Soil Geochemical Characteristics and Prospecting Prediction in Sanyu Area, Li County, Gansu Province
-
摘要:
三峪地区位于甘肃崖湾–大桥金锑矿带，属于国家级整装勘查内，具有金、锑、铜等多金属成矿条件及找矿潜力。为进一步提高地质找矿工作，在研究区开展了1∶2.5万土壤地球化学测量，以Au、Ag、Cu、Pb、Zn、Ni、Sb、Bi、Hg等9种元素原始数据为基础，运用分形特征及元素的变异系数、浓度系数等方法，对9种元素基础数据进行了统计，并分析了元素空间富集状态及分布趋势。结果显示，Pb、Zn、Sb和Au具有一定的找矿指标，利用SPSS 25对9种元素进行聚类及因子分析，共划分出F1（Ag−Pb−Zn−Sb）、F2（Au−Cu−Ni−Bi）、F3（Hg）3种组合元素，通过衬度异常法得出元素组合异常下限，根据软件Sufer 13对组合元素做出因子得分异常图，共圈定出4个找矿远景区，为下一步开展地质找矿、缩小远景区提供依据。
Abstract:Sanyu area is located in the Yawan−Daqiao gold−antimony ore belt of Gansu Province, which belongs to the national integrated exploration, and has the metallogenic conditions and prospecting potential of gold, antimony, copper and other polymetals. In order to further improve the geological prospecting work, 1∶25000 soil geochemical survey was carried out in the research area. Based on the original data of Au, Ag, Cu, Pb, Zn, Ni, Sb, Bi and Hg elements, fractal characteristics, coefficient of variation, coefficient of concentration and other methods, The basic data of 9 elements were statistically analyzed, and the spatial enrichment status and distribution trend of elements were analyzed. The results showed that Pb, Zn, Sb and Au had certain prospecting indexes, SPSS 25 was used for clustering and factor analysis of 9 elements, and three combination elements were divided into F1 (Ag−Pb−Zn−Sb), F2 (Au−Cu−Ni−Bi) and F3 (Hg). The lower limit of element combination anomaly was obtained by contrast anomaly method, and according to software Sufer. The factor score anomaly map of 13 combination elements was made, and a total of 4 prospecting prospects were delineated, which provided a basis for further geological prospecting and reduction of prospective areas.
-
Key words:
- soil geochemistry /
- fractal /
- abnormal combination /
- prospecting prediction /
- Sanyu region
-
-
表 1 甘肃省礼县三峪地区地球化学元素含量参数统计特征表
Table 1. Statistical characteristics of geochemical element content parameters in Sanyu area, Lixian County, Gansu Province
元素 样品数目
（件）最大值 算术
平均值标准
离差变异系数
CV1浓度
系数陇南地区
背景值算术
平均值标准
离差变异系数
CV2Au 1200 6.4 1.6 0.7 0.46 1.01 1.58 1.58 0.61 0.39 Ag 1200 0.23 0.04 0.02 0.44 / 71.14 0.04 0.02 0.39 Cu 1200 65 30.5 5.1 0.17 1.23 24.7 30.24 4.31 0.15 Pb 1200 24 36.8 6 0.16 1.69 21.81 35.75 3.31 0.1 Zn 1200 700 95.1 28.8 0.3 1.29 73.89 90.92 12.56 0.16 Ni 1200 201 46 9.8 0.21 1.52 30.25 44.85 4.82 0.14 Sb 1200 23.11 1.8 0.98 0.55 2.2 0.82 1.57 0.26 0.23 Bi 1200 3.37 0.43 0.16 0.38 1.3 0.33 0.42 0.11 0.29 Hg 1200 21 14 3 0.19 0.52 26.75 14.46 2.74 0.19 注： Au、Ag含量为10−9；其他元素含量为10−6；变异系数=标准离差/平均值；浓度系数=平均值/陇南地区背景值；“/”表示数值低。
下载: 导出CSV
表 2 KMO和巴特利特检验表
Table 2. KMO and Bartlett test
KMO取样适切性量数 0.655 巴特利特球形度检验 近似卡方 1668.056 自由度 36 显著性 0
下载: 导出CSV
表 3 正交旋转因子载荷矩阵表
Table 3. Orthogonal rotation factor loading matrix
元素 F1 F2 F3 Au 0.052 0.489 0.263 Ag 0.512 −0.111 −0.502 Cu 0.235 0.792 −0.134 Pb 0.852 0.096 −0.015 Zn 0.821 0.119 −0.071 Ni 0.009 0.682 0.15 Sb 0.642 0.106 0.252 Bi 0.02 0.565 −0.273 Hg 0.114 −0.034 0.763 方差贡献率（%） 28.655 22.239 14.902 旋转累计方差贡献率（%） 28.655 50.894 65.796
下载: 导出CSV
表 4 甘肃礼县三峪地区元素组合异常衬值参数统计表
Table 4. Statistics of soil geochemical lining parameters in Sanyu area, Li County, Gansu
元素组合 背景值 标准差 外带值下限 中带值 内带值 F1 4.090 0.586 4.382 4.676 5.262 F2 4.024 0.615 4.332 4.639 5.254 F3 1.000 0.190 1.095 1.190 1.380
下载: 导出CSV
-
[1] 成秋明. 覆盖区矿产综合预测思路与方法[J]. 地球科学(中国地质大学学报), 2012, 37(06): 1109-1125
CHENG Qiuming. Ideas and Methods for Mineral Resources Integrated Prediction in Covered Areas[J]. Earth Science(Journal of China University of Geosciences), 2012, 37(06): 1109-1125.
[2] 段晓华, 陈健. 甘肃省礼县崖湾金矿床地球化学异常特征[J].甘肃地质, 2008, 17(4):17−20+25.
DUAN Xiaohua, CHEN Jian. Study on Geochemical Anomaly Mode of Aiwan Gold Deposit, Lixian County of Gansu Province[J]. Gansu Geology, 2008, 17(4): 17−20+25.
[3] 樊会民, 安兴, 张嘉声, 等. 陕西省秦巴地区金元素找矿预测区划分及其地球化学特征[J]. 物探与化探, 2018, 42(04): 682-688
FAN Hui min, An Xing, ZHANG Jiasheng, et al. Division of gold element prospecting area in Qinba region of Shaanxi Province and its geochemical characteristics[J]. Geophysical and Geochemical Exploration, 2018, 42(04): 682-688.
[4] 冯博鑫, 徐多勋, 张宏宇, 等. 基于最小数据集的周至地区土壤重金属地球化学特征及成因分析[J]. 西北地质, 2023, 56(01): 284-292 doi: 10.12401/j.nwg.2022022
FENG Boxin, XU Duoyun, ZHANG Hongyu, et al. Geochemical Characteristic of Heavy Metal in Zhouzhi Area and Analysis of Their Causes Based on Minimum Data Set[J]. Northwestern Geology, 2023, 56(01): 284-292. doi: 10.12401/j.nwg.2022022
[5] 黄学强, 罗先熔, 刘巍, 等. 凹陷盆地铜镍多金属矿床地电化学异常特征及找矿预测[J]. 物探与化探, 2013, 37(02): 199-205
HUANG Xueqiang, LUO Xianrong, LIU Wei, et al. Features of Geo-Electrochemical Anomaly and Copper-Nickel Prospecting Prognosis in Hollow Basin[J]. Geophysical and Geochemical Exploration, 2013, 37(02): 199-205.
[6] 黄文斌, 罗先熔, 刘攀峰, 等. 青海省石灰沟地区水系沉积物测量地球化学特征及找矿预测[J]. 地质科技通报, 2020, 39(03): 150-159
HUANG Wenbin, LUO Xianrong, LIU Panfeng, et al. Geochemical characteristics of stream sediments and ore prospecting prediction in Shi hui gou Aear, Qinghai Province[J]. Bulletin of Geological Science and Technology, 2020, 39(03): 150-159.
[7] 何旺, 罗先熔, 高文, 等, 青海省都兰县五龙沟-高地地区水系沉积物地球化学特征及找矿远景[J]. 矿物岩石地球化学通报, 2019, 38(05): 1017-1023
HE Wang, LUO Xianrong, GAO Wen, et al. Geochemical Characteristics of Stream Sediments in the Wulonggou-Gaodi area, Dulan County, Qinghai Province and Their Exploration Prospective[J] Bulletin of Mineralogy Petrology and Geochemistry, 2019, 38(05): 1017-1023.
[8] 龚晶晶, 杨剑洲, 马生明, 等. 利用因子分析和分形分析识别内蒙古黑鹰山地区矿致地球化学异常[J]. 物探与化探, 2020, 44(01): 122-131
GONG Jingjing, YANG Jianzhou, MA Shengming, et al. Recognition of ore-induced geochemical anomaly by combined factor and fractal analysis in Heiyingshan, Inner Mongolia[J]. Geophysical and Geochemical Exploration. 2020, 44(01): 122-131.
[9] 姜寒冰, 杨合群, 赵国斌, 等. 西秦岭成矿带区域成矿规律概论[J]. 西北地质, 2023, 56(2): 187−202.
JIANG Hanbing, YANG Hequn, ZHAO Guobin, et al. Discussion on the Metallogenic Regularity in West Qinling Metallogenic Belt, China[J]. Northwestern Geology, 2023, 56(2): 187−202.
[10] 黎彤. 化学元素的地球丰度[J]. 地球化学, 1976, 5(3): 167-174 doi: 10.3321/j.issn:0379-1726.1976.03.004
LI Tong. Chemical element abundances in the Earth and its major shells[J]. Geochemistry, 1976, 5(3): 167-174. doi: 10.3321/j.issn:0379-1726.1976.03.004
[11] 罗先熔, 文美兰, 欧阳菲, 等. 勘查地球化学[M]. 北京: 冶金工业出版社, 2008
LUO Xianrong, WEN Meilan, OUYANG Fei, et al. Exploration geochemistry[M]. Beijing: Metallurgical Industy Press, 2008.
[12] 刘建宏, 张新虎, 牛洪斌, 等. 甘肃省区域地球化学场特征[J]. 甘肃地质, 2015, 24(04): 1-15
LIU Jianhong, ZHANG Xinhu, NIU Hongbin, et al. Characteristics of regional field in Gansu Province[J]. Gansu Geology, 2015, 24(04): 1-15.
[13] 刘开君. 西秦岭热液金矿床地球化学特征及成因探讨-以大桥金矿为例[D]. 兰州: 兰州大学, 2016
LIU Kaijun. Geochemistry Characteristics and Genesis of Hydrothermal Gold Deposits in West Qinling: As Exemplified by Daqiao Gold Deposit[D]. Lanzhou: Lanzhou University, 2016.
[14] 李超, 罗先熔, 汤国栋, 等. 内蒙古额济纳旗标山北土壤地球化学异常特征及找矿前景[J]. 地质与勘探, 2020, 56(06): 1170-1182
LI Chao, LUO Xianrong, TANG Guodong, et al. Characteristics of Soil Geochemical Anomalies and Ore-Search Prospect in the North of Biaoshan, Ejinaqi, Inner Mongolia[J]. Geology and Exploration, 2020, 56(06): 1170-1182.
[15] 李文明, 刘拓, 孙吉明, 等. 新疆北山白山地区地球化学特征及找矿远景预测[J]. 西北地质, 2021, 54(04): 42-48
LI Wenming, LIU Tuo, SUN Jiming, et al. Geochemical Characteristics and Prospecting Prognosis in Baishan Area of Xinjiang Beishan[J]. Northwestern Geology, 2021, 54(04): 42-48.
[16] 李天虎, 彭桥梁, 王伟, 等. 新疆温宿县盐场地区水系沉积物地球化学特征及找矿效果[J]. 西北地质, 2022, 55(01): 78-92
LI Tianhu, PENG Qiaoliang, WANG Wei, et al. Geochemical Characteristics and Ore Prospecting of Stream Sediment in Yanchang Area of Wensu, Xinjiang[J]. Northwestern Geology, 2022, 55(01): 78-92.
[17] 牟妮妮, 孙祥, 万修权. 西藏米拉山地区化探异常特征与找矿预测[J]. 地质通报, 2020, 39(08): 1182-1190
MOU Nini, SUN Xiang, WAN Xiuquan, Geochemical anomaly characteristics and mineral potential mapping in Milashan area of Tibet[J]Geological Bulletin of China, 2020, 39(08): 1182-1190.
[18] 彭素霞, 赵文川. 寨上金矿区成矿机制及成矿预测[J]. 地质与勘探, 2007, 43(02): 40-44 doi: 10.3969/j.issn.0495-5331.2007.02.008
PENG Suxia, ZHAO Wenchuan. Mineralization Mechanism and Prognosis in the Zhaishang Gold mining area[J]. Geology and Prospecting, 2007(02): 40-44. doi: 10.3969/j.issn.0495-5331.2007.02.008
[19] 施海鹏, 魏俊浩, 赵少卿, 等. 宁夏贺兰山北段1∶5万化探数据的含量-面积分形异常特征及找矿预测[J]. 地质科技情报, 2015, 34(03): 71-79+95
SHI Haipeng, WEI Junhao, ZHAO Shaoqing, et al. Content-Area Fractal Characteristics and Prospecting Prediction for the Northern Helanshan: 1∶50 000 Geochemical Measurement Data[J]. Geological Science and Technology Information, 2015, 34(03): 71-79+95.
[20] 申维. 分形求和法及其在地球化学数据分组中的应用[J]. 物探化探计算技术, 2007(02): 134-137+88 doi: 10.3969/j.issn.1001-1749.2007.02.012
SHEN Wei. Fractal Summation Methods and Its Application in Geochemical ElementL Date for Population Limits[J]. Computing Techniques for Geophysical and Geochemical Exploration, 2007(02): 134-137+88. doi: 10.3969/j.issn.1001-1749.2007.02.012
[21] 孙则朋, 王自翔, 徐亮, 等. 甘肃大桥金矿硅质岩地球化学特征及其地质意义探讨[J]. 地球化学, 2016, 45(05): 499-509 doi: 10.3969/j.issn.0379-1726.2016.05.006
SUN Zepeng, WANG Zixu, XU Liang, et al. Geochemical characteristics and geological significance of cherts from the Daqiao gold deposit, Gansu Province[J]. Geochimica, 2016, 45(05): 499-509. doi: 10.3969/j.issn.0379-1726.2016.05.006
[22] 苏艺怀, 刘攀峰, 罗先熔, 等. 甘肃省夏河县唐尕昂地区土壤地球化学特征及找矿前景分析[J]. 桂林理工大学学报, 2021, 41(01): 34-41
SU Yihuai, LIU Panfeng, LUO Xianrong, et al. Soil geochemical characteristics and prospect potential of Tanggaang survey area, Xiahe County, Gansu[J]. Journal of Guilin University of Technology. 2021, 41(01): 34-41.
[23] 唐瑞, 欧阳菲, 罗先熔, 等. 相山矿田游坊地区地电提取找矿预测[J]. 物探与化探, 2021, 45(06): 1425-1438
TANG Rui, OUYANG Fei, LUO Xianrong, et al. The prediction of electrochemical prospecting in Youfan area of the Xiangshan ore field[J]. Geophysical and Geochemical Exploration, 2021, 45(06): 1425-1438.
[24] 王会敏, 陈守余, 赵江南, 等. 柴北缘都兰地区Pb-Zn矿化信息提取与评价[J]. 地质科技情报, 2016, 35(05): 131-138
WANG Huiming, CHEN Shouyu, ZHAO Jiangnan, et al. Pb-Zn Mineralization Information Extraction and Evaluation in Doulan Area, Qaidam[J]. Geological Science and Technology Information, 2016, 35(05): 131-138.
[25] 王发明, 翟玉林, 李艳军, 等. 青海大场金矿田北缘灭格滩矿区土壤地球化学异常信息提取及找矿预测[J]. 地质科技情报, 2015, 34(05): 127-133
WANG Fanming, ZHAI Yulin, LI Yanjun, et al. Soil Geochemical Anomaly Information Extraction and Prospecting Prediction of the Miegetan Gold Deposit, Northern Segment of the Dachang Gold Mine, Qinghai Province[J]. Geological Science and Technology Information, 2015, 34(05): 127-133.
[26] 王乔林, 孔牧, 韩伟, 等. 甘肃国宝山铷矿区土壤地球化学特征研究[J]. 干旱区资源与环境, 2021, 35(05): 101-107 doi: 10.13448/j.cnki.jalre.2021.134
WANG Qiaolin, KONG Mu, HAN Wei, et al. Geochemical characteristics of soil in Guobaoshan rubidium mining area, Gansu province[J]. Journal of Arid Land Resources and Environment, 2021, 35(05): 101-107. doi: 10.13448/j.cnki.jalre.2021.134
[27] 王东, 罗先熔, 韦彦婷, 等, 陕南何家垭地区土壤地球化学特征及找矿预测[J]. 金属矿山, 2020(11): 172-182
WANG Dong, LUO Xianrong, WEI Yanting, et al. Soil Geochemical Characteristics and Prospecting Prediction in Hejiaya Area of Southern Shaanxi[J]. Metal Mine, 2020(11): 172-182.
[28] 谢学锦. 勘查地球化学: 发展史·现状·展望[J]. 地质与勘探, 2002, 38(06): 1-9 doi: 10.3969/j.issn.0495-5331.2002.06.001
XIE Xuejin. Exploration geochemistry: Retrospect and Prospect[J]. Geology and Exploration, 2002, 38(06): 1-9. doi: 10.3969/j.issn.0495-5331.2002.06.001
[29] 谢世强. 西秦岭大桥金矿成矿物质来源及成因探讨[D]. 成都: 成都理工大学, 2018
XIE Shiqiang. Ore Fluids and Metal Sources and Genesis of the Daqiao Gold Deposit, Western Qinling Orogen[D]. Chengdu: Chengdu University of Technology, 2018.
[30] 杨宝荣, 张新铭, 李文君, 等. 青海沟里地区水系沉积物地球化学异常特征及找矿预测[J]. 地质科技情报, 2019, 38(04): 181-192 doi: 10.19509/j.cnki.dzkq.2019.0419
YANG Baorong, ZHANG Xinming, LI Wenjun, et al. Geochemical Characteristics of Stream Sediments and Ore Prospecting Orientation in Gouli Area, Qinghai Province[J]. Geological Science and Technology Information, 2019, 38(04): 181-192. doi: 10.19509/j.cnki.dzkq.2019.0419
[31] 杨明莉, 薛林福, 冉祥金, 等. 智能矿产地质调查方法——以甘肃大桥-崖湾地区为例[J]. 岩石学报, 2021, 37(12): 3880−3892.
YANG Mingli, XUE Linfu, RAN Xiangjin, et al. Intelligent mineral geological survey method: DaqiaoYawan area in Gansu Province as an example[J]. Acta Petrologica Sinica, 2021, 37(12): 3880-3892.
[32] 袁和, 罗先熔, 李武毅, 等. 西藏邦卓玛地区土壤地球化学特征及找矿预测[J]. 地质与勘探, 2017, 53(03): 472-481 doi: 10.13712/j.cnki.dzykt.2017.03.007
YUAN He, LUO Xianrong, LI Wuyi, et al. Geochemical Characteristics of Soil and Prospecting Prediction of the Bangzhuoma Region, Tibet[J]. Geology and Exploration, 2017, 53(03): 472-481. doi: 10.13712/j.cnki.dzykt.2017.03.007
[33] 周叶泽. 甘肃崖湾锑矿床地质地球化学特征及成因探讨[D]. 北京: 中国地质大学, 2020
ZHOU Yeze. Geological and Geochemical Characteristics and Genesis of the Yawan Antimony Deposit in Gansu Province[D]. Beijing: China University of Geosciences, 2020.
[34] 张鹤启, 牛鹏飞, 刘胜江, 等. 甘肃崖湾-大桥整装勘查区石峡幅1∶50000矿产地质调查成果数据库[J]. 中国地质, 2020, 47(S2): 95–121.
ZHANG Heqi, NIU Pengfei, LIU Shengjiang, et al. Database of 1∶50 000 Mineral Geological Survey Resultsof the Shixia Map-sheet in Yawan–Daqiao Integrated Exploration Area, Gansu Province[J]. Geology in China, 2020, 47(S2): 95–121.
[35] 赵欣怡, 罗先熔, 杨笑笑, 等. 河南洛宁石龙山金多金属矿预查区土壤地球化学特征及找矿远景分析[J]. 矿物岩石地球化学通报, 2020, 39(4): 768–778
ZHAO Xinyi, LUO Xianrong, YANG Xiaoxiao, et al. Soil Geochemical Characteristics and Prospecting Potential Analysis of the Shilongshan Au-polymetallic Prospecting Area, Luoning County, Henan Province [J]. Bulletin of Mineralogy Petrology and Geochemistry, 2020, 39(04): 768-778.
[36] 张焱, 成秋明, 周永章, 等. 分形插值在地球化学数据中的应用[J]. 中山大学学报(自然科学版), 2011, 50(01): 133-137
ZHANG Yan, CHENG Qiuming, ZHOU Yongzhang, et al. Assessment of Fractal Interpolation Method in GeochemicalExploration[J]. Acta Scientiarum Naturalium Universitatis Sunyatseni, 2011, 50(01): 133-137.
[37] 张翔, 戴霜, 刘建宏. 甘肃西秦岭金矿成矿与找矿研究[M]. 北京: 地质出版社, 2009
ZHANG Xiang, DAI Shuang, LIU Jianhong. Research on Metallogenesis and Prospecting of Gold Deposit in West Qinling, Gansu[M]. Beijing: Geological Publishing Press, 2009.
[38] 张家瑞, 宿虎, 蒋文, 等. 甘肃崖湾-大桥金锑矿整装勘查区1∶50000矿产资源潜力评价数据集[J]. 中国地质, 2020, 47(S2): 161-192 doi: 10.12029/gc2020Z213
ZHANG Jiarui, SU Hu, JIANG Wen, et al. Dataset of 1∶50000 Mineral Resource Potential Assessment of Gold–Antimony Deposit Integrated Exploration Area in Yawan–Daqiao Area, Gansu Province[J]. Geology in China, 2020, 47(S2): 161-192. doi: 10.12029/gc2020Z213
[39] Cohen D R, Kelley D L, Anand R, et al. Major Advances in Exploration Geochemistry, 1998-2007[J]. Geo-chemistry: Exploration, Environment, Analysis, 2010, 10(1): 3-16. doi: 10.1144/1467-7873/09-215
[40] Liu X C, Wang W L, Pei Y R , et al. A knowledge-driven way to interpret the isometric log-ratio transfor-mation and mixture distributions of geochemical data[J]. Journal of Geochemical Exploration, 2020, 210: 1–9.
[41] Wang J, Zuo R G , Caers J. Discovering geochemicalpatterns by factor-based cluster analysis[J]. Journal of Geochemical Exploration, 2017, 181: 106–115. doi: 10.1016/j.gexplo.2017.07.006
-
