Microwave Preparation of Expanded Vermiculite and Its Application in Building Energy Saving and Reducing CO2 Emission
-
摘要:
基于蛭石结构层水分子遇热瞬间汽化导致体积快速膨胀的特点，采用微波法和微波化学法对工业蛭石进行加热膨胀处理制备不同粒径的膨胀蛭石，研究了模压成型和浇注成型工艺制作膨胀蛭石/石膏基复合保温板的力学和热学等性能，评价了膨胀蛭石保温材料在建筑内墙和热工管道保温的节能效果。结果表明：以微波化学法制备的膨胀蛭石为骨料制作的保温板具有更小的密度和导热系数（0.082 W·m-1·K-1），含水率稍高；膨胀蛭石/石膏复合保温板的密度、导热系数和抗压强度随膨胀蛭石的片径增大而减小；在冬季室外平均气温为7℃条件下，与内墙和管道未增加保温层相比，节能保温样板和管道保温样板节能效率都稳定在20%，在建筑节能领域具有广阔的应用前景。
Abstract:Based on the characteristics of rapid volume expansion caused by instantaneous vaporization of water molecules in vermiculite structural layer when exposed to heat, the industrial vermiculite was heated and expanded by microwave method and microwave chemical method to prepare expanded vermiculite with different particle sizes; The mechanical and thermal properties of expanded vermiculite/gypsum-based composite insulation board made by mold pressing and casting molding were studied; evaluate the energy-saving effect of expanded vermiculite thermal insulation material in building interior wall and thermal pipeline. The results show that The thermal insulation board made of expanded vermiculite prepared by microwave method as aggregate has lower density and thermal conductivity (0.082 W/(m·k)), and slightly higher moisture content; The density, thermal conductivity and compressive strength of expanded vermiculite/gypsum composite insulation board will decrease with the increase of expanded vermiculite sheet diameter; Under the condition that the average outdoor temperature in winter is 7℃, the energy-saving heat preservation template and pipeline heat-preservation template can save electricity by 20% stably, which have a broad application prospects in the field of building energy conservation.
-
-
表 1 膨胀蛭石的工艺性能
Table 1. Properties of expanded vermiculite
制备方法 编号 片径/mm 堆积密度/(kg·m-3) 含水率/% 导热系数/(W·m-1·K-1) 微波法 Sm 0.5~1 472.30 2.30 0.112 Bm 2~4 241.82 2.45 0.092 微波化学法 Smc 0.5~1 146.66 3.06 0.062 Bmc 2~4 80.60 3.56 0.060
下载: 导出CSV
表 2 膨胀蛭石/石膏保温板的抗压强度
Table 2. Compressive strength of expanded vermiculite/gypsum insulation boards
烧石膏/膨胀蛭石质量比 P-Sm /MPa P-Bm /MPa P-Smc /MPa P-Bmc /MPa C-Sm /MPa C-Bm /MPa 0.4 0.47 0.32 0.20 0.18 0.64 0.52 0.5 0.69 0.34 0.27 0.19 0.86 0.75 0.6 0.99 0.39 0.36 0.20 1.18 0.98 0.8 1.17 0.43 0.43 0.21 1.41 1.20 1.1 1.45 0.67 0.50 0.24 1.65 1.43 1.3 1.76 1.02 0.67 0.27 2.02 1.66 1.5 1.92 1.49 0.77 0.37 2.38 1.85
下载: 导出CSV
-
[1] 臧鑫宇, 王峤, 李含嫣. "双碳"目标下的生态城市发展战略与实施路径[J]. 科技导报, 2022, 40(6): 30-37. https://www.cnki.com.cn/Article/CJFDTOTAL-KJDB202206004.htm
ZANG X Y, WANG Q, LI H Y. Eco-city development strategy and implementation under the target of carbon peaking and carbon neutrality?[J]. Science & Technology Review, 2022, 40(6): 30-37. https://www.cnki.com.cn/Article/CJFDTOTAL-KJDB202206004.htm
[2] 彭同江, 孙红娟, 罗利明, 等. 工业蛭石的矿物学属性及在"双碳"战略中的作用[J]. 矿产保护与利用, 2021, 41(6): 1-8. http://kcbh.cbpt.cnki.net/WKD/WebPublication/paperDigest.aspx?paperID=270a939b-ed69-49f1-beaf-613d7a9859bc
PENG T J, SUN H J, LUO L M. The mineralogical properties of industrial vermiculite and its role in the srategy of saving energy and reducing CO2 emission[J]. Conservation and Utilization of Mineral Resources, 2021, 41(6): 1-8. http://kcbh.cbpt.cnki.net/WKD/WebPublication/paperDigest.aspx?paperID=270a939b-ed69-49f1-beaf-613d7a9859bc
[3] A. G, A. Y, S. D, et al. Effect of expanded vermiculite and expanded perlite as pore forming additives on the physical properties and thermal conductivity of porous clay bricks[J]. Journal of Chemical Technology and Metallurgy, 2018, 53(2).
[4] 潘兆橹. 结晶学及矿物学[M]. 北京: 地质出版社, 1993.
PAN Z L. Crystallography and Mineralogy[M]. Beijing: Geological Press, 1993.
[5] SONG W, WANG M, LIU S, et al. Preparation and properties of rigid polyurethane/expanded vermiculite composite thermal insulation material[J]. Engineering Plastics Application, 2019.
[6] NIGMATULLINA A I, GALIMZYANOVA R Y, YU N K, et al. Sound-absorbing polymer composite materials for construction purposes[J]. IOP Conference Series Materials Science and Engineering, 2020, 753: 52027.
[7] 方小林. 膨胀蛭石复合阻燃保温材料的制备与性能研究[D]. 天津: 天津工业大学, 2016.
FANG X L. Preparation and properties of expanded vermiculite composite flame retardant thermal insulation materials[D]. Tianjin: Tianjin Polytechnic University, 2016.
[8] 薛韩玲, 郭佩奇, 彭俊杰, 等. 高地温掘进巷水玻璃膨胀蛭石隔热围岩传热与降温特性[J]. 西安科技大学学报, 2021, 41(6): 997-1005. https://www.cnki.com.cn/Article/CJFDTOTAL-XKXB202106004.htm
XUE H L, GUO P Q, PENG J J, et al. Characteristics of airflow temperature decline and heat transfer from surrounding rock of digging tunnel insulated by waterglass/expanded vermiculite in high temperature mine[J]. Journal of Xi'an University of Science and Technology, 2021, 41(6): 997-1005. https://www.cnki.com.cn/Article/CJFDTOTAL-XKXB202106004.htm
[9] 刘文, 陈朝阳, 闫世友. 耐水性膨胀蛭石板材的研制[J]. 应用化工, 2011, 40(6): 993-996. https://www.cnki.com.cn/Article/CJFDTOTAL-SXHG201106019.htm
LIU W, CHEN Z Y, YAN S Y. Development of water-resistance expanded vermiculite board[J]. Applied Chemical Industry, 2011, 40(6): 993-996. https://www.cnki.com.cn/Article/CJFDTOTAL-SXHG201106019.htm
[10] 方小林, 宋俊, 郑云波, 等. 膨胀蛭石/酚醛阻燃保温复合材料的制备及性能[J]. 复合材料学报, 2016, 33(11): 2426-2435. https://www.cnki.com.cn/Article/CJFDTOTAL-FUHE201611004.htm
FANG X L, SONG J, ZHEN Y B, et al. Preparation and performance of expanded vermiculite/phenolic flame retardant and insulation composites[J]. Acta Materiae Compositae Sinica, 2016, 33(11): 2426-2435. https://www.cnki.com.cn/Article/CJFDTOTAL-FUHE201611004.htm
[11] 余剑英, 魏连启, 曹献坤, 等. 有机蛭石/酚醛树脂熔融插层纳米复合材料的研究[J]. 材料工程, 2004(4): 20-23. https://www.cnki.com.cn/Article/CJFDTOTAL-CLGC200404004.htm
YU J Y, WEI L Q, CAO X K, et al. Organized vermiculite/phenolic resin nanocomposites prepared by melt intercalation[J]. Journal of Materials Engineering, 2004(4): 20-23. https://www.cnki.com.cn/Article/CJFDTOTAL-CLGC200404004.htm
[12] 江甜甜. 聚酰亚胺泡沫的制备及其改性研究[D]. 绵阳: 西南科技大学, 2020.
JIANG T T. Preparation and modification of polyimide foam[D]. Mianyang: Southwest University of Science and Technology, 2020.
[13] 高欢. 珍珠岩基多孔地质聚合物保温材料制备及其传热机理[D]. 北京: 中国地质大学, 2021.
GAO H. Preparation and heat transfer mechanism of perlite-based porous geopolymer thermal insulation materials[D]. Beijing: China University of Geosciences, 2021.
[14] 王正洲, 杨婷. 膨胀蛭石包覆聚苯乙烯发泡颗粒/水泥复合泡沫材料的制备及性能[J]. 高等学校化学学报, 2018, 39(5): 1098-1104. https://www.cnki.com.cn/Article/CJFDTOTAL-GDXH201805038.htm
WANG Z Z, YANG T. Preparation and properties of expanded vermiculite coated expanded polystyrene/cement composite foams[J]. Chemical Journal of Chinese Universities, 2018, 39(5): 1098-1104. https://www.cnki.com.cn/Article/CJFDTOTAL-GDXH201805038.htm
[15] 罗斌, 黄炜, 马相, 等. 采用发泡聚苯乙烯保温砂浆芯材的夹芯叠合板受弯性能[J]. 浙江大学学报(工学版), 2019, 53(11): 2185-2196. https://www.cnki.com.cn/Article/CJFDTOTAL-ZDZC201911017.htm
LUO B, HUANG W, MA X, et al. Flexural behavior of sandwich composite panels with core material of expanded polystyrene thermal insulation motar[J]. Journal of Zhejiang University(Engineering Edition), 2019, 53(11): 2185-2196. https://www.cnki.com.cn/Article/CJFDTOTAL-ZDZC201911017.htm
[16] 刘卓, 赵志曼, 吴磊, 等. 膨胀蛭石对石膏制品性能影响研究[J]. 非金属矿, 2020, 43(1): 52-54. https://www.cnki.com.cn/Article/CJFDTOTAL-FJSK202001014.htm
LIU Z, ZHAO Z M, WU L, et al. Study on the effect of expanded vermiculite on the properties of gypsum products[J]. Non-Metallic Mines, 2020, 43(1): 52-54. https://www.cnki.com.cn/Article/CJFDTOTAL-FJSK202001014.htm
[17] 习永广, 彭同江. 膨胀蛭石/石膏复合保温材料的制备与表征[J]. 复合材料学报, 2011, 28(5): 156-161. https://www.cnki.com.cn/Article/CJFDTOTAL-FUHE201105026.htm
XI Y G, PENG T J. Preparation and characterization of expanded vermiculite/gypsum thermal insulation composites[J]. Acta Materiae Compositae Sinica, 2011, 28(5): 156-161. https://www.cnki.com.cn/Article/CJFDTOTAL-FUHE201105026.htm
[18] XI Y G, PENG T J, LIU H F, et al. Preparation and properties of expanded vermiculite/gypsum thermal insulation boards[J]. Advanced Materials Research, 2010, 178: 220-225.
[19] 管柏伦. 新型轻质低导热地聚合物材料高温性能研究[D]. 昆明: 昆明理工大学, 2021.
GUAN B L. Research on high temperature performance of new lightweight and low thermal conductivity geopolymer materials[D]. Kunming: Kunming University of Science and Technology, 2021.
[20] 管亚斐. 储热混凝土制备及热性能研究[D]. 南京: 东南大学, 2020.
GUAN Y F. Preparation and thermal properties of heat storage concrete[D]. Nanjing: Southeast University, 2020.
[21] 廖仕雄, 赵志曼, 张晖, 等. 储能磷建筑石膏基的制备与性能研究[J]. 非金属矿, 2021, 44(4): 53-57. https://www.cnki.com.cn/Article/CJFDTOTAL-FJSK202104016.htm
LIAO S X, ZHAO Z M, ZHANG H, et al. Study on preparation and properties of phosphorus building gypsum base for energy storage[J]. Non-Metallic Mines, 2021, 44(4): 53-57. https://www.cnki.com.cn/Article/CJFDTOTAL-FJSK202104016.htm
[22] RASHAD, ALAA M. Vermiculite as a construction material-a short guide for civil engineer[J]. Construction & Building Materials, 2016, 125: 53-62.
[23] 周国富, 杨新生. 膨胀蛭石防火板的性能及用途[J]. 新型建筑材料, 2009, 36(12): 3. https://www.cnki.com.cn/Article/CJFDTOTAL-XXJZ200912028.htm
ZHOU G F, YANG X S. Properties and application of vermiculite fireproof board[J]. New Building Materials, 2009, 36(12): 3. https://www.cnki.com.cn/Article/CJFDTOTAL-XXJZ200912028.htm
[24] 张焜, 程胜高. 膨胀蛭石的性质及其应用前景[J]. 矿物岩石地球化学通报, 2007(z1): 584-585. https://cpfd.cnki.com.cn/Article/CPFDTOTAL-ZGKD200704001286.htm
ZHANG K, CHENG S G. Properties and application prospects of expanded vermiculite[J]. Bulletin of Mineralogy Petrology and Geochemistry, 2007(z1): 584-585. https://cpfd.cnki.com.cn/Article/CPFDTOTAL-ZGKD200704001286.htm
[25] 刘福生, 彭同江, 张宝述. 膨胀蛭石的利用及其新进展[J]. 非金属矿, 2001(4): 2-4. https://www.cnki.com.cn/Article/CJFDTOTAL-FJSK200104000.htm
LIU F S, PENG T J, ZHANG B S. Utilization of expanded vermiculite and its new progression[J]. Non-metallic Mines, 2001(4): 2-4. https://www.cnki.com.cn/Article/CJFDTOTAL-FJSK200104000.htm
-
