):495-502.
JIANG Zhongcheng, XIA Riyuan, SHI Jian, PEI Jianguo, HE Shiyi, LIANG Bin. The application effects and exploitation capacity of karst underground water resources in Southwest China[J]. Acta Geoscientica Sinica, 2006(5):495-502.
[5] 李潇, 漆继红, 许模. 西南典型紧窄褶皱小尺度浅层岩溶水系统特征及隧道涌水分析[J]. 中国岩溶, 2020, 39(3):375-383.
LI Xiao, QI Jihong, XU Mo. Analysis on the characteristics of small-scale shallow karst water systems in typical tight-narrow folds and tunnel water inrush in Southwestern China[J]. Carsologica Sinica, 2020, 39(3):375-383.
[6] 郭绪磊, 周宏, 罗明明, 黄琨, 况野, 曾圆梦, 陈一帆, 张苏雅. 黄陵穹隆周缘岩溶水流系统特征及成因[J]. 地质科技通报, 2022, 41(1):328-340.
GUO Xulei, ZHOU Hong, LUO Mingming, HUANG Kun, KUANG Ye, ZENG Yuanmeng, CHEN Yifan, ZHANG Suya. Characteristics and genesis of karst water flow system around Huangling anticline[J]. Bulletin of Geological Science and Technology, 2022, 41(1):328-340.
[7] 裴建国, 梁茂珍, 陈阵. 西南岩溶石山地区岩溶地下水系统划分及其主要特征值统计[J]. 中国岩溶, 2008, 27(1):6-10.
PEI Jianguo, LIANG Maozhen, CHEN Zhen. Classification of karst groundwater system and statistics of the main characteristic values in Southwest China karst mountain[J]. Carsologica Sinica, 2008, 27(1):6-10.
[8] 王宇, 张华, 张贵, 王波, 彭淑惠, 何绕生, 周翠琼. 喀斯特断陷盆地环境地质分区及功能[J]. 中国岩溶, 2017, 36(3):283-295.
WANG Yu, ZHANG Hua, ZHANG Gui, WANG Bo, PENG Shuhui, HE Raosheng, ZHOU Cuiqiong. Zoning of environmental geology and functions in karst fault depression basins[J]. Carsologica Sinica, 2017, 36(3):283-295.
[9] 罗明明, 周宏, 郭绪磊, 陈乾龙, 齐凌轩, 况野. 峡口隧道间歇性岩溶涌突水过程及来源解析[J]. 地质科技通报, 2021, 40(6):246-254.
LUO Mingming, ZHOU Hong, GUO Xulei, CHEN Qianlong, QI Lingxuan, KUANG Ye. Processes and sources identification of intermittent karst water inrush in Xiakou tunnel[J]. Bulletin of Geological Science and Technology, 2021, 40(6):246-254.
[10] 郭纯青, 田西昭. 岩溶隧道涌水量综合预测:以朱家岩岩溶隧道为例[J]. 水文地质工程地质, 2011, 38(3):1-8.
GUO Chunqing, TIAN Xizhao. A comprehensive forecast of water inflow in karst tunnels: Exemplified by the Zhujiayan karst tunnel[J]. Hydrogeology & Engineering Geology, 2011, 38(3):1-8.
[11] 常威, 谭家华, 黄琨, 程烯, 黄镇, 万军伟. 地下水多元示踪试验在岩溶隧道水害预测中的应用:以张吉怀高铁兰花隧道为例[J]. 中国岩溶, 2020, 39(3):400-408.
CHANG Wei, TAN Jiahua, HUANG Kun, CHENG Xi, HUANG Zhen, WAN Junwei. Application of groundwater multi-element tracing tests to water hazard prediction of karst tunnels: An example of the Lanhua tunnel on the Zhangjiajie-Jishou-Huaihua high-speed railway[J]. Carsologica Sinica, 2020, 39(3):400-408.
[12] Luo Mingming, Chen Zhihua, Criss Robert E, Zhou Hong, Huang He, Han Zhaofeng, Shi Tingting. Dynamics and anthropogenic impacts of multiple karst flow systems in a mountainous area of South China[J]. Hydrogeology Journal, 2016, 24(8):1993-2002. doi: 10.1007/s10040-016-1462-3
[13] 张华, 王宇, 柴金龙. 滇池流域石漠化特征分析[J]. 中国岩溶, 2011, 30(2):181-186. doi: 10.3969/j.issn.1001-4810.2011.02.010
ZHANG Hua, WANG Yu, CHAI Jinlong. Analysis on the desert's characteristics in Dianchi watershed[J]. Carsologica Sinica, 2011, 30(2):181-186. doi: 10.3969/j.issn.1001-4810.2011.02.010
[14] 徐则民, 黄润秋, 罗杏春. 特长岩溶隧道涌水预测的系统辨识方法[J]. 水文地质工程地质, 2002, 29(4):50-54.
XU Zemin, HUANG Runqiu, LUO Xingchun. Identification of karst water system in long tunnel[J]. Hydrogeology & Engineering Geology, 2002, 29(4):50-54.
[15] 连会青, 刘德民, 尹尚先. 水化学综合识别模式在矿井水源判别中的应用[J]. 煤炭工程, 2012(8):107-109, 113.
LIAN Huiqing, LIU Demin, YIN Shangxian. Application of hydrochemistry comprehensive identification mode to distinguish mine water resources[J]. Coal Engineering, 2012(8):107-109, 113.
[16] 谈树成, 周家喜, 罗开, 向震中, 何小虎, 张亚辉. 云南毛坪大型铅锌矿床成矿物质来源:原位S和Pb同位素制约[J]. 岩石学报, 2019, 35(11):3461-3476. doi: 10.18654/1000-0569/2019.11.13
TAN Shucheng, ZHOU Jiaxi, LUO Kai, XIANG Zhenzhong, HE Xiaohu, ZHANG Yahui. The sources of ore-forming elements of the Maoping large-scale Pb-Zn deposit, Yunnan Province: Constrains from in-situ S and Pb isotopes[J]. Acta Petrologica Sinica, 2019, 35(11):3461-3476. doi: 10.18654/1000-0569/2019.11.13
[17] 彭晓红, 丁文荣. 滇中高原岩溶区典型植物旱雨季水分来源的差异特征[J]. 应用与环境生物学报, 2023, 29(1): 204-211.
PENG Xiaohong, DING Wenrong. Different characteristics of water sources of typical plants in dry and rainy seasons in karst area of central Yunnan Plateau[J]. Chinese Journal of Applied and Environmental Biology, 2023, 29(1): 204-211.
[18] 黄荷, 罗明明, 陈植华, 周宏, 张亮, 周彬, 史婷婷. 香溪河流域大气降水稳定氢氧同位素时空分布特征[J]. 水文地质工程地质, 2016, 43(4):36-42.
HUANG He, LUO Mingming, CHEN Zhihua, ZHOU Hong, ZHANG Liang, ZHOU Bin, SHI Tingting. The spatial and temporal distribution of stable hydrogen and oxygen isotope of meteoric water in Xiangxi river basin[J]. Hydrogeology & Engineering Geology, 2016, 43(4):36-42.
[19] 王梅, 许模. 滇池盆地东侧黑龙潭与白龙潭水力关系研究[J]. 地下水, 2018, 40(2):15-17.
WANG Mei, XU Mo. On the hydraulic connection between Heilongtan and Bailongtan in the eastern part of Dianchi basin[J]. Ground Water, 2018, 40(2):15-17.
-
