A new method for detecting gypsum mineral salt enriched layer of urban underground space in red bed area: A case study of Chengdu International Biological City
-
摘要:
含膏盐岩体是红层地区城市地下空间利用过程中常见的不良地质体。提前获知基岩内膏盐富集地层的埋深及空间展布规律，对城市地下空间资源的开发利用以及地基承载力、持力层、基础选型等参数的确定具有重要的参考意义。本文以成都市天府新区国际生物城为研究区，选择了一种快速、无损、抗干扰能力强的全新瞬变电磁法——等值反磁通瞬变电磁法(OCTEM)，对白垩系灌口组红层内膏盐富集层进行探测研究。首先根据研究区内不同地层的电阻率特征，建立了三层、四层、五层3种地电模型，分别进行OCTEM正演响应分析，结果表明该方法能够有效地识别出与围岩电阻率差异明显的膏盐富集层；然后对2 km2的试验区开展了网度为100 m×10 m的实测扫面工作，通过反演计算建立了研究区200 m以浅的三维电性结构，结合钻孔结果综合验证与分析，成功推断出膏盐富集层的空间展布形态，证明了该方法对红层地区城市地下空间膏盐富集层探测的有效性。
Abstract:Gypsum mineral salt enriched layers are common bad geological body in the process of utilizing urban underground space in the red beds area. The detection of the burial depth and spatial distribution of gypsum-salt enriched strata in advance is of great significance for the development of urban underground space resources,the determination of foundation bearing capacity,bearing stratum and foundation type selection. Taking the International Biological City of Tianfu New District of Chengdu as the experimental area,the authors chose a fast,non-destructive and anti-jamming new transient electromagnetic method,opposing coils transient electromagnetic method (OCTEM),to detect and study the gypsum-salt enriched layer in red mudstone of Cretaceous Guankou Formation. Firstly,according to the resistivity characteristics of different strata in the study area,the authors established geoelectric models such as three-layer model,four-layer model and five-layer model,and carried out OCTEM forward response analysis for these models,respectively. The forwarding calculation shows that,with OCTEM method,the gypsum salt enriched layer can be effectively identified from surrounding rocks with obvious resistivity difference. Then,the authors took the practical measurement in the test area covered about two square kilometers,and swept the field with a network of 100m×10 m. Finally,the authors obtained the inversion results and established the three-dimensional electrical structure of strata in the depth greater than 200 m in the study area. With the comprehensive verification and analysis of drilling results,the spatial distribution pattern of gypsum mineral salt enriched layer was successfully inferred,which proves that this method is effective for the detection of gypsum-salt enrichment layer in urban underground space of the red bed area.
-
-
Ander Guinea, Elisabet Playà, Luis Rivero, 2009. Geoelectrical imaging supporting glauberite deposits evaluation in the Montes de Torrero area (Zaragoza)[J]. Geogaceta, 47:145-148. http://dialnet.unirioja.es/servlet/articulo?codigo=3282928
Ander Guinea, Elisabet Playà, Lluís Rivero, Josep Maria Salvany. 2014. Geoelectrical prospecting of glauberite deposits in the Ebro basin (Spain)[J]. Engineering Geology, 174:73-86. doi: 10.1016/j.enggeo.2014.03.007
Chen Qiyu, Liu Gang, Wu Chonglong, Li Xinchuan, Zhang Zhiting. 2016. Knowledge-driven multiple scale 3D geological modeling method in urban geological survey[J]. Geography and GeoInformation Science, 32(4):11-16(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-DLGT201604003.htm
Qiu Kaili, Chu Yongbin, Zhang Zhiming. 2014. Spatial distribution of geological hazards in Tianfu district (Chengdu part)[J]. Journal of Guilin University of Technology, 34(2):245-253(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-GLGX201402005.htm
He Jing, He Hanhan, Zheng Guisen, Liu Yu, Zhou YuanXin, Xiao JingZe, Wang Chunjun. 2019.3D geological modelling of superficial deposits in Beijing City[J]. Geology in China, 46(2):244-254(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTotal-DIZI201902004.htm
Fang Yinchen, Gong Rixiang, Li Sanfeng, Pan Shengyong, Gu Mingguang, Huang Weiping. 2017. Suitability evaluation of underground space development based on a three-dimensional geological model, using the Jiaxing urban geological survey as an example[J]. Shanghai Land & Resources, 38(2):43-45(in Chinese with English Abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-SHAD201702012.htm
Lin Liangjun, Li Yamin, Ge Weiya, Hu Qiuyun, Li Xiaozhao, Li Yun, Meng Hui, Zhang Lizhong, Yang Jianfeng. 2017. General ideas forurban geological survey in China and key theory and techniques[J]. Geology in China, 44(6):1086-1101 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-DIZI201706006.htm
Liu Wei, Gan Fuping, Zhang Wei. 2015. Application of geophysical prospecting to Karst collapse in red bed area[J]. Progress in Geophysics, 30 (6):2923-2930 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTotal-DQWJ201506063.htm
Niu Zhilian. 2007. Theory of Time Domain Electromagnetic[M]. Changsha:Central South University Press, 1-298 (in Chinese).
Qiu Enxi, Kang Jingwen, Zheng Lining. 2015. Study of corrosion characters of red-bed soft rock containing saline deposit in Chengdu[J]. Chinese Journal of Rock and Soil Mechanics, 36(Supp. 2):274-280(in Chinese with English abstract). http://www.researchgate.net/publication/283527236_Study_of_corrosion_characters_of_red-bed_soft_rock_containing_saline_deposit_in_Chengdu
Su Maoxin, Qian Qihu, Li Shucai. 2011. A method of metro advanced geological prediction under karst geology condiction[J]. Chinese Journal of Rock Mechanics and Engineering, 30(7):1428-1434(in Chinese with English abstract). http://www.cnki.com.cn/Article/CJFDTotal-YSLX201107018.htm
Sun Huaifeng, Li Kai, Chen Rujun. 2018. Experimental study on transient electromagnetic responses to shallow karst[J]. Chinese Journal of Rock Mechanics and Engineering, 37(3):652-661 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTotal-YSLX201803013.htm
Theis Raaschou Andersen, Søren Erbs Poulsen, Peter Thomsen. 2018.Geological characterization in urban areas based on geophysical mapping:A case study from Horsens, Denmark[J]. Journal of Applied Geophysics, 150:338-349. doi: 10.1016/j.jappgeo.2017.08.009
Wang Yahui, Zhang Maosheng, Shi Yunchao, Dong Ying, Wang Feng, Yu Fengdan. 2019. Precise detection and modeling of urban underground space based on integrated geophysical exploration[J]. Northwestern Geology, 52(2):83-94(in Chinese with English abstract).
Wang Zizhong, Xu Mo. 2011. Characteristics of red bed containing saline deposit and engineering geological issues of dam foundation in Sichuan Basin(I)[J]. Water Resources and Hydropower Engineering, 42 (3):10-12(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-SJWJ201103003.htm
Wei Wanshun, Zheng Guisen, Yu Chunlin, Xu Jixiang. 2016. Strategic thinking on China urban geological work in the next five years[J]. Urban Geology, 11(2):1-5 (in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTOTAL-CSDZ201602002.htm
Wei Yufeng, Nie Dexin. 2005. The speciality of gypsum dissolution of the Neogene red clay and its influence to engineering[J]. Hydrogeology & Engineering Geology, 13(2):62-64 (in Chinese with English abstract). http://d.wanfangdata.com.cn/Periodical/swdzgcdz200502013
Xi Zhenzhu, Liu Jian, Long Xia. 2010. Three-component measurement intransient electromagnetic method[J]. Journal of Central South University:Science and Technology, 41(1):272-276(in Chinese with English abstract). http://www.researchgate.net/publication/289028402_Three-component_measurement_in_transient_electromagnetic_method
Xi Zhenzhu, Long Xia, Zhou Sheng. 2016. Opposing coils transient electromagnetic method for shallow subsurface detection[J]. Chinese J. Geophys, 59(9):3428-3435(in Chinese with English abstract). http://www.en.cnki.com.cn/Article_en/CJFDTotal-DQWX201609025.htm
Yang Wencai, Tian Gang, Xia Jianghai, Yang Bo. 2019. The prospect of exploitation and utilization of urban underground space in hilly areas of South China[J]. Geology in China, 46(3):447-454(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTotal-DIZI201903002.htm
Yang Xiaogang, Wang Rui, Huang Wei. 2019. Status and challenges of underground space development and utilization in China based on comparative analysis of typical Chinese cities[J]. Earth Science Frontiers, 26(3):69-75(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTotal-DXQY201903012.htm
Zhou Sheng, Xi Zhenzhu, Song Gang. 2012. Responses of the towed transient electromagnetic sounding on deep seafloor[J]. Journal of Central South University, 43(2):605-610(in Chinese with English abstract). http://en.cnki.com.cn/Article_en/CJFDTotal-ZNGD201202034.htm
陈麒玉, 刘刚, 吴冲龙, 李新川, 张志庭. 2016.城市地质调查中知识驱动的多尺度三维地质体模型构建方法[J].地理与地理信息科学, 32(4):11-16. http://d.wanfangdata.com.cn/Periodical/dlxygtyj201604003
仇开莉, 褚永彬, 张志明. 2014.天府新区(成都部分)地质灾害空间分布特征[J].桂林理工大学学报, 34 (2):245-253. http://qikan.cqvip.com/Qikan/Article/Detail?id=661661144
何静, 何晗晗, 郑桂森, 刘予, 周圆心, 肖景泽, 王纯君. 2019.北京五环城区浅部沉积层的三维地质结构建模[J].中国地质, 46(2):244-254. http://geochina.cgs.gov.cn/geochina/ch/reader/view_abstract.aspx?file_no=20190203&flag=1
方寅琛, 龚日祥, 李三凤, 潘声勇, 顾明光, 黄卫平. 2017.基于三维地质模型的地下空间开发适宜性评价——以嘉兴城市地质调查工作为例[J].上海国土资源, 38(2):43-45. http://www.cqvip.com/main/zcps.aspx?c=1&id=7000248828
林良俊, 李亚民, 葛伟亚, 胡秋韵, 李晓昭, 李云, 孟晖, 张礼中, 杨建锋. 2017.中国城市地质调查总体构想与关键理论技术[J].中国地质, 44(6):1086-1101. http://geochina.cgs.gov.cn/geochina/ch/reader/view_abstract.aspx?file_no=20170605&flag=1
刘伟, 甘伏平, 张伟. 2015.红层区岩溶塌陷调查地球物理勘探技术应用研究[J].地球物理学进展, 30 (6):2923-2930. http://www.cqvip.com/QK/98047X/201506/667842896.html
牛之琏. 2007.时间域电磁法原理[M].长沙:中南大学出版社, 1-298.
邱恩喜, 康景文, 郑立宁. 2015.成都地区含膏红层软岩溶蚀特性研究[J].岩土力学, 36(增刊2):274-280. http://www.cnki.com.cn/Article/CJFDTotal-YTLX2015S2037.htm
苏茂鑫, 钱七虎, 李术才. 2011.一种岩溶地质条件下的城市地铁超前预报方法[J].岩石力学与工程学报, 30(7):1428-1434. http://www.cnki.com.cn/Article/CJFDTotal-YSLX201107018.htm
孙怀凤, 李凯, 陈儒军. 2018.浅层岩溶瞬变电磁响应规律试验研究[J].岩石力学与工程学报, 37(3):652-661. http://www.cnki.com.cn/Article/CJFDTotal-YSLX201803013.htm
王亚辉, 张茂省, 师云超, 董英, 王锋, 于峰丹. 2019.基于综合物探的城市地下空间探测与建模[J].西北地质, 52(2):83-94. http://www.cnki.com.cn/Article/CJFDTotal-XBDI201902013.htm
王子忠, 许模. 2011.四川盆地含膏盐红层特征及坝基工程地质问题(I)[J].水利水电技术, 42(3):10-12. http://qikan.cqvip.com/Qikan/Article/Detail?id=37478626
卫万顺, 郑桂森, 于春林, 徐吉祥. 2016.未来五年我国城市地质工作战略思考[J].城市地质, 11(2):1-5. http://www.cnki.com.cn/Article/CJFDTotal-CSDZ201602002.htm
魏玉峰, 聂德新. 2005.第三系红层石膏溶蚀特征及其对工程的影响[J].水文地质工程地质, 13(2):62-64. http://d.wanfangdata.com.cn/Periodical/swdzgcdz200502013
席振珠, 刘剑, 龙霞. 2010.瞬变电磁法三分量测量方法研究[J].中南大学学报:自然科学版, 41(1):272-276. http://d.wanfangdata.com.cn/Periodical/zngydxxb201001046
席振铢, 龙霞, 周胜. 2016.基于等值反磁通原理的浅层瞬变电磁法[J].地球物理学报, 59(9):3428-3435. http://www.cqvip.com/QK/94718X/201609/669991133.html
杨文采, 田钢, 夏江海, 杨波. 2019.华南丘陵地区城市地下空间开发利用前景[J].中国地质, 46(3):447-454. http://geochina.cgs.gov.cn/geochina/ch/reader/view_abstract.aspx?file_no=20190301&flag=1
杨晓刚, 王睿, 黄伟. 2019.亮华南丘陵地区城市地下空间开发利用前景[J].地学前缘. 26(3):069-075. http://www.cnki.com.cn/Article/CJFDTotal-DIZI201903002.htm
周胜, 席振铢, 宋刚. 2012.深海拖曳式瞬变电磁的响应规律[J].中南大学学报:自然科学版, 43(2):605-610. http://www.cqvip.com/QK/90745B/20122/41046514.html
-
