Shale gas accumulation conditions and exploration prospects of Wufeng−Longmaxi Formation in Shixi Area, Northern Guizhou
-
摘要:
研究目的 文章旨在通过分析狮溪地区狮溪1井五峰组—龙马溪组页岩成藏要素，揭示黔北地区复杂构造区页岩气成藏条件，查明黔北地区五峰组—龙马溪组页岩气成藏潜力。
研究方法 本次研究基于黔北地区狮溪1井的系列钻井取心、测井曲线、地震资料、地化测试以及储层特征等综合实验分析，围绕“生—储—保”三个维度开展页岩气成藏综合研究。
研究结果 狮溪1井五峰组—龙马溪组富有机质页岩厚度约25 m，TOC含量分布在2.79%~4.77%，等效镜质体反射率为2.01%~2.59%，有机质类型以I型为主，具有良好的生气基础；富有机质页岩层段脆性矿物含量较高，平均值约为61.05%，具有较高的脆性；发育大量微纳米级孔隙，主要为有机质孔、无机—有机质复合孔，孔体积以及比表面积参数表现良好，为页岩气的赋存提供了良好的储集空间；残留向斜内部富有机质页岩段顶底板具有较好的封闭能力，三者纵向上形成良好的生储盖组合；狮溪1井东部与西部发育两条通天断裂，距离断层较远的同时，得益于断层较好的封闭性以及平缓的地层产状，狮溪1井因而具有良好的含气显示。
结论 黔北地区残留向斜内部五峰组—龙马溪组页岩同样具有页岩气高效、规模建产的油气地质条件，是下一步勘查与攻关研究的重点方向。该成果扩大了页岩气勘查范围，拓宽了四川盆地周缘页岩气勘探深度和广度，有望形成新的资源接替区。
Abstract:This paper is the result of oil and gas exploration engineering.
Objective The purpose of this paper is to reveal the shale gas accumulation conditions in the complex structural area and to identify the shale gas accumulation potential of Wufeng Formation−Longmaxi Formation in Northern Guizhou by analyzing the shale accumulation elements of Wufeng−Longmaxi Formation in Well SX 1.
Methods This paper focuses on the comprehensive study of shale gas accumulation from the three dimensions of "source, reservoir, and protection", based on the comprehensive experimental analysis of the series drilling coring, logging curves, seismic data, and geochemical testing and reservoir characteristics of Well SX−1.
Results The thickness of organic−rich shale in Wufeng−Longmaxi Formation of Well SX 1 is about 25 m, the TOC content is between 2.79% and 4.77%, and the equivalent vitrinite reflectance is about 2.01%−2.59%. The organic matter type is the primary type I, which has a good gas foundation. The content of brittle minerals in the organic−rich shale section is relatively high, with an average value of about 61.05%, indicating high brittleness. A large number of micro−nano pores are developed, mainly organic pores and inorganic−organic composite pores. The pore volume and specific surface area parameters are good, which provides a good reservoir space for the occurrence of shale gas. The roof and floor of the organic−rich shale section in the residual syncline have a good sealing ability. The three vertically form a good source−reservoir−cap assemblage. There are two large faults in the east and west of Well SX 1, but they are far from Well SX 1. At the same time, due to the good sealing of the faults and the gentle formation occurrence, Well SX 1 has a good gas−bearing display.
Conclusions In summary, the shale of Wufeng−Longmaxi Formation in the residual syncline in northern Guizhou also has oil and gas geological conditions with high efficiency and large−scale production of shale gas, which is the key direction of next exploration and research. The results expand the scope of shale gas exploration, broaden the depth and breadth of shale gas exploration around the Sichuan Basin, and are expected to form a new resource replacement area.
-
-
表 1 狮溪1井五峰组—龙马溪组页岩干酪根显微组分组成
Table 1. Microscopic composition of kerogen in Wufeng−Longmaxi Formation shale of Well SX1
编号 深度
/m腐泥组
/%壳质组/% 镜质组
/%惰质组/% 类型 腐泥无定形体 腐泥碎屑体 无结构镜质体 丝质体 TI 类型 SX-11 1334.24 53 43 0 4 0 93 Ⅰ SX-12 1336.81 83 15 0 2 0 97 Ⅰ SX-13 1338.92 39 58 0 1 2 94 Ⅰ SX-14 1340.27 30 68 0 2 0 97 Ⅰ SX-15 1340.64 45 53 0 1 0 98 Ⅰ SX-16 1341.49 26 72 0 2 0 97 Ⅰ SX-17 1343.36 60 37 0 2 1 95 Ⅰ SX-18 1344.96 37 61 0 1 1 96 Ⅰ SX-19 1347.75 63 33 0 3 1 93 Ⅰ SX-20 1349.27 63 34 0 1 2 94 Ⅰ
下载: 导出CSV
表 2 狮溪1井五峰组—龙马溪组页岩不同岩相页岩孔体积与比表面积统计
Table 2. Statistics of pore volume and specific surface area of shale with different lithofacies in Wufeng−Longmaxi Formation of Well SX 1
样品编号 层位 深度/m 岩相 孔体积/（10−3 mL/g） 比表面积/（m2/g） 微孔 中孔 宏孔 总孔体积 微孔 中孔 宏孔 总比表面积 1 龙三段 1293.12 黏土质页岩 2.20 6.40 0.76 9.36 5.96 2.24 0.02 8.23 2 龙三段 1297.02 黏土质页岩 2.32 6.58 0.77 9.67 6.31 2.25 0.09 8.64 3 龙三段 1301 黏土质页岩 2.53 6.96 0.90 10.39 6.58 2.27 0.03 8.88 4 龙二段 1305.57 混合质页岩 2.15 5.90 0.73 8.78 5.61 1.87 0.02 7.51 5 龙二段 1309.72 硅质页岩 3.48 10.13 1.20 14.82 9.80 3.69 0.04 13.53 6 龙二段 1317.36 硅质页岩 3.26 8.97 1.15 13.38 10.06 3.47 0.04 13.57 7 龙一段 1322.97 硅质页岩 3.05 8.36 1.03 12.43 10.16 3.38 0.04 13.58 8 龙一段 1333.69 硅质页岩 3.32 9.94 0.49 13.75 9.01 4.52 0.01 13.54 9 龙一段 1340.27 硅质页岩 2.96 8.86 0.44 12.26 9.04 4.53 0.02 13.59 10 五峰组 1347.75 硅质页岩 3.96 10.69 0.43 15.08 9.95 3.52 0.01 13.48
下载: 导出CSV
-
[1] Chen L, Jiang Z X, Liu K Y, Wang P F, Ji W M, Gao F L, Li P, Hu T, Zhang B, Huang H X. 2016. Effect of lithofacies on gas storage capacity of marine and continental shales in the Sichuan Basin, China[J]. Journal of Natural Gas Science & Engineering, 36: 773−785.
[2] Chen Shangbin, Zhu Yanming, Wang Hongyan, Liu Honglin, Wei Wei, Fang Junhua. 2012. Structure characteristics and accumulation significance of nanopores in Longmaxi shale gas reservoir in the southern Sichuan Basin[J]. Journal of China Coal Society, 37(3): 438−444 (in Chinese with English abstract).
[3] Chen Xu, Rong Jiayu, Zhou Zhiyi, Zhang Yuandong, Zhan Renbin, Liu Jianbo, Fan Junxuan. 2001. Central Guizhou uplift and Yichang uplift at the turn of Ordovician−Silurian in upper Yangtze Region[J]. Chinese Science Bulletin, (12): 1052−1056 (in Chinese).
[4] Dembicki H. 2009. Three common source rock evaluation errors made by geologists during prospect or play appraisals[J]. AAPG Bull, 93(3): 341−356. doi: 10.1306/10230808076
[5] Ding Wenlong, Li Chao, Li Chunyan, Xu Changchun, Jiu Kai, Zeng Weite. 2012. Main controlling factors of shale fracture development and their influence on gas bearing property[J]. Earth Science Frontiers, 19(2): 212−220 (in Chinese with English abstract).
[6] Du Wei, Peng Yongmin, Long Shengxiang, Nie Haikuan, Sun Chuanxiang, Talihar Erhaz. 2022. Geological characteristics of Shale in Wufeng−Longmaxi Formation of Bayu outcrop in Daozhen, northern Guizhou[J]. Reservoir Evaluation and Development, 12(1): 130−138 (in Chinese with English abstract).
[7] Fang Zhixiong, He Xipeng. 2016. Formation and evolution of normal pressure shale gas reservoir in Wulong Syncline Southeast Chongqing, China[J]. Oil and Gas Geology, 37(6): 819−827 (in Chinese with English abstract).
[8] Fu Jinglong, Ding Wenlong, Zeng Wei, He Jianhua, Wang Zhe. 2016. Influence of structure of Northwest Guizhou area on preservation of Lower Cambrian shale gas reservoirs[J]. Journal of Southwest Petroleum University (Science & Technology Edition), 38(5): 22−32 (in Chinese with English abstract).
[9] He Guisong, He Xipeng, Gao Yuqiao, Wan Jingya, Zhang Peixian, Danei Zhang, Gao Hequn. 2020. Enrichment model of normal−pressure shale gas in the Jinfo slope of the basin−margin transition zone in Southeast Chongqing[J]. Natural Gas Industry, 40(6): 50−60 (in Chinese with English abstract).
[10] He Xipeng, Gao Yuqiao, Tang Xianchun, Zhang Peixian, He Guisong. 2017. Analysis of main controlling factors of atmospheric pressure shale gas enrichment in southeast Chongqing[J]. Natural Gas Geoscience, 28(4): 654−664 (in Chinese with English abstract).
[11] He Xipeng, He Guisong, Gao Yuqiao, Zhang Peixian, Lu Shuangfang, Wan Jingya. 2018. Geological characteristics and enrichment laws of normal−pressure shale gas in the basin−margin transition zone of SE Chongqing[J]. Natural Gas Industry, 38(12): 1−14 (in Chinese with English abstract).
[12] Hu Dongfeng. 2019. Main controlling factors on normal pressure shale gas enrichments in Wufeng−Longmaxi Formations in synclines, southeastern Sichuan Basin[J]. Natural Gas Geoscience, 30(5): 605−615 (in Chinese with English abstract).
[13] Hu Zongquan, Du Wei, Liu Zhongbao. 2018. Coupling Mechanism of Shale Gas Source Storage and its Application[M]. Beijing: Geological Publishing House, 113−123(in Chinese).
[14] Jia Chengzao, Zheng Min, Zhang Yongfeng. 2012. Unconventional oil and gas resources and exploration and development prospects in China[J]. Petroleum Exploration and Development, 39(2): 129−136 (in Chinese with English abstract).
[15] Jiang Zhenxue, Li Xin, Wang Xingmeng, Wang Guozhen, Qiu Hengyuan, Zhu Deyu, Jiang Hongyang. 2021. Characteristic differences and controlling factors of pores in typical South China shale[J]. Oil and Gas Geology, 42(1): 41−53 (in Chinese with English abstract).
[16] Jiang Zhenxue, Song Yan, Tang Xianglu, Li Zhuo, Wang Xingmeng, Wang Guozhen, Xue Zixin, Li Xin, Zhang Kun, Chang Jiaqi, Qiu Hengyuan. 2020. Controlling factors of marine shale gas differential enrichment in southern China[J]. Petroleum Exploration and Development, 47(3): 617−628 (in Chinese with English abstract).
[17] Jin Zhijun, Bai Zhenrui, Gao Bo, Li Maowen. 2019. Has China ushered in the shale oil and gas revolution?[J]. Oil & Gas Geology, 40(3): 451−458 (in Chinese with English abstract).
[18] Li Shuangjian, Xiao Kaihua, Wo Yujin, Long Shengxiang, Cai Liguo. 2008. Controlling factors for the development of high−quality hydrocarbon source rocks in Ordovician−Lower sillionic in the southern marine phase[J]. Acta Sedimentologica Sinica, 26(5): 872−880 (in Chinese with English abstract).
[19] Li Xinjing, Hu Suyun, Cheng Keming. 2007. Suggestions from the development of fractured shale gas in North America[J]. Petroleum Exploration and Development, 34(4): 392−400 (in Chinese with English abstract).
[20] Li Y, Chen S J, Wang Y X, Su K M, He Q B, Qiu W, Xiao Z L. 2020. Relationships between hydrocarbon evolution and the geochemistry of solid bitumen in the Guanwushan Formation, NW Sichuan Basin[J]. Marine and Petroleum Geology, 43(1): 116−134.
[21] Liang Digang, Guo Tonglou, Chen Jianping, Bian Lizeng, Zhao Zhe. 2008. New progress on hydrocarbon generation and accumulation of Marine source rocks in Southern China (I): Distribution of four sets of regional Marine source rocks in Southern China[J]. Marine Origin Petroleum Geology, 13(2): 1−16 (in Chinese with English abstract).
[22] Liang Xing, Xu Zhengyu, Zhang Chao, Wang Weixu, Zhang Jiehui, Lu Huili, Zhang Lei, Zou Chen, Wang Gaocheng, Mei Jue, Rui Yun. 2020. Breakthrough of shallow shale gas exploration in Taiyang anticline area and its significance for resource development in Zhaotong, Yunnan province, China[J]. Petroleum Exploration and Development, 47(1): 11−18 (in Chinese with English abstract).
[23] Liang Zhikai, Li Zhuo, Jiang Zhenxue, Gao Fenglin, Zhang Yinghan, Xiao Lei, Yang Youdong, Hou Yufei, Wang Liwei. 2020. Characteristics of pore structure and fractal dimension in continental shale based on NMR experiments and SEM image analyses[J]. Journal of Earth Sciences and Environment, 42(3): 313−328 (in Chinese with English abstract).
[24] Long Pengyu, Zhang Jinchuan, Tang Xuan, Nie Haikuan, Liu Zhujiang, Han Shuangbiao, Zhu Liangliang. 2011. Developmental characteristics of mud shale cracks and its impact on shale gas exploration and development[J]. Natural Gas Geoscience, 22(3): 525−532 (in Chinese with English abstract).
[25] Loucks R G, Reed R M, Ruppel S C, Jarvie D M. 2009. Morphology, genesis, and distribution of nanometer−scale pores in siliceous mudstones of the Mississippian Barnett Shale[J]. Journal of Sedimentary Research, 79(12): 848−861.
[26] Ma Xinhua, Xie Jun. 2018. Progress and prospect of shale gas exploration and development in southern Sichuan[J]. Petroleum Exploration and Development, 45(1): 161−169 (in Chinese with English abstract).
[27] Nie Haikuan, He Faqi, Bao Shujing. 2011. The progress and prospects of shale gas exploration and exploitation in southern Sichuan Basin, NW China[J]. Natural Gas Industry, 31(11): 111−116, 131−132 (in Chinese with English abstract).
[28] Nie Haikuan, Jin Zhijun, Bian Ruikang, Du Wei. 2016. "Source−cap controlled accumulation" enrichment of shale gas in Upper Ordovician Wufeng Formation−Lower Silurian Longmaxi Formation, Sichuan Basin and its periphery[J]. Acta Petrolei Sinica, 37(5): 557−571 (in Chinese with English abstract).
[29] Nie Haikuan, Wang Hu, He Zhiliang, Wang Fengyue, Zhang Peixian, Peng Yongmin. 2019. Formation mechanism, distribution and exploration prospect of normal pressure shale gas reservoir: A case study of Wufeng Formation−Longmaxi Formation in Sichuan Basin and its periphery[J]. Acta Petrolei Sinica, 40(2): 131−143,164 (in Chinese with English abstract).
[30] Peters K E. 1986. Guidelines for evaluating petroleum source rock using programmed pyrolysis[J]. AAPG Bulletin, 70(4): 318−329
[31] Peters K E, Cassa M R. 1994. Applied source rock geochemistry. In: In Magoon L B, Dow W G (eds.), The Petroleum System−From Source to Trap[J]. American Association of Petroleum Geologists Memoir, 60(8): 93−120.
[32] Powley D E. 1990. Pressures and hydrogeology in petroleum basins[J]. Earth−Science Reviews, 29(1): 215−226.
[33] Shao X D, Chen S J, Lei J J, Bai Y J, Zhou K, Liu Y, Zhu J, Han M M. 2021. Inversion of tight oil origin by geochemical characteristics: A case study of central Northern Shaanxi Slope, Ordos Basin[J]. Arabian Journal of Geosciences, 14(8): 698. doi: 10.1007/s12517-021-07045-y
[34] Tang Liangjie, Guo Tonglou, Tian Haiqin, Jin Wenzheng, Li Rufeng, Wan Guimei, Dong Li, Wang Pengwan. 2008. Multi−stage tectonic evolution, differential deformation and oil and gas preservation conditions in central Qianzhong[J]. Acta Geologica Sinica, 82(3): 298−307 (in Chinese with English abstract).
[35] Wang Guozhen, Jiang Zhenxue, Tang Xianglu, He Shijie, Wang Yuchao, Chang Jiaqi. 2023. Critical pore size and transport capacity of different transport types of shale gas in Longmaxi Formation, Jiaoshiba area, Sichuan Basin[J]. Acta Geologica Sinica, 97(1): 210−220 (in Chinese with English abstract).
[36] Wang Pengwan, Zou Chen, Li Xianjing, Jiang Liwei, Li Junjun, Mei Jue, Zhang Chao, Li Qingfei. 2018. Main geological controlling factors of shale gas enrichment and high yield in Zhaotong demonstration area[J]. Acta Petrolei Sinica, 39(7): 744−753 (in Chinese with English abstract).
[37] Wang Ruyue, Hu Zongquan, Long Shengxiang, Du Wei, Wu Jing, Wu Zhonghu, Nie Haikuan, Wang Pengwei, Sun Chuanxiang, Zhao Jianhua. 2022. Reservoir characteristics and evolution mechanisms of the Upper Ordovician Wufeng−Lower Silurian Longmaxi shale, Sichuan Basin[J]. Oil and Gas Geology, 43(2): 353−364 (in Chinese with English abstract).
[38] Wang Ye, Qiu Nansheng, Yang Yunfeng, Rui Xiaoqing, Zhou Yuanyuan, Fang Guangjian, Wu Hang, Shen Baojian, Cheng Lijun, Tenger. 2019. Thermal maturity of Wufeng−Longmaxi shale in Sichuan Bain[J]. Earth Science, 44(3): 953−971 (in Chinese with English abstract).
[39] Wang Yuman, Li Xinjing, Chen Bo, Wu Wei, Dong Dazhong, Zhang Jian, Han Jing, Ma Jie, Dai Bing, Wang Hao, Jiang Shan. 2018. Lower limit of thermal maturity for the carbonization of organic matter in marine shale and its exploration risk[J]. Petroleum Exploration and Development, 45(3): 385−395 (in Chinese with English abstract).
[40] Wei Xiangfeng, Liu Ruobing, Zhang Tingshan, Liang Xing. 2013. Micro−pores structure characteristics and development control factors of shale gas reservoir: A case of Longmaxi Formation in XX area of southern Sichuan and northern Guizhou[J]. Natural Gas Geoscience, 24(5): 1048−1059 (in Chinese with English abstract).
[41] Yan Detian, Wang Qingchen, Chen Daizhao, Wang Jianguo, Wang Zhuozhuo. 2008. Development environment and controlling factors of Upper Ordovician−Lower Silurian source rocks in Yangtze and its surrounding areas[J]. Acta Geologica Sinica, 82(3): 322−327 (in Chinese with English abstract).
[42] Yang Changqing, Yue Quanling, Cao Bo. 2008. Prospect and direction of Lower Paleozoic oil and gas exploration in the uplift of Qianzhong and its surrounding area[J]. Geoscience, 22(4): 558−566 (in Chinese with English abstract).
[43] Zhai Gangyi, Bao Shujing, Pang Fei, Ren Shumai, Chen Ke, Wang Yufang, Zhou Zhi, Wang Shengjian. 2017. Reservoir−forming pattern “of four−storey” hydrocarbon accumulation in Anchang syncline of northern Guizhou Province[J]. Geology in China, 44(1): 1−12 (in Chinese with English abstract).
[44] Zhang Chunming, Zhang Weisheng, Guo Yinghai. 2012. Sedimentary environment and its influence on source rocks of Longmaxi Formation in southeastern Sichuan and northern Guizhou area[J]. Earth Science Frontiers, 19(1): 136−145 (in Chinese with English abstract).
[45] Zhang Shuichang, Liang Digang, Zhang Dajiang. 2002. Evaluation criteria for organic matter abundance of Paleozoic source rocks[J]. Petroleum Exploration and Development, 29(2): 8−12 (in Chinese with English abstract).
[46] Zou Caineng, Dong Dazhong, Wang Shejiao, Li Jianzhong, Li Xinjing, Wang Yuman, Li Denghua, Cheng Keming. 2010. Formation mechanism, geological characteristics and resource potential of shale gas in China[J]. Petroleum Exploration and Development, 37(6): 641−653 (in Chinese with English abstract). doi: 10.1016/S1876-3804(11)60001-3
[47] Zou Caineng, Zhu Rukai, Wu Songtao, Yang Zhi, Tao Shizhen, Yuan Xuanjun, Hou Lianhua, Yang Hua, Xu Chunchun, Li Denghua, Bai Bin, Wang Lan. 2012. Types, characteristics, mechanisms and prospects of conventional and unconventional oil and gas aggregation: A case study of tight oil and tight gas in China[J]. Acta Petrolei Sinica, 33(2): 173−187 (in Chinese with English abstract). doi: 10.1038/aps.2011.203
[48] 陈尚斌, 朱炎铭, 王红岩, 刘洪林, 魏伟, 方俊华. 2012. 川南龙马溪组页岩气储层纳米孔隙结构特征及其成藏意义[J]. 煤炭学报, 37(3): 438−444.
[49] 陈旭, 戎嘉余, 周志毅, 张元动, 詹仁斌, 刘建波, 樊隽轩. 2001. 上扬子区奥陶—志留纪之交的黔中隆起和宜昌上升[J]. 科学通报, 46(12): 1052−1056. doi: 10.3321/j.issn:0023-074X.2001.12.021
[50] 丁文龙, 李超, 李春燕, 许长春, 久凯, 曾维特. 2012. 页岩裂缝发育主控因素及其对含气性的影响[J]. 地学前缘, 19(2): 212−220.
[51] 杜伟, 彭勇民, 龙胜祥, 聂海宽, 孙川翔, 塔力哈尔·叶尔哈孜. 2022. 黔北道真巴渔剖面五峰组—龙马溪组页岩地质特征[J]. 油气藏评价与开发, 12(1): 130−138.
[52] 方志雄, 何希鹏. 2016. 渝东南武隆向斜常压页岩气形成与演化[J]. 石油与天然气地质, 37(6): 819−827. doi: 10.11743/ogg20160603
[53] 付景龙, 丁文龙, 曾维特, 何建华, 王哲. 2016. 黔西北地区构造对下寒武统页岩气藏保存的影响[J]. 西南石油大学学报(自然科学版), 38(5): 22−32.
[54] 何贵松, 何希鹏, 高玉巧, 万静雅, 张培先, 张勇, 高和群. 2020. 渝东南盆缘转换带金佛斜坡常压页岩气富集模式[J]. 天然气工业, 40(6): 50−60.
[55] 何希鹏, 高玉巧, 唐显春, 张培先, 何贵松. 2017. 渝东南地区常压页岩气富集主控因素分析[J]. 天然气地球科学, 28(4): 654−664.
[56] 何希鹏, 何贵松, 高玉巧, 张培先, 卢双舫, 万静雅. 2018. 渝东南盆缘转换带常压页岩气地质特征及富集高产规律[J]. 天然气工业, 38(12): 1−14. doi: 10.3787/j.issn.1000-0976.2018.12.001
[57] 胡东风. 2019. 四川盆地东南缘向斜构造五峰组−龙马溪组常压页岩气富集主控因素[J]. 天然气地球科学, 30(5): 605−615. doi: 10.11764/j.issn.1672-1926.2019.01.013
[58] 胡宗全, 杜伟, 刘忠宝. 2018. 页岩气源储耦合机理及其应用[M]. 北京: 地质出版社, 113−123.
[59] 贾承造, 郑民, 张永峰. 2012. 中国非常规油气资源与勘探开发前景[J]. 石油勘探与开发, 39(2): 129−136.
[60] 姜振学, 李鑫, 王幸蒙, 王国臻, 仇恒远, 朱德宇, 姜鸿阳. 2021. 中国南方典型页岩孔隙特征差异及其控制因素[J]. 石油与天然气地质, 42(1): 41−53. doi: 10.11743/ogg20210104
[61] 姜振学, 宋岩, 唐相路, 李卓, 王幸蒙, 王国臻, 薛子鑫, 李鑫, 张昆, 常佳琦, 仇恒远. 2020. 中国南方海相页岩气差异富集的控制因素[J]. 石油勘探与开发, 47(3): 617−628. doi: 10.11698/PED.2020.03.18
[62] 金之钧, 白振瑞, 高波, 黎茂稳. 2019. 中国迎来页岩油气革命了吗?[J]. 石油与天然气地质, 40(3): 451−458. doi: 10.11743/ogg20190301
[63] 李双建, 肖开华, 沃玉进, 龙胜祥, 黎立国. 2008. 南方海相上奥陶统−下志留统优质烃源岩发育的控制因素[J]. 沉积学报, 26(5): 872−888
[64] 李新景, 胡素云, 程克明. 2007. 北美裂缝性页岩气勘探开发的启示[J]. 石油勘探与开发, 34(4): 392−400. doi: 10.3321/j.issn:1000-0747.2007.04.002
[65] 梁狄刚, 郭彤楼, 陈建平, 边立曾, 赵喆. 2008. 中国南方海相生烃成藏研究的若干新进展(一): 南方四套区域性海相烃源岩的分布[J]. 海相油气地质, 13(2): 1−16. doi: 10.3969/j.issn.1672-9854.2008.02.001
[66] 梁兴, 徐政语, 张朝, 王维旭, 张介辉, 鲁慧丽, 张磊, 邹辰, 王高成, 梅珏, 芮昀. 2020. 昭通太阳背斜区浅层页岩气勘探突破及其资源开发意义[J]. 石油勘探与开发, 47(1): 11−18. doi: 10.11698/PED.2020.01.02
[67] 梁志凯, 李卓, 姜振学, 高凤琳, 张瀛涵, 肖磊, 杨有东, 侯煜菲, 王立伟. 2020. 基于NMR和SEM技术研究陆相页岩孔隙结构与分形维数特征—以松辽盆地长岭断陷沙河子组页岩为例[J]. 地球科学与环境学报, 42(3): 313−328.
[68] 龙鹏宇, 张金川, 唐玄, 聂海宽, 刘珠江, 韩双彪, 朱亮亮. 2011. 泥页岩裂缝发育特征及其对页岩气勘探和开发的影响[J]. 天然气地球科学, 22(3): 525−532.
[69] 马新华, 谢军. 2018. 川南地区页岩气勘探开发进展及发展前景[J]. 石油勘探与开发, 45(1): 161−169. doi: 10.11698/PED.2018.01.18
[70] 聂海宽, 何发岐, 包书景. 2011. 中国页岩气地质特殊性及其勘探对策[J]. 天然气工业, 31(11): 111−116,131−132. doi: 10.3787/j.issn.1000-0976.2011.11.028
[71] 聂海宽, 金之钧, 边瑞康, 杜伟. 2016. 四川盆地及其周缘上奥陶统五峰组—下志留统龙马溪组页岩气“源−盖控藏”富集[J]. 石油学报, 37(5): 557−571. doi: 10.7623/syxb201605001
[72] 聂海宽, 汪虎, 何治亮, 王濡岳, 张培先, 彭勇民. 2019. 常压页岩气形成机制、分布规律及勘探前景—以四川盆地及其周缘五峰组—龙马溪组为例[J]. 石油学报, 40(2): 131−143,164. doi: 10.7623/syxb201902001
[73] 汤良杰, 郭彤楼, 田海芹, 金文正, 李儒峰, 万桂梅, 董立, 王鹏万. 2008. 黔中地区多期构造演化、差异变形与油气保存条件[J]. 地质学报, 82(3): 289−307. doi: 10.3321/j.issn:0001-5717.2008.03.001
[74] 王国臻, 姜振学, 唐相路, 贺世杰, 王昱超, 常佳琦. 2023. 四川盆地焦石坝地区龙马溪组页岩气不同传输类型的临界孔径与传输能力[J]. 地质学报, 97(1): 210−220. doi: 10.3969/j.issn.0001-5717.2023.01.014
[75] 王鹏万, 邹辰, 李娴静, 蒋立伟, 李君山, 梅珏, 张朝, 李庆飞. 2018. 昭通示范区页岩气富集高产的地质主控因素[J]. 石油学报, 39(7): 744−753. doi: 10.7623/syxb201807002
[76] 王濡岳, 胡宗全, 龙胜祥, 杜伟, 吴靖, 邬忠虎, 聂海宽, 王鹏威, 孙川翔, 赵建华. 2022. 四川盆地上奥陶统五峰组—下志留统龙马溪组页岩储层特征与演化机制[J]. 石油与天然气地质, 43(2): 353−364. doi: 10.11743/ogg20220209
[77] 王晔, 邱楠生, 仰云峰, 芮晓庆, 周圆圆, 方光建, 吴航, 申宝剑, 程礼军, 腾格尔. 2019. 四川盆地五峰—龙马溪组页岩成熟度研究[J]. 地球科学, 44(3): 953−971.
[78] 王玉满, 李新景, 陈波, 吴伟, 董大忠, 张鉴, 韩京, 马杰, 代兵, 王浩, 蒋珊. 2018. 海相页岩有机质炭化的热成熟度下限及勘探风险[J]. 石油勘探与开发, 45(3): 385−395. doi: 10.11698/PED.2018.03.03
[79] 魏祥峰, 刘若冰, 张廷山, 梁兴. 2013. 页岩气储层微观孔隙结构特征及发育控制因素—以川南—黔北XX地区龙马溪组为例[J]. 天然气地球科学, 24(5): 1048−1059.
[80] 严德天, 王清晨, 陈代钊, 汪建国, 王卓卓. 2008. 扬子及周缘地区上奥陶统—下志留统烃源岩发育环境及其控制因素[J]. 地质学报, 82(3): 322−327 doi: 10.3321/j.issn:0001-5717.2008.03.005
[81] 杨长清, 岳全玲, 曹波. 2008. 黔中隆起及其周缘地区下古生界油气勘探前景与方向[J]. 现代地质, 22(4): 558−566. doi: 10.3969/j.issn.1000-8527.2008.04.010
[82] 翟刚毅, 包书景, 庞飞, 任收麦, 陈科, 王玉芳, 周志, 王胜建. 2017. 贵州遵义地区安场向斜“四层楼”页岩油气成藏模式研究[J]. 中国地质, 44(1): 1−12. doi: 10.12029/gc20170101
[83] 张春明, 张维生, 郭英海. 2012. 川东南—黔北地区龙马溪组沉积环境及对烃源岩的影响[J]. 地学前缘, 19(1): 136−145.
[84] 张水昌, 梁狄刚, 张大江. 2002. 关于古生界烃源岩有机质丰度的评价标准[J]. 石油勘探与开发, 29(2): 8−12. doi: 10.3321/j.issn:1000-0747.2002.02.002
[85] 邹才能, 董大忠, 王社教, 李建忠, 李新景, 王玉满, 李登华, 程克明. 2010. 中国页岩气形成机理、地质特征及资源潜力[J]. 石油勘探与开发, 37(6): 641−653.
[86] 邹才能, 朱如凯, 吴松涛, 杨智, 陶士振, 袁选俊, 侯连华, 杨华, 徐春春, 李登华, 白斌, 王岚. 2012. 常规与非常规油气聚集类型、特征、机理及展望—以中国致密油和致密气为例[J]. 石油学报, 33(2): 173−187. doi: 10.7623/syxb201202001
-
