Elution of Adsorbed n-alkanes by 5Å Molecular Sieve Using Solvent Mixtures for Compound-Specific Hydrogen Isotopic Analysis
-
摘要: 混合溶剂萃取洗脱5Å分子筛吸附正构烷烃的方法在单体碳同位素分析研究中已得到了应用。由于5Å分子筛在长时间加热条件下可能对有机分子的氢交换反应具有一定的催化作用,因此对于该方法能否用于正构烷烃的单体氢同位素分析需要做进一步研究。本文以两种不同类型原油的饱和烃和正构烷烃混合标准样品为对象,采用环己烷-正戊烷溶剂和氢氟酸溶解-正戊烷溶剂洗脱5Å分子筛吸附的正构烷烃,对比分析两种萃取方式的分离效果,并分别测定了正构烷烃的单体氢同位素比值。结果表明:两种萃取方式都得到了纯化效果良好的正构烷烃组分,氢同位素测定结果的差值总体上小于4‰,在仪器分析误差范围内。经过三次环己烷-正戊烷洗脱方式获得正构烷烃回收率平均值为58%,氢氟酸溶解-正戊烷洗脱方式经过多次萃取操作获得正构烷烃回收率平均值为68%。尽管环己烷-正戊烷洗脱方式提取正构烷烃的效率较低,并且涉及在分子筛条件下多次较长时间的加热过程,但这两个因素没有导致氢同位素发生明显的分馏或交换过程,适合用于正构烷烃分离、纯化以及单体氢同位素测定。Abstract: The extraction procedure using solvent mixtures has been used to elute n-alkanes adsorped by 5Å molecular sieve and subsequent stable carbon isotope ratio analysis of individual n-alkanes. However, a 5Å molecular sieve may catalyze the hydrogen exchange of organic molecules during long-term heating. Therefore, the usage of this method for hydrogen isotopic analysis needs to be evaluated. Two different types of crude oil saturated hydrocarbon and n-alkanes mixed standard samples were used as the object for this study. The extraction method using cyclohexane and n--heptane solvent mixtures and another method evolving the digestion with hydrofluoric-acid and solvent extraction were both used to elute adsorbed n-alkanes by the 5Å molecular sieve. The separation efficiency of the two methods was compared, and both carbon and hydrogen isotopes of obtained n-alkanes have been analyzed. Results show that the two methods enable excellent separations of n-alkanes, and yield variations of the hydrogen isotope ratios smaller than 4‰, within uncertainty. The average recovery of n-alkanes obtained by three-time solvent extraction was 58%, whereas that obtained by hydrofluoric acid dissolution and solvent extraction was 68%. Although cyclohexane and n-heptane solvent mixture has lower extraction efficiency and involves multiple heating processes, these two factors do not result in significant fractionation or exchange of hydrogen isotopes, indicating that this method can be applied to the separation and purifying of n-alkanes and subsequent compound-specific hydrogen isotopic analysis.
-
Key words:
- 5Å molecular sieve /
- adsorption /
- separation /
- n-alkanes /
- hydrogen isotope
-
表 1 氢氟酸溶解结合溶剂萃取和混合溶解热萃取两种洗脱方法的对比
Table 1. A comparison of the two elution methods: hydrofluoric acid solution combining solvent extraction and solvent mixtures involved heating extraction
萃取方式 操作流程 操作时间 氢氟酸溶解-溶剂萃取 ① 氢氟酸(腐蚀性)逐滴加入,缓慢溶解(逐个样品)。
② 采用磁力搅拌,完全溶解后,中和溶液。
③ 四次加入正戊烷试剂萃取正构烷烃,合并萃取液。
④ 对于萃取得到的正构烷烃进行除水处理。约12 h/10个
样品混合溶剂加热萃取 ① 加入混合溶剂进行热萃取(批量进行)。
② 过滤得到正构烷烃。
③ 重复步骤① 和② 两次,共三次萃取得到正构烷烃。一次萃取约
9 h/20个
样品 -
[1] Li M, Huang Y, Obermajer M, et al.Hydrogen isotopic compositions of individual alkanes as a new approach to petroleum correlation:Case studies from the Western Canada sedimentary basin[J].Organic Geochemistry, 2001, 32(12):1387-1399. doi: 10.1016/S0146-6380(01)00116-4
[2] Schimmelmann A, Sessions A L, Boreham C J, et al.D/H ratios in terrestrially sourced petroleum systems[J].Organic Geochemistry, 2004, 35(10):1169-1195. doi: 10.1016/j.orggeochem.2004.05.006
[3] Dawson D, Grice K, Alexander R, et al.The effect of source and maturity on the stable isotopic compositions of individual hydrocarbons in sediments and crudeoils from the Vulcan Sub-basin, Timor Sea, Northern Australia[J].Organic Geochemistry, 2007, 38(7):1015-1038. doi: 10.1016/j.orggeochem.2007.02.018
[4] Aboglila S, Grice K, Trinajstic K, et al.Use of biomarker distributions and compound specific isotopes of carbon and hydrogen to delineate hydrocarbon characteristics in the East Sirte Basin (Libya)[J].Organic Geochemistry, 2010, 41(12):1249-1258. doi: 10.1016/j.orggeochem.2010.05.011
[5] Jia W, Wang Q, Peng P, et al.Isotopic compositions and biomarkers in crude oils from the Tarim Basin:Oil maturity and oil mixing[J].Organic Geochemistry, 2013, 57:95-106. doi: 10.1016/j.orggeochem.2013.01.002
[6] 张文正, 裴戈.原油轻烃单体系列GC/C/MS在线碳同位素分析方法[J].石油实验地质, 1992, 14(3):302-311. http://www.cnki.com.cn/Article/CJFDTOTAL-SYSD199203010.htm
Zhang W Z, Pei G.A series of on-line carbon isotopic analyses of monosomeric hydrocarbons in crude oil by GC/C/MS[J].Experimental Petroleum Geology, 1992, 14(3):302-311. http://www.cnki.com.cn/Article/CJFDTOTAL-SYSD199203010.htm
[7] 张文正, 裴戈, 关德师.液态正构烷烃系列、姥鲛烷、植烷碳同位素研究[J].石油勘探与开发, 1992, 19(5):32-41. http://www.cnki.com.cn/Article/CJFDTOTAL-SKYK199205006.htm
Zhang W Z, Pei G, Guan D S.A primary study on carbon isotope of n-alkane, pristine and phytane in crude oil[J].Petroleum Exploration and Development, 1992, 19(5):32-41. http://www.cnki.com.cn/Article/CJFDTOTAL-SKYK199205006.htm
[8] 王欢业, 刘卫国, 张普.地质样品正构烷烃组分分离纯化的部分问题探究[J].岩矿测试, 2011, 30(1):1-6. http://www.ykcs.ac.cn/ykcs/ch/reader/view_abstract.aspx?file_no=20110101&flag=1
Wang H Y, Liu W G, Zhang P.Exploration of some problems in the separation and purification of n-alkanes in geological samples[J].Rock and Mineral Analysis, 2011, 30(1):1-6. http://www.ykcs.ac.cn/ykcs/ch/reader/view_abstract.aspx?file_no=20110101&flag=1
[9] Chen S, Jia W, Peng P.Carbon isotope analyses of n-alkanes released from rapid pyrolysis of oil asphaltenes in a closed system[J].Rapid Communications in Mass Spectrometry, 2016, 30(15):1779-1786. doi: 10.1002/rcm.7656
[10] Ellis L, Fincannon A L.Analytical improvements in IRM-GC/MS analyses:Advanced techniques in tube furnace design and sample preparation[J].Organic Geochemistry, 1998, 29(5):1101-1117. http://www.academia.edu/189212/GC_and_IRMS_Technology_for_13C_and_15N_Analysis_of_Organic_Compounds_and_Related_Gases
[11] 董爱正, 黄第藩.饱和烃单体化合物稳定碳同位素测定方法[J].石油勘探与开发, 1996, 23(2):98-102. http://www.cnki.com.cn/Article/CJFDTOTAL-SKYK602.025.htm
Dong A Z, Huang D F.The method of carbon isotope measurement of individual compounds in saturated hydrocarbon[J].Petroleum Exploration and Development, 1996, 23(2):98-102. http://www.cnki.com.cn/Article/CJFDTOTAL-SKYK602.025.htm
[12] 朱雷, 史权.吸附法分离饱和烃组分在石油地球化学中的应用[J].石油大学学报(自然科学版), 1999, 23(2):30-34. http://www.cnki.com.cn/Article/CJFDTOTAL-SYDX902.007.htm
Zhu L, Shi Q.Separation of saturated hydrocarbons using adsorption method and its application in petroleum geochemistry[J].Journal of China University of Petroleum (Edition of Natural Sciences), 1999, 23(2):30-34. http://www.cnki.com.cn/Article/CJFDTOTAL-SYDX902.007.htm
[13] 杜丽, 李立武, 孟仟祥, 等.饱和烃经5Å分子筛络合前后单体烃碳同位素分析对比研究[J].沉积学报, 2005, 23(4):747-752. http://www.cnki.com.cn/Article/CJFDTOTAL-CJXB200504027.htm
Du L, Li L W, Meng Q X, et al.Comparison of carbon isotopic composition of the saturated hydrocarbons before and after complexation 5Å molecular sieve[J].Acta Sedimentologica Sinica, 2005, 23(4):747-752. http://www.cnki.com.cn/Article/CJFDTOTAL-CJXB200504027.htm
[14] Grice K, Mesmay R D, Glucina A, et al.An improved and rapid 5Å molecular sieve method for gas chromatography isotope ratio mass spectrometry of n-alkanes (C8-C30+)[J].Organic Geochemistry, 2008, 39(3):284-288. doi: 10.1016/j.orggeochem.2007.12.009
[15] 李钜源.单分子烃碳同位素分析方法及影响因素探讨[J].地球学报, 2004, 25(2):109-113. http://cpfd.cnki.com.cn/Article/CPFDTOTAL-ZGDJ200311002046.htm
Li J Y.The carbon isotope analytical method for monomolecular hydrocarbons and its affecting factors[J].Journal of Earth Sciences, 2004, 25(2):109-113. http://cpfd.cnki.com.cn/Article/CPFDTOTAL-ZGDJ200311002046.htm
[16] 王宁, 朱庆增, 谢曼曼, 等.尿素络合法分离-气相色谱/同位素质谱法分析土壤和植物中低含量(ppm级)正构烷烃的碳同位素[J].岩矿测试, 2015, 34(4):471-479. http://www.ykcs.ac.cn/ykcs/ch/reader/view_abstract.aspx?file_no=20150416&flag=1
Wang N, Zhu Q Z, Xie M M, et al.An improved urea adduction method for analyzing carbon isotope of ppm-level n-alkanes in soil and plant samples[J].Rock and Mineral Analysis, 2015, 34(4):471-479. http://www.ykcs.ac.cn/ykcs/ch/reader/view_abstract.aspx?file_no=20150416&flag=1
[17] Tolosa I, Ogrinc N.Utility of 5Å molecular sieves to measure carbon isotope ratios in lipid biomarkers[J].Journal of Chromatography A, 2007, 1165(1-2):172-181. doi: 10.1016/j.chroma.2007.07.046
[18] Jiménez-Cruz F, Laredo G C.Molecular size evaluation of linear and branched paraffins from the gasoline pool by DFT quantum chemical calculations[J].Fuel, 2004, 83(16):2183-2188. doi: 10.1016/j.fuel.2004.06.010
[19] 段毅, 吴保祥, 郑国东, 等.沉积物的单体异构和环烷烃碳同位素研究[J].科学通报, 2004, 49(2):199-202. http://www.cnki.com.cn/Article/CJFDTOTAL-KXTB200402018.htm
Duan Y, Wu B X, Zheng G D, et al.The study of the carbon isotope in individal iso-alkanes and cyclanes of the sediment[J].Chinese Science Bulletin, 2004, 49(2):199-202. http://www.cnki.com.cn/Article/CJFDTOTAL-KXTB200402018.htm
[20] 张逐月, 刘美美, 谢曼曼, 等.5Å分子筛吸附混合溶剂洗脱-气相色谱-同位素质谱分析土壤中正构烷烃单体碳同位素[J].岩矿测试, 2012, 31(1):178-183. http://www.ykcs.ac.cn/ykcs/ch/reader/view_abstract.aspx?file_no=20120126&flag=1
Zhang Z Y, Liu M M, Xie M M, et al.Specific carbon isotopic analysis of n-alkanes in soils by gas chromatography-isotope ratio mass spectrometry with 5Å molecular sieve adsorption and mixed solvent elution[J].Rock and Mineral Analysis, 2012, 31(1):178-183. http://www.ykcs.ac.cn/ykcs/ch/reader/view_abstract.aspx?file_no=20120126&flag=1
[21] Dawson D, Grice K, Alexander R.Effect of maturation on the indigenous δD signatures of individual hydrocarbons in sediments and crude oils from the Perth Basin (Western Australia)[J].Organic Geochemistry, 2005, 36(1):95-104. doi: 10.1016/j.orggeochem.2004.06.020
[22] Ferreira A A, Neto E V S, Sessions A L, et al.2H/1H ratio of hopanes, tricyclic and tetracyclic terpanes in oils and source rocks from the Potiguar Basin, Brazil[J].Organic Geochemistry, 2012, 51(12):13-16. https://www.researchgate.net/profile/Arndt_Schimmelmann/citations?sorting=recent&page=5
