西藏阿翁错地区早白垩世花岗闪长岩——班公湖-怒江洋壳南向俯冲消减证据

,  ,  ,  ,  ,

文章导航 > 中国地质 > 2019 > 46(5): 1105-1115

上一篇

下一篇

尹滔, 李威, 尹显科, 张伟, 袁华云, 裴亚伦. 2019. 西藏阿翁错地区早白垩世花岗闪长岩——班公湖-怒江洋壳南向俯冲消减证据[J]. 中国地质, 46(5): 1105-1115. doi: 10.12029/gc20190511
引用本文: 尹滔, 李威, 尹显科, 张伟, 袁华云, 裴亚伦. 2019. 西藏阿翁错地区早白垩世花岗闪长岩——班公湖-怒江洋壳南向俯冲消减证据[J]. 中国地质, 46(5): 1105-1115. doi: 10.12029/gc20190511
shu
YIN Tao, LI Wei, YIN Xianke, ZHANG Wei, YUAN Huayun, PEI Yalun. 2019. The Early Cretaceous granodiorites in the Aweng Co area, Tibet: Evidence for the subduction of the Bangong Co-Nujiang River oceanic crust to the south[J]. Geology in China, 46(5): 1105-1115. doi: 10.12029/gc20190511
Citation: YIN Tao, LI Wei, YIN Xianke, ZHANG Wei, YUAN Huayun, PEI Yalun. 2019. The Early Cretaceous granodiorites in the Aweng Co area, Tibet: Evidence for the subduction of the Bangong Co-Nujiang River oceanic crust to the south[J]. Geology in China, 46(5): 1105-1115. doi: 10.12029/gc20190511
shu

西藏阿翁错地区早白垩世花岗闪长岩——班公湖-怒江洋壳南向俯冲消减证据

  • 四川省地质调查院 稀有稀土战略资源评价与利用四川省重点实验室, 四川 成都 610081

  • 基金项目:
    中国地质调查局项目（DD20160026，DD20191029）资助
详细信息
    作者简介: 尹滔, 男, 1983年, 硕士生, 工程师, 主要从事地质调查与矿产勘查; E-mail:406593621@qq.com

  • 中图分类号: P588.12+1

The Early Cretaceous granodiorites in the Aweng Co area, Tibet: Evidence for the subduction of the Bangong Co-Nujiang River oceanic crust to the south

  • Evaluation and Utilization of Strategic Rare Metals and Rare Earth Resource Key Laboratory of Sichuan Province, Sichuan Geological Survey, Chengdu 610081, Sichuan, China

  • Fund Project: Supported by China Geological Survey Project (No. DD20160026, No. DD20191029)
More Information
    Author Bio: YIN Tao, male, born in 1983, engineer, master candidate, mainly engages in geological survey and mineral resources exploration. E-mail:406593621@qq.com .

    摘要

  • 对拉萨地块北部阿翁错地区花岗闪长岩进行了年龄分析、岩石地球化学研究。锆石LA-ICP-MS定年测得花岗闪长岩U-Pb年龄为（114.4±1.9）Ma，属于早白垩世晚期岩浆活动的产物。花岗闪长岩地球化学特征表明，其具有典型镁安山岩/闪长岩（MA）的地球化学特征，所有样品均具有较高Mg#值（45.42~54.29），低的TFeO*/MgO值（1.58~2.26）；所有样品都显示轻稀土元素富集，富集大离子亲石元素，亏损高场强元素的特征。研究表明，阿翁错花岗闪长岩是班公湖-怒江洋壳在俯冲消减背景下，由俯冲洋壳脱水熔融产生的溶体与地幔橄榄岩发生交代作用的产物，为晚中生代班公湖-怒江洋盆的南向俯冲消减提供了直接的岩石学、地球化学、年代学证据。

    This paper reports zircon U-Pb data of major and trace elements for the granodiorites from the Aweng Co area in northern Lhasa block. Zircon LA-ICP-MS U-Pb dating of granodiorite yielded an age of 163.3 ±1.7 Ma, suggesting that the intruded rocks were formed in late Early Cretaceous period. Geochemical studies show that Aweng Co granodiorites have typical geochemical characteristics similar to the magnesian andesite/diorite (MA). They are characterized by high Mg# values (45.42~54.29) and low TFeO*/MgO ratios (1.58~2.26). They are enriched in LREE in the chondrite-normalized REE patterns, and are enriched in large ion lithophile elements (LILEs) and depleted in high field strength elements (HFSEs). Geochemical features of the Aweng Co magnesian granodiorites are considered to have been generated by the southward subduction of Bangong Co-Nujiang River oceanic lithosphere, and can be genetically regarded as resulting from partial melting of dewatered and subducted oceanic crust melts, which had been metasomatized by mantle peridotite under the condition of oceanic crust subduction. These results provide direct petrologic evidence of the intruded rocks for the southward subduction of the Bangong Co-Nujiang River Ocean.

    • HTML全文
  • 加载中

  • 图 1  阿翁错—盐湖地区地质图及采样位置

    Figure 1.

    下载: 全尺寸图片 幻灯片

    图 2  阿翁错花岗闪长岩锆石阴极发光图像（含U-Pb年龄值）

    Figure 2.

    下载: 全尺寸图片 幻灯片

    图 3  阿翁错花岗闪长岩锆石U-Pb谐和图

    Figure 3.

    下载: 全尺寸图片 幻灯片

    图 4  阿翁错花岗闪长岩K2O-SiO2（a，据Rickwood，1989）及A/CNK-A/NK（b，据Maniar and Piccoli, 1989）图解

    Figure 4.

    下载: 全尺寸图片 幻灯片

    图 5  阿翁错花岗闪长岩球粒陨石标准化稀土元素配分曲线图（a，标准化值据Boynton，1984）及原始地幔标准化微量元素蛛网图（b，标准化值据Sun and McDonough, 1989）

    Figure 5.

    下载: 全尺寸图片 幻灯片

    图 6  MA的SiO2-MgO图（a）和SiO2-FeO*/MgO图（b）（据Deng et al., 2009修改）

    Figure 6.

    下载: 全尺寸图片 幻灯片

    图 7  阿翁错花岗闪长岩选择性地球化学图解

    Figure 7.

    下载: 全尺寸图片 幻灯片

    表 1  阿翁错花岗闪长岩LA-ICP-MS锆石U-Pb定年结果

    Table 1.  LA-ICP-MS zircon U-Pb dating results of the Aweng Co granodiorites

    下载: 导出CSV

    表 2  阿翁错花岗闪长岩主量元素(%)和微量元素（10-6）分析结果

    Table 2.  Major elements(%) and trace elements(10-6)compositions of the Aweng Co granodiorites

    下载: 导出CSV
    • 参考文献(54)

  • Anderson T. 2002. Correction of common lead in U-Pb analyses that do not report 204Pb[J]. Chemical Geology, 192:59-79. doi: 10.1016/S0009-2541(02)00195-X

    Atherton M P, Petford N. 1993. Generation of sodium-rich magmas from newly underplated basaltic crust[J]. Nature, 362:144-146. doi: 10.1038/362144a0

    Barth M G, McDonough W F, Rudnick R L.2000. Tracking the budget of Nb and Ta in the continental crust[J]. Chemical Geology, 165(3-4):197-213. doi: 10.1016/S0009-2541(99)00173-4

    Boynton W V.1984. Geochemistry of the rare earth elements: Meteorite studies[C]//Henderson P(ed.) Rare Earth Element Geochemistry[J]. Amsterdam: Elsevier, 63-114.

    Coulon C, Maluski H, Bollinger C, Wang S.1986. Mesozoic and Cenozoic volcanic-rocks from Central and Southern Tibet 39Ar-40Ar dating, petrological Characteristics and geodynamical significance[J]. Earth and Planetary Science Letters, 79:281-302. doi: 10.1016/0012-821X(86)90186-X

    Defaut M J, Richerson P M, Deboer J Z, Stewart R H, Maury R C, Bellon H, Drummond M S, Feigenson M D and Jackson T E.1991.Dacite genesis via both Slab melting and differentiation:Petrogenesis of La Yeguada volcanic complex, Panama[J].Journal of Petrology, 32:1101-1142. doi: 10.1093/petrology/32.6.1101

    Deng J F, Flower M F J, Liu C, Mo Xuanxue. 2009. Nomeuclature, diagnosis and oringin of high-magnesian andesites (HMA) and magnesian andesites (MA): A review from petrographic and experimental data[J]. Geochimica et Cosmochimica Acta, 73(13): Issue 13 Supplement 1, A279.

    Deng Jinfu, Liu Cui, Feng Yanfang, Xiao Qinghui, Su Shangguo, Zhao Guochun, Kong Weiqiong, Cao Wenyan. 2010. High-magnesian andesitic/dioritic rocks (HMA) and magnesian andesitic/dioritic rocks (MA):Two igneous rock types related to oceanic subduction[J]. Geology in China, 37:1112-1118(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTotal-DIZI201004027.htm

    Ding X, Hu Y H, Zhang H, Li CY, Ling M X, Sun W D.2013.Major Nb/Ta fractionation recorded in garnet amphibolite facies metagabbro[J]. Journal of Geology 121, 255-274. doi: 10.1086/669978

    Du Daode, Qu Xiaoming, Wang Genghou, Xin Hongbo, Liu Zhibo. 2011. Bidirectional subduction of the Middle Tethys oceanic basin in the west segment of Bangonghu-Nujiang suture, Tibet:Evidence from zircon U-Pb LA-ICP-MS dating and petrogeochemistry of arc granites[J]. Acta Petrologica Sinica, 27(7):1993-2002(in Chinese with English abstract).

    Foley S, Tiepolo M, Vannucci R.2002. Growth of early continental crust controlled by melting of amphibolite in subduction zones[J]. Nature, 417:837-840. doi: 10.1038/nature00799

    Hu Jun, Wan YongWen, Tao Zhuan, Zhang Dan, Chen GuoDong.2014 Newgeochemisty and geochronology evidences related to southward subduction of Tethys Ocean basin in west segment of Bangonghu-Nujiang suture belt[J]. Journal of Chengdu University of Technology(Science & Technology Edition), 41(4):505-515(in Chinese with English abstract).

    Kang Zhiqiang, Xu Jifeng, Wang Baodi, Dong Yanhui, Wang Shuqing, Chen Jianlin. 2009. Geochemistry of Cretaceous volcanic rocks of Duoni Formation in Northern Lhasa Block:Discussion of tectonic Setting[J]. Earth Science (Journal of China University of Geosciences, 34(1):89-104(in Chinese with English abstract). doi: 10.3799/dqkx.2009.009

    Kapp P, DeCelles P G, Gehrels G E, Heizier M, Ding L. 2007.Geological records of the Lhasa-Qiangtang and Indo-Asian collisions in the Nima area of central Tibet[J]. Geol. Soc. Am.Bull., 119:917-932. doi: 10.1130/B26033.1

    Kapp P, Yin A, Harrison TM, Ding L.2005.Cretaceous-Tertiary shortening, basin development, and volcanism in central Tibet[J]. Geol. Soc. Am. Bull., 117:865-878. doi: 10.1130/B25595.1

    Kay RW. 1978. Aleutian magnesian andesites:Melts from subductcd Pacific Ocean crust[J]. Journal of Volcanology and Geothermal Research, 4(1/2):117-132.

    Kelemen P B. Genesisof high Mg-number andesites and the continental-crust[J]. Contributions to Mineralogy and Petrology, 1995, 120(1):1-19. doi: 10.1007/BF00311004

    Leier A L, Kapp P, Gehrels G E, DeCelles P G. 2007. Detrital zircon geochronology of Carboniferous? Cretaceous strata in the Lhasa terrane, Southern Tibet[J]. Basin Research, 19:361-378. doi: 10.1111/j.1365-2117.2007.00330.x

    Liang J L, Ding X, Sun X M, Zhang Z M, Zhang H, Sun W D. 2009.Nb/Ta fractionation observed in eclogites from the Chinese Continental Scientific Drilling Project[J]. Chemical Geology, 268:27-40. doi: 10.1016/j.chemgeo.2009.07.006

    Liu Yongsheng, Hu Zhaochu, Zong Keqing, Gao Changgui, Gao Shan, Xu Juan, Chen Haihong. 2010b. Reappraisement and refinement of zircon U-Pb isotope and trace element analyses by LA-ICPMS[J]. Chinese Science Bulletin, 55:1535-1546. doi: 10.1007/s11434-010-3052-4

    Liu Y S, Gao S, Hu Z C, Gao C G, Zong K Q, Wang D B. 2010a.Continental and oceanic crust recycling-induced melt-peridotite interactions in the Trans-North China Orogen:U-Pb dating, Hf isotopes and trace elements in zircons from mantle xenoliths[J]. Journal of Petrology, 51(1/2):537-571. http://d.old.wanfangdata.com.cn/NSTLQK/10.1093-petrology-egp082/

    Liu Y S, Hu Z C, Gao S, Gunther D, Xu J, Gao C G, Chen H H. 2008.In situ analysis of major and trace elements of anhydrous minerals by LA-ICP-MS without applying an internal standard[J]. Chemical Geology, 2008, 257: 34-43.

    Ludwig K R. 2003.User's Manual for Isoplot 3.0: A Geochronological Toolkit for Microsoft Exce[M]. Berkeley Geochronological Center, Special Publication, Berkeley, 4: 1-71.

    Maniar P D, Piccoli P M. 1989. Tectonic discrimination of granitoids[J]. Geological Society of America Bulletin, 101(5):635-643. doi: 10.1130/0016-7606(1989)101<0635:TDOG>2.3.CO;2

    Qian Bing, Zhang ZhaoWei, Lu PengRui, Wang YaLei.2018.Petrogenesis and Geodynamics Processes of Early Paleozoic Niubiziliang High-Mg Diorites in West Segment of North Qaidam, Qinghai[J].Earth Science, 43(12):4375-4389 (in Chinese with English abstract). http://d.old.wanfangdata.com.cn/Periodical/dqkx201812008

    Rickwood P C.1989. Boundary lines within petrologic diagrams which use oxides of major and minor elements[J]. Lithos, 22(4):247-263. doi: 10.1016/0024-4937(89)90028-5

    Sui Qinglin. 2014. Chronology, Petrogenesis, and Tectonic Implication of Magmatic Rocks from Yanhu in Northern Lhasa Terrane, Tibet[M].Beijing:China University of Geosciences(in Chinese with English abstract).

    Sun S S, McDonough W F. 1989. Chemical and isotopic systematics of oceanic basalts: Implications for mantle composition and processes.[C]//Saunders A D, Norry M J (eds.). Magmatism in the Oceanic Basins[J]. Geological Society, London, Special Publications, 42(1): 313-345.

    Tang Gongjian, Wang Qiang.2010. High-Mg andesites and their geodynamic implications[J]. Acta Petrologica Sinica, 26(8):2495-2512(in Chinese with English abstract). http://d.old.wanfangdata.com.cn/Periodical/ysxb98201008021

    Tatsumi Y, Ishizaka K. 1982. Origin of high-magnesium andesites in the Setouchi volcanic belt, Southwest Japan, I.petrographical and chemical characteristics[J].EPSL, 60:293-304. doi: 10.1016/0012-821X(82)90008-5

    Tiepolo M, Vannucci R, Obert R, Foley S, Bottazzi P, Zanetti A.2000.Nb and Ta incorporation and fractionation in titanian pargasite and kaersutite:crystal-chemical constraints and implications for natural systems[J]. Earth and Planetary Science Letters, 176:185-201. doi: 10.1016/S0012-821X(00)00004-2

    Wu Hao, Li Cai, Xu Mengjing, Li Xingkui. 2015. Early Cretaceous adakitic magmatism in the Dachagou area, northern Lhasa terrane, Tibet:Implications for slab roll-back and subsequent slab breakoff of the lithosphere of the Bangong-Nujiang Ocean[J].Journal of Asian Earth Sciences, 97:51-66. doi: 10.1016/j.jseaes.2014.10.014

    Xiao Yilin, Sun Weidong, Hoefs Jochen, Simon Klaus, Zhang Zeming, Li Shugang, Hofmann Albrecht W. et al. 2006. Making continental crust through slab melting:Constraints from niobium-tantalum fractionation in UHP metamorphic rutile[J]. Geochimica et Cosmochimica Acta, 70:4770-4782. doi: 10.1016/j.gca.2006.07.010

    Yogodzinski G M, Kay R W, Volynets O N, Koloskov A V, Kay S M. 1995. Magnesian andestites in the western Aleutions Komandorsky region:Implications for slab melting and processes in the mantle wedge[J]. GSA Bull., 107(5):505-519. doi: 10.1130/0016-7606(1995)107<0505:MAITWA>2.3.CO;2

    Zhang K J, Xia B D, Wang G M, Li Y T, Ye H F. 2004. Early Cretaceous stratigraphy, depositional environments, sandstone provenance, and tectonic setting of central Tibet, western China[J]. GSA Bulletin, 116(9/10):1202-1222. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=2dde0cdfe5346a052582ae71bfa7b881

    Zhao Zhenghua, Wang Qiang, Xiong Xiaolin, Niu Hecai, Zhang Haixiang, Qiao Yulou.2007. Magnesian igneous rocks in northern Xinjiang[J]. Acta Petrologica Sinica, 23(7):1696-1707(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=ysxb98200707015

    Zhu Dicheng, Zhao Zhidan, Niu Yaolin, Dilek Yildirim, Mo Xuanxue. 2011b. Lhasa Terrane in southern Tibet came from Australia[J]. Geology, 39:727-730. doi: 10.1130/G31895.1

    Zhu Dicheng, Zhao Zhidan, Niu Yaolin, Mo Xuanxue, Chung Sunlin, Hou Zengqian, Wang Liquan, Wu Fuyuan. 2011a. The Lhasa Terrane:Record of a microcontinent and its histories of drift and growth[J]. Earth and Planetary Science Letters, 301:241-255. doi: 10.1016/j.epsl.2010.11.005

    Zhu Dicheng, Mo Xuanxue, Zhao Zhidan, Xu Jifeng, Zhou Changyong, Sun Chenguang, Wang Liquan, Chen Haihong, Dong Guochen, Zhou Su. 2008. Zircon U-Pb geochronology of Zenong Group volcanic rocks in Coqen area of the Gangdese, Tibet and tectonic significance[J]. Acta Petrologica Sinica, 24(3):401-412(in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=ysxb98200803001

    Zhu Dicheng, Pan Guitang, Mo Xuanxue, Wang Liquan, Liao Zhongli, Zhao Zhidan, Dong Guochen, Zhou Changyong. 2006. Late Jurassic-Early Cretaceous geodynamic setting in middle-northern Gangdese:New insights from volcanic rocks[J]. Acta Petrologica Sinica, 22(3):534-546(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTotal-YSXB200603002.htm

    Zhu Dicheng, Zhao Zhidan, Niu Yaolin, Dilek Y, Hou Zengqian, Mo Xuanxue.2013. The Origin and pre-Cenozoic evolution of the Tibetan Plateau[J]. Gondwana Research 23:1429-1454. doi: 10.1016/j.gr.2012.02.002

    Zhu Dicheng, Mo Xuanxue, Niu Yaolin, Zhao Zhidan, Wang Liquan, Liu Yongsheng, Wu Fuyuan.2009. Geochemical investigation of Early Cretaceous igneous rocks along an east-west traverse throughout the central Lhasa Terrane, Tibet[J]. Chemical Geology, 268:298-312. doi: 10.1016/j.chemgeo.2009.09.008

    Zhu Dicheng, Zhao Zhidan, NiuYaoling, Wang Qing, Yildirim DILEK, Dong Guochen, Mo Xuanxue. 2012. Origin and Paleozoic Tectonic Evolution of the Lhasa Terrane[J]. Geological Journal of China Universities, 18(1):1-15(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-GXDX201201003.htm

    杜道德, 曲晓明, 王根厚, 辛洪波, 刘治博.2011.西藏班公湖-怒江缝合带西段中特提斯洋盆的双向俯冲:来自岛弧型花岗岩锆石U-Pb年龄和元素地球化学的证据[J].岩石学报, 27(7):1993-2002. http://d.old.wanfangdata.com.cn/Periodical/ysxb98201107008

    邓晋福, 刘翠, 冯艳芳, 肖庆辉, 苏尚国, 赵国春, 孔维琼, 曹文燕.2010.高镁安山岩/闪长岩类(HMA)和镁安山岩闪长岩类(MA):与洋壳俯冲作用相关的两类典型的火成岩类[J].中国地质, 37:1112-1118. doi: 10.3969/j.issn.1000-3657.2010.04.025 http://geochina.cgs.gov.cn/ch/reader/view_abstract.aspx?file_no=20100424&flag=1

    胡隽, 万永文, 陶专, 张旦, 陈国东.2014.班公湖-怒江缝合带西段特提斯洋盆南向俯冲的地球化学和年代学证据[J].成都理工大学学报(自然科学版), 41(4):505-515. doi: 10.3969/j.issn.1671-9727.2014.04.14

    康志强, 许继峰, 王保弟, 董彦辉, 王树庆, 陈建林.2009.拉萨地块北部白垩纪多尼组火山岩的地球化学:形成的构造环境[J].地球科学, 34(1):89-104 http://d.old.wanfangdata.com.cn/Periodical/dqkx200901009

    隋清霖.2014.西藏拉萨地块盐湖地区早白垩世岩浆岩年代学、岩石成因及构造意义[D].北京: 中国地质大学.

    钱兵, 张照伟, 吕鹏瑞, 王亚磊.2018.柴北缘西段晚古生代牛鼻子梁高镁闪长岩成因机制及地球动力学过程[J].地球科学, 43(12):4375-4389. http://d.old.wanfangdata.com.cn/Periodical/dqkx201812008

    唐功建, 王强.2010.高镁安山岩及其地球动力学意义[J].岩石学报, 26(8):2495-2512. http://d.old.wanfangdata.com.cn/Periodical/ysxb98201008021

    赵振华, 王强, 熊小林, 牛贺才, 张海祥, 乔玉楼, 2007.新疆北部的富镁火成岩[J].岩石学报, 23(7):1696-1707. doi: 10.3969/j.issn.1000-0569.2007.07.015

    朱弟成, 莫宣学, 赵志丹, 许继峰, 周长勇, 孙晨光, 王立全, 陈海红, 董国臣, 周肃.2008.西藏冈底斯带措勤地区则弄群火山岩锆石U-Pb年代学格架及构造意义[J].岩石学报, 24(3):401-412. http://d.old.wanfangdata.com.cn/Periodical/ysxb98200803001

    朱弟成, 潘桂棠, 莫宣学, 王立全, 廖忠礼, 赵志丹, 董国臣, 周长勇.2006.冈底斯中北部晚侏罗世-早白垩世地球动力学环境:火山岩约束[J].岩石学报, 22(3):534-546. http://d.old.wanfangdata.com.cn/Periodical/ysxb98200603002

    朱弟成, 赵志丹, 牛耀龄, 王青, Yildirim DILEK, 董国臣, 莫宣学.2012.拉萨地体的起源和古生代构造演化[J].高校地质学报, 18(1):1-15. doi: 10.3969/j.issn.1006-7493.2012.01.001
