Paleogeomorphic features and sedimentary facies model of Jurassic strata in Chaoshan sub-basin, northern South China Sea
-
摘要:
南海北部潮汕坳陷中生界极具油气勘探潜力；综合运用最新采集的地震资料结合测井数据，在侏罗纪地层精细划分的基础上，通过对目的层剥蚀量计算，对侏罗系古地貌进行了恢复；利用残留地层的沉积相标志分析结果，建立了潮汕坳陷侏罗系沉积模式。结果表明，在早侏罗世末期和中侏罗世末期，地层遭受剥蚀改造；古地貌各要素对沉积体系发育的影响，古隆起（凸起）指明了沉积物的来源和方向；古海底峡谷是沉积物从物源区搬运到沉积区的重要运移通道；斜坡带为重要的沉积场所，并对储层的品质和规模有巨大影响，制约着盆地可容纳空间的大小；盆底的地貌形态控制着沉积体形态和产状。研究结果表明，古地貌恢复后的各要素在时空上的有效配置关系是准确把握沉积体系展布特征及范围的关键因素，对沉积储层及烃源岩的控制作用非常明显。该结论对侏罗系下一步勘探及有利储层预测有积极意义。
Abstract:The Mesozoic strata in the Chaoshan sub-basin of northern South China Sea have rich oil and gas resources. Seismic data and well logging data were used in combination with fine stratigraphic division and denudation calculation to restore paleogeomorphology of the Jurassic sedimentary strata.On the basis of sedimentary facies marker analysis of residual strata, a Jurassic sedimentary model was established. The Jurassic strata suffered denudation alterations at the end of Early Jurassic and Middle Jurassic. Various elements of paleogeomorphology influenced sedimentary system development. Ancient uplift (bulge) indicated the source and direction of sediments. The ancient sea bottom canyon was an important transport passage between source and sedimentation. The slope zone was an important deposition site and had great influence on the quality and size of reservoirs, thus restricting the accommodation space of the basin. The basin bottom (depression) topography controlled the morphology and occurrence of sediments and influenced the quality and size of source rocks. Effective combination of all the elements of paleogeomorphology in time and space seems to be the key to accurate determination of the distribution and range of a sedimentary system, and its control of sedimentary reservoirs and source rocks is very obvious. The conclusion has positive significance for the next exploration and favorable reservoir prediction of the Jurassic strata.
-
Key words:
- sedimentary faces /
- depositional characteristics /
- Chaoshan Sub-basin /
- Jurassic
-
-
Can Qianzhong. 1998. Primary hydrocarbon-bearing basins and the pool-forming conditions in China seas and adjacent regions[J]. Marine Geology & Quaternary Geology, 1998(4):1-10(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-HYDZ804.000.htm
Chen Shuguang, Ren Jianye, Wu Feng, Cui Can, Zhang Jianli. 2015.Palaeogeomorphic recovery and its application in Shabei Area, central Bohai Depression[J]. Special Oil & Gas Reservoirs, 22(2):52-55(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-TZCZ201502012.htm
Chen Jie. 2007. Geophysical characteristics of the Chaoshan depressionand its hydrocarbon exploration potential[J]. Progress in Geophysics, 22(1):147-155(in Chinese with English abstract). http://www.cnki.com.cn/Article/CJFDTotal-DZLP200702004.htm
Duan Jiuchun, Mi Huifen. 2012. Seismic Facies and Sedimentary Facies Study of Mesozoic in Chaoshan Sag[J]. Resources & Industries, 14(1):106-111(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=zycy201201019
Hao Hujun, Shi Hesheng, Zhang Xiangtao, Wang Tiancai, Tang Shouli. 2009. Mesozoic sediments and their petroleum geologyconditions in Chaoshan sag:a discussion based ondrilling results from the exploratory well LF35-1-1[J]. China Offshore Oil and Gas, 21(3):151-156(in Chinese with English abstract).
He Jiaxiong, Chen Shenghong, Cui Shasha, Ma Wenhong, Luan Xiwu. 2009. Early-stage prediction and evaluation of hydrocarbon source rocks in the deepbasin on the northern continental margin of the South China Sea[J]. Geology in China, 36(2):404-416(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-DIZI200902015.htm
He Jiaxiong, Chen Shenghong, Ma Wenhong, Gong Xiaofeng. 2012.The evolution, migration and accumulation regularity of oil and gas in Zhujiangkou basin, northeastern South China Sea[J]. Geology in China, 39(1):106-118(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=zgdizhi201201011
Li Wenhao, Zhang Zhihuan, Li Youchuan, Zhang Gongcheng, Fu Ning. 2014. The development characteristics of source rocks in the main deepwater petroliferous basins of the world and their enlightenment to the study of source rocks in deep-water area of northern South China Sea[J]. Geology in China, 41(5):1673-681(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=zgdizhi201405021
Lu Baoliang, Wang Pujun, Wu Jingfu, Li Wuzhi, Wang Wanyin, Lang Yuanqiang. 2014. Distribution of the Mesozoic in the continental margin basins of the South China Sea and its petroliferous significance[J]. Petroleum Exploration And Development, 41(4):497-503(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=syktykf201404017
Qiang Kunsheng, Zhang Guangxue, Zhang Li, Lv Baofeng, Zhong Guangjian, Feng Changmao, Yi Hai, Zhao Zhongquan, Yang Zhen, Yan Wei.2018. A study of depositional characteristics of the Jurassic strata in Chaoshan Sub-basin, northern South China Sea, and its control on reservoir beds[J]. Geology in China, 45(1):48-58(in Chinese with English abstract) http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=zgdizhi201801005
Shao Lei, You Hongqing, Hao Hujun, Wu Guoxuan, Qiao Peijun, Lei Yangchang. 2007. Petrology and Depositional Environments of Mesozoic Strata in the Northeastern South China Sea[J]. Geological Review, 53(2):164-169. http://d.old.wanfangdata.com.cn/Periodical/OA000004687
Su Pibo, Liang Jianqiang, Fu Shaoying, Lü Wanjun, Gong Yuehua. 2017. Geological background and accumulation models of gas hydrate reservoir in northern South China Sea[J]. Geology in China, 44(3):415-427(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=zgdizhi201703001
Wang Changshi, Zhu Weilin, Zhong Kai, Xu Changhai. 2015. Late Cretaceous Tectonic Thrusting and Its Genesis in Northern Slope of the South China Sea[J]. Earth Science, 40(9):1505-1516. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dqkx201509006
Wu Guoxuan, Wang Rujian, Hao Hujun, Shao Lei. 2007. Microfossil evidence for development of marine Mesozoic in the north of south china sea[J]. Marine Geology & Quaternary Geology, 27(1):79-85(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=hydzydsjdz200701010
Xia Kanyuan, Huang Ciliu. 2000. The discovery of meso-tethys sedimentary basins in the southchina sea and their oil and gas perspective[J]. Earth Science Frontiers, 7(3):227-238(in Chinese with English abstract).
Yan Shuchun, Tong Zhigang, He Qing, Hao Jianrong. 2008. Mesozoic hydrocarbon generation history andigneous intrusion impacts in Chaoshan depression, South China Sea:A case of LF35-1-1 well[J]. China Offshore Oil and Gas, 20(3):152-156(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-ZHSD200803002.htm
Zhong Dalai, Ding Lin, Zhang Jinjiang, Ji Jianqing. 2002. Study of orogenic belts in China:Retrospects and prospects[J]. Geological Review, 48(2):147-152(in Chinese with English abstract). http://d.old.wanfangdata.com.cn/Periodical/OA000005772
Zhou Di, Sun Zhen, Chen Hanzong. Tectonic features of World's major deep-water oil/gas fields and their enlightenment to deep-water exploration in northern South China Sea[J]. Advances in Earth Science, 2007, 22(6):561-572(in Chinese with English Abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dqkxjz200706002
蔡乾忠. 1998.中国海域及邻区主要含油气盆地与成藏地质条件[J].海洋地质与第四纪地质, (4):1-10. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=QK199800270735
陈洁. 2007.潮汕坳陷地球物理特征及油气勘探潜力[J].地球物理学进展, 22(1):147-155. doi: 10.3969/j.issn.1004-2903.2007.01.021
陈树光, 任建业, 吴峰, 崔灿, 张建丽. 2015.渤中坳陷沙北地区古地貌恢复及其应用[J].特种油气藏, 22(2):52-55. doi: 10.3969/j.issn.1006-6535.2015.02.012
段九春, 米慧芬. 2012.潮汕坳陷中生界地震相与沉积相研究[J].资源与产业, 14(1):106-111. doi: 10.3969/j.issn.1673-2464.2012.01.020
郝沪军, 施和生, 张向涛, 汪天才, 汤守立. 2009.潮汕坳陷中生界及其石油地质条件——基于LF35-1-1探索井钻探结果的讨论[J].中国海上油气, 21(3):151-156. doi: 10.3969/j.issn.1673-1506.2009.03.002
何家雄, 陈胜红, 崔莎莎, 马文宏, 栾锡武. 2009.南海北部大陆边缘深水盆地烃源岩早期预测与评价[J].中国地质, 36(2):404-416. doi: 10.3969/j.issn.1000-3657.2009.02.014 http://geochina.cgs.gov.cn/geochina/ch/reader/view_abstract.aspx?file_no=20090214&flag=1
何家雄, 陈胜红, 马文宏, 龚晓峰. 2012.南海东北部珠江口盆地成生演化与油气运聚成藏规律[J].中国地质, 39(1):106-118. http://geochina.cgs.gov.cn/geochina/ch/reader/view_abstract.aspx?file_no=20120111&flag=1
李文浩, 张枝焕, 李友川, 张功成, 傅宁. 2014.世界深水含油气盆地烃源岩的发育特征及对中国南海北部深水区烃源岩的启示[J].中国地质, 41(5):1673-1681. doi: 10.3969/j.issn.1000-3657.2014.05.021 http://geochina.cgs.gov.cn/geochina/ch/reader/view_abstract.aspx?file_no=20140521&flag=1
鲁宝亮, 王璞珺, 吴景富, 李伍志, 王万银, 郎元强. 2014.南海陆缘盆地中生界分布特征及其油气地质意义[J].石油勘探与开发, 41(4):497-503. http://d.old.wanfangdata.com.cn/Periodical/syktykf201404017
强昆生, 张光学, 张莉, 吕宝凤, 钟广见, 冯常茂, 易海, 赵忠泉, 杨振, 鄢伟. 2018.南海北部潮汕坳陷侏罗系沉积特征及对储层的控制作用研究[J].中国地质, 45(1):48-58. http://geochina.cgs.gov.cn/geochina/ch/reader/view_abstract.aspx?file_no=20180105&flag=1
苏丕波, 梁金强, 付少英, 吕万军, 龚跃华. 2017.南海北部天然气水合物成藏地质条件及成因模式探讨[J].中国地质, 44(3):415-427. http://geochina.cgs.gov.cn/geochina/ch/reader/view_abstract.aspx?file_no=20170301&flag=1
邵磊, 尤洪庆, 郝沪军, 吴国瑄, 乔培军, 雷永昌. 2007.南海东北部中生界岩石学特征及沉积环境[J].地质论评, 53(2):164-169. doi: 10.3321/j.issn:0371-5736.2007.02.003
邵磊, 尤洪庆, 郝沪军, 吴国瑄, 乔培军, 雷永昌. 2007.南海东北部中生界岩石学特征及沉积环境[J].地质论评, 53(2):164-169. doi: 10.3321/j.issn:0371-5736.2007.02.003
王长势, 朱伟林, 钟锴, 许长海.2015.南海北部陆坡晚白垩世构造逆冲及其成因[J].地球科学-中国地质大学学报, 40(9):1505-1516. http://d.old.wanfangdata.com.cn/Periodical/dqkx201509006
吴国瑄, 王汝建, 郝沪军, 邵磊. 2007.南海北部海相中生界发育的微体化石证据[J].海洋地质与第四纪地质, 27(1):79-85. http://d.old.wanfangdata.com.cn/Periodical/hydzydsjdz200701010
夏戡原, 黄慈流. 2000.南海中生代特提斯期沉积盆地的发现与找寻中生代含油气盆地的前景[J].地学前缘, 7(3):227-238. doi: 10.3321/j.issn:1005-2321.2000.03.021
杨树春, 仝志刚, 贺清, 郝建荣. 2008.潮汕坳陷中生界生烃历史及火成岩侵入影响分析——以LF35-1-1井为例[J].中国海上油气, 20(3):152-156. doi: 10.3969/j.issn.1673-1506.2008.03.003
周蒂, 孙珍, 陈汉宗. 2007.世界著名深水油气盆地的构造特征及对我国南海北部深水油气勘探的启示[J].地球科学进展, 22(6):561-572. doi: 10.3321/j.issn:1001-8166.2007.06.002
钟大赉, 张进江. 2002.中国造山带研究的回顾和展望[J].地质论评, 48(2):147-152. doi: 10.3321/j.issn:0371-5736.2002.02.004
-
