Dynamic characteristics of groundwater level and exploitable amount of groundwater source in Jiuxian county, Tai'an
-
摘要:
泰安市城区水资源供需矛盾突出，地下水资源开采引发了岩溶塌陷等地质环境问题，亟需查明岩溶塌陷生态水位约束下水源地的允许开采量，确定水源地最优取水方案。以旧县水源地1980—2021年的地下水位、年降水量、地下水开采量、岩溶塌陷等数据为基础，探讨人类活动对水源地地下水位的演变的影响因素，分析发生岩溶塌陷的地下水临界水位。基于Modflow-GWM软件构建泰安城区−旧县岩溶水系统流动与管理耦合模拟模型，探讨防止岩溶塌陷发生的地下水允许开采的资源量。结果表明：（1）孔隙水水位年内动态受降水影响明显，呈现“降水−补给”型特点；岩溶水水位变化呈“枯低丰高”的特征，水位动态变化属降水入渗−开采型；（2）旧县水源地地下水位自1980—1990年呈现大幅下降，1990—2003年岩溶地下水位基本呈现波动下降，2004年后水源地地下水位上升较为明显；（3）研究水位动态与岩溶塌陷关系得出，防止发生岩溶塌陷的水源地临界水位为108 m，处于岩溶含水层顶板以上2 m；（4）通过地下水管理模型，确定在临界水位时模拟区岩溶水可开采量为8.2~8.5 万m3·d−1，其中旧县水源地可开采资源量为3.2~3.5万m3·d−1。
Abstract:In this study, the effect of human activities on the evolution characteristics of groundwater levels in the water source area of Jiuxian county and its influencing factors have been discussed, based on the data of groundwater levels, annual precipitation, groundwater mining output and karst collapse in the study area from 1980 to 2021. The critical groundwater level to prevent karst collapse has also been determined. In addition, based on Modflow-GWM software, a coupled simulation model for the flow and management of karst water system in Tai'an City and Jiuxian county has been constructed, thereby exploring the allowable extraction of water resources in terms of the karst collapse prevention.
The research results indicate that, (1) The annual dynamics of interstitial water are significantly affected by precipitation, with the lowest annual water level in late June and the annual highest from late August to late September during the rainy season, presenting the characteristics of "precipitation-replenishment" type. The dynamics of karst groundwater within the year are affected by the obstruction of pore water discharge in the Quaternary system. The highest water level within the year generally lags slightly behind the concentration from September to October, while the lowest water level occurs from May to June. The groundwater level changes by about 5 meters within the year. The water level changes exhibit a characteristic of "a low water level in the dry season and a high water level in the wet season", and the dynamic changes of water levels are characterized with the type of "precipitation infiltration-mining". (2) The groundwater level in the water source area of Jiuxian county showed a significant downward trend from 1980 to 1990, and the karst groundwater level showed a basic fluctuation and decline from 1990 to 2003. The groundwater level in the water source area has increased significantly since 2004. (3) Since 1988, the water source area in Jiuxian county has entered a period of high incidence of karst collapse. From then on to 1994, the water level had rebounded, fluctuating between 96 m and 108 m and was located near the bedrock surface. This period had also experienced a high incidence of karst collapse in this area, with the collapse area expanding northward from Jiuxian county to the Yuanzhuang-Yanglou area. After 1995, the intensity of karst collapse in the area decreased, but there still occurred collapse from time to time. By 2001 the development period of karst collapse in the area, the water level showed an overall downward trend and fluctuated above and below the bedrock surface, with an elevation of 95–110 m. In the first half of 2003, high-intensity mining continued, with water levels ranging from 86 m to 98 m. In 2013, the high-intensity mining in the rainy season and continuous low water levels caused geological disasters of high-intensity karst collapse at a large-scale. Since 2005, water levels have shown an overall upward trend, fluctuating between 106 m and 116 m above the bedrock surface. During this period, one time of collapse occurred in 2006, and no new collapse was observed. Based on the relationship between water level dynamics and karst collapse, the critical water level of the water source area to prevent karst collapse is 108 m, located 2 m above the roof of the karst aquifer. (4) According to the groundwater management model, the mining output of karst water in the simulation area at the critical water level is determined to be 82,000–85,000 m3·d−1, of which the exploitable volume of centralized exploitation in the water source area of Jiuxian county is 32,000−35,000 m3·d−1. This study is of great significance for the sustainable development and utilization of karst groundwater resources and the tackling of environmental geological problems.
-
-
表 1 识别验证后模拟区降水入渗系数取值一览表
Table 1. Values for precipitation infiltration coefficient in the simulated area after identification and verification
参数分区 参数分区 参数分区描述 1 0.12 山前基岩裸露区 2 0.20 丘陵山前地带，岩性为砂质黏土夹砾石粉砂，厚度薄 3 0.30 牟汶河河道两侧，岩性为砂含砾石 4 0.14 基岩裸露区 5 0.25 位于牟汶河西侧，土地类型主要为农耕地、林地，植被覆盖率较高 6 0.22 位于泰安城区及以西，岩性主要为粉质黏土夹中粗砂 7 0.22 分布于城区水源地周边 8 0.21 丘陵山前地带
下载: 导出CSV
表 2 识别验证后模拟区孔隙水渗透系数和给水度赋值
Table 2. Pore groundwater permeability coefficient and yield value in the simulated area after identification and verification
分区 水平K/m·d−1 垂向/m·d−1 给水度 分区 水平K/m·d−1 垂向K/m·d−1 给水度 1 0.15 0.000 10 0.040 8 3.00 0.000 30 0.23 2 0.15 0.000 10 0.040 9 0.85 0.000 15 0.30 3 2.80 0.000 18 0.070 10 0.75 0.000 15 0.30 4 3.00 0.000 30 0.230 11 3.00 0.000 50 0.35 5 15.50 1.500 00 0.200 12 0.50 0.000 10 0.25 6 0.15 0.000 15 0.045 13 5.00 0.000 50 0.35 7 3.00 0.000 30 0.230
下载: 导出CSV
表 3 识别验证后模拟区岩溶水渗透系数和贮水系数赋值
Table 3. Values of permeability coefficient and storage coefficient of karst water in the simulated area after identification and verification
分区 水平K/m·d−1 垂向K/m·d−1 弹性储水率/m−1 0 15.0 104.00 6.0×10−4 1 5.0 0.50 5.0×10−4 2 4.5 0.45 3.0×10−4 3 2.5 0.25 2.5×10−4 4 2.8 0.28 3.0×10−5 5 2.0 0.20 5.5×10−4 6 2.3 0.21 3.5×10−5 7 4.0 0.40 5.0×10−5 8 4.5 0.80 9.5×10−5 9 4.0 0.20 5.0×10−5
下载: 导出CSV
表 4 模拟开采10年地下水量均衡分析表
Table 4. Equilibrium analysis of groundwater amount in simulated mining for 10 years
均衡项 流入流出量/万m3·d−1 流入流出量/万m3·年−1 百分比/% 补给项 孔隙水 降水入渗量 6.80 2 482.00 83.64 河流入渗量 0.28 102.20 3.44 灌溉入渗量 0.85 310.25 10.46 侧向流入量 0.20 73.00 2.46 小计 8.13 2 967.45 100 岩溶水 降雨入渗量 0.58 211.70 6.61 河道渗漏量 2.55 930.75 29.04 侧向径流量 0.65 237.25 7.40 越流补给量 5.00 1 825.00 56.95 小计 8.78 3 204.70 100 排泄项 孔隙水 农业开采量 1.50 547.50 23.08 越流排泄量 5.00 1 825.00 76.92 小计 6.50 2 372.50 100 岩溶水 水源地集中开采量 3.50 1 277.50 41.18 分散开采量 5.00 1 825.00 58.82 小 计 8.50 3 102.50 100 孔隙水补排差 1.63 594.95 / 岩溶水补排差 0.28 102.20 /
下载: 导出CSV
-
[1] 闫佰忠, 孙丰博, 李晓萌, 王玉清, 范成博, 陈佳琦. 气候变化与人类活动对石家庄市藁城区地下水位埋深的影响[J]. 吉林大学学报(地球科学版), 2021, 51(3):854-863. doi: 10.13278/j.cnki.jjuese.20200147
YAN Baizhong, SUN Fengbo, LI Xiaomeng, WANG Yuqing, FAN Chengbo, CHEN Jiaqi. Impact of climate change and human activities on groundwater depth of Gaocheng district in Shijiazhuang City[J]. Journal of Jilin University (Earth Science Edition), 2021, 51(3):854-863. doi: 10.13278/j.cnki.jjuese.20200147
[2] 胡振通, 王亚华. 华北地下水超采综合治理效果评估:以冬小麦春灌节水政策为例[J]. 干旱区资源与环境, 2019, 33(5):101-106.
HU Zhentong, WANG Yahua. Effectiveness assessment on comprehensive governance of groundwater over-exploition in North China Plain: The policy of winter wheat's water-saving by reducing spring irrigation[J]. Journal of Arid Land Resources and Environment, 2019, 33(5):101-106.
[3] 戴长雷, 王羽, 王美玉, 韩心宇. 区域地下水水位水量双控管理研究[J]. 黑龙江大学工程学报, 2021, 12(1):1-8. doi: 10.13524/j.2095-008x.2021.01.001
DAI Changlei, WANG Yu, WANG Meiyu, HAN Xinyu. Study on dual control management of regional groundwater level and groundwater volume[J]. Journal of Engineering of Heilongjiang University, 2021, 12(1):1-8. doi: 10.13524/j.2095-008x.2021.01.001
[4] 吴亚楠. 泰安市城区−旧县水源地岩溶地面塌陷历程及影响因素分析[J]. 中国岩溶, 2020, 39(2):225-231.
WU Ya'nan. Process and influencing factors of karst ground collapse in the water sources of Tai'an-Jiuxian[J]. Carsologica Sinica, 2020, 39(2):225-231.
[5] 吴亚楠. 泰安市城区−旧县水源地岩溶塌陷演化过程分析[J]. 中国岩溶, 2017, 36(1):94-100. doi: 10.11932/karst20170112
WU Ya'nan. Analysis of karst collapse development in Tai'an-Jiuxian water source area[J]. Carsologica Sinica, 2017, 36(1):94-100. doi: 10.11932/karst20170112
[6] 周博文, 李华明, 常宝成. 额仁淖尔水源地靶区地下水可开采潜力分析及可增加开采量评价[J]. 世界核地质科学, 2022, 39(2):364-373. doi: 10.3969/j.issn.1672-0636.2022.02.020
ZHOU Bowen, LI Huaming, CHANG Baocheng. Analysis on exploitable groundwater potential and evaluation of exploitable augmentation in Erennur water source target area[J]. World Nuclear Geoscience, 2022, 39(2):364-373. doi: 10.3969/j.issn.1672-0636.2022.02.020
[7] 李若怡, 王旭升, 尹立河, 张俊, 王晓勇. 基于生态约束模拟评价浩勒报吉水源地的地下水可开采量[J]. 工程勘察, 2021, 49(3):36-42, 78.
LI Ruoyi, WANG Xusheng, YIN Lihe, ZHANG Jun, WANG Xiaoyong. Simulation and assessment on allowable groundwater exploitation in the Haolebaoji well field based on ecological constraint[J]. Geotechnical Investigation & Surveying, 2021, 49(3):36-42, 78.
[8] Vimalav. Groundwater management strategy for the sustainability of quality water resources in Coimbatore: A case study[J]. Asian Journal of Multidimensional Research, 2018, 7(1):115-128.
[9] Alfaro P, Liesch T, Goldscheider N. Modelling groundwater over-extraction in the southern Jordan Valley with scarce data[J]. Hydrogeology Journal, 2017, 25(5):1319-1340. doi: 10.1007/s10040-017-1535-y
[10] 马雄德, 黄金廷, 李吉祥, 宁世雄. 面向生态的矿区地下水位阈限研究[J]. 煤炭学报, 2019, 44(3):675-680. doi: 10.13225/j.cnki.jccs.2018.6050
MA Xiongde, HUANG Jinting, LI Jixiang, NING Shixiong. Groundwater level threshold under the constrain of ecology security in mining area[J]. Journal of China Coal Society, 2019, 44(3):675-680. doi: 10.13225/j.cnki.jccs.2018.6050
[11] 付晓刚, 唐仲华, 刘彬涛, 蔺林林,卜华, 闫佰忠. 基于模拟−优化模型的山东羊庄盆地地下水可开采量研究[J]. 吉林大学学报(地球科学版), 2019, 49(3):784-796. doi: 10.13278/j.cnki.jjuese.20180083
FU Xiaogang, TANG Zhonghua, LIU Bintao, LIN Linlin, BU Hua, YAN Baizhong. Study on exploitable groundwater resources of Yangzhuang basin in Shandong Province by using simulation-optimization model[J]. Journal of Jilin University (Earth Science Edition), 2019, 49(3):784-796. doi: 10.13278/j.cnki.jjuese.20180083
[12] 陈伟清, 王延岭. 山东省泰安市城区−旧县岩溶水系统地下水资源潜力评价[J]. 中国岩溶, 2014, 33(1):9-14.
CHEN Weiqing, WANG Yanling. Evaluation of the potential groundwater resources in Tai'an urban-Jiuxian karst water system, Shandong Province[J]. Carsologica Sinica, 2014, 33(1):9-14.
[13] 山东省地矿局第一地质大队. 山东省泰安市水资源管理模型报告[R]. 1990.
[14] 高宗军, 孙文广, 唐蒙生, 武新岭, 刘明, 韩云龙, 程锡良. 泰安−旧县水源区岩溶水开采与地质环境的关系[J]. 山东地质, 2001, 17(3):86-91.
GAO Zongjun, SUN Wenguang, TANG Mengsheng, WU Xinling, LIU Ming, HAN Yunlong, CHENG Xiliang. Relation between karstic water exploitation and geological environment in Tai'an-Jiuxian water source area[J]. Shandong Geology, 2001, 17(3):86-91.
-
