Control action of thrust fault to oil and gas accumulation in Hade block of the Fuman oilfield
-
摘要:
塔里木盆地奥陶系碳酸盐岩是我国深层油气勘探开发的重点领域。近年来，富满油田断控油气藏成为油气勘探开发的重点目标，走滑断裂具有控储层、控圈闭、控富集的作用。但在富满油田哈得区块发育的逆冲断裂对油气成藏的控制作用认识不清，制约了该区油气藏的高效开发。为此，文章在分析塔里木盆地富满油田地质背景的基础上，系统总结了哈得区块逆冲断裂及走滑断裂的展布特征，明确了两者平面展布、纵向切割关系和活动时期。结合区域油气成藏期次研究，明确了逆冲断裂对油气成藏的控制作用。研究结果表明：①富满油田走滑断裂形成于中奥陶世末期，即中加里东期，逆冲断裂主要活动期在海西期，晚于走滑断裂形成期；②富满油田主要为3期成藏（晚加里东期、晚海西期和喜山期），逆冲断裂可对晚海西期、喜山期充注成藏造成影响；③逆冲断裂与走滑断裂具有3种组合模式，在此基础上建立了哈得区块受逆冲断裂影响的3种油气成藏输导模式。结论认为，逆冲断裂与油源走滑断裂交汇点在上寒武统一间房组时，对油气成藏最为有利，具有多源供烃、多期成藏特点，对同类型油气藏勘探开发具有一定的指导意义。
Abstract:The Tarim Basin, renowned for its super large Ordovician marine carbonate oil and gas reservoirs, is a key area in the field of deep oil and gas exploration and development in China. Especially, the Fuman oilfield has become an important area in oil and gas exploration and development in recent years, largely owing to its extensively distributed fault-controlled gas reservoirs. Nevertheless, Hade block of the Fuman oilfield faces the complex interaction of thrust faults and strike-slip faults, which poses severe challenges. Due to the lack of comprehensive understanding of the impact of thrust faults on reservoir development, many wells with low yield and low efficiency had been drilled, which seriously hindered the effective exploration and development of oil and gas in this area. Therefore, an exhaustive geological examination of the Fuman oilfield in the Tarim Basin was meticulously conducted. This analytical endeavor was directed towards illuminating the intricacies underlying the synergy of thrust faults and strike-slip faults, and their consequential influence on oil and gas reservoirs. Methodologically, a methodical exploration was undertaken based on state-of-the-art 3D seismic data, thereby offering an all-encompassing perspective on the spatiotemporal characteristics of these fault structures in Hade block. The scrutiny further encompassed the delineation of the planar distribution of these faults, the elucidation of vertical crosscutting relationships, and the ascertaining of fault activity periods. The research findings were subsequently amalgamated with a comprehensive investigation of the regional temporal periods underpinning oil and gas accumulation, thereby proffering a lucid perspective on the dominion of thrust faults in this context.
The investigation results display the key information on the endemic geological evolution of the Fuman oilfield. Foremost, the research findings determine that these fault structures originated from the late Middle Ordovician, especially the Middle Caledonian period. Noticeably, thrust fault activities peaked during the subsequent Hercynian period, i.e. after the appearance of strike-slip faults. This temporal distinction between the fault types is of profound significance for understanding their respective roles in oil and gas accumulation. The Fuman oilfield is divided into three different stages of oil and gas accumulation, namely, the late Caledonian, late Hercynian, and Himalayan stages. The results show that the oil and gas accumulation in the late Caledonian period is mainly affected by strike-slip faults, while the influence of thrust faults is great in the late Hercynian and Himalayan periods. The understanding of the interplay between fault types and oil and gas accumulation is of great significance for accurate exploration and development of benefit model in oil areas. In addition, this study unveiled three distinct modes of convergence between thrust faults and strike-slip faults, based on which three different modes of oil and gas accumulation and conveyance steered by thrust faults in Hade block were delineated.
It is concluded that when thrust faults intersect with non-petroleum-endowed strike-slip faults in the Upper Cambrian-Yijianfang Formation, the reservoir is mainly formed in the late Hercynian period. When thrust faults and petroleum-endowed strike-slip faults intersect in the Middle Cambrian, the reservoir is mainly formed in the late Caledonian period. The intersection of thrust faults and petroleum-endowed strike-slip faults in the Upper Cambrian-Yijianfang Formation is most favorable for oil and gas accumulation, with characteristics of multi-source hydrocarbon supply and multi-stage accumulation. These conclusions provide valuable experience of and incisive insights into the exploration and development of similar oil and gas reservoirs, which is conducive to efficient decision making in the ongoing search for energy resources.
-
Key words:
- Tarim Basin /
- the Fuman oilfield /
- thrust fault /
- strike-slip fault /
- oil and gas accumulation
-
-
[1] 康玉柱. 塔里木盆地海相古生界油气勘探的进展[J]. 新疆石油地质, 2002, 23(1):76-78.
KANG Yuzhu. The progress for onshore marine petroleum exploration of paleozoic in Tarim Basin[J]. Xinjiang Petroleum Geology, 2002, 23(1):76-78.
[2] 张朝军, 贾承造, 李本亮, 罗秀羽, 刘云祥. 塔北隆起中西部地区古岩溶与油气聚集[J]. 石油勘探与开发, 2010, 37(3):263-269. doi: 10.1016/S1876-3804(10)60032-8
ZHANG Chaojun, JIA Chengzao, LI Benliang, LUO Xiuyu, LIU Yunxiang. Ancient karsts and hydrocarbon accumulation in the middle and western parts of the north Tarim Uplift, NW China[J]. Petroleum Exploration and Development, 2010, 37(3):263-269. doi: 10.1016/S1876-3804(10)60032-8
[3] 邬光辉, 李启明, 张宝收, 董立胜, 张亚光, 张欢庆. 塔中Ⅰ号断裂坡折带构造特征及勘探领域[J]. 石油学报, 2005, 26(1):27-30.
WU Guanghui, LI Qiming, ZHANG Baoshou, DONG Lisheng, ZHANG Yaguang, ZHANG Huanqing. Structural characteristics and exploration fields of No.1 faulted slope break in Tazhong area[J]. Acta Petrologica Sinica, 2005, 26(1):27-30.
[4] Childs C, Holdsworth R E, Jackson C A L, Manzocchi T, Walsh J J, Yielding G. Introduction to the geometry and growth of normal faults[J]. Geological Society London Special Publications, 2017, 439(1): 1-9. DOI: 10. 1144/SP439. 23.
[5] Allen M B, Vincent S J, Wheeler P J. Late Cenozoic tectonics of the Kepingtage thrust zone: Interactions of the Tien Shan and Tarim Basin, Northwest China[J]. Tectonics, 1999, 18(4):639-654. doi: 10.1029/1999TC900019
[6] 邬光辉, 杨海军, 屈泰来, 李浩武, 罗春树, 李本亮. 塔里木盆地塔中隆起断裂系统特征及其对海相碳酸盐岩油气的控制作用[J]. 岩石学报, 2012, 28(3):793-805.
WU Guanghui, YANG Haijun, QU Tailai, LI Haowu, LUO Chunshu, LI Benliang. The fault system characteristics and its controlling roles on marine carbonate hydrocarbon in the central uplift, Tarim Basin[J]. Acta Petrologica Sinica, 2012, 28(3):793-805.
[7] 廖涛, 侯加根, 陈利新, 马克, 杨文明, 董越, 白晓佳. 断裂对塔北地区哈拉哈塘油田奥陶系非暴露岩溶缝洞型储集层的控制作用[J]. 古地理学报, 2016, 18(2):221-235.
LIAO Tao, HOU Jiagen, CHEN Lixin, MA Ke, YANG Wenming, DONG Yue, BAI Xiaojia. Fault controlling on non-exposed karst fracture-vug reservoirs of the Ordovician in Halahatang oilfield, northern Tarim Basin[J]. Journal of Palaeogeography, 2016, 18(2):221-235.
[8] 余一欣, 张立伟, 朱秀香, 罗吉, 刘士林, 张仲培, 金峰. 塔里木盆地塘北断裂带分段变形及其活动特征[J]. 现代地质, 2020, 34(6):1103-1109.
YU Yixin, ZHANG Liwei, ZHU Xiuxiang, LUO Ji, LIU Shilin, ZHANG Zhongpei, JIN Feng. Segmented deformation and activity characteristics of the Tangbei fault zone in the Tarim Basin[J]. Geoscience, 2020, 34(6):1103-1109.
[9] 焦方正. 塔里木盆地顺托果勒地区北东向走滑断裂带的油气勘探意义[J]. 石油与天然气地质, 2017, 38(5):831-839.
JIAO Fangzheng. Significance of oil and gas exploration in NE strike-slip fault belts in Shuntuoguole area of Tarim Basin[J]. Oil & Gas Geology, 2017, 38(5):831-839.
[10] 李萌, 汤良杰, 漆立新, 黄太柱, 甄素静, 田亚杰. 塔北隆起南坡差异构造演化及其对油气成藏的控制[J]. 天然气地球科学, 2015, 26(2):218-228.
LI Meng, TANG Liangjie, QI Lixin, HUANG Taizhu, ZHEN Sujing, TIAN Yajie. Differential tectonic evolution and its controlling on hydrocarbon accumulation in the south slope of Tabei Uplift[J]. Natural Gas Geoscience, 2015, 26(2):218-228.
[11] Deng Shang, Li Huili, Zhang Zhongpei, Zhang Jibiao, Yang Xin. Structural characterization of intracratonic strike-slip faults in the central Tarim Basin[J]. AAPG Bulletin, 2019, 103(1):109-137. doi: 10.1306/06071817354
[12] 邓尚, 李慧莉, 张仲培, 吴鲜, 张继标. 塔里木盆地顺北及邻区主干走滑断裂带差异活动特征及其与油气富集的关系[J]. 石油与天然气地质, 2018, 39(5):878-888.
DENG Shang, LI Huili, ZHANG Zhongpei, WU Xian, ZHANG Jibiao. Characteristics of differential activities in major strike-slip fault zones and their control on hydrocarbon enrichment in Shunbei area and its surroundings, Tarim Basin[J]. Oil & Gas Geology, 2018, 39(5):878-888.
[13] 何登发, 李德生, 王成善, 刘少峰, 陈槚俊. 活动论构造古地理的研究现状、思路与方法[J]. 古地理学报, 2020, 22(1):1-28.
HE Dengfa, LI Desheng, WANG Chengshan, LIU Shaofeng, CHEN Jiajun. Status, thinking, and methodology of studying on the mobile tectono-palaeogeography[J]. Journal of Palaeogeography, 2020, 22(1):1-28.
[14] 陈槚俊, 何登发, 孙方源, 王峰, 张伟康. 塔北古隆起的三维地质结构及相关问题探讨[J]. 地学前缘, 2019, 26(1):121-133.
CHEN Jiajun, HE Dengfa, SUN Fangyuan, WANG Feng, ZHANG Weikang. Three-dimensional geological modeling of the Tabei paleo-uplift and discussion on related issues[J]. Earth Science Frontiers, 2019, 26(1):121-133.
[15] Roberts N M, Walker R J. U-Pb geochronology of calcite-mineralized faults: Absolute timing of rift-related fault events on the northeast Atlantic margin[J]. Geology, 2016, 44(7):531-534. doi: 10.1130/G37868.1
[16] Nuriel P, Craddock J, Kylander Clark A R C, Uysal I T, Karabacak V, Dirik R K, Hacker B R, Weinberger R. Reactivation history of the North Anatolian fault zone based on calcite age-strain analyses[J]. Geology, 2019, 47(5):465-469.
[17] Nuriel P, Wotzlaw J F, Ovtcharova M, Vaks A, Stremtan C, Sala M, Roberts N M W, Kylander Clark A R C. The use of ASH-15 flowstone as a matrix-matched reference material for laser-ablation U-Pb geochronology of calcite[J]. Geochronology, 2021, 3(1): 35-47.
[18] 吕艳萍, 罗君兰, 王炯, 张娟, 张振哲, 马海陇, 李兴. 塔河油田典型碳酸盐岩断溶体发育模式[J]. 西安石油大学学报(自然科学版), 2021, 36(1):20-27.
LYU Yanping, LUO Junlan, WANG Jiong, ZHANG Juan, ZHANG Zhenzhe, MA Hailong, LI Xing. Development mode of typical carbonate fault-affected karst system in Tahe oilfield[J]. Journal of Xi'an Shiyou University (Natural Science Edition), 2021, 36(1):20-27.
[19] 鲁新便, 胡文革, 汪彦, 李新华, 李涛, 吕艳萍, 何新明, 杨德彬. 塔河地区碳酸盐岩断溶体油藏特征与开发实践[J]. 石油与天然气地质, 2015(3):347-355.
LU Xinbian, HU Wenge, WANG Yan, LI Xinhua, LI Tao, LYU Yanping, HE Xinming, YANG Debin. Characteristics and development practice of fault-karst carbonate reservoirs in Tahe area, Tarim Basin[J]. Oil and Gas Geology, 2015(3):347-355.
[20] 郑晓丽, 安海亭, 王祖君, 周红波, 张亮亮. 哈拉哈塘地区走滑断裂与断溶体油藏特征[J]. 新疆石油地质, 2019, 40(4):449-455.
ZHENG Xiaoli, AN Haiting, WANG Zujun, ZHOU Hongbo, ZHANG Liangliang. Characteristics of strike-slip faults and fault-karst carbonate reservoirs in Halahatang area, Tarim Basin[J]. Xinjiang Petroleum Geology, 2019, 40(4):449-455.
[21] 李国会, 李世银, 李会元, 孙冲, 谢舟, 李飞. 塔里木盆地中部走滑断裂系统分布格局及其成因[J]. 天然气工业, 2021, 41(3):30-37.
LI Guohui, LI Shiyin, LI Huiyuan, SUN Chong, XIE Zhou, LI Fei. Distribution pattern and formation mechanism of the strike-slip fault system in the central Tarim Basin[J]. Natural Gas Industry, 2021, 41(3):30-37.
-
