Method and effect of delineating concealed plutons with airborne gravity and magnetic data in the Qihe thick coverage area of Shandong Province
-
摘要:
山东齐河地区被大面积巨厚的新生代地层覆盖,但富铁矿资源潜力大,隐伏岩体的圈定对于提高厚覆盖区基础地质研究程度和矿产勘查具有重要意义。通过航空重磁数据处理提高解释的准确性,利用航磁△T化极垂向一阶导数、归一化总水平导数垂向导数、航空重力剩余异常等实现隐伏岩体范围圈定,在研究区共圈定6处中基性岩体,并利用航磁切线法、航空重磁剖面联合反演,结合地面电法、钻孔等资料,获取隐伏岩体的顶面埋深,编制了李屯、潘店、大张岩体的顶面深度三维立体图。在厚覆盖区利用航空重磁并结合地面物探和钻探进行综合研究、圈定隐伏岩体,为今后该地区继续开展地质研究、找矿、钻探等提供了重要信息。
Abstract:The Qihe area of Shandong Province is widely covered with thick Cenozoic strata, however it has great potential for the exploration of high-grade iron resources.Delineation of concealed intrusives is of great significance to improve the degree of basic geological research and mineral exploration in the thick overburden area.The accuracy of anomaly interpretation was improved by aeromagnetic gravity and magnetic data processing, and the range of concealed intrusives were delineated by aeromagnetic △T vertical first derivative, normalized total horizontal derivative vertical derivative and airborne gravity residual anomaly.Six intermediate-basic plutons were delineated in the study area.The depths of the concealed plutons' top surfaces are obtained by means of airborne magnetic tangent method, joint inversion of airborne gravity and magnetic profile and the information from ground electrical survey and boreholes.The three-dimension imagines of the top surface of Litun, Pandian and Dazhang plutons were plotted.In the thick overburden area, the application of airborne gravity and magnetism combined with geophysical exploration and drilling to the delineation of concealed plutons provides important information for further geological research, prospecting and drilling.
-
-
表 1 齐河地区隐伏岩体信息
Table 1. Information of the concealed plutons in the Qihe area
岩体编号 岩体名称 岩体规模/km2 地质和航空重磁简要特征 ① 李屯岩体 104 地表为第四系覆盖,低缓重力高异常,多异常中心的中强航磁异常,呈重磁同高 ② 潘店岩体 59 地表为第四系覆盖,似椭圆状低缓重力高异常,中等强度航磁异常,呈重磁同高 ③ 大张岩体 40 地表为第四系覆盖,低缓重力高异常;似椭圆状中强航磁异常,呈重磁同高 ④ 梁庄岩体 27 地表为第四系覆盖,低缓重力梯度带,航磁化极垂向一导图上呈北西向带状展布 ⑤ 杜集岩体 2.4 地表为第四系覆盖,位于航空重力梯度带上,航磁化极垂向一导图上呈北西向似椭圆状 ⑥ 郭庄岩体 27 地表为第四系覆盖,位于重力异常梯度带上,在航磁ΔT平面图上呈北北东向展布的团块状 表 2 钻孔中岩体顶深
Table 2. Depths of the top surface from concealed plutons in boleholes
序号 钻孔编号 岩体顶深/m 地点 序号 钻孔编号 岩体顶深/m 地点 1 ZK1 1127 李屯 8 ZK101 697 大张 2 ZK0701 1165 李屯 9 ZK201 772 大张 3 ZK3 839 李屯 10 ZK001 800 大张 4 ZK4 763 李屯 11 ZK002 756 大张 5 ZK5 1109 李屯 12 ZK003 713 大张 6 PZK01 1287 潘店 13 ZK004 856 大张 7 DZK01 854 大张 14 ZK1401 863 大张 -
