摘要:
中国地质环境图系数据库，是中国首套统一结构、统一格式、统一编码的涵盖地质环境、地质灾害、地下水、矿山地质环境、地质遗迹5个专业领域的全国性数据库。该套数据库是基于1∶1 000 000数据源的地理信息库，以分省1∶500 000环境地质调查、县市地质灾害调查、重点地区1∶50 000地质灾害调查、新一轮地下水资源评价、第二轮全国矿山地质环境摸底调查和矿产资源集中开采区矿山地质环境调查、首轮地质遗迹调查等数据为基础，集成近20年来水工环地质调查监测数据和最新综合研究成果，根据统一的建库技术要求建立而成。该套数据库具有统一的系统库（符号库、颜色库、图案库、线型库），属性按照统一的编码规则和要求建立，图件按照统一的图饰图例进行了规范化处理，共包含163个专业图层，图元数量共337 833个，容量约8.8 GB。该套数据库为实现成果图件的动态管理与更新、构建数字地质环境奠定了基础，可为地质环境保护管理、国土空间规划、生态修复、地质灾害防治提供详细的基础信息资料。
Abstract:The Database of Geological Environmental Map System of China is China’s first national database with uniform structure, format and codes, covering five professional fields, namely, geological environment, geologic hazards, groundwater, geological environment of mines and geological relics (geoheritage). Using 1∶1 000 000 data sources as the geographic information base, this database is built on 1∶500 000 environmental geological surveys in different provinces, county- and city-level geologic hazard surveys, 1∶50 000 geologic hazard surveys in key areas, the latest groundwater resources assessment, the second national survey of the geological environment of mines and investigation of such in areas with concentrated mining, and the first survey of geological relics. According to uniform requirements, it integrated the data of hydrological, engineering and environmental geological surveys and monitoring data over the past 20 years as well as the latest related research results. It has a unified system library (symbol, color, pattern and line libraries), with attributes established according to uniform coding rules and requirements, and with maps standardized according to uniform finishing and legend. The database contains 163 professional map layers with a total number of 337 833 elements and a capacity of 8.8 GB. It lays a solid foundation for the dynamic management and updating of maps and the construction of a digital geological environment, and provides detailed fundamental information for the protection and management of China’s geological environment, spatial planning of national territory, ecological restoration and the prevention and control of geologic disasters.
-
Key words:
- geological environment /
- national database /
- MapGIS /
- map layer /
- attribute data
-
-
表 1 数据库(集)元数据简表
条目 描述 数据库(集)名称 中国地质环境图系数据库 数据作者 李瑞敏，中国地质调查局地质环境监测院
徐慧珍，中国地质调查局地质环境监测院
曾青石，中国地质调查局地质环境监测院
王祎萍，中国地质调查局地质环境监测院
李媛，中国地质调查局地质环境监测院
荆继红，中国地质科学院水文地质环境地质研究所
张进德，中国地质调查局地质环境监测院
董颖，中国地质调查局地质环境监测院数据时间范围 2012—2017年 地理区域 全国、重要地区，经纬度范围为：东经73°～135°，北纬2°～54° 数据格式 MapGIS 数据量 8.8 GB 数据服务系统网址 http://dcc.cgs.gov.cn 基金项目 中国地质调查局全国环境地质编图研究项目（1212011220127，12120112200893）、重要地区地质环境图件编制项目（12120112200894）、全国水文地质类图件编制项目（1212011220941）、全国地质环境图系管理系统开发项目（12120112200895）、全国地质资源环境承载能力评价与监测预警项目（DD20160328）资助。 语种 中文 数据库(集)组成 系统库：颜色库为4 467个、花纹库954个、线型库641个、符号库2 912个；专业要素：包含地质环境条件类、地质灾害类、地下水类、矿山地质环境类、地质遗迹类等5类36个图件的163个专业图层，337 833个图元
下载: 导出CSV
表 2 岩体工程地质分类图层属性结构表
序号 数据项名称 数据项代码 定义或描述 数据类型与长度 约束条件 值域 单位 1 统一编号 HJCAABQ 按要求编号 C14 M 自由文本 / 2 岩体类型 GCCC 岩体类型代码 C1 M 1～4 / 3 岩石强度 YSQD C10 O 见填写说明 / 4 岩体结构 YTJG C10 O 见填写说明 /
下载: 导出CSV
表 3 地质实体要素图层
序号 类别 地质实体要素图层 1 地质环境条件类 地质环境分区线.WL，地质环境分区.WP，地质环境安全程度.WL，地面沉降高易发区.WL，断层线.WL，地质界线.WL，岩溶环境地质分区.WP，岩溶环境地质分区界线.WL，典型岩溶现象及资源.WT，典型岩溶现象及资源-峡谷.WL，主要岩溶地质灾害及环境地质问题.WT，荒漠化.WP，石漠化.WP，第四纪等厚线.WL，第四纪盆地.WP，晚新生代火山岩.WP，晚新生代火山.WT，活动断裂类型及活动性.WL，活动地块边界.WL，活动地块分区.WP，地震.WT，地震地表破裂带.WL，震源机制解数据.WT，GPS观测数据.WT，岩体工程地质分类.WP，土体工程地质分类.WP，活动断裂分布.WL，地震震中分布.WT，火山口分布.WT，应力场和地壳运动特征.WT，新构造运动地壳升降幅度.WT，崩滑流分布.WT，冰丘、冰锥分布.WT，岩溶现象分布.WT，人为工程地质现象.WT，地下水埋藏界线及深度.WL，泉点分布.WT，侵蚀性泉或钻孔分布.WT，多年冻土及积雪分布.WP，CO2地质储存示范工 程分布.WP，沉积盆地分布.WP，一二级构造线.WL，CO2地质储存示范工程分布数据.WT，钻孔分布.WT，岩性分布.WP，第四系成因类型及时代-面.WP，第四系成因类型及时代-线.WL，第四系岩性-面.WP，第四系岩性-线.WL，新构造运动形迹-构造线.WL，新构造运动形迹-点.WT，地貌形态-线.WL，地貌形态-点.WT，地貌形态-面.WP，滑坡和泥石流.WT，冻土分布区.WP，前第四纪基岩及其高程分区-面.WP，前第四系基岩及其高程分区-线.WL，掩埋的第四系堆积物分布.WP，掩埋的第四系堆积物界线.WL，第四系等厚线.WL，黄土等厚线.WL，最大海侵范围线.WL，泉.WT，地质点.WT，其他线.WL，其他点.WT，环境地质区划.WP，环境地质区划界线.WL，岩体类型.WT，土体类型.WT，岩土体类型界线.WL，活动断裂.WL，地震.WT，环境地质问题(面).WP，环境地质问题(线).WL，环境地质问题(点).WT，地下水水文地球化学异常及污染点.WT，土壤地球化学异常点.WT，地质资源.WT，硒元素分区.WP，硒元素等值线.WL，植被分区界线.WL，地方病.WP 2 地质灾害类 崩滑流灾害点.WT，崩滑流隐患点.WT，年均降雨量等值线.WL，崩滑流易发分区.WP，累计地面沉降.WP，沉降速率等值线.WL，沉降中心值.WT 3 地下水类 地下水资源类型.WP，地下水资源类型界线.WL，天然补给资源模数.WP，径流模数.WP，水文地质分区.WP，水文地质分区界线.WL，省(市区)地下水资源量.WT，主要平原(盆地)地下水资源量表.WT，主要城市地下水供水比重.WT，咸水分布区.WP，冻土分布区.WL，冰川、雪被分布区.WP，地下水含盐量及主要水化学类型分区.WP，不合理开发利用地下水相关的环境地质问题(点).WT，不合理开发利用地下水相关的环境地质问题(线).WL，不合理开发利用地下水相关的环境地质问题(面).WP，地下水典型微量元素环境背景.WP，地下水特征污染物.WT，地下水硝酸盐氮含量等值线表.WL，地下水亚硝酸盐氮含量等值线.WL，地下水氨氮含量等值线.WL，地下水高锰酸盐含量等值线.WL，地下水挥发酚含量等值线.WL，地下水氰化物含量等值线.WL，浅层地下水类型及富水性.WP，深层地下水类型及富水性.WP，咸水区分布.WP，中低纬度冻结层水.WP，潜水含水层零星分布.WP，承压埋藏深度等值线.WL，地表水分水岭.WL，地下河.WL，顶板埋深等值线.WL，多年冻结层厚度等值线.WL，泉点.WT，热储类型分区.WP，地热资源量.WP，隆起山地型地热带分布.WP，沉积盆地型地热区(田)分布.WP，主要断裂.WL，温泉.WT，地热井.WT，大地热流点.WT 4 矿山地质环境类 非金属矿山.WT，金属矿山.WT，煤炭矿山.WT，矿群.WT，矿产资源开发区.WP，矿产资源集中开采区.WP，地貌单元.WP，矿山地质环境保护与治理区划.WP，已经实施的治理工程.WT，矿山地质环境一级保护区.WP，矿山地质环境二级保护区.WP，矿山地质环境三级保护区.WP 5 地质遗迹类 地质遗迹-地层剖面.WT，地质遗迹-岩石剖面.WT，地质遗迹-构造剖面.WT，地质遗迹-重要化石产地.WT，地质遗迹-重要岩矿石产地.WT，地质遗迹-岩土体地貌.WT，地质遗迹-水体地貌.WT，地质遗迹-构造地貌.WT，地质遗迹-火山地貌.WT，地质遗迹-冰川地貌.WT，地质遗迹-海岸地貌.WT，地震遗迹.WT，地质灾害遗迹.WT，古人类化石产地.WT，古生物群化石产地.WT，古植物化石产地.WT，古生物遗迹化石产地.WT
下载: 导出CSV
表 4 图系数据库参加人员单位及质量控制人员列表
序号 图名 参加单位 参加人员 1 中国地质环境分区图 中国地质环境监测院 徐慧珍、王祎萍、刘琼、高萌萌、李小磊、夏遥、曹峰 2 中国地质环境安全
程度图中国地质环境监测院 孟晖、张若琳、 石菊松 、李春燕 3 中国岩溶环境地质图 中国地质科学院岩溶地质研究所 毕雪丽、时坚、周立新、许琦、陈阵、
毕奔腾、杨辰、韦延兰、杨象鹏4 中国荒漠化土地分布图 中国国土资源航空物探遥感中心 孙永军、高会军、邢宇、李侠、时文文 5 中国及毗邻海区活动断裂分布图 中国地质科学院地质力学研究所 吴中海、周春景、马晓雪、王继龙、黄小龙、吴小林、胡萌萌、哈广浩、刘杰 6 中国工程地质图 中国地质科学院水文地质工程地质研究所 梁国玲、张礼中、张春英、 朱吉祥 、石磊 7 中国及毗邻海域主要沉积盆地二氧化碳地质储存适宜性评价图 中国地质调查局水文地质环境地质调查中心 郭建强、金晓琳、贾小丰、张森琦、李旭峰、刁玉杰、范基姣、张徽、张杨、胡丽莎、张超、张成龙 8 中华人民共和国及其毗邻海区第四纪地质图 中国地质科学院水文地质工程地质研究所 梁国玲、张礼中、张春英、朱吉祥、石磊 9 中国沿海地区环境
地质图中国地质调查局天津地质调查中心 孟庆华、杨齐青、谢海澜、王小丹、夏雨波、刘宏伟、柳富田、孟利山、白耀楠、杜东 10 环渤海重点经济区环境地质图 中国地质调查局天津地质调查中心 孟庆华、杨齐青、谢海澜、王小丹、夏雨波、刘宏伟、柳富田、孟利山、白耀楠、杜东 11 长江三角洲经济区环境地质图 中国地质调查局南京地质调查中心 苏晶文、姜月华、黄金玉、张泰丽、贾军元、周权平、李云、刘红樱、朱意萍 12 海峡西岸经济区(核心区)环境地质图 中国地质调查局南京地质调查中心 邢怀学、葛伟亚、李亮、田福金、李云峰、常晓军、唐小雯 13 长江中游城市群环境
地质图中国地质调查局武汉地质调查中心 路韬、刘凤梅、邵长生、杨艳林、张傲、王岑 14 珠江三角洲经济区环境地质图 中国地质调查局武汉地质调查中心 刘凤梅、黄长生、赵信文、刘广宁 15 北部湾经济区环境
地质图中国地质调查局武汉地质调查中心 刘凤梅、黎清华、刘怀庆 16 成渝经济区环境地质图 中国地质调查局成都地质调查中心 李明辉、徐如阁、王东辉、田凯、陈绪钰 17 长吉图经济区环境
地质图中国地质调查局沈阳地质调查中心 赵海卿、代雅建、石旭飞、郭晓东 18 关中盆地城市群环境
地质图中国地质调查局西安地质调查中心 曾庆铭、朱桦、李清 19 黄淮海平原土壤硒
环境图中国地质环境监测院 王轶、王祎萍、高萌萌、李小磊、刘琼、仝晓霞、夏遥、曹峰 20 中国崩塌滑坡泥石流分布图 中国地质环境监测院 尹春荣、曲雪妍、杨旭东、佟彬、房浩、张艳玲 21 中国崩塌滑坡泥石流易发程度图 中国地质环境监测院 房浩、李媛、杨旭东、曲雪妍、尹春荣、佟彬 22 中国地面沉降现状图 中国地质环境监测院 王云龙、郭海朋、朱菊艳、王桂杰、王海刚、秦同春、臧西胜 23 三峡库区崩塌滑坡泥石流分布图 中国地质环境监测院 杨建英、叶润青、程温鸣、吴润泽、付小林、霍志涛 24 长江三角洲地区地面沉降现状图 上海地质调查研究院 严学新、杨天亮、吴建中、朱晓强、龚绪龙、吴孟杰、沈慧珍、闵望、黄鑫磊、林金鑫、赵云捷 25 中国地下水资源图 中国地质科学院水文地质环境地质研究所 张宗祜、秦毅苏、荆继红、孙继朝、戴喜生、刘春燕 26 中国地下水环境图 中国地质科学院水文地质环境地质研究所 孙继朝、荆继红、汪珊、李政红、刘春燕 27 中国水文地质图 中国地质科学院水文地质环境地质研究所 程彦培、董华、张健康、温雪茹、岳晨、盖立强、易卿、倪增石、刘坤、邱玉玲、靳凤清、裴玉杉 28 中国地热资源分布图 中国地质科学院水文地质环境地质研究所 王贵玲、刘志明、蔺文静、张薇、梁继运、刘峰、李龙 29 黄淮海平原水文地质图 中国地质科学院水文地质环境地质研究所 程彦培、董华、张健康、温雪茹、岳晨、盖立强、易卿、倪增石、刘玲霞、王春晓、刘坤、邱玉玲、靳凤清、裴玉杉 30 鄂尔多斯盆地水文
地质图中国地质调查局西安地质调查中心 朱桦、赵振宏、李清、曾庆铭 31 松嫩平原水文地质图 中国地质调查局沈阳地质调查中心 赵海卿、代雅建、石旭飞、郭晓东 32 江汉洞庭平原水文
地质图中国地质调查局武汉地质调查中心 喻望、肖攀、关义涛、姚腾飞 33 中国矿山地质环境
问题图中国地质环境监测院 张进德、张志鹏、任鹰、余洋 34 中国矿山地质环境保护与治理区划图 中国地质环境监测院 张进德、张志鹏、任鹰、余洋 35 中国重要地质遗迹资源分布图 中国地质环境监测院 董颖、黄卓、季燕南、陈梓慧、曹晓娟、王剑昆、杨宏斌 36 中国重要古生物化石产地分布图 中国地质环境监测院 季燕南、曹晓娟、董颖、唐灿、黄卓、杨宏斌、刘嵘、陈梓慧、娄连惠、王剑昆
下载: 导出CSV
Table 1. Metadata Table of Database (Dataset)
Items Description Database (dateset) name Database of Geological Environmental Map System of China Based on MapGIS Database (dateset) authors Li Ruimin, China Institute for Geoenvironmental Monitoring, China Geological Survey
Xu Huizhen, China Institute for Geoenvironmental Monitoring, China Geological Survey
Zeng Qingshi, China Institute for Geoenvironmental Monitoring, China Geological Survey
Wang Yiping, China Institute for Geoenvironmental Monitoring, China Geological Survey
Li Yuan, China Institute for Geoenvironmental Monitoring, China Geological Survey
Jing Jihong, Institute of Hydrogeology and Environmental Geology, Chinese Academy of Geological Sciences
Zhang Jinde, China Institute for Geoenvironmental Monitoring, China Geological Survey
Dong Ying, China Institute for Geoenvironmental Monitoring, China Geological SurveyData acquisition time 2012—2017 Geographic area The whole country and key areas (73°–135° E, 2°–54° N) Data format MapGIS Data size 8.8 GB Data service system URL http://dcc.cgs.gov.cn Fund Project China Geological Survey Projects titled “National Environmental Geological Mapping Research”(121201122017, 12120112200893), “Mapping of Geological environment in Key Areas” (12120112200894), “Compilation of National Hydrogeological Maps” (1212011220941), “National Geological Mapping Management System Development” (12120112200895), and “Assessment of Environmental carrying Capacity and Monitoring and Early Warning of National Geological Resources” (DD20160328). Language Chinese Database (dataset) composition System database: 4 467 colors, 954 patterns, 641 line styles, 2 912 symbols; professional elements: include 5 categories, namely, geological environmental conditions, geologic hazards, groundwater, geological environment of mines, and geological relics, with 163 professional map layers of 36 maps, and 337 833 primitives.
下载: 导出CSV
Table 2. Attribute Structure of Rockmass Engineering Geological Map Layer
Number Data item
nameData item code Definition or description Data type and length Constraints Range Unit 1 Uniform number HJCAABQ Numbered according to requirements C14 M Free text / 2 Rockmass type GCCC Rockmass code C1 M 1–4 / 3 Rock strength YSQD C10 O See instructions / 4 Rockmass structure YTJG C10 O See instruction /
下载: 导出CSV
Table 3. Element Map Layers of Geological Entities
Number Type Element Map Layers of Geological Entities 1 Geological environmental conditions Geoenvironmental zoning lines.WL, Geoenvironmental zoning.WP, Geological environment safety level.WL, High incidence area of land subsidence.WL, Fault line.WL, Geological boundaries.WL, Karst environmental geology zoning.WP, Geological zoning boundaries of karst environment.WL, Typical karst phenomena and resources.WT, Typical karst phenomena and resources-canyons.WL, Main karst geologic hazards and environmental geological problems.WT, Desertification.WP, Rocky desertification.WP, Quaternary isopachy.WL, Quaternary basins.WP, Late Cenozoic volcanic rocks.WP, Late Cenozoic volcanoes.WT, Type and activity of active faults.WL, Active block boundaries.WL, Active block partitions.WP, Earthquake.WT, Earthquake surface rupture zone.WL, Focal mechanism solution data.WT, GPS observation data.WT, Classification of engineering geology of rock masses.WP, Classification of soil engineering geology.WP, active fault distribution.WL, Epicentral distribution of earthquakes.WT, Crater distribution.WT, Stress field and crustal movement characteristics.WT, Crustal rising and falling amplitude of neotectonic movement.WT, Collapse-slip flow distribution.WT, Distribution of ice dunes and ice cones.WT, Distribution of karst phenomena.WT, Anthropogenic engineering geological phenomena.WT, Groundwater burial boundary and depth.WL, Distribution of springs.WT, Distribution of erosive springs or boreholes.WT, Permafrost and snow cover distribution.WP, CO2 geological storage demonstration project distribution.WP, Distribution of boreholes.WT, Lithologic distribution.WP, Quaternary genetic types and epoch-polygon.WP, Quaternary genetic types and epoch-line.WL, Quaternary lithology-polygon.WP, Quaternary lithology-line.WL, Neotectonic movement trace-tectonic line.WL, Neotectonic movement trace-point.WT, Geomorphology-line.WL, Geomorphology-point.WT, Geomorphology-polygon.WP, Landslides and debris flows.WT, Permafrost distribution.WP, Pre-Quaternary bedrock and its elevation zonation-polygon.WP, Pre-Quaternary bedrock and its elevation zoning-line.WL, Distribution of buried Quaternary deposits.WP, Buried Quaternary deposit boundary.WL, Quaternary isopachy.WL, Loess isopach.WL, Maximum transgression range line.WL,Spring.WT, Geological point.WT, Additional line.WL, Other point.WT, Environmental geological zoning.WP, Environmental geological zoning boundary.WL, Rock type.WT, Soil type.WT, Rock soil type boundary.WL, Active fault.WL, Earthquake.WT, Environmental geological problem (polygon).WP, Environmental geological problem (line).WL, Environmental geological problem (point).WT, Groundwater hydrogeochemical anomaly and pollution point.WT, Soil geochemical anomaly.WT, Geological resources.WT, Selenium zoning.WP, Selenium isoline.WL, Vegetation zoning boundary.WL, Endemic.WP 2 Geologic hazards Disaster points of landslide flow.WT, Hidden trouble points of landslide flow.WT, Average annual rainfall isoline.WL, Landslide flow susceptible area.WP, Cumulative land subsidence.WP, Subsidence rate isoline.WL, Subsidence center value.WT 3 Groundwater Types of groundwater resources.WP, Boundary of groundwater resource types.WL, Modulus of natural recharge resources.WP, Runoff modulus.WP, Hydrogeological zoning.WP, Hydrogeological zoning boundaries.WL, Groundwater resources of the province (city).WT, Groundwater resources of main plains (Basins).WT, Proportion of groundwater supply in major cities.WT, Saline water distribution area.WP, Permafrost distribution.WL, Glaciers, snow cover areas.WP, Groundwater salinity and major hydrochemical types zoning.WP, Environmental geological problems related to irrational exploitation and utilization of groundwater (point).WT, Environmental geological problems related to irrational exploitation and utilization of groundwater (line).WL, Environmental geological problems related to irrational exploitation and utilization of groundwater (polygon).WP, Environmental background of typical trace elements in groundwater.WP, Groundwater characteristic contaminants.WT, Contours of nitrate and nitrogen in groundwater.WL, Contours of nitrite nitrogen content in groundwater.WL, Contours of ammonia nitrogen content in groundwater.WL, Contours of permanganate content in groundwater.WL, Contours of volatile phenols in groundwater.WL, Contours of cyanide content in groundwater.WL, Types of shallow groundwater and its water abundance.WP, Types of deep groundwater and its water abundance.WP, saline water distribution.WP, Frozen layer water in middle and low latitudes.WP, Sporadic distribution of phreatic aquifer.WP, Contour line of confined buried depth.WL, Surface water dividing line.WL, Underground river.WL, Roof buried depth contour line.WL, Contour line of frozen layer thickness.WL, Spring point.WT, Thermal reservoir-type zoning.WP, Geothermal resources.WP, Uplift-type geothermal distribution.WP, Sedimentary basin-type geothermal area (field) distribution.WP, Main fault.WL, Geothermal well.WT, Geothermal flow point.WT 4 Geological environment
of minesNon-metal mines.WT, Metal mines.WT, Coal mines.WT, Ore groups.WT, Mineral resources development zone.WP, Mineral resources concentrated mining area.WP, Geomorphological unit.WP, Mine geological environment protection and treatment zoning.WP, Already implemented treatment engineering.WT, Mine geological environment first-class protection zone.WP, Mine geological environment second-class protection zone.WP, Mine geological environment third-class protection zone.WP 5 Geological relics Geological relics-stratigraphic sections.WT, Geological relics-rock profiles.WT, Geological relics-structural profiles.WT, Geological relics-important fossil occurrence.WT, Geological relics-important rock and mineral occurrence.WT, Geological relics-rock and soil physiognomy.WT, Geological relics-water physiognomy.WT. Geological relics-tectonic physiognomy.WT. Geological relics-glacial physiognomy.WT. Geological relics-coastal physiognomy.WT, Seismic relics.WT, Geologic hazard relics.WT, Human fossil occurrence.WT, Biota fossil occurrence.WT, Plant fossil occurrence.WT, trace fossil occurrence.WT
下载: 导出CSV
Table 4. Participating Institutions and Quality Control Personnel in the Database Construction ofthe Map System
Number Map name Participating institution Participant 1 China Geological Environment Zoning Map China Geological Environmental Monitoring Institute Xu Huizhen, Wang Yiping, Liu Qiong, Gao Mengmeng, Li Xiaolei, Xia Yao and Cao Feng 2 China Geological Environment Safety Level Map China Geological Environmental Monitoring Institute Meng Hui, Zhang Ruolin, Shi Jusong, Li Chunyan 3 Karst Environmental Geological Map of China Institute of Karst Geology, Chinese Academy of Geological Sciences Bi Xueli, Shi Jian, Zhou Lixin, Xu Qi, Chen Zhen, Bi Benteng, Yang Chen, Wei Yanlan, Yang Xiangpeng 4 Desertification Land Distribution Map of China China Aero Geophysical Survey and Remote Sensing Center for Land and Resources Sun Yongjun, Gao Huijun, Xing Yu, Li Xia, Shi Wenwen 5 Distribution Map of Active Faults in China and Adjacent Sea Areas Institute of Geology, Chinese Academy of Geological Sciences Wu Zhonghai, Zhou Chunjing, Ma Xiaoxue, Wang Jilong, Huang Xiaolong, Wu Xiaolin, Hu Mengmeng, Ha Guanghao, Liu Jie 6 Engineering Geological Map of China Institute of Hydrogeology and Engineering Geology, Chinese Academy of Geological Sciences Liang Guoling, Zhang Lizhong, Zhang Chunying, Zhu Jixiang,
Shi Lei7 Evaluation Map for Suitability of Carbon Dioxide Geological Storage in Major Sedimentary Basins of China and Adjacent Sea Areas Center for Hydrogeology and Environmental Geology of China Geological Survey Guo Jianqiang, Jin Xiaolin, Jia Xiaofeng, Zhang Senqi, Li Xufeng, Diao Yujie, Fan Jijiao, Zhang Hui, Zhang Yang, Hu Lisha, Zhang Chao, Zhang Chenglong 8 Quaternary Geological Map of the People’s Republic of China and Its Adjacent Sea Areas Institute of Hydrogeology and Engineering Geology, Chinese Academy of Geological Sciences Liang Guoling, Zhang Lizhong, Zhang Chunying, Zhu Jixiang,
Shi Lei9 Environmental Geological Map of Coastal Areas of China Tianjin Center, China Geological Survey Meng Qinghua, Yang Qiqing, Xie Hailan, Wang Xiaodan, Xia Yubo, Liu Hongwei, Liu Futian, Meng Lishan, Bai Yaonan, Du Dong 10 Environmental Geological Map of the Key Economic Zone Around the Bohai Sea Tianjin Center, China Geological Survey Meng Qinghua, Yang Qiqing, Xie Hailan, Wang Xiaodan, Xia Yubo, Liu Hongwei, Liu Futian, Meng Lishan, Bai Yaonan, Du Dong 11 Environmental Geological Map of Yangtze Delta Economic Zone Nanjing Center, China Geological Survey Su Jingwen, Jiang Yuehua, Huang Jinyu, Zhang Taili, Jia Junyuan, Zhou Quanping, Li Yun, Liu Hongying, Zhu Yiping 12 Environmental Geological Map of the Economic Zone (Core Area) on the West Coast of the Straits Nanjing Center, China Geological Survey Xing Huaixue, Ge Weiya, Li Liang, Tian Fujin, Li Yunfeng, Chang Xiaojun, Tang Xiaowen 13 Environmental Geological Map of Urban Agglomeration in the Middle Reaches of the Yangtze River Wuhan Center, China Geological Survey Lu Tao, Liu Fengmei, Shao Changsheng, Yang Yanlin, Zhang Ao, Wang Cen 14 Environmental Geological Map of the Pearl River Delta Economic Zone Wuhan Center, China Geological Survey Liu Fengmei, Huang Changsheng, Zhao Xinwen, Liu Guangning 15 Environmental Geological Map of Beibu Gulf Economic Zone Wuhan Center, China Geological Survey Liu Fengmei, Li Qinghua, Liu Huaiqing 16 Environmental Geological Map of Chengdu-Chongqing Economic Zone Chengdu Center, China Geological Survey Li Minghui, Xu Ruge, Wang Donghui, Tian Kai, Chen Xuyu 17 Environmental Geological Map of Changjitu Economic Zone Shenyang Center, China Geological Survey Zhao Haiqing, Dai Yajian, Shi Xufei, Guo Xiaodong 18 Environmental Geological Map of Urban Agglomeration in Guanzhong Basin Xi’an Center, China Geological Survey Zeng Qingming, Zhu Hua, Li Qing 19 Environmental Map of Soil Selenium in the Huang-Huai-Hai Plain China Geological Environmental Monitoring Institute Wang Yi, Wang Yiping, Gao Mengmeng, Li Xiaolei, Liu Qiong, Tong Xiaoxia, Xia Yao, Cao Feng 20 Distribution Map of Collapse and Landslide Debris Flows in China China Geological Environmental Monitoring Institute Yin Chunrong, Qu Xueyan, Yang Xudong, Tong Bin, Fang Hao, Zhang Yanling 21 Prevalence Map of Landslides and Debris Flows in China China Geological Environmental Monitoring Institute Fang Hao, Li Yuan, Yang Xudong, Qu Xueyan, Yin Chunrong, Tong Bin 22 Current Situation of Land Subsidence in China China Geological Environmental Monitoring Institute Wang Yunlong, Guo Haipeng, Zhu Juyan, Wang Guijie, Wang Haigang, Qin Tongchun, Zang Xisheng 23 Distribution Map of Collapse Landslide and Debris Flow in Three Gorges Reservoir Area China Geological Environmental Monitoring Institute Yang Jianying, Ye Runqing, Cheng Wenming, Wu Runze, Fu Xiaolin, Huo Zhitao 24 Current Situation of Land Subsidence in the Yangtze Delta Area Shanghai Institute of Geological Survey Yan Xuexin, Yang Tianliang, Wu Jianzhong, Zhu Xiaoqiang, Gong Xulong, Wu Mengjie, Shen Huizhen, Min Wang, Huang Xinlei, Lin Jinxin, Zhao Yunjie 25 China Groundwater Resources Map Institute of Hydrogeology and Environmental Geology, Chinese Academy of Sciences Zhang Zonghu, Qin Yisu, Jing Jihong, Sun Jichao, Dai Xisheng, Liu Chunyan 26 China Groundwater Environment Map Institute of Hydrogeology and Environmental Geology, Chinese Academy of Sciences Sun Jichao, Jing Jihong, Wang Shan, Li Zhenghong, Liu Chunyan 27 Hydrogeological Map of China Institute of Hydrogeology and Environmental Geology, Chinese Academy of Sciences Cheng Yanpei, Dong Hua, Zhang Jiankang, Wen Xueru, Yue Chen, Gai Liqiang, Yi Qing, Ni Zengshi, Liu Kun, Qiu Yuling, Jin Fengqing, Pei Yushan 28 Geothermal Resources Distribution Map of China Institute of Hydrogeology and Environmental Geology, Chinese Academy of Sciences Wang Guiling, Liu Zhiming, Lin Wenjing, Zhang Wei, Liang Jiyun, Liu Feng, Li Long 29 Hydrogeological Map of the Huang-Huai-Hai Plain Institute of Hydrogeology and Environmental Geology, Chinese Academy of Sciences Cheng Yanpei, Dong Hua, Zhang Jiankang, Wen Xueru, Yue Chen, Gai Liqiang, Yi Qing, Ni Zengshi, Liu Lingxia, Wang Chunxiao, Liu Kun, Qiu Yuling, Jin Fengqing, Pei Yushan 30 Hydrogeological Map of the Ordos Basin Xi’an Center, China Geological Survey Zhu Hua, Zhao Zhenhong, Li Qing, Zeng Qingming 31 Hydrogeological Map of Songnen Plain Shenyang Center, China Geological Survey Zhao Haiqing, Dai Yajian, Shi Xufei, Guo Xiaodong 32 Hydrogeological Map of Jianghan-Dongting Plain Wuhan Center, China Geological Survey Zhang Jinde, Zhang Zhipeng, Ren Ying, Yu Yang 33 Map of Geological Environment Problems in Mines of China China Geological Environmental Monitoring Institute Yu Wang, Xiao Pan, Guan Yitao, Yao Tengfei 34 Zoning Map for Protection and Control of Mine Geological Environment of China China Geological Environmental Monitoring Institute Zhang Jinde, Zhang Zhipeng, Ren Ying, Yu Yang 35 Distribution Map of Important Geological Remains Resources in China China Geological Environmental Monitoring Institute Dong Ying, Huang Zhuo, Ji Yannan, Chen Zihui, Cao Xiaojuan, Wang Jiankun, Yang Hongbin 36 Distribution Map of Important Palaeontological Fossils in China China Geological Environmental Monitoring Institute Ji Yannan, Cao Xiaojuan, Dong Ying, Tang Can, Huang Zhuo, Yang Hongbin, Liu Rong, Chen Zihui, Lou Lianhui, Wang Jiankun
下载: 导出CSV
-
[1] 邓起东. 2007. 中国活动构造图[M]. 北京: 地震出版社.
[2] 段永侯. 1992. 中国环境地质图系[M]. 北京: 中国地图出版社.
[3] 韩坤英, 丁孝忠, 范本贤, 耿树方, 剧远景, 王振洋. 2005. 基于GIS的区域地质编图方法[J]. 中国地质, 32(4): 713−717. doi: 10.3969/j.issn.1000-3657.2005.04.022
[4] 郝爱兵, 李瑞敏, 石菊松, 等. 2019. 中国地质环境图系[M]. 北京: 地质出版社.
[5] 柯学, 丁孝忠, 韩坤英, 剧远景, 庞健峰. 2008. 基于MAPGIS建立地质图数据库的方法——以全国1∶100万地质图数据库为例[J]. 地质力学学报, 14(2): 186−192. doi: 10.3969/j.issn.1006-6616.2008.02.010
[6] 李炳元. 1994. 中国地貌图[M]. 北京: 科学出版社.
[7] 李瑞敏. 2015. 全国地质环境图系编图技术要求[Z]. 中国地质环境监测院.
[8] 梁国玲, 张永波, 张礼中, 陈京生, 周小元, 张春英. 2008. GIS环境下的中国环境地质图系空间数据库建设[J]. 南水北调与水利科技, 6(6): 23−27. doi: 10.3969/j.issn.1672-1683.2008.06.007
[9] 庞健峰, 丁孝忠, 韩坤英, 曾勇, 陈安蜀, 张艳玲, 张庆合, 姚冬生. 2017. 1∶100万中华人民共和国数字地质图空间数据库[J]. 中国地质, 44(S1): 8−18.
[10] 王欢, 邓书金, 刘江, 林志龙. 2017. 基于MapGIS的重庆市地质环境三级分区及编图[J]. 资源环境与工程, 31(5): 624−627. http://d.old.wanfangdata.com.cn/Periodical/hbdk201705025
[11] 徐友宁, 何芳, 张江华, 乔冈, 等. 2011. 中国矿山环境地质图[M]. 西安: 西安地图出版社.
[12] 叶天竺, 黄崇轲, 邓志奇. 2017. 1∶250万中华人民共和国数字地质图空间数据库[J]. 中国地质, 44(S1): 19−24.
[13] 殷跃平. 2013. 中国地质环境图系[M]. 西安: 西安地图出版社.
[14] 张发旺, 程彦培, 董华, 等. 2012. 亚洲地下水系列图[M]. 北京: 中国地图出版社.
[15] 张宗祜, 秦毅苏, 等. 2004. 中国地下水资源图[M]. 北京: 中国地图出版社.
[16] 张宗祜, 孙继超, 等. 2006. 中国地下水环境图[M]. 北京: 中国地图出版社.
[17] 曾青石. 2015. 全国地质环境图系建库技术要求[Z]. 中国地质环境监测院.
[1] Deng Qidong. 2007. Active structure map of China[M]. Beijing: Earthquake Press (in Chinese).
[2] Duan Yonghou. 1992. Environmental geological map system of China[M]. Beijing: China Map Publishing House (in Chinese).
[3] Hao Aibing, Li Ruimin, Shi Jusong, et al. 2019. Geological environmental map system of China[M]. Beijing: Geological Publishing House (in Chinese).
[4] Han Kunying, Ding Xiaozhong, Fan Benxian, Geng Shufang, Ju Yuanjing, Wang Zhenyang. 2005. Methods of regional geological map production based on GIS[J]. Chinese Geology, 32(4): 713−717 (in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=zgdizhi200504022
[5] Ke Xue, Ding Xiaozhong, Han Kunying, Ju Yuanjing, Pang Jianfeng. 2008. Method For The Construction Of The Geological Map Database Based On MapGIS−Example From The 1∶1 000 000Geological Map Database Of China[J]. Journal of Geomechanics, 14(2): 186−192 (in Chinese with English abstract).
[6] Li Bingyuan. 1994. Landform map of China[M]. Beijing: Science Press (in Chinese).
[7] Li Ruinmin. 2015. Technical requirements for mapping of national geological environment map system[Z]. Beijing: China Institute for Geoenvironmental Monitoring (in Chinese).
[8] Liang Guoling, Zhang Yongbo, Zhang Lizhong, Chen Jingsheng, Zhou Xiaoyuan, Zhang Chunying. 2008. Construction of the Spatial Database of Chinese Environmental Geological Map System by GIS[J]. South-to-North Water Transfers and Water Science & Technology, 6(6): 23−27 (in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=nsbdyslkj200806007
[9] Pang Jianfeng, Ding Xiaozhong, Han Kunying, Zeng Yong, Chen Anshu, Zhang Yanling, Zhang Qinghe, Yao Dong sheng. 2017. The national 1:1 000 000 geological map spatial database[J]. Geology in China, 44(S1): 10−23. http://d.old.wanfangdata.com.cn/Periodical/OA000006962
[10] Wang Huan, Deng Shujin, Liu Jiang, Lin Zhilong. 2017. Geological Environment Three-level Partition and Mapping in Chongqing Based on MapGIS[J]. Resources Environment & Engineering, 31(5): 624−627 (in Chinese with English abstract). http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=hbdk201705025
[11] Xu Youning, He Fang, Zhang Jianghua, Qiao Gang, et al. 2011. Environmental Geological Map of China's Mines M]. Xi’an: Xi'an Map Publishing House (in Chinese).
[12] Ye Tianzhu, Huang Chongke, Deng Zhiqi. 2017. Spatial database of 1:2 500 000 digital geologic map of People’s Republic of China[J]. Geology in China, 44(S1): 24−31.
[13] Yin Yueping. 2013. Geological environmental map system of China[M]. Xi’an: Xi'an Map Publishing House (in Chinese).
[14] Zeng Qingshi. 2015. Technical requirements for the database construction of the national geological environment map system[Z]. Beijing: China Institute for Geoenvironmental Monitoring (in Chinese).
[15] Zhang Fawang, Cheng Yanpei, Dong Hua, et al. 2012. Groundwater series of Asia[M]. Beijing: China Map Publishing House (in Chinese).
[16] Zhang Zonghu, Qin Yisu, et al. 2004. Groundwater resources map of China[M]. Beijing: China Map Publishing House (in Chinese).
[17] Zhang Zonghu, Sun Jichao, et al. 2006. Groundwater environmental map of China[M]. Beijing: China Map Publishing House (in Chinese).
-
