Zircon U-Pb ages and Hf isotopic compostions of Sugensala pluton in the western Junggar: Constraints on the tectonic evolution
-
摘要: 【研究目的】 为了进一步了解西准噶尔地区构造演化。【研究方法】 对西准谢米斯台西段苏根萨拉岩体的花岗岩进行了LA-ICP-MS锆石U-Pb年龄和Hf同位素测试。【研究结果】 定年结果呈现出2期年龄：一期集中在440~450 Ma，第二期集中在410~420 Ma，根据锆石CL图像特征，认为(444.2±2.2) Ma（MSWD=0.99）代表了捕获锆石的年龄，(415.6±1.1)Ma代表了岩体的结晶年龄，为晚志留世，指示博什库尔—成吉斯岩浆弧至少在晚志留世就开始了广泛的岩浆活动。锆石的εHf(t)值变化范围为+8.6~+13.2，加权平均值为10.8±1.4，显示其原岩来源于地幔物质，其一阶段Hf模式年龄TDM1为521~742 Ma，两阶段模式年龄TDM2变化于565~858 Ma，本区花岗岩是亏损地幔物质上升到地壳，并在此停留一段时间后的熔融产物，其来源于年轻的地壳物质，表明花岗岩类的源岩为新生地壳物质的部分熔融，加入到大陆地壳中的新生组分可能主要为来自亏损地幔的玄武质岩浆。【结论】 推测准噶尔盆地可能是以新元古代晚期至早古生代早期，由亏损地幔演化而来的洋壳和岛弧建造组成的年轻地壳为主。这为进一步认识西准噶尔博什库尔—成吉斯岩浆弧的性质及构造演化提供了证据。Abstract: This paper is the result of geological survey engineering.
[Objective]In order to further understand the tectonic evolution of the West Junggar region. [Methods]In this paper, the zircon UPb geochronology and Hf isotopes of Sugensala granites were carried out. [Results]The dating results show two stages of age. The first phase focused on 440-440 Ma and the second phase is concentrated in the 410-420 Ma. According to the characteristics of the zircon CL images, we consider a capture zircon age of (444.2±2.2) Ma and a crystallization zircon age of (415.6±1.1) Ma. It is implied there was a wide range of magmatic activity at least on late- Silurian in Boshchekul—Chingiz magmatic arc. The εHf(t) values of the zircon range of 8.6-13.2, with a weighted average of 10.8±1.4, indicating that its original rock is derived from mantle materials. The one-stage Hf model ages (TDM1) are 521-742 Ma and two-stage Hf model ages (TDM2) are 565-858 Ma. The granite was derived from the younger crustal materials from partial melting of the depleted mantle which raised to crust and stayed for a period of time. It shows that the source rocks of granites were generated from partial melting of new crustal material. The new components of continental crust may mainly come from depleted mantle-derived basaltic magma. [Conclusions]We speculate that Junggar basin is composed of young crust which evolved from depleted mantle in the period of late Neoproterozoic to Early Paleozoic. It is helpful to the further understanding the nature and tectonic evolution for Boshchekul-Chingiz magmatic arc. -
-
Chen B, Arakawa Y. 2005. Elemental and Nd-Sr isotopic geochemistry of granitoids from the West Junggar foldbelt (NW China), with implications for Phanerozoic continental growth[J]. Geochimica et Cosmochimica Acta, 69(5): 1307-1320.
Chen B, Jahn B M. 2004. Genesis of post-collisional granitoids and basement nature of the Junggar Terrane, NW China: Nd-Sr isotope and trace element evidence[J]. Journal of Asian Earth Sciences, 3: 691-703.
Chen J F, Han B F, Ji J Q, Zhang L, Xu Z, He G Q, Wang T. 2010. Zircon U-Pb ages and tectonic implications of Paleozoic plutons in northern West Junggar, North Xinjiang, China[J]. Lithos, 115(1): 137-152.
Goolaerts A, Mattielli N, de Jong J, Weis D, Scoates J S. 2004. Hf and Lu isotopic reference values for the zircon standard 91500 by MC-ICP-MS[J]. Chemical Geology, 206: 1-9.
Guo Zhaojie. 2012. A review on the Paleozoic tectonic evolution of northern Xinjiang and a discussion on the important role of geological maps in tectonic study[J]. Geological Bulletin of China, 31(7):1054-1060(in Chinese with English abstract).
Han Baofu, Ji Jianqing, Song Biao, Chen Lihui, Zhang Lei. 2006. Late Paleozoic Vertical Growth of Continental Crust around the Junggar Basin, Xinjiang, China(Part I): Timing of post-collisional plutonism[J]. Acta Petrologica Sinica, 22(5): 1077-1086(in Chinese with English abstract).
Han Baofu, He Guoqi, Wang Shiguang, Hong Dawei. 1998. Postcollisional mantle-derived magmatism and vertical growth of the continental crust in North Xinjiang[J]. Geological Review, 44(4): 396-406 (in Chinese with English abstract).
Han Baofu, He Guoqi, Wang Shiguang. 1999. Postcollisional mantle-derived magmatism, underplating and implications for basement of the Junggar Basin[J]. Science in China (Series D: Earth Sciences), 2: 113-119(in Chinese).
Han Lele, Ding Weicui, Chen Xuanhua, Liu Meiling, Wang Ye, Xu Shenlin, Zhang Da, Cui Yanjun. 2019. Linear structure extraction and quantitative analysis of multi-source remote sensing information in West Junggar Basin[J]. Geology in China, 46(5): 1209-1223(in Chinese with English abstract).
Jahn Bor-ming, Windley Brian, Natal'in Boris, Dobretsov Nick. 2004. Phanerozoic continental growth in Central Asia[J]. Journal of Asian Earth Sciences, 23: 599-603.
Jahn B M, Wu F Y, Chen B. 2000. Massive granitoid generation in Central Asia: Nd istope evidence and implication for continental growth in the Phanerozoic[J]. Episodes, 22: 82-92.
Jin Song, Zhang Zhaoyi, Rong Guilin, Liu Xinyu, Li Yuehui，Zhang Hanwen, Bi Li. 2015. Geochemical characteristics, zircon U-Pb age, and Hf isotopes of Yushenkala pluton in western Junggar, Xinjiang: Constraint on the closure of Paleo-Asian Ocean[J]. Geology in China, 42(3): 494-508(in Chinese with English abstract).
Jin Song, Zhang Zhaoyi, Rong Guilin, Zeng Wen, Lin Qian, Wu Liang. 2016. Petrogenesis and tectonic implication for Jiaerluafu granitic porphyry pluton in western Junggar, Xinjiang: Constraints from the element and zircon Hf isotope geochemistry[J]. Chinese Journal of Geology, 51(1): 262-280(in Chinese with English abstract).
Li Huaikun, Geng Jianzhen, Hao Shuang, Zhang Yongqing, Li Huiming. 2009. The study of determination zircon U-Pb isotopic age using laser ablation multi-collector inductively coupled plasma mass spectrometry (LA-MC-ICPMS) [J]. Acta Mineralogica Sinica, S1: 600-601(in Chinese).
Meng Lei, Shen Ping, Shen Yuanchao, Liu Tiebing, Song Guoxue, Dai Huawu, Li Chenkai, Lang Zesong. 2010. Igneous rocks geochemistry, zircon U-Pb age and its geological significance in the central section of Xiemisitai area, Xinjiang[J]. Acta Petrologica Sinica, 26(10): 3047-3056(in Chinese with English abstract).
Shen P, Shen Y C, Li X H, Pan Hongdi, Zhu Heping, Meng Lei, Dai Huawu. 2012. Northwestern Junggar Basin, Xiemisitai Mountains, China: A geochemical and geochronological approach[J]. Lithos, 140: 103-118.
Su Yuping, Tang Hongfeng, Hou Guangshun, Liu Congqiang. 2006. Geochemistry of aluminous A-type granites along Darabut tectonic belt in western Junggar, Xinjiang[J]. Geochimica, 35(1): 55-67(in Chinese with English abstract).
Sun Yong, Li Yongjun, Yang Gaoxue, Yi Shanxin, Zhang Shenglong, Sun Yu, Wang Junnian. 2015. Zircon LA-ICP-MS U-Pb dating and tectonic settings implications of the middle Silurian volcanic rocks in the west of Xiemisitai mountain, west Juggar[J]. Xinjiang Geology, 33(1): 27-32(in Chinese with English abstract).
Tang Hejun, Meng Guixiang, Wang Zhaolin, Deng Zhen, Yan Jiayong, Qi Guang, Xue Ronghui. 2020. Zircon U-Pb geochronology of the newly discovered Kulabiye Cu-Ni sulfide-mineralized gabbroic complex, East Junggar Basin in Xinjiang, China[J]. China Geology, 3(4): 490-492.
Tong Ying, Wang Tao, Hong Dawei, Han Baofu, Zhang Jianjun, Shi Xingjun, Wang Chao. 2010. Spatial and temporal distribution of the Carboniferous-Permian granitoids in northern Xinjiang and its adjacent areas, and its tectonic significance[J]. Acta Petrologica et Mineralogica, 29(6): 619-641(in Chinese with English abstract).
Wang Jingbin, Xu Xin. 2006. Post-collisional tectonic evolution and metallogenesis in Northern Xinjiang, China[J]. Acta Geologica Sinica, 80(1): 23-31(in Chinese with English abstract).
Wang Jinrong, Jia Zhilei, Li Taide, Ma Jinlong, Zhao Lei, He Yanbin, Zhang Wei, Liu Kunxin. 2013. Discovery of early Devonian adakite in west Junggar, Xinjiang: Implications for geotectonics and Cu mineralization[J]. Acta Petrologica Sinica, 29(3): 840-852(in Chinese with English abstract).
Windley Brian F, Kröner Alfred, Guo Jinghui, Qu Guosheng, Li Yingyi, Zhang Chi. 2002. Neoproterozoic to Paleozoic geology of the Altai orogen, NW China: New zircon age data and tectonic evolution[J]. Joumal of Geology, 110: 719-737.
Woodhead J, Hergt J, Shelley M, Eggins S, Kemp R. 2004. Zircon Hf-isotopic analysis with an excimer laser, depth profiling, ablation of complex geometries, and concomitant age estimation[J]. Chemical Geology, 209:121-135.
Wu Chu, Hong Tao, Xu Xingwang, Wang Chengxi, Dong Lianhui. 2022. A-type granites induced by a breaking-off and delamination of the subducted Junggar oceanic plate, West Junggar, Northwest China[J]. China Geology, 5, 457-474.
Wu Fuyuan, Yang Yueheng, Xie Liewen, Yang Jinhui, Xu Ping. 2006. Hf isotopic compositions of the standard zircons and baddeleyites used in U-Pb geochronology[J]. Chemical Geology, 234: 105-126.
Xiao W J, Windley B F, Badarch G, Sun S, Li J, Qin K Z, Wang Z. 2004. Palaeozoic accretionary and convergent tectonics of the southern Altaids: Implications fot the growths of Central Asia[J]. Journal of the Geological Society, 161: 339-342.
Xiao Wenjiao, Han Chunming, Yuan Chao, Chen Hanlin, Sun Ming, Lin Shoufa, Li Zilong, Mao Qigui, Zhang Jien, Sun Shu, Li Jiliang. 2006. Unique Carboniferous-Permian tectonic-metallogenic framework of Northern Xinjiang(NW China): Constraints for the tectonics of the southern Paleoasian Domain[J]. Acta Petrologica Sininca, 22(5): 1062-1076(in Chinese with English abstract).
Xu Shenglin, Chen Xuanhua, Li Tingdong, Ding Weicui, Shi Jianjie, Li Bing, Ma Feizhou. 2019. Time of the ocean-continent transition in West Junggar: Constraints from zircon U-Pb dating and Lu-Hf isotopic composition[J]. Geology in China, 46(5): 1061-1078(in Chinese with English abstract).
Xu Xueyi, Li Rongshe, Chen Junlu, Ma Zhongping, Li Zhipei, Wang Hongliang, Bai Jianke, Tang Zhuo. 2014. New constrains on the Paleozoic tectonic evolution of the northern Xinjiang area[J]. Acta Petrologica Sinica, 30(6):1521-1534(in Chinese with English abstract).
Yang Gang, Xiao Long, Wang Guocan, Gao Rui, He Xinxing, Yan Shengwu, Yang Wei, Yan Wenbo, Zhou Pei. 2015. Geochronology, geochemistry and zircon Lu-Hf study of granites in western section of Xiemisitai area, western Junggar[J]. Earth Science—Journal of China University of Geosciences, 40(3): 548-562.
Zhang Dayu, Zhou Taofa, Yuan Feng, Deng Yufeng, Xu Chao, Zhang Ruofei, Li Peng, Wang Jinlin. 2015. The discovery on the Early Paleozoic magmatism in the Sawuer area, West Junggaar[J]. Acta Petrologica, 31(2): 415-425.
Yang Wei, Wang Guocan, Zong Ruiwen, Xiao Long, Li Li, Yang Gang. 2015. Determination of Silurian-Devonian arc-basin pattern in western Juggar and its regional tectonic significance[J]. Earth Science—Journal of China University of Geosciences, 40(3): 448-460(in Chinese with English abstract).
Zong Ruiwen, Gong Yiming. 2019. The discovery of the Late Devonian fossils from the Hebukehe Formation and its stratal position in Kelasaileke Mountain, western Junggar, Xinjiang[J]. Geology in China, 46(6): 1259-1269(in Chinese with English abstract).
附中文参考文献
郭召杰. 2012. 新疆北部大地构造研究中几个问题的评述——兼论地质图在区域构造研究中的重要意义[J]. 地质通报, 31(7): 1054-1060.
韩宝福, 何国琦, 王式洸, 洪大卫. 1998.新疆北部碰撞后幔源岩浆活动与陆壳纵向生长[J]. 地质论评, 44(4): 396-406.
韩宝福, 何国琦, 王式洸. 1999. 后碰撞幔源岩浆活动、底垫作用及准噶尔盆地基底的性质[J]. 中国科学(D辑), 42(2): 113-119.
韩宝福, 季建清, 宋彪, 陈立辉, 张磊. 2006. 新疆准噶尔晚古生代陆壳垂向生长(I)——后碰撞深成岩浆活动的时限[J].岩石学报, 22(5): 1077-1086.
韩乐乐, 丁伟翠, 陈宣华, 刘美玲, 王叶, 徐盛林, 张达, 崔艳军. 2019. 西准噶尔地区多源遥感信息的线性构造提取与定量分析[J]. 中国地质, 46(5): 1209-1223.
靳松, 张兆祎, 荣桂林, 刘新宇, 李跃辉, 张瀚文, 毕立. 2015. 新疆西准噶尔玉什喀腊岩体的地球化学特征、锆石U-Pb 年龄及Hf同位素：对古亚洲洋闭合的制约[J]. 中国地质, 42(3): 494-508.
靳松, 张兆祎, 荣桂林, 曾雯, 林茜, 吴立昂. 2016. 新疆西准噶尔地区加尔路阿甫花岗斑岩岩石成因及地质意义：元素和锆石Hf同位素地球化学制约[J]. 地质科学, 51(1): 262-280.
李怀坤, 耿建珍, 郝爽, 张永清, 李惠民. 2009. 用激光烧蚀多接收器等离子体质谱仪(LA-MC-ICPMS)测定锆石U-Pb同位素年龄的研究[J]. 矿物学报, S1: 600-601.
孟磊, 申萍, 沈远超, 刘铁兵, 宋国学, 代华五, 李成凯, 郎泽松. 2010. 新疆谢米斯台中段火山岩岩石地球化学特征、锆石U-Pb年龄及其地质意义[J]. 岩石学报, 26(10): 3047-3056.
苏玉平, 唐红峰, 侯广顺, 刘丛强. 2006. 新疆西准噶尔达拉布特构造带铝质A型花岗岩的地球化学研究[J]. 地球化学, 35(1): 55-67.
孙勇, 李永军, 杨高学, 易善鑫, 张胜龙, 孙羽, 王军年. 2015. 西准噶尔谢米斯台山西缘中志留世火山岩LA-ICP-MS锆石U-Pb测年及构造意义[J]. 新疆地质, 33(1): 27-32.
童英, 王涛, 洪大卫, 韩宝福, 张建军, 史兴俊, 王超. 2010. 北疆及邻区石炭—二叠纪花岗岩时空分布特征及其构造意义[J]. 岩石矿物学杂志, 29(6): 619-641.
王金荣, 贾志磊, 李泰德, 马锦龙, 赵磊, 何彦彬, 张伟, 刘昆鑫. 2013. 新疆西准噶尔发现早泥盆世埃达克岩:大地构造及成矿意义[J].岩石学报, 29(3): 840-852.
王京彬, 徐新. 2006. 新疆北部后碰撞构造演化[J].地质学报， 80(1):23-31.
肖文交, 韩春明, 袁超, 陈汉林, 孙敏, 林寿发, 厉子龙, 毛启贵, 张继恩, 孙枢, 李继亮. 2006. 新疆北部石炭纪—二叠纪独特的构造-成矿作用: 对古亚洲洋构造域南部大地构造演化的制约[J]. 岩石学报, 22(5): 1062-1076.
徐盛林, 陈宣华, 李廷栋, 丁伟翠, 史建杰, 李冰, 马飞宙. 2019. 西准噶尔地区洋陆转换时代:来自锆石U-Pb定年与Lu-Hf同位素的约束[J]. 中国地质, 46(5): 1061-1078.
徐学义, 李荣社, 陈隽璐, 马中平, 李智佩, 王洪亮, 白建科, 唐卓. 2014. 新疆北部古生代构造演化的几点认识[J]. 岩石学报, 30(6): 1521-1534.
杨钢, 肖龙, 王国灿, 高睿, 贺新星, 鄢圣武, 杨维, 晏文博, 周佩. 2015. 西准噶尔谢米斯台西段花岗岩年代学、地球化学、锆石Lu-Hf同位素特征及大地构造意义[J]. 地球科学——中国地质大学学报, 40(3): 548-562.
杨维, 王国灿, 纵瑞文, 肖龙, 李理, 杨钢. 2015. 西准噶尔志留纪—泥盆纪弧盆格局的确定及其区域构造演化意义[J]. 地球科学——中国地质大学学报, 40(3): 448-460.
纵瑞文, 龚一鸣. 2019. 西准噶尔克拉赛勒克山和布克河组晚泥盆世化石的发现及其地层归属[J]. 中国地质, 46(6): 1259-1269.
-
