1:5万三维地质填图方法技术在本溪矿集区的应用

详细信息

收稿日期: 2014-09-20

修回日期: 2015-08-07

刊出日期: 2015-08-31

APPLICATION OF 1:50000 THREE-DIMENSIONAL GEOLOGICAL MAPPING METHOD IN BENXI ORE CONCENTRATION AREA

Received Date: 20 September 2014

Revised Date: 07 August 2015

Publish Date: 31 August 2015

摘要: 矿集区三维地质填图是采用1：5万的调查尺度，提交地表地质图及具有一定精度的深部地质图，为圈定含矿建造、控矿构造等主要目标地质要素提供基础地质依据.通过在本溪矿集区开展的三维地质填图工作，认为构造填图是三维地质填图的基础，提出"分级分块"的三维地质建模方法，并总结了矿集区三维地质填图方法技术流程.
- 三维地质填图 /
- 地质信息集成 /
- 地质概念模型 /
- 本溪矿集区 /
- 辽宁省
Abstract: The 3D geological mapping in ore concentration areas adopts the 1:50000 survey scale and submits surface and deep geological maps with certain precision, which provides geological basis for the delineation of main geological targets like ore-bearing formation and ore-controlling structure. With the 3D geological mapping work in Benxi ore concentration area, the authors think that the structural mapping is the basis for 3D geological mapping. The authors also propose the 3D geological modeling method of "grading and blocking", and summarize the 3D geological mapping method and technique process in ore concentration areas.
- 3D geological mapping /
- geological information integration /
- geological conceptual model /
- Benxi ore concentration area /
- Liaoning Province
