SHEAR STRENGTH CHARACTERISTICS OF SOIL IN THE SLIDING ZONE ON HIGHWAY SLOPE IN GUIZHOU PROVINCE
-
摘要:
为了探究公路旁边坡滑带土的强度性质和法向变形性质的变化规律，以贵州山区公路为例，利用环剪仪研究了滑带土在不同含水率和不同法向应力下的抗剪强度特性.结果表明：不同含水率滑带土的峰值强度和残余强度与法向应力间具有良好的线性关系；法向应力越大，试样达到峰值强度所需要的剪切位移也会越大；含水率较高的条件下，滑带土从峰值强度下降到达残余强度期间内，剪应力有增加的趋势；随着含水率的增加，黏聚力呈现增大的趋势，内摩擦角在塑限附近达到峰值，之后逐渐减小.滑带土性质的研究可为公路旁滑坡识别与预防提供科学依据.
Abstract:To explore the change rule of strength and normal deformation properties of soil in the sliding zone on highway slopes, taking the mountainous highway in Guizhou Province as an example, the paper studies the shear strength characteristics of sliding zone soil under different water content and normal stress by ring shear apparatus. The results show that there is a good linear relation between the peak strength and residual strength of sliding zone soil with different water content and the normal stress. The larger the normal stress is, the larger the shear displacement required for the specimen to reach the peak strength will be. Under the condition of high water content, the shear stress tends to increase when the sliding zone soil decreases from peak strength to residual strength. With the increase of water content, the cohesion shows an increasing trend, and the internal friction angle reaches the peak near the plastic limit and then gradually decreases. The study on the properties of sliding zone soil will provide scientific basis for the identification and prevention of highway landslides.
-
Key words:
- landslide /
- ring shear test /
- sliding zone soil /
- moisture content /
- normal stress /
- shear strength /
- Guizhou Province
-
-
表 1 滑带土基本物理性质
Table 1. Basic physical properties of sliding zone soil
密度/g·cm-3 液限/% 天然含水率/% 比重(GS) 塑限/% 塑性指数/% 干密度/g·cm-3 1.30 52.89 40.05 2.57 38.74 14.15 0.77
下载: 导出CSV
表 2 滑带土环剪试验方案
Table 2. Ring shear test scheme of sliding zone soil
含水率ω/% 法向应力σ/kPa 试样编号 36 20, 50, 80 A-1, A-2, A-3 40 20, 50, 80 B-1, B-2, B-3 44 20, 50, 80 C-1, C-2, C-3
下载: 导出CSV
表 3 不同含水率滑带土的黏聚力与内摩擦角参数值
Table 3. Parameters of cohesion and internal friction angle of sliding zone soil with different water content
含水率/% CP/kPa φp/(°) Cr/kPa φr/(°) 36 137.14 52.17 129.13 47.47 40 173.01 33.45 148.23 41.10 44 199.67 28.01 182.97 30.49
下载: 导出CSV
-
[1] 刘伟. 我国地质灾害调查统计与分析[J]. 采矿技术, 2021, 21(5): 100-103. https://www.cnki.com.cn/Article/CJFDTOTAL-SJCK202105029.htm
Liu W. Investigation statistics and analysis of geological hazards in China[J]. Mining Technology, 2021, 21(5): 100-103. (in Chinese) https://www.cnki.com.cn/Article/CJFDTOTAL-SJCK202105029.htm
[2] 郑伟, 王中美. 贵州喀斯特地区降雨强度对土壤侵蚀特征的影响[J]. 水土保持研究, 2016, 23(6): 333-339. https://www.cnki.com.cn/Article/CJFDTOTAL-STBY201606057.htm
Zheng W, Wang Z M. Laboratorial simulation influences of different rainfall intensities on soil erosion in karst area, China[J]. Research of Soil and Water Conservation, 2016, 23(6): 333-339. https://www.cnki.com.cn/Article/CJFDTOTAL-STBY201606057.htm
[3] 杨玲, 张柳金, 吴青波. 降雨型红层滑坡形成机理研究[J]. 地质与资源, 2021, 30(4): 485-491, 520. http://manu25.magtech.com.cn/Jweb_dzyzy/CN/abstract/abstract10320.shtml
Yang L, Zhang L J, Wu Q B. Formation mechanism of rainfall-induced redbed landslide[J]. Geology and Resources, 2021, 30(4): 485-491, 520. http://manu25.magtech.com.cn/Jweb_dzyzy/CN/abstract/abstract10320.shtml
[4] 孙萍萍, 张茂省, 江睿君, 等. 降雨诱发浅层黄土滑坡变形破坏机制[J]. 地质通报, 2021, 40(10): 1617-1625. https://www.cnki.com.cn/Article/CJFDTOTAL-ZQYD202110003.htm
Sun P P, Zhang M S, Jiang R J, et al. Deformation and failure mechanism of rainfall-induced shallow loess landslide[J]. Geological Bulletin of China, 2021, 40(10): 1617-1625. https://www.cnki.com.cn/Article/CJFDTOTAL-ZQYD202110003.htm
[5] Vithana S B, Nakamura S, Gibo S, et al. Correlation of large displacement drained shear strength of landslide soils measured by direct shear and ring shear devices[J]. Landslides, 2012, 9(3): 305-314. doi: 10.1007/s10346-011-0301-9
[6] Wang C X, Yamasaki H, Watanabe N, et al. Analysis of failure mechanics of the 2012 Kokugawa landslide caused by snowmelt, Niigata Prefecture[J]. Journal of the Japan Landslide Society, 2016, 53(2): 50-57. doi: 10.3313/jls.53.50
[7] 汤文, 姚志宾, 李邵军, 等. 水化学作用对滑坡滑带土的物理力学特性影响试验研究[J]. 岩土力学, 2016, 37(10): 2885-2892. https://www.cnki.com.cn/Article/CJFDTOTAL-YTLX201610020.htm
Tang W, Yao Z B, Li S J, et al. Effect of pore water chemistry on physical and mechanical properties of sliding-zone soil: An experimental study[J]. Rock and Soil Mechanics, 2016, 37(10): 2885-2892. https://www.cnki.com.cn/Article/CJFDTOTAL-YTLX201610020.htm
[8] 赵利云, 张茂省, 孙萍萍, 等. 基于原位监测的浅层黄土斜坡水分运移规律分析[J]. 地质与资源, 2021, 30(4): 492-498. http://manu25.magtech.com.cn/Jweb_dzyzy/CN/abstract/abstract10321.shtml
Zhao L Y, Zhang M S, Sun P P, et al. Analysis of water movement law in shallow loess slope based on in-situ monitoring[J]. Geology and Resources, 2021, 30(4): 492-498. http://manu25.magtech.com.cn/Jweb_dzyzy/CN/abstract/abstract10321.shtml
[9] 赵志强. 含水量对黄土强度特性影响的研究[D]. 郑州: 华北水利水电大学, 2016.
Zhao Z Q. Influence of moisture content on shear strength of loess[D]. Zhengzhou: North China University of Water Resources and Electric Power, 2016.
[10] 赵晓铭, 李锦辉. 降雨诱发滑坡的实时概率分析[J]. 地下空间与工程学报, 2012, 8(S2): 1690-1694. https://www.cnki.com.cn/Article/CJFDTOTAL-BASE2012S2013.htm
Zhao X M, Li J H. Real-time probability analysis of rainfall-induced landslide[J]. Chinese Journal of Underground Space and Engineering, 2012, 8(S2): 1690-1694. https://www.cnki.com.cn/Article/CJFDTOTAL-BASE2012S2013.htm
[11] 任三绍, 郭长宝, 张永双, 等. 川西巴塘茶树山滑坡发育特征及形成机理[J]. 现代地质, 2017, 31(5): 978-989. https://www.cnki.com.cn/Article/CJFDTOTAL-XDDZ201705009.htm
Ren S S, Guo C B, Zhang Y S, et al. Development characteristics and formation mechanism of Chashushan landslide in Batang, western Sichuan[J]. Geoscience, 2017, 31(5): 978-989. https://www.cnki.com.cn/Article/CJFDTOTAL-XDDZ201705009.htm
[12] 张怡颖, 郭长宝, 杨志华, 等. 四川茂县周场坪深层滑坡滑带土环剪试验强度研究[J]. 工程地质学报, 2021, 29(3): 764-776. https://www.cnki.com.cn/Article/CJFDTOTAL-GCDZ202103019.htm
Zhang Y Y, Guo C B, Yang Z H, et al. Study on shear strength of deep-seated sliding zone soil of Zhouchangping landslide in Maoxian, Sichuan[J]. Journal of Engineering Geology, 2021, 29(3): 764-776. https://www.cnki.com.cn/Article/CJFDTOTAL-GCDZ202103019.htm
[13] Bao H, Qi Q, Lan H X, et al. Sliding mechanical properties of fault gouge studied from ring shear test-based microscopic morphology characterization[J]. Engineering Geology, 2020, 279: 105879.
[14] 刘虎虎, 缪海波, 陈志伟, 等. 含水率和离子浓度对滑带土抗剪强度的影响[J]. 地质科技情报, 2019, 38(1): 228-234. https://www.cnki.com.cn/Article/CJFDTOTAL-DZKQ201901025.htm
Liu H H, Miao H B, Chen Z W, et al. Effect of water content and ion concentration on shear strength of sliding zone soil[J]. Geological Science and Technology Information, 2019, 38(1): 228-234. https://www.cnki.com.cn/Article/CJFDTOTAL-DZKQ201901025.htm
[15] 范志强, 唐辉明, 谭钦文, 等. 滑带土环剪试验及其对水库滑坡临滑强度的启示[J]. 岩土工程学报, 2019, 41(9): 1698-1706. https://www.cnki.com.cn/Article/CJFDTOTAL-YTGC201909016.htm
Fan Z Q, Tang H M, Tan Q W, et al. Ring shear tests on slip soils and their enlightenment to critical strength of reservoir landslides[J]. Chinese Journal of Geotechnical Engineering, 2019, 41(9): 1698-1706. https://www.cnki.com.cn/Article/CJFDTOTAL-YTGC201909016.htm
[16] 谢强, 张国栋, 胡学文, 等. 饱和粉质黏土残余强度剪切速率效应试验研究[J]. 三峡大学学报(自然科学版), 2019, 41(1): 52-55. https://www.cnki.com.cn/Article/CJFDTOTAL-WHYC201901013.htm
Xie Q, Zhang G D, Hu X W, et al. Experimental researches on residual strength of saturated silty clay at different shear rates[J]. Journal of China Three Gorges University (Natural Sciences), 2019, 41(1): 52-55. https://www.cnki.com.cn/Article/CJFDTOTAL-WHYC201901013.htm
[17] 陈洁, 雷学文, 孟庆山, 等. 重塑红棕色玄武岩残积土的残余强度试验研究[J]. 人民长江, 2016, 47(7): 86-90. https://www.cnki.com.cn/Article/CJFDTOTAL-RIVE201607019.htm
Chen J, Lei X W, Meng Q S, et al. Study of residual strength test on remodeling reddish brown basalt residual soil[J]. Yangtze River, 2016, 47(7): 86-90. https://www.cnki.com.cn/Article/CJFDTOTAL-RIVE201607019.htm
[18] 谢辉辉, 刘清秉, 胡桂阳. 基于环剪试验的滑带土抗剪强度特性研究[J]. 人民长江, 2018, 49(11): 108-113. https://www.cnki.com.cn/Article/CJFDTOTAL-RIVE201811021.htm
Xie H H, Liu Q B, Hu G Y. Research on shear strength characteristics of slide soil based on ring-shear test[J]. Yangtze River, 2018, 49(11): 108-113. https://www.cnki.com.cn/Article/CJFDTOTAL-RIVE201811021.htm
[19] 李姝, 张立展, 许强, 等. 基于环剪试验的黄土完全软化强度研究[J]. 人民长江, 2015, 46(21): 84-87. https://www.cnki.com.cn/Article/CJFDTOTAL-RIVE201521021.htm
Li S, Zhang L Z, Xu Q, et al. Research on fully softened strength of loess based on ring shear tests[J]. Yangtze River, 2015, 46(21): 84-87. https://www.cnki.com.cn/Article/CJFDTOTAL-RIVE201521021.htm
[20] 王炜, 骆亚生. 重塑黄土抗剪强度的环剪试验研究[J]. 水土保持通报, 2017, 37(5): 110-113, 122. https://www.cnki.com.cn/Article/CJFDTOTAL-STTB201705019.htm
Wang W, Luo Y S. Experimental study on shear strength of remolded loess by ring shear test[J]. Bulletin of Soil and Water Conservation, 2017, 37(5): 110-113, 122. https://www.cnki.com.cn/Article/CJFDTOTAL-STTB201705019.htm
-
