Methods of ASTER remote sensing data used in extracting mineralization and alteration information in the Hutouya mining area of the Qimantag metallogenic belt, Qinghai Province
-
摘要:
以ASTER遥感影像为数据源，对青海祁漫塔格成矿带虎头崖矿区，应用成像光谱法和主成分分析法对矿区矿化蚀变异常信息进行提取分析。成像光谱方法利用最小噪音分量（MNF）变换、像元纯度指数（PPI），n维可视化（n-Dimensional Visualization）端元识别，并进行混合谐调匹配滤波（MTMF），最终得到矿区的矿物信息分布图。而主成分分析法则选择ASTER1、2、3、4波段提取铁染异常信息，1、3、4、5波段提取矽卡岩化蚀变异常信息，1、3、4、（5+6）/2波段提取蒙脱石、伊利石与绢云母等矿物的蚀变异常信息，1、3、4、8波段提取方解石、黑云母、绿泥石等矿物的蚀变异常信息。利用野外实地踏勘确定的矿床、矿（化）点，在ArcGIS10.1软件中对遥感提取蚀变异常信息进行验证显示，二者吻合效果良好，表明提取结果与数据处理方法较可靠，对于扩大找矿规模和发现矿化富集地段具有重要的指导意义。
Abstract:Using ASTER remote sensing images as the data source, the extraction of mineralization and alteration anomaly in the Hutouya mining area of the Qimantag metallogenic belt in Qinghai Province is studied through two methods. One method is using the minimum noise component (MNF) transform, pixel purity index (PPI), n-Dimensional Visualization to do the end element recognition and mixture tuned matched filtering (MTMF), in order to obtain the mineral distribution map of the mining area. The other is principal component analysis, through which ferric contamination anomaly is extracted in ASTER1, 2, 3, 4 band, skarnization alteration anomaly in 1, 3, 4, 5 band, montmorillonite, illite and sericite in 3, 4, (5+6)/2 band and calcite, biomica, chlorite and other minerals in 1, 3, 4, 8 band. The results of remote sensing extraction of alteration anomaly verified by ArcGIS10.1 software are in good consistency with the mineral deposits and mineralization points determined by the field survey, indicating that the extraction results and the data processing method are reliable, which is of great guiding significance for the expansion of the prospecting scale and the discovery of mineralization enrichment areas.
-
-
表 1 各波段平均值和特征值
Table 1. Average value and eigenvalue of each band
波段名称 平均值 特征值 Band 1 21.173028 28.297260 Band 2 7.034879 9.762023 Band 3 6.628618 4.759365 Band 4 6.013828 2.901527 Band 5 4.625094 2.367740 Band 6 3.821772 1.830600
下载: 导出CSV
表 2 虎头崖矿区ASTER1、3、4、(5+6)/2主分量变换统计值
Table 2. Statistical values of ASTER1, 3, 4, (5 + 6)/2 principal component transformation in the Hutouya mining area
ASTER1 ASTER3 ASTER4 ASTER(5+6)/2 PC1 0.78201 0.61025 0.12076 0.03833 PC2 -0.62199 0.75182 0.21406 0.04560 PC3 -0.03748 0.24894 -0.91790 -0.30674 PC4 -0.01380 0.01967 -0.31155 0.94993
下载: 导出CSV
表 3 虎头崖矿区ASTER1、3、4、8主分量变换统计值
Table 3. Statistical values of ASTER1, 3, 4, 8 principal component transformation in the Hutouya mining area
ASTER1 ASTER3 ASTER4 ASTER8 PC1 0.78225 0.61043 0.12078 0.02951 PC2 -0.62173 0.75383 0.21140 0.02240 PC3 -0.03460 0.24181 -0.93799 -0.24599 PC4 -0.01824 0.02538 -0.24679 0.96856.
下载: 导出CSV
表 4 虎头崖矿区ASTER1、2、3、4主分量变换统计值
Table 4. Statistical values of ASTER1, 2, 3, 4 principal component transformation in the Hutouya mining area
ASTER1 ASTER2 ASTER3 ASTER4 PC1 0.61068 0.62611 0.47567 0.09382 PC2 0.53342 0.12541 -0.80518 -0.22677 PC3 0.45937 -0.56826 0.02367 0.68227 PC4 0.36264 -0.51898 0.35338 -0.68868
下载: 导出CSV
表 5 虎头崖矿区ASTER1、3、4、5主分量变换统计值
Table 5. Statistical values of ASTER1, 3, 4, 5 principal component transformation in the Hutouya mining area
ASTER1 ASTER3 ASTER4 ASTER5 PC1 0.78211 0.61033 0.12077 0.03498 PC2 -0.62190 0.75288 0.21263 0.03464 PC3 -0.03584 0.24549 -0.92974 -0.27209 PC4 -0.01620 0.02015 -0.27530 0.96101
下载: 导出CSV
表 6 虎头崖矿区矿化点坐标(因涉密故总分用*号代替)
Table 6. Coordinates of the mineralization points of the Hutouya mining area (The * sign is used instead due to confidentiality reasons)
点号 X Y 矿化类型 HT126 E91°38′*″ N37°5′*″ 褐铁矿化、黄铁矿化 HT145 E91°38′*″ N37°4′*″ 铜矿化、磁铁矿化 HT137 E91°37′*″ N37°6′*″ 黄铜矿化 HT25 E91°36′*″ N37°5′*″ 铜铅锌矿化、锡矿化、钨锑矿化 HT27 E91°36′*″ N37°5′*″ 黄铁矿化、黄铜矿化、方铅矿化、铅锌矿化 HT48 E91°36′*″ N37°4′*″ 褐铁矿化、黄铁矿化、磁铁矿化 HT23 E91°37′*″ N37°5′*″ 黄铜矿化、孔雀石化 DY06 E91°36′*″ N37°5′*″ 黄铁矿化、褐铁矿化 DT108 E91°36′*″ N37°4′*″ 矽卡岩化、孔雀石化 HT163 E91°36′*″ N37°4′*″ 闪锌矿化、黄铜矿化 HT189 E91°34′*″ N37°4′*″ 石英斑岩、黄铜矿化、黄铁矿化 HT193 E91°34′*″ N37°4′*″ 黄铁矿化、黄铜矿化
下载: 导出CSV
-
CHEN J, ZHOU P, 2015. Extraction of linear structure and alteration information using ASTER data and prospecting prognosis for Tudun, Hami[J]. Journal of Geomechanics, 21(2):209-217. (in Chinese with English abstract) http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dzlxxb201502011
CHEN J M, SUN W D, YAN B K, et al., 2009. The application and research of the anomaly extraction process base on the ASTER multi-spectral remote sensing in Tianhu iron ore mine[J]. Xinjiang Geology, 27(4):368-372. (in Chinese with English abstract) http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=xjdz200904014
CHEN Y, HE Z W, DENG H, et al., 2014. Identification and extraction of mineralized alteration information by ASTER remote sensing data[J]. Journal of Guilin University of Technology, 34(1):51-57. (in Chinese with English abstract) http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=glgxy201401008
GAO H, ZHANG J L, OUYANG Y, et al., 2013. Lithological classification based on ASTER data by minimum noise fraction transform[J]. Journal of Guilin University of Technology, 33(2):259-265. (in Chinese with English abstract) http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=glgxy201302010
GAO W L, ZHANG X J, WANG Z G, et al., 2010. Extraction of lithologic information from the east Kulun orogenic belt using ASTER remote sensing image[J]. Journal of Geomechanics, 16(1):59-69. (in Chinese with English abstract) http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dzlxxb201001008
GAO X F, XIAO P X, XIE C R, et al., 2010. Discussion on tectonic-magmatic process and mineralization in the Qimantage Region[J]. Northwestern Geology, 43(4):119-123. (in Chinese with English abstract) http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=xbdz201004014
GENG X X, YANG J M, ZHANG Y J, et al., 2008. The application of ASTER remote sensing data for extraction of alteration anomalies information in shallow overburden area——a case study of the Baoguto porphyry copper deposit intrusion in western Junggar, Xinjiang[J]. Geological Review, 54(2):184-191. (in Chinese with English abstract) http://en.cnki.com.cn/Article_en/CJFDTOTAL-DZLP200802006.htm
GU P Y, CHEN R M, CHA X F, et al., 2016. Exploration and practice of 1:50000 geological mapping techniques for alpine-gorge area:a case study in Beishan Area of Wushi, Xinjiang[J]. Journal of Geomechanics, 22(4):837-855. (in Chinese with English abstract) http://www.en.cnki.com.cn/Article_en/CJFDTotal-DZLX201604004.htm
HU X H, ZHU G C, LIU H, et al., 2011. Characteristics and mineralization of the Hutouya polymetallic deposit in the Qimantage Metallogenetic Belt[J]. Geology and Prospecting, 47(2):216-221. (in Chinese with English abstract) http://d.old.wanfangdata.com.cn/Periodical/dzykt201102011
LI K, GAO Y B, QIAN B, et al., 2015. Geochronology, geochemical characteristics and Hf isotopic compositions of granite in the Hutouya deposit, Qimantag, East Kunlune[J]. Geology in China, 42(3):630-645. (in Chinese with English abstract) http://en.cnki.com.cn/Article_en/CJFDTotal-DIZI201503017.htm
LI R S, JI W H, YANG Y C, et al., 2008. Geology of Kunlun Mountains and adjacent areas[M]. Beijing:Geological Publishing House:1-400. (in Chinese)
LI Z M, XUE C J, WANG X H, et al., 2007. Features of regional mineralization and analysis of the exploration development in the eastern Kunlun Mountains[J]. Geological Review, 53(5):708-718. (in Chinese with English abstract) http://d.old.wanfangdata.com.cn/Periodical/OA000004811
LIU W, YANG X K, WANG S L, et al., 2014. Characteristics of ore-controlling structures of the Hutouya orefield in the Qimantage metallogenic belt, Qinghai province[J]. Geology in China, 41(1):222-234. (in Chinese with English abstract) http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=zgdizhi201401018
LIU Z, ZHOU P, 2017. Information extraction of alteration of Huaniushan region, Gansu province based on ASTER data[J]. Journal of North University of China (Natural Science Edition), 38(2):124-132, 139. (in Chinese with English abstract) http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=hbgxyxb201702006
MA S C, FENG C Y, ZHANG D J, et al., 2013. Alteration and mineralization zoning of Hutouya polymetallic deposit in Qimantag area, Qinghai province[J]. Mineral Deposits, 32(1):109-121. (in Chinese with English abstract) http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=kcdz201301007
MAO X C, LIU W C, DU J G, et al., 2005. Comparison between ETM+ and ASTER data for extraction of alteration information:a case study of Fenghuangshan Orefield, Tongling, Anhui province[J]. Geoscience, 19(2):309-314. (in Chinese with English abstract) http://en.cnki.com.cn/Article_en/CJFDTOTAL-XDDZ20050200L.htm
POUR A B, HASHIM M, 2012. The application of ASTER remote sensing data to porphyry copper and epithermal gold deposits[J]. Ore Geology Reviews, 44:1-9. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=781743811e925019f3090bf4d69edba5
SU S, 2011. Study of mineralization law and analysis of economic value of Hutouya lead-zinc mine in the Qimatage Mine Margine of East Kulun[D]. Beijing: China University of Geosciences (Beijing): 1-127. (in Chinese with English abstract)
https://kns.cnki.net/KCMS/detail/detail.aspx?dbcode=CDFD&dbname=CDFDLAST2015&filename=1011077457.nh&v=MjE2MTJxSkViUElSOGVYMUx1eFlTN0RoMVQzcVRyV00xRnJDVVI3cWZZT2RuRnlIa1ZyckpWRjI2SDdPL0dkWEo= WU Y Z, QIAO G B, CHEN D H, 2011. A preliminary study on relationship between tectonic magmatism and mineralization in Qimantage Area, eastern Kunlun Mountains[J]. Geotectonica et Metallogenia, 35(2):232-241. (in Chinese with English abstract) http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=ddgzyckx201102008
YAN S X, WU X B, ZHOU C X, et al., 2011. Remote sensing and spectral geology and their applications to mineral exploration[J]. Advances in Earth Science, 26(1):13-29. (in Chinese with English abstract) http://d.old.wanfangdata.com.cn/Periodical/dqkxjz201101002
YANG C B, JIANG Q G, ZHU Q, et al., 2009. Altered minerals discriminating using ASTER Data at low vegetation cover area[J]. Geology and Exploration, 45(6):761-766. (in Chinese with English abstract) http://d.old.wanfangdata.com.cn/Periodical/dzykt200906019
YANG R H, LI Z Z, CHEN X F, 2012. Information extraction of typical alteration mineral assemblage in porphyry copper using ASTER satellite data, Arequipa province of South Peru[J]. Journal of Geo-information Science, 14(3):411-418. (in Chinese with English abstract) http://d.old.wanfangdata.com.cn/Periodical/dqxxkx201203019
YANG X K, HAN K, FAN Y, et al., 2016. Tectonic background and magma-thermodynamic structural features of typical orefields in Qimantage Ore Belt, Eastern Kunlun[J]. Geotectonica et Metallogenia, 40(2):201-212. (in Chinese with English abstract) http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=ddgzyckx201602002
YAO F J, ZHANG Y J, YANG J M, et al., 2012. Application of ASTER remote sensing data to extraction of alterration zoning information from Dexing porphyry copper deposit[J]. Mineral Deposits, 31(4):881-890. (in Chinese with English abstract) http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=kcdz201204016
YI L W, LU A H, GU X P, et al., 2019. Evaluation of the methods for quantitative determination of Fe2+/Fe3+ ratios of magnetite from Qimantag metallogenic belts[J]. Journal of Geomechanics, 25(S1):1-4. (in Chinese with English abstract) https://kns.cnki.net/KCMS/detail/detail.aspx?dbcode=CJFQ&dbname=CJFDLAST2019&filename=DZLX2019S1001&v=MDUwNjg3RGgxVDNxVHJXTTFGckNVUjdxZllPZG5GeUhrVnJ2QklUZkhkckc0SDlpdnJvOUZaWVI4ZVgxTHV4WVM=
ZHANG A K, MO X X, LI Y P, et al., 2010. New progress and significance in the Qimantage metallogenic belt prospecting, western Qinghai, China[J]. Geological Bulletin of China, 29(7):1062-1074. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=zgqydz201007013
ZHANG D M, ZHANG A K, QU G J, et al., 2020. Metallogenic and prospecting model of Kaerqueka Iron-copper polymetallic deposit in western segment of eastern Kunlun[J]. Northwestern Geology, 53(1):91-106. (in Chinese with English abstract) http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=xbdz202001009
ZHANG X F, LI Z M, CHEN B, et al., 2012. The contribution of the Tanjianshan group stratum to Skarnization in Qimantage region, Qinghai province[J]. Northwestern Geology, 45(1):40-47. (in Chinese with English abstract) http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=xbdz201201006
ZHANG Y J, YANG J M, YAO F J, 2006. The extraction of OHA from different types of deposits by using ASTER data[J]. Mineral Deposits, 25(S1):507-510. (in Chinese with English abstract)
ZHANG Y J, YAO F J, 2009. Application study of multi-spectral ASTER data for determination of ETM remote sensing anomaly property:Taking Wulonggou region of eastern Kunlun mountain range as example[J]. Acta Petrologica Sinica, 25(4):963-970. (in Chinese with English abstract) http://en.cnki.com.cn/Article_en/CJFDTOTAL-YSXB200904020.htm
ZHOU D, NI Z Y, YANG Z Y, 2018. Object-oriented remote sensing information extraction method for rocky desertification in Karst area-a case study of Dafang county, Guizhou[J]. Journal of Geomechanics, 24(2):263-273. (in Chinese with English abstract) http://d.old.wanfangdata.com.cn/Periodical/dzlxxb201802014
陈建明, 孙卫东, 闫柏琨, 等, 2009. Aster多光谱遥感异常提取在新疆天湖铁矿中的应用[J].新疆地质, 27(4):368-372. http://d.old.wanfangdata.com.cn/Periodical/xjdz200904014
陈菁, 周萍, 2015.基于ASTER的哈密土墩地区构造及蚀变信息提取与找矿预测[J].地质力学学报, 21(2):209-217. https://journal.geomech.ac.cn/ch/reader/view_abstract.aspx?flag=1&file_no=20150211&journal_id=dzlxxb
陈晔, 何政伟, 邓辉, 等, 2014.利用ASTER影像识别和提取矿化蚀变信息[J].桂林理工大学学报, 34(1):51-57. http://d.old.wanfangdata.com.cn/Periodical/glgxy201401008
高慧, 张建龙, 欧阳渊, 等, 2013.基于最小噪声分量变换的ASTER遥感数据岩性分类[J].桂林理工大学学报, 33(2):259-265. http://d.old.wanfangdata.com.cn/Periodical/glgxy201302010
高万里, 张绪教, 王志刚, 等, 2010.基于ASTER遥感图像的东昆仑造山带岩性信息提取研究[J].地质力学学报, 16(1):59-69. https://journal.geomech.ac.cn/ch/reader/view_abstract.aspx?flag=1&file_no=20100108&journal_id=dzlxxb
高晓峰, 校培喜, 谢从瑞, 等, 2010.祁漫塔格地区构造-岩浆作用与成矿[J].西北地质, 43(4):119-123. http://d.old.wanfangdata.com.cn/Periodical/ddgzyckx201102008
耿新霞, 杨建民, 张玉君, 等, 2008. ASTER数据在浅覆盖区蚀变遥感异常信息提取中的应用:以新疆西准噶尔包古图斑岩铜矿岩体为例[J].地质论评, 54(2):184-191. http://d.old.wanfangdata.com.cn/Periodical/dzlp200802005
辜平阳, 陈瑞明, 查显峰, 等, 2016.高山峡谷区1:50000地质填图技术方法探索与实践:以新疆乌什北山为例[J].地质力学学报, 22(4):837-855. https://journal.geomech.ac.cn/ch/reader/view_abstract.aspx?flag=1&file_no=20160404&journal_id=dzlxxb
胡杏花, 朱谷昌, 刘欢, 等, 2011.祁漫塔格矿带虎头崖多金属矿矿床特征和成矿作用分析[J].地质与勘探, 47(2):216-221. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dzykt201102011
李侃, 高永宝, 钱兵, 等, 2015.东昆仑祁漫塔格虎头崖铅锌多金属矿区花岗岩年代学、地球化学及Hf同位素特征[J].中国地质, 42(3):630-645. http://d.old.wanfangdata.com.cn/Periodical/zgdizhi201503017
李荣社, 计文化, 杨永成, 等, 2008.昆仑山及邻区地质[M].北京:地质出版社:1-400.
李智明, 薛春纪, 王晓虎, 等, 2007.东昆仑区域成矿特征及有关找矿突破问题分析[J].地质评论, 53(5):708-718. http://d.old.wanfangdata.com.cn/Periodical/dzlp200705017
刘渭, 杨兴科, 王守良, 等, 2014.青海省祁漫塔格矿带虎头崖矿田构造控矿特征[J].中国地质, 41(1):222-234. http://d.old.wanfangdata.com.cn/Periodical/zgdizhi201401018
刘知, 周萍, 2017.基于ASTER数据的甘肃花牛山地区蚀变信息提取[J].中北大学学报(自然科学版), 38(2):124-132, 139. http://d.old.wanfangdata.com.cn/Periodical/hbgxyxb201702006
马圣钞, 丰成友, 张道俊, 等, 2013.青海虎头崖矽卡岩型多金属矿床蚀变矿化分带特征研究[J].矿床地质, 32(1):109-121. http://d.old.wanfangdata.com.cn/Periodical/kcdz201301007
毛晓长, 刘文灿, 杜建国, 等, 2005. ETM+和ASTER数据在遥感矿化蚀变信息提取应用中的比较-以安徽铜陵凤凰山矿田为例[J].现代地质, 19(2):309-314. http://d.old.wanfangdata.com.cn/Periodical/xddz200502022
苏松, 2011.东昆仑祁漫塔格成矿带虎头崖铅锌矿矿化规律和经济评价[D].北京: 中国地质大学(北京): 1-127.
http://cdmd.cnki.com.cn/Article/CDMD-11415-1011077457.htm 伍跃中, 乔耿彪, 陈登辉, 2011.东昆仑祁漫塔格地区构造岩浆作用与成矿关系初步探讨[J].大地构造与成矿学, 35(2):232-241. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=ddgzyckx201102008
燕守勋, 武晓波, 周朝宪, 等, 2011.遥感和光谱地质进展及其对矿产勘查的实践应用[J].地球科学进展, 26(1):13-29. http://d.old.wanfangdata.com.cn/Periodical/mtjs201111059
杨长保, 姜琦刚, 朱群, 等, 2009.浅覆盖区基于ASTER数据的蚀变矿物识别方法[J].地质与勘探, 45(6):761-766. http://d.old.wanfangdata.com.cn/Periodical/dzykt200906019
杨日红, 李志忠, 陈秀法, 2012. ASTER数据的斑岩铜矿典型蚀变矿物组合信息提取方法:以秘鲁南部阿雷基帕省斑岩铜矿区为例[J].地球信息科学学报, 14(3):411-418. http://d.old.wanfangdata.com.cn/Periodical/dqxxkx201203019
杨兴科, 韩珂, 范阅, 等, 2016.东昆仑祁漫塔格矿带典型矿田构造背景与岩浆-热力构造特征[J].大地构造与成矿学, 40(2):201-212. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=ddgzyckx201602002
姚佛军, 张玉君, 杨建民, 等, 2012.利用ASTER提取德兴斑岩铜矿遥感蚀变分带信息[J].矿床地质, 31(4):881-890. http://d.old.wanfangdata.com.cn/Periodical/kcdz201204016
易立文, 鲁安怀, 谷湘平, 等, 2019.祁漫塔格成矿带磁铁矿Fe2+/Fe3+比值测定方法对比研究[J].地质力学学报, 25(S1):1-4. https://journal.geomech.ac.cn/ch/reader/view_abstract.aspx?flag=1&file_no=2019S101&journal_id=dzlxxb
张爱奎, 莫宣学, 李云平, 等, 2010.青海西部祁漫塔格成矿带找矿新进展及其意义[J].地质通报, 29(7):1062-1074. http://d.old.wanfangdata.com.cn/Periodical/zgqydz201007013
张大明, 张爱奎, 屈光菊, 等, 2020.东昆仑西段卡而却卡铁铜多金属矿床成矿模式及找矿模型[J].西北地质, 53(1):91-106. http://d.old.wanfangdata.com.cn/Periodical/xbdz202001009
张晓飞, 李智明, 陈博, 等, 2012.东昆仑祁漫塔格地区滩间山群矽卡岩化成矿作用[J].西北地质, 45(1):40-47. http://d.old.wanfangdata.com.cn/Periodical/xbdz201201006
张玉君, 杨建民, 姚佛军, 2006.用ASTER数据进行不同类型矿床蚀变异常提取研究[J].矿床地质, 25(S1):507-510. http://d.old.wanfangdata.com.cn/Conference/6278224
张玉君, 姚佛军, 2009.应用多光谱ASTER数据对ETM遥感异常的定性判别研究:以东昆仑五龙沟为例[J].岩石学报, 25(4):963-970. http://d.old.wanfangdata.com.cn/Periodical/ysxb98200904020
周迪, 倪忠云, 杨振宇, 2018.面向对象的喀斯特地区石漠化遥感信息提取研究:以贵州省大方地区为例[J].地质力学学报, 24(2):263-273. https://journal.geomech.ac.cn/ch/reader/view_abstract.aspx?flag=1&file_no=20180213&journal_id=dzlxxb
-
