Geochemical Characteristics of Rare Earth and Heavy Metal Elements in Ion-type Rare Earth Mining Area and Surrounding Soil
-
摘要:
20世纪60年代末中国离子型稀土矿在江西赣州首次发现并开采,在长期开采过程中对矿区及周边水土的生态环境问题产生了持续影响,本文选择赣南足洞离子型稀土矿及其周边地区进行了系统的土壤地球化学调查和风险评价。结果表明,土壤中重稀土含量明显高于轻稀土,其中Y含量是全国背景值(22.90 μg/g)的7.2倍,占比最高;地累积指数评价Igeo均值显示HREE和Sm分别有77.44%和99.55%为无污染至中等污染,95.92%的LREE为无污染;重金属除Pb处于轻度-中等污染水平外,As、Cd、Cr、Cu、Hg、Zn、Ni元素均为无污染,与农用地污染风险筛选值相比,样品中重金属的超标率为7.35%,区内土壤重金属生态风险低。统计结果显示稀土含量与重金属污染具有较好的相关性,花岗岩风化壳地质背景对稀土、重金属Pb的控制占主导地位,意味着重稀土含量越高,Pb污染可能越大,因此,在矿山土壤修复中需重视Pb元素的地球化学特征与分布,采用合理的修复技术和手段。
Abstract:In the late 1960s, China's ion-type rare earth ore was first discovered and mined in Ganzhou, Jiangxi Province. In the long-term mining process, it has a continuous impact on the ecological environment of the mining area and the surrounding water and soil. In this paper, the soil geochemical survey and risk assessment of the ion-type rare earth ore in Southern Jiangxi Province and its surrounding areas were carried out.The results showed that the content of heavy rare earth in soil was significantly higher than that of light rare earth, and the content of Y was 7.2 times of the national background value (22.90 μg/g), accounting for the highest proportion.The Igeo mean of geo-accumulation index evaluation showed that 77.44% of HREE and 99.55% of Sm were non-pollution to medium pollution, and 95.92% of LREE was non-pollution.Except for Pb at mild to moderate pollution levels, As, Cd, Cr, Cu, Hg, Zn and Ni were all non-polluting. Compared with the pollution risk screening value of agricultural land, the exceeding rate of heavy metals in the samples was 7.35%, and the ecological risk of heavy metals in the soil was low.The statistical results show that there is a good correlation between rare earth content and heavy metal pollution. The geological background of granite weathering crust dominates the control of rare earth and heavy metal Pb, which means that the higher the content of heavy rare earth is, the greater the Pb pollution may be. Therefore, it is necessary to pay attention to the geochemical characteristics and distribution of Pb elements in mine soil remediation, and adopt reasonable remediation technologies and means.
-
Key words:
- ion-type rare earth ore /
- heavy metals /
- geo-accumulation index /
- Ganzhou /
- geochemical characteristics
-
-
表 1 地累积指数(Igeo)级别划分
Table 1. Classification for index of geo-accumulation
地累积指数(Igeo) 分级 污染程度 Igeo≤0 0 无污染 0 < Igeo≤1 1 轻度—中等污染 1 < Igeo≤2 2 中等污染 2 < Igeo≤3 3 中等—强污染 3 < Igeo≤4 4 强污染 4 < Igeo≤5 5 强—极严重污染 5 < Igeo≤10 6 极严重污染 表 2 足洞矿区及周边土壤中稀土元素含量统计
Table 2. Statistics of rare earth elements in soil and surrounding area of Zudong mining area
元素 最小值 最大值 平均值 中位数 标准差 变异系数 江西表层土壤背景值 全国土壤背景值 La 0 279.09 23.16 20.36 23.11 1 45.00 39.7 Ce 0 338.25 42.55 37.97 37.12 0.87 79.9 68.4 Pr 1.14 56.07 8.69 8.26 3.86 0.44 10.34 7.17 Nd 5.79 195.62 39.35 39.54 14.51 0.37 33.33 26.4 Sm 2.48 99.81 15.74 16.28 7.34 0.47 6.64 5.22 Eu 0 6.04 0.61 0.5 0.67 1.1 1.02 1.03 Gd 1.98 134.17 19.97 20.69 10.52 0.53 6.01 4.6 Tb 0.33 29.1 4.23 4.41 2.44 0.58 0.9 0.63 Dy 2.01 197.81 28.96 29.81 17.01 0.59 6.27 4.13 Ho 0.4 38.26 5.83 6.1 3.43 0.59 1.22 0.87 Er 1.22 108.9 16.23 16.95 9.55 0.59 3.9 2.54 Tm 0.22 20.03 2.72 2.84 1.63 0.6 0.49 0.37 Lu 0.28 22.98 2.71 2.81 1.67 0.62 0.51 0.36 Y 8.37 1091.77 164.92 171.5 98.84 0.6 34.2 22.9 ∑REE 86.64 2512.59 392.19 401.71 163.72 0.42 228.9 187.6 LREE 41.89 834.04 130.1 119.27 71.14 0.55 176.12 143.2 HREE 16.41 1781.96 262.09 273.77 155.01 0.59 55.88 37.2 $\frac{{LREE}}{{HREE}}$ 0.14 5.02 0.96 0.46 1.13 1.18 - - 注:元素含量单位为μg/g,∑REE为不含Pm、Sc的15个稀土元素的总量,LREE为轻稀土元素La~Eu,HREE为Gd~Lu+Y,全国土壤背景和江西省土壤背景参考《中国土壤元素背景值》[32]。 表 3 足洞矿区及周边土壤中重金属含量统计
Table 3. Statistics of heavy metal contents in soil and surrounding area of Zudong mining area
元素 最小值 最大值 平均值 中位数 标准差 变异系数 赣州市表层土壤背景值 江西省表层土壤背景值 样品数 Cd 0.02 1.12 0.13 0.09 0.13 0.98 0.09 0.11 449 Hg 0.00 3.92 0.09 0.06 0.28 3.14 0.06 0.08 As 0.85 81.24 8.55 5.45 10.04 1.17 8.85 14.90 Pb 12.01 2 164.00 83.60 54.14 116.95 1.40 34.19 32.30 Cr 2.31 688.00 46.97 28.70 61.49 1.31 34.56 45.90 Cu 2.04 129.76 18.90 13.93 17.06 0.90 15.17 20.30 Ni 0.59 334.22 18.46 9.97 27.26 1.48 12.35 18.90 Zn 18.83 198.60 82.66 80.09 29.90 0.36 58.05 69.40 注:元素含量单位为μg/g。 表 4 重金属元素地累积指数分级频率分布表
Table 4. Graded frequency distribution table of geo-accumulation index of heavy metals
分级 地累积指数 污染程度 As Cd Cr Cu Hg Pb Zn Ni 0 Igeo≤0 无污染 93.32 77.51 74.16 77.73 89.31 46.33 69.49 78.84 1 0 < Igeo≤1 轻度-中等污染 4.68 17.15 22.05 20.27 9.13 23.39 29.40 16.93 2 1 < Igeo≤2 中等污染 2.00 3.56 2.45 1.78 1.56 24.28 1.11 3.12 3 2 < Igeo≤3 中等-强污染 0.00 1.78 1.11% 0.22 0.00 5.57 0.00 0.89 4 3 < Igeo≤4 强污染 0.00 0.00 0.22 0.00 0.00 0.22 0.00 0.22 5 4 < Igeo≤5 强-极严重污染 0.00 0.00 0.00 0.00 0..00 0.00 0.00 0.00 6 5 < Igeo≤10 极严重污染 0.00 0.0 0.00 0.00 0.00 0.0 0.00 0.00 注:元素单位为百分比(%)。 表 5 华南地区不同时期花岗岩重金属元素平均含量[42]
Table 5. Average content of heavy metal elements in granite of South China in different periods
元素 加里东期 海西期 印支期 燕山期 Pb/(μg·g-1) 37 36 78 54 表 6 中国不同构造单元花岗岩类的元素丰度
Table 6. Element abundance of granitoids in different tectonic units in China
单元 Nc Ns Pb/(μg·g-1) 华南-右江造山带 172 1220 32 天山-兴安造山系 138 1259 19 中朝准地台 196 1883 23 昆仑-祁连-秦岭造山带 94 716 28 滇藏造山系 68 343 22 扬子准地台 89 643 27 喜马拉雅造山带 10 15 17 注:数据引自史长义等[43],2007。Nc为组合样数,Ns为采集样品数。 -
