Geochemical Characteristics of Crude Oil in Jigeda Sag of Yingen–Ejin Basin and Its Significances
-
摘要:
银额盆地石炭系—二叠系油源存在争议，在一定程度上制约了该区的油气勘探进程。通过对居延海坳陷吉格达凹陷蒙额参3井原油物理性质、地球化学特征的研究，以期明确原油的成因及来源，为油气勘探提供依据。研究结果表明，蒙额参3井华力西期侵入岩和二叠系白云质砂岩中的原油物理性质基本一致，为低密度低硫中质正常原油，原油族组成具有高饱和烃、低非烃和沥青质以及高饱芳比的特征，且下部原油饱芳比远高于上部原油。吉格达凹陷华力西期侵入岩与二叠系砂岩原油饱和烃气相色谱特征、C同位素及生物标志化合物特征共性与差异同在，指示生烃母质均来源于盐度较高的海相还原环境，以浮游植物为主；二叠系原油陆生高等植物的贡献较大。油源对比表明，蒙额参3井华力西期侵入岩和二叠系砂岩原油均与白垩系巴音戈壁组烃源岩生物标志化合物特征差异明显，与石炭系—二叠系烃源岩具有良好的亲缘关系。其中，二叠系原油与二叠系烃源岩具有较好亲缘关系，华力西期侵入岩原油与干泉组上段烃源岩关系更密切。石炭系—二叠系油源的发现拓展了银额盆地油气勘探新层系，对北方古生界油气勘探具有很好的指导作用。
Abstract:There is a dispute on the oil–source of Carboniferous and Permian system in Yingen–Ejin basin, which restricts the process of oil and gas exploration in this area to a certain extent. In order to clarify the oil origin and source and provide basis for oil & gas exploration in this area, research of the basic physical properties and geochemical characteristics of the crude oil from well Mengecan 3 in Jigeda Sag of Juyanhai depression was conducted. The results show that the physical properties of the crude oil in the Variscan intrusive rocks are basically the same as those in the dolomite sandstones of the Permian system for well Mengecan 3. The oil is low–density, low–sulfur and normal medium crude oil, composition of which is characterized as high saturated hydrocarbon content, low non–hydrocarbon and asphaltenes content, and high ratio of saturated to aromatic hydrocarbons, and the saturated to aromatic hydrocarbons ratio of the lower crude oil is much higher than that of the upper crude oil. The gas chromatography characteristics of saturated hydrocarbon, carbon isotope characteristics and biomarkers of the crude oil in the Variscan intrusive rocks and Permian sandstones of Jigeda Sag have both similarities and differences, As the aforementioned, the results indicate that the parent materials of hydrocarbon were derived from reducing and high paleo–salinity conditions in the marine, and phytoplankton was the main source, while the proportion of terrestrial higher plants is higher for the oil source in Permian sandstone. Oil source comparison shows that the characteristics of biomarkers of Variscan intrusive rocks and Permian sandstone crude oil in well Mengecan 3 are significantly different from those of cretaceous Bayingebi formation, and it is closely related to the Carboniferous–Permian source rocks. The crude oil from Permian sandstones show favorable correlations with the Permian source rocks, while the crude oil from Variscan intrusive rocks show more closely correlations with the source rock of upper Ganquan formation. The discovery of Carboniferous Permian oil source has expanded the new series of oil and gas exploration in Yingen–Ejin basin, and has a good guiding role in oil and gas exploration of Paleozoic in North China.
-
Key words:
- crude oil /
- biomarkers /
- geochemistry /
- oil genesis /
- oil–source correlation /
- Jigeda sag /
- Yingen–Ejin basin
-
-
表 1 蒙额参3井原油物理性质统计表
Table 1. Physical propertiesstatistical table of the crude oil of Mengecan 3 well
样品
编号层位及
产油岩性密度
（g/cm3、
50 ℃）粘度
（mPa·s，
50 ℃）含沙
（%）S含量
（%）初馏点
（℃）倾点
（℃）含水
（%）盐含量
（mg/kg，
以NaCL计）含沥青
（%）含蜡
（%）含胶
（%）MEC3-Y2 华力西期侵入岩 0.802 5.11 0.022 0.0128 60 20 0.28 16.61 0.13 30.87 4.33 MEC3-Y3 二叠系白云质砂岩 0.795 3.49 0.02 0.0224 55 19 0.20 6.38 0.69 35.59 5.51
下载: 导出CSV
表 2 蒙额参3井原油族组成统计表
Table 2. Group componentsstatistical table of the crude oil of Mengecan 3 well
样品编号 井深（m） 层位及
产油岩性饱和烃
（%）芳烃
（%）非烃
（%）沥青质
（%）饱和烃/
芳烃非烃/
沥青质非烃+
沥青质（%）MEC3-Y1-1 2788～2790
2800～2802华力西期
侵入岩89.82 4.58 3.29 2.31 19.61 1.42 5.60 MEC3-Y1-2 88.69 2.60 6.65 2.06 34.11 3.23 8.71 MEC3-Y1-3 92.34 3.67 2.51 1.48 25.16 1.70 3.99 MEC3-Y2-1 93.05 2.64 2.08 2.23 35.25 0.93 4.31 MEC3-Y2-2 92.95 3.51 1.89 1.65 26.48 1.15 3.54 MEC3-Y2-3 91.80 4.76 2.02 1.43 19.29 1.41 3.45 MEC3-Y3-1 2474.2～2475.2 二叠系白
云质砂岩84.26 10.67 4.21 0.86 7.90 4.90 5.07 MEC3-Y3-2 87.32 7.95 3.53 1.20 10.98 2.94 4.73 MEC3-Y3-3 87.45 8.00 2.80 1.74 10.93 1.61 4.54 MEC3-Y3-4 88.01 7.89 3.06 1.05 11.15 2.91 4.11
下载: 导出CSV
表 3 蒙额参3井原油稳定碳同位素统计表
Table 3. Statistical table of stable carbon isotopes of the crude oil of Mengecan 3 well
样品编号 δ13C（‰），PDB 全油 饱和烃 芳烃 非烃 沥青质 MEC3-Y1 −34.06 −32.3 −31.1 −29.65 −29.9 MEC3-Y2 −32.8 −32.12 −30.8 −28.57 −29.61 MEC3-Y3 −29.79 −32.44 −30.78 −30.84 −29.17
下载: 导出CSV
表 4 蒙额参3井原油饱和烃气相色谱数据统计表
Table 4. Statistical table of gas chromatograms of saturated hydrocarbons of the crude oil of Mengecan 3 well
样品编号 碳数范围 主峰碳 Pr（%） Ph（%） Pr/Ph OEP CPI Pr/nC17 Ph/nC18 MEC3-Y1 nC11～nC37 nC17 1.33 1.88 0.70 1.08 0.83 0.14 0.21 MEC3-Y2 nC11～nC37 nC17 1.33 1.97 0.67 1.07 0.83 0.14 0.22 MEC3-Y3 nC11～nC37 nC17 2.05 2.94 0.70 1.12 0.85 0.24 0.36
下载: 导出CSV
表 5 蒙额参3井原油甾萜烷数据统计表
Table 5. Statistical table of steraneand sterane compounds of the crude oil of Mengecan 3 well
样品编号 Ts/Tm C27甾烷（%） C28甾烷（%） C29甾烷（%） ααα甾烷C29S/（S+R） C29甾烷ββ/（αα+ββ） 藿烷C32S/R MEC3-Y1 1.90 24.49 39.79 35.72 0.53 0.38 1.84 MEC3-Y2 1.40 25.74 35.30 38.96 0.54 0.39 1.92 MEC3-Y3 1.15 32.37 32.30 35.33 0.55 0.41 1.50
下载: 导出CSV
-
[1] 常俊合, 李新军, 吕红玉, 等. 东濮凹陷文留潜山构造文古2井原油地球化学特征和油源研究[J]. 石油与天然气地质, 2004, 25(1): 44-48 doi: 10.3321/j.issn:0253-9985.2004.01.008
CHANG Junhe, LI Xinjun, LÜ Hongyu, et al. A study on geochemical characteristics and sources of oil produced from Wengu 2 well in Wenliu buried hill in Dongpu Depression[J]. Oil & Gas Geology, 2004, 25(1): 44-48 doi: 10.3321/j.issn:0253-9985.2004.01.008
[2] 陈建平, 王绪龙, 邓春萍, 等. 准噶尔盆地南缘油气生成与分布规律——典型类型原油油源对比[J]. 石油学报, 2016, 37(2): 160-171
CHEN Jianping, WANG Xulong, DENG Chunping, et al. Oil source correlation of typical crude oils in the southern margin, Junggar Basin, Northwestern China [J]. Acta Petrolei Sinica, 2016, 37(2): 160-171
[3] 陈治军, 高怡文, 刘护创, 等. 银根—额济纳旗盆地哈日凹陷下白垩统烃源岩地球化学特征与油源对比[J]. 石油学报, 2018, 39(1): 69-81 doi: 10.7623/syxb201801006
CHEN Zhijun, GAO Yiwen, LIU Huchuang, et al. Geochemical cha racteristics of I ower C retaceous source rocks and oil source correlation in Hari sag, Yingen-Ejinaqi Basin [J]. Acta Petrolei Sinica, 2018, 39(1): 69-81. doi: 10.7623/syxb201801006
[4] 董君妍, 陈世加, 邹贤利, 等. 鄂尔多斯盆地吴起—高桥地区延长组重排类藿烷分布特征及成因探讨[J]. 石油实验地质, 2017, 39(6): 834-841
DONG Junyan, CHEN Shijia, ZOU Xianli, et al. Distribution and origin of rearranged hopanes in Yanchang Formation, Wuqi –Gaoqiao area, Ordos Basin[ J ]. Petroleum Geology & Experiment, 2017, 39(6): 834-841.
[5] 郭艳琴, 李文厚, 陈全红, 等. 鄂尔多斯盆地安塞—富县地区延长组—延安组原油地球化学特征及油源对比[J]. 石油与天然气地质, 2006, 27(2): 218-224 doi: 10.3321/j.issn:0253-9985.2006.02.012
GUO Yanqin, LI Wenhou, CHEN Quanhong, et al. Geochemical behaviors of oil and oil—source correlation in Yanchang—Yan’an Formations in Ansai—Fuxian area, Ordos Basin[J]. Oil & Gas Geology, 2006, 27(2): 218-224. doi: 10.3321/j.issn:0253-9985.2006.02.012
[6] 姜亭, 周俊林, 牛亚卓, 等. 西北公益性油气地质调查进展和展望[J]. 西北地质, 2022, 55(3): 64-80 doi: 10.19751/j.cnki.61-1149/p.2022.03.005
JIANG Ting, ZHOU Junlin, NIU Yazhuo, et al. Progress and Prospect of Public Petroleum Geological Survey in Northwest China[J]. Northwestern Geology, 2022, 55(3): 64-80. doi: 10.19751/j.cnki.61-1149/p.2022.03.005
[7] 康玉柱. 中国西北地区石炭—二叠系油气勘探前景[J]. 新疆石油地质, 2008, 28(4): 415-419
KANG Yuzhu. Petroleum Resource Prospects of Carboniferous and Permian in Northwestern China[J]. Xinjiang Petroleum Geology, 2008, 28(4): 415-419.
[8] 李洪, 姚亚明, 张俊敏, 等. 焉耆盆地煤系源岩特征、生烃机理及烃源岩倾向性研究[J]. 西北地质, 2015, 48(1): 229-240
LI Hong, YAO Yaming, ZHANG Junmin, et al. Research on characteristics and hydrocarbon-generating mechanism of Jurassic coal measures source rock of Yanqi Basin and analysis on hydrocarbon-generating capacity and tendency(liquid and gas) of different source rock[J]. Northwestern Geology, 2015, 48(1): 229-240.
[9] 李谨, 王超, 李剑, 等. 库车坳陷北部迪北段致密油气来源与勘探方向[J]. 中国石油勘探, 2019, 24(4): 485-497
LI Jin, WANG Chao, LI Jian, et al. Source and exploration direction of tight oil and gas in the Dibei section of northern Kuqa depression [J]. China Petroleum Exploration, 2019, 24(4): 485-497.
[10] 刘洛夫, 孟江辉, 王维斌, 等. 准噶尔盆地西北缘车排子凸起上、下层系原油的地球化学特征差异及其意义[J]. 吉林大学学报(地球科学版), 2011, 41(2): 377-390
LIU Luofu, MENG Jianghui, WANG Weibin, et al. Differences in geochemical characteristics of oils trapped in the upper and the lower series of strata of Chepaizi uplift along northwest margin of Junggar basin and their significances[J]. Journal of Jilin University(Earth Science Edition), 2011, 41(2): 377-390.
[11] 刘文章. 热采稠油油藏开发模式[M]. 北京: 石油工业出版社, 1998: 1-2
LIU Wenzhang. The development models of heavy oil reservoirs by thermal recovery[M]. Beijing: Petroleum Industry Press, 1998: 1-2.
[12] 卢进才, 陈高潮, 李玉宏, 等. 银额盆地及邻区石炭系—二叠系油气地质条件与资源前景[M]. 北京: 地质出版社, 2012: 210-215
LU Jincai, CHEN Gaochao, LI Yuhong, et al. Carboniferous—Permian geological conditions and resources perspective in Yingen-Ejin Banner basin and its vicinities [M]. Beijing: Geological Publishing House, 2012: 210-215.
[13] 卢进才, 陈高潮, 魏仙样, 等. 内蒙古西部额济纳旗及其邻区石炭系—二叠系沉积建造与生烃条件研究——油气地质条件研究之一[J]. 地质通报, 2011, 30(6): 811-826
LU Jincai, CHEN Gaochao, WEI Xianyang, et al. Carboniferous-Permian sedimentary formation and hydrocarbon generation conditions in Ejin Banner and its vicinities, western Inner Mongolia: a study of Carboniferous-Permian petroleum geological conditions(part 1)[J]. Geological Bulletin of China, 2011, 30(6): 811-826.
[14] 卢进才, 陈践发, 郭建军, 等. 古亚洲与特提斯交汇带盆地群油气资源潜力[J]. 西北地质, 2006, 39(3): 39-47 doi: 10.3969/j.issn.1009-6248.2006.03.006
LU Jincai, CHEN Jianfa, GUO Jianjun, et al. Potential of Oil and gas Resources of Basin Groups in Conjunction Area between the Paleoa-Asia and Tethys[J]. Northwest Geology, 2006, 39(3): 39-47. doi: 10.3969/j.issn.1009-6248.2006.03.006
[15] 卢进才, 魏建设, 姜亭, 等. 银额盆地居延海坳陷原油物理化学特征与油源探讨[J]. 地质通报, 2020, 39(10): 1589-1599 doi: 10.12097/j.issn.1671-2552.2020.10.010
LU Jincai, WEI Jianshe, JIANG Ting, et al. Discussion on physical and chemical characteristics of crude oil and oil-source of Juyanhai depression in Yingen-Ejina Basin[J]. Geological Bulletin of China, 2020, 39(10): 1589-1599. doi: 10.12097/j.issn.1671-2552.2020.10.010
[16] 卢双舫, 张敏. 油气地球化学[M]. 北京: 石油工业出版社, 2008: 171-191.
LU Shuangfang, ZHANG Min. Oil and Gas Geochemical[M]. Beijing: Petroleum Industry Press, 2010: 171-191.
[17] 田德瑞, 吴奎, 张如才, 等. 渤海湾盆地辽西凸起北段锦州20油田原油地球化学特征及油源对比[J]. 石油实验地质, 2018, 40(3): 410-417 doi: 10.11781/sysydz201803410
TIAN Derui, WU Kui, ZHANG Rucai, et al. Geochemical features and oil- -source correlation of crude oils from JZ20 oil field on the northern margin of Liaoxi Uplift, Bohai Bay Basin[J]. Petroleum Geology & Experiment, 2018, 40(3): 410-417. doi: 10.11781/sysydz201803410
[18] 罗丽荣, 李剑锋, 赵占良, 等. 河套盆地临河坳陷新生界油源对比及其勘探意义[J]. 中国石油勘探, 2019, 24(3): 323-330 doi: 10.3969/j.issn.1672-7703.2019.03.005
LUO Lirong, LI Jianfeng, ZHAO Zhanliang, et al. Cenozoic oil-source correlation and exploration significance in Linhe depression, the Hetao Basin [J]. China Petroleum Exploration, 2019, 24(3): 323-330. doi: 10.3969/j.issn.1672-7703.2019.03.005
[19] 彭兴芳, 李周波. 生物标志化合物在石油地质中的应用[J]. 资源环境与工程, 2006, 20(3): 279-283 doi: 10.3969/j.issn.1671-1211.2006.03.017
PENG Xingfang, LI Zhoubo. The application of biomarker in the research of petroleum geology[J]. Resources Environment& Engineering, 2006, 20(3): 279-283. doi: 10.3969/j.issn.1671-1211.2006.03.017
[20] 任纪舜, 王作勋, 陈炳蔚, 等. 从全球看中国大地构造: 中国及邻区大地构造图简要说明[M]. 北京: 地质出版社, 1999: 11-17
REN Jishun, WANG Zuoxun, CHEN Bingwei, et al. Contrast study of the prospecting of Copper-gold ore between west China and its adjacent area[M]. Beijing: Geological Publishing House, 1999: 11-17.
[21] 宋来亮, 刘华, 徐昊清, 等. 潍北凹陷孔店组烃源岩地化特征及油源对比[J]. 西南石油大学学报(自然科学版), 2016, 38(2): 1-10
SONG Lailiang, LIU Hua, XU Haoqing, et al. Geochemical characteristics of hydrocarbon source rocks and oil—source correlation of Kongdian Formation, Weibei Depression[J]. Journal of Southwest Petroleum University(Science & Technology Edition), 2016, 38(2): 1-10.
[22] 王朋, 柳广弟, 曹喆, 等. 查干凹陷下白垩统稠油地球化学特征及成因分析[J]. 沉积学报, 2015, 33(6): 1265-1274
WANG Peng, LIU Guangdi, CAO Zhe, et al. Geochemistry and origin of heavy oil in lower cretaceous of Chagan Depression[J]. Acta Sedimentologica Sinica, 2015, 33(6): 1265-1274.
[23] 魏建设, 姜亭, 王宝文, 等. 银额盆地居延海坳陷吉格达凹陷石炭系—二叠系烃源岩生物标志化合物特征及其意义[J]. 西北地质, 2020, 53(3): 273-283
WEI Jianshe, JIANG Ting, WANG Baowen, et al. The Biomarker Characteristics and Its Significance of the Carboniferous-Permian Source Rocks in Jigeda Sag of Juyanhai Depression in Yin'er Basin[J]. Northwestern Geology, 2020, 53(3): 273-283.
[24] 魏建设, 许伟, 周俊林, 等. 河套盆地临河坳陷庆浅1井区原油地球化学特征与油源对比[J]. 西北地质, 2019, 52(3): 181-193
WEI Jianshe, XU Wei, ZHOU Junlin, et al. Geochemical Characteristics of Crude Oil in the well Zone of Qingqian 1 in Linhe Depression of Hetao Basin, China: Implication for Oil-Source Correlation[J]. Northwestern Geology, 2019, 52(3): 181-193.
[25] 杨尚儒, 高岗, 张永超等. 南堡2号构造带中浅层油源对比及原油运聚模式[J]. 油气地质与采收率, 2018, 25(1): 30-36
YANG Shangru, GAO Gang, ZHANG Yongchao, et al. Oil-source correlation and model of migration and accumulation of shallow-middle crude oil in No. 2 structural belt, Nanpu Sag[J]. Petroleum Geology and Recovery Efficiency, 2018, 25(1): 30-36.
[26] 尹伟, 郑和荣, 孟闲龙, 等. 准噶尔盆地中部原油地球化学特征[J]. 石油与天然气质, 2005, 26(4): 461-466, 472
YIN Wei, ZHENG Herong, MENG Xianlong, et al. Geochemical be-haviors of crude oils in central Junggar Basin[J]. Oil & Gas Geo-logy, 2005, 26(4): 461-466, 472.
[27] 于连东. 世界稠油资源的分布及其开采技术的现状与展望[J]. 特种油气藏, 2001, 8(2): 98-103 doi: 10.3969/j.issn.1006-6535.2001.02.029
YU Liandong. Distribution of world heavy oil reserves and its recovery technologies and future[J]. Special Oil & Gas Reservoirs, 2001, 8( 2): 98-103. doi: 10.3969/j.issn.1006-6535.2001.02.029
[28] 余琪祥, 陈君, 余风华. 西北中小型盆地油气资源潜力与勘探领域分析[J]. 西北地质, 2016, 49(1): 224-233 doi: 10.3969/j.issn.1009-6248.2016.01.023
YU Qixiang, CHEN Jun, YU Fenghua. Hydrocarbon Resource Potential within Middle and Small-sized Basins and Their Exploration Fields in Northwest China[J]. Northwest Geology, 2016, 49(1): 224-233. doi: 10.3969/j.issn.1009-6248.2016.01.023
[29] 张厚福, 方朝亮, 高先志, 等. 石油地质学[M]. 北京: 石油工业出版社, 1999: 30−34
ZHANG Houfu, FANG Chaoliang, GAO Xianzhi, et al. Petroleum geology[M]. Beijing: Petroleum Industry Press, 1999: 30−34.
[30] Chen Jianyu, Bi Yanpong, Zhang Jiguo, et al. Oil-source correlation in the Fulin Basin, Shengli petroleum province, EastChina[J ]. Organic Geochemistry, 1996, 24( 8/9): 931-940.
[31] Hao Fang, Zhou Xinhuai, Zhu Yangming, et al. Mechanisms of petroleum accumullation in the Bozhong Sub-basin, Bohai BayBasin , China. Part 1 : Origin and occurrence. of crude oils[J]. Marine and Petroleum Geology, 2009, 26(8): 1528−1542.
[32] Peters K E, Walters C C, Moldowan. The biomarker guide (Second edition, Part Ⅱ): Biomarkers and isotopes in petroleum systems and earth history[M]. New York: Cambridge University Press, 2005: 475−1155.
[33] XIAO W J, MAO Q G, WINDLEY B F, et al. Paleozoic multiple accretionary and collisional processes of the Beishan orogenic collage[J]. American Journal of Science, 2011, 310(10): 1553-1594.
[34] XIAO W J, WINDLEY B F, SUN S, LI J L, et al. . A tale of amalgamation of three PermoTriassic collage systems in Central Asia: oroclines, sutures, andterminal accretion[J]. Annual Review of Earth and PlanetarySciences, 2015, 43(1): 477-507. doi: 10.1146/annurev-earth-060614-105254
-
