微波消解-双浊点萃取ICP-MS测定地球化学样品中的痕量铂钯钌铑

沈宇; 张尼; 高小红; 李展; 李日升; 郑建斌

doi:10.15898/j.cnki.11-2131/td.2016.03.007

微波消解-双浊点萃取ICP-MS测定地球化学样品中的痕量铂钯钌铑

1.
西安西北有色地质研究院有限公司, 陕西西安 710054

2.
西北大学分析科学研究所, 陕西省电分析化学重点实验室, 陕西西安 710069

基金项目:
陕西省科技计划项目(2015KJXX-81);陕西省工业科技攻关项目(2015GY54)

详细信息

作者简介: 沈宇,在读博士研究生,工程师,从事无机元素分析和方法研究工作。E-mail:shenyusherry@163.com

通讯作者: 郑建斌,博士生导师,教授,从事电化学分析研究。E-mail:zhengjb@nwu.edu.cn

中图分类号: O657.63;O614.82

收稿日期: 2015-11-26

修回日期: 2016-04-28

录用日期: 2016-05-20

Determination of Pt, Pd, Ru, Rh in Geochemical Samples by ICP-MS with Microwave Digestion and Dual-cloud Point Extraction

1.
Xi'an Northwest Geological Research Institute for Nonferrous Metals, Xi'an 710054, China

2.
Institute of Analytical Science, Northwest University, Shannxi Provincal Key Laboratory of Electroanalytical Chemistry, Xi'an 710069, China

More Information

Corresponding author: Jian-bin ZHENG, zhengjb@nwu.edu.cn

Received Date: 26 November 2015

Revised Date: 28 April 2016

Accepted Date: 20 May 2016

摘要

摘要: 传统浊点萃取技术是将待测元素富集在黏稠的表面活性剂相中,溶液的黏度会对等离子体检测信号产生影响,通常使用甲醇作为稀释剂降低有机相黏度,有机成分也对等离子体的稳定性产生影响,同时有机物在进样管路上的吸附还会提高待测元素的记忆效应,因而限制了ICP-MS在浊点萃取中的应用。本文建立了双浊点萃取技术ICP-MS测定地球化学样品中铂钯钌铑的分析方法。样品用微波消解处理后,以DDTP为螯合剂,Triton X-114为表面活性剂,对消解溶液第一次浊点萃取,再在有机相中加入硝酸,通过加热完成第二次浊点萃取,使铂钯钌铑由有机相进入水相,铂钯钌铑的富集因子分别为45、33、18和35,高于单次浊点萃取的富集因子,ICP-MS检出限分别为0.05、0.02、0.10和0.03μg/L。本方法通过两次浊点萃取过程实现了基体复杂的地球化学样品中痕量铂族元素的同时富集,提高了ICP-MS的稳定性。
- 地球化学样品 /
- 铂族元素 /
- 双浊点萃取 /
- 有机相 /
- 水相 /
- 电感耦合等离子体质谱法
Abstract: Traditional cloud point extraction methods commonly enrich elements in the viscous surfactant. However, the viscosity of the solution will adversely affect the detection signal of the plasma. Harmful agents such as methanol are usually adopted as a thinner to reduce the viscosity of the organic phase, but the organic component affects the stability of the plasma, and organic absorption on the injection tube will enhance elemental memory effect. These disadvantages limit the widespread application of Inductively Coupled Plasma-Mass Spectrometry (ICP-MS) in cloud point extraction. A method to determine Pt, Pd, Ru, Rh in geochemical samples by ICP-MS based dual-cloud point extraction has been established, and is reported in this paper. After the microwave digestion procedure, first cloud point extraction is performed on the sample solution using DDTP as the sequestrant and Triton X-114 as the surfactant. HNO₃ is added into the organic phase, and second cloud point extraction is performed by heating so that Pt, Pd, Ru, Rh enter the water phase from the organic phase. Enrichment factors are 45, 33, 18, 35, and detection limits are 0.05, 0.02, 0.10 and 0.03 μg/L for Pt, Pd, Ru and Rh, respectively. The proposed method succeeds in the simultaneous enrichment of trace platinum group elements in complex matrix geochemical samples, improving the stability of the ICP-MS measurement.
- geochemical samples /
- platinum group elements /
- dual-cloud point extraction /
- organic phase /
- aqueous phase /
- Inductively Coupled Plasma-Mass Spectrometry

HTML全文

图 1 不同浓度的硝酸对各金属离子萃取的影响

Figure 1.

下载: 全尺寸图片幻灯片

表 1 本文方法与其他方法对比

Table 1. Comparison of analytical results of PGEs determined by this method and other methods

样品类型	测定元素	表面活性剂	螯合试剂	稀释剂	检测手段	富集因子	检出限	线性范围	文献
环境样品	Cd²⁺ Pb²⁺ Pd²⁺ Ag⁺	Triton X-114	2-苯并咪唑乙硫醚	甲醇	FAAS	48 39 32 42	1.4 μg/L 2.8 μg/L 1.6 μg/L 1.4 μg/L	-	^[14]
土壤和岩石样品	Pd Ag Au	Triton X-114	4-对氯苯基-1-(2-吡啶)-氨基硫脲	甲醇	ETAAS	52 46 56	0.12 μg/L 0.08 μg/L 0.30 μg/L	0~125 μg/L 0~50 μg/L 0~100 μg/L	^[15]
矿石和标准物质	Au Pd	Triton X-114	1,8-二氨基-4,5-二羟基-9,10-蒽二酮	硝酸	ICP-OES	8.6 20.2	0.5 μg/L 0.3 μg/L	0.5~1000 μg/L	^[16]
街尘	Pt	Triton X-100	十六烷基三甲基溴化铵	甲醇	ICP-MS	13	10 pg/g	100~50000 ng/L	^[17]
环境样品	Pt Pd	Triton X-100	2-巯基苯并噻唑	盐酸	ICP-MS	6 6	0.22 ng/g 0.17 ng/g	-	^[18]
地球化学样品	Pt Pd Rh Ru	Triton X-114	O,O-二乙基二硫代磷酸铵	硝酸	ICP-MS	45 33 18 35	0.05 μg/L 0.02 μg/L 0.10 μg/L 0.03 μg/L	0.0005~0.3 μg/mL	本文
注：表格中的“-”表示文献中未列出。

下载: 导出CSV

表 2 方法准确度及精密度

Table 2. Accuracy and precision tests of the method

铂族元素	GBW07291			GBW07293
铂族元素	标准值(ng/g)	测定值 (ng/g)	RSD (%)	标准值 (ng/g)	测定值 (ng/g)	RSD (%)
Pt	58	49	3.0	440	392	2.8
Pd	60	51	3.3	568	497	3.0
Ru	2.5	1.8	5.7	13	9.5	4.1
Rh	4.3	3.2	4.9	22	16	3.9

下载: 导出CSV

表 3 实际样品分析

Table 3. Analytical results of the actual samples

样品编号	元素	元素含量测定值(ng/g)		ICP-MS(n=3)精密度 (%)	对数误差
样品编号	元素	d-CPE	火试金/树脂吸附	ICP-MS(n=3)精密度 (%)	对数误差
S-1	Pt	1.3	1.1	2.9	0.03
	Pd	2.1	2.5	2.6	0.06
	Ru	0.58	0.49	3.3	0.10
	Rh	0.89	0.86	4.1	0.09
S-2	Pt	6.3	6.6	2.2	0.07
	Pd	3.3	3.1	2.3	0.06
	Ru	2.1	1.8	2.9	0.10
	Rh	2.6	2.6	3.5	0.07
S-3	Pt	29	30	1.9	0.01
	Pd	16.8	15.9	1.5	0.03
	Ru	0.83	0.77	3.0	0.10
	Rh	0.53	0.49	3.6	0.11
S-4	Pt	18.3	19.2	1.9	0.03
	Pd	13.6	12.8	1.2	0.05
	Ru	0.66	0.64	3.6	0.13
	Rh	1.9	2.3	2.9	0.09
注：“对数误差”参见DZ/T 0130—2006《地质矿产实验室测试质量管理规范》。

下载: 导出CSV

参考文献(23)

[1]	Li Z,Feng Y.Determination of the Platinum Group Elements in Geological Samples by ICP-MS after NiS Fire Assay and Te Coprecipitation:Ultrasound-assisted Extraction of PGEs from Te Precipitate[J].Journal of Analytical Atomic Spectrometry,2006,21(1):90-93.
[2]	Li K J,Liu S J,Shao K.Determination of Ruthenium,Rhodium,Palladium,Iridium and Platinum in Copper-Nickel Sulfide Ores by Bismuth-Antimony Fire Assay[J].Chinese Journal of Analytical Chemistry,2014,42(6):909-912.
[3]	段玉然,李维华,徐羽梧.螯合树脂富集-激光气化等离子体发射光谱测定地质样品中铂族元素和金[J].分析化学,1994,22(4):366-369. Duan Y R,Li W H,Xu Y W.Determination of Platinum Group Elements and Gold in Geological Samples by Inductively Coupled Plasma-Atomic Emission Spectrometry after Precon-centration Using Chelating Resin[J].Chinese Journal of Analytical Chemistry,1994,22(4):366-369.
[4]	甘树才,来雅文,段太成,等.DT-1016型阴离子交换树脂分离富集金铂钯[J].岩矿测试,2002,21(2):113-116. Gan S C,Lai Y W,Duan T C,et al.Separation and Preconcentration of Gold,Platinum and Palladium in Geological Samples with DT-1016 Anion Exchange Resin[J].Rock and Mineral Analysis,2002,21(2):113-116.
[5]	赵正,漆亮,黄智龙,等.地质样品中铂族元素的分析测定方法[J].地学前缘,2009,16(1):181-193. Zhao Z,Qi L,Huang Z L,et al.The Analytical Methods for Determination of Platinum Group Elements in Geological Samples[J].Earth Science Frontiers,2009,16(1):181-193.
[6]	梁沛,李静.浊点萃取技术在金属离子分离和富集以及形态分析中应用的进展[J].理化检验(化学分册),2006,42(7):582-587. Liang P,Li J.Progress of the Application of Cloud Point Extraction to the Separation and Enrichment of Metal Ions and to the Speciation Analysis[J].Physical Testing and Chemical Analysis (Part B:Chemical Analysis),2006,42(7):582-587.
[7]	Bezerra M A,Arruda M A Z,Ferreira S L C.Cloud Point Extraction as A Procedure of Separation and Pre-concentration for Metal Determination Using Spectro-analytical Techniques:A Review[J].Applied Spectroscopy Reviews,2005,40(4):269-299.
[8]	Ojeda C B,Rojas F S.Separation and Preconcentration by Cloud Point Extraction Procedures for Determination of Ions:Recent Trends and Applications[J].Microchimica Acta,2012,177(1-2):1-21.
[9]	Pytlakowska K,Kozik V,Dabioch M.Complex-forming Organic Ligands in Cloud-point Extraction of Metalions:A Review[J].Talanta,2013,110:202-228.
[10]	孙梅,刘桂建,吴强华.浊点萃取技术在环境样品痕量元素分析中的应用研究进展[J].环境化学,2013,32(6):1016-1024. Sun M,Liu G J,Wu Q H.Progress and Application of Cloud Point Extraction in the Analysis of Trace Elements in Environmental Samples[J].Environmental Chemistry,2013,32(6):1016-1024.
[11]	Oya A U,Zeynep Y G,Sabahattin D,et al.A Novel Ligand for Cloud Point Extraction to Determine Gold Content in Ore Samples[J].Environmental Chemistry Letters,2014,12(3):449-453.
[12]	Zia Mohammadi S,Mohammadnezhad M,Afzali D,et al.Selective Ligandless Cloud Point Extraction of Gold from Wastewater and Ore Samples[J].Current Analytical Chemistry,2014,10(4):473-478.
[13]	Li Z,Zhen W,Tai Z,et al.Cloud Point Extraction Coupled with Ultrasonic-assisted for Determination of Au and Ag in Water Samples by Flame Atomic Absorption Spectrometry[J].Asian Journal of Chemistry,2013,25(4):2208-2212.
[14]	Ghaedi M,Shokrollahi A,Niknam K,et al.Cloud Point Extraction and Flame Atomic Absorption Spectrometric Determination of Cadmium (Ⅱ),Lead (Ⅱ),Palladium (Ⅱ) and Silver (Ⅰ) in Environmental Samples[J].Journal of Hazardous Materials,2009,168(2-3):1022-1027.
[15]	Mortada W I,Hassanien M M,El-Asmy A A.Cloud Point Extraction of Some Precious Metals Using Triton X-114 and a Thioamide Derivative with a Salting-out Effect[J].Egyptian Journal of Basic & Applied Sciences,2014,1(3-4):184-191.
[16]	Laleh T,Yadollah Y,Homeyra E,et al.Development of Cloud Point Extraction for Simultaneous Extraction and Determination of Gold and Palladium Using ICP-OES[J].Journal of Hazardous Materials,2008,152(2):737-743.
[17]	Meeravali N N,Kumar S J,Jiang S J.An Acid Induced Mixed-micelle Mediated Cloud Point Extraction for the Separation and Pre-concentration of Platinum from Road Dust and Determination by Inductively Coupled Plasma Mass Spectrometry[J].Analytical Methods,2010,2(8):1101-1105.
[18]	张欣,刘崴,李冰,等.浊点萃取-电感耦合等离子体质谱法测定环境样品中的痕量铂钯[J].分析试验室,2012,31(11):63-66. Zhang X,Liu W,Li B,et al.Determination of Trace Platinum and Palladium in Environmental Samples by Cloud Point Extraction Coupled with Inductively Coupled Plasma-Mass Spectrometry[J].Chinese Journal of Analysis Laboratory,2012,31(11):63-66.
[19]	Peng G,He Q,Zhou G,et al.Determination of Heavy Metals in Water Samples Using Dual-cloud Point Extraction Coupled with Inductively Coupled Plasma Mass Spectrometry[J].Analytical Methods,2015,7(16):6732-6739.
[20]	Wang Y,Chen H,Han J,et al.A novel Cyclic Non-ligand Dual-cloud Point Extraction for Preconcentration of Cadmium(Ⅱ) through pH Regulation in Food and Environmental Matrices[J].New Journal of Chemistry,2015,39:9116-9123.
[21]	Arain M S,Kazi T G,Afridi H I,et al.Preconcentration and Determination of Manganese in Biological Samples by Dual-cloud Point Extraction Coupled with Flame Atomic Absorption Spectrometry[J].Journal of Analytical Atomic Spectrometry,2014,29(12):2349-2355.
[22]	王磊.双浊点萃取-ICP-AES测定环境样品中痕量金属元素的研究[D].杭州:浙江师范大学,2010. Wang L.Study on Determination of Trace Elements in Environmental Samples by Inductively Coupled Plasma-Atomic Emission Spectrometry after Dual Cloud Point Extraction[D].Hangzhou:Zhejiang Normal University,2010.
[23]	Mortada W I,Ali A A,Hassanien M M.Cloud Point Extraction of Pd (Ⅱ),Au (Ⅲ),and Ag(Ⅰ) Prior to Their Determination by Graphite Furnace Atomic Absorption Spectrometry[J].Canadian Journal of Chemistry,2013,91(12):1219-1224.
