Application of Portable X-ray Fluorescence Spectrometer in the Analysis of Rock Samples
-
摘要: 便携式X射线荧光光谱仪(PXRF)因具有快速、无损检测元素含量的能力，通常被用于野外或实验室地质样品的元素含量检测工作中，对于大多数地质样品，在2 min内就能够获得几十种元素的半定量-定量分析结果。但在实际应用中，被测样品的表面平整度、样品中物质的均一性和施测时间等因素都会影响元素分析结果。为了进一步了解样品类型和分析测试方法等因素对元素分析的具体影响，本文对比了PXRF与实验室分析结果、岩石和粉末样品PXRF分析结果、不同检测时间所得PXRF分析结果的关系，在不损失过多分析精度的前提下提出了通过PXRF降低勘查成本、提高工作效率的方案。结果表明：用PXRF直接分析岩石样品时，大多数元素的分析结果可靠性较差，尤其是成矿预测工作中常用的Cu、Pb、Zn、As和Ni等元素；粉末样品的PXRF分析结果与实验室分析结果具有较好的相关性，表明对岩石样品进行粉碎处理能够明显改善PXRF分析质量；元素种类不同，岩石和粉末样品PXRF测量结果的相关性也不同。因此，在实际工作中可以根据感兴趣的目标元素确定是否需要对岩石样品进行粉碎制样处理；检测时间对元素含量分析结果没有明显影响，对于特定元素，如果能够在较短时间内获得其含量信息，则无需增加检测时间。
-
关键词:
- 便携式X射线荧光光谱仪 /
- 岩石样品 /
- 岩石粉末样品 /
- 元素含量 /
- 检测时间
Abstract: Portable X-ray Fluorescence Spectrometer (PXRF) is often used in the laboratory and the field because it is a portable, high-efficiency and non-destructive piece of equipment. PXRF can be used to obtain semi-quantitative/quantitative results of multiple elements in geological samples within two minutes. However, there are many factors that can affect the analytical results of geological samples by PXRF, including the surface state, sample heterogeneity, and the measurement time. In order to further understand the effect of sample types and analytical methods on the element contents, the study described here compares the analytical results of rocks by PXRF with those acquired by conventional laboratory analysis. Results of rocks and rock powder samples by PXRF were also compared, and the effect of different detection time on the results of rock powder samples by PXRF was also investigated. A method has been proposed which will reduce the exploration cost and improve work efficiency without a significant loss of analytical precision. The results shows that analytical results of most of the detectable elements is not reliable when analyzing rocks directly by PXRF, especially for the frequently used trace elements (Cu, Pb, Zn, As and Ni). However, PXRF can be used to analyze rock powders and the analytical result is acceptable. There is a difference between the correlation of various elements between rock and rock powder samples by PXRF. Therefore, it is possible to determine whether the rock sample needs to be ground for sample preparation according to the target elements of interest in practical work. The detection time has no obvious effect on the elemental content results. Whether a specific element can be obtained in a relatively short time, further detection time is unnecessary. -
-
表 1 PXRF检测时间不同时所测元素含量间的相关关系
Table 1. The influence of detection time on the analytical results of PXRF
元素 检测时间不同时的相关系数 120 s-60 s 60 s-30 s 120 s-30 s Bi 0.86 0.86 0.96 Zr 0.9966 0.9976 0.9972 Mn 0.9987 0.9991 0.999 Nb 0.8769 0.8856 0.8781 Fe 0.9995 0.9995 0.999 Ti 0.9949 0.87 0.8801 Rb 0.9819 0.8289 0.8332 Zn 0.8749 0.9335 0.916 Sr 0.9995 0.9998 0.9993 Cu 0.95 0.96 0.94 Si - - - Ni 0.6792 0.5595 0.4274 Pb 0.605 0.4726 0.4753 As 0.52 0.53 0.36 Th 0.4304 0.459 0.5531 K 0.9979 - - Ca 0.9999 - - Cr 0.7743 - - Ba - - - V - - - Al - - - 注：表中“120 s-60 s”列表示PXRF检测时间为120 s和60 s时所测各种元素含量间的相关系数。
下载: 导出CSV
-
[1] Zhang W, Lentz D R, Charnley B E.Petrogeochemical assessment of rock units and identification of alteration/mineralization indicators using portable X-ray fluorescence measurements:Applications to the Fire Tower Zone (W-Mo-Bi) and the North Zone (Sn-Zn-In), Mount Pleasant deposit, New Brunswick, Canada[J].Journal of Geochemical Exploration, 2017, 177:61-72. doi: 10.1016/j.gexplo.2017.02.005
[2] Liao S, Tao C, Li H, et al.Use of portable X-ray fluorescence in the analysis of surficial sediments in the exploration of hydrothermal vents on the Southwest Indian Ridge[J].Acta Oceanologica Sinica, 2017, 36(7):66-76. doi: 10.1007/s13131-017-1085-0
[3] Ribeiro B T, Silva S H G, Silva E A, et al.Portable X-ray fluorescence (pXRF) applications in tropical soil science[J].Ciência E Agrotecnologia, 2017, 41(3):245-254. doi: 10.1590/1413-70542017413000117
[4] 黄阳晓.对比等离子发射光谱法/原子荧光法探讨便携式X射线荧光光谱法在测定土壤重金属中的应用[J].广东化工, 2016, 43(13):261-263. doi: 10.3969/j.issn.1007-1865.2016.13.127
Huang Y X.Compared with plasma emission spectrometry, atomic fluorescence method to investigate the portable X-ray fluorescence spectrometry in determination of the application of the soil heavy metal[J].Guangdong Chemical Industry, 2016, 43(13):261-263. doi: 10.3969/j.issn.1007-1865.2016.13.127
[5] 王豹, 余建新, 黄标, 等.便携式X射线荧光光谱仪快速监测重金属土壤环境质量[J].光谱学与光谱分析, 2015, 35(6):1735-1740. http://www.cnki.com.cn/Article/CJFDTotal-TURA201503025.htm
Wang B, Yu J X, Huang B, et al.Fast monitoring soil environmental qualities of heavy metal by portable X-ray fluorescence spectrometer[J].Spectroscopy and Spectral Analysis, 2015, 35(6):1735-1740. http://www.cnki.com.cn/Article/CJFDTotal-TURA201503025.htm
[6] 廖学亮, 程大伟, 周超, 等.便携式X射线荧光光谱法检测大米中的镉[J].粮食与饲料工业, 2014(9):62-65. http://d.wanfangdata.com.cn/Periodical_lsyslgy201409016.aspx
Liao X L, Cheng D W, Zhou C, et al.Determination of cadmium in rice by portable X-ray fluorescence spectrometer[J].Cereal & Feed Industry, 2014(9):62-65. http://d.wanfangdata.com.cn/Periodical_lsyslgy201409016.aspx
[7] 耿志旺, 乐健, 杨永健.便携式X射线荧光光谱仪快速鉴别硫熏八角[J].食品安全质量检测学报, 2017, 8(6):2277-2281. http://kns.cnki.net/KCMS/detail/detail.aspx?filename=spaj201706063&dbname=CJFD&dbcode=CJFQ
Geng Z W, Le J, Yang Y J.Rapid screening of sulfur fumigated star anises by field-portable X-ray fluorescence[J].Journal of Food Safety and Quality, 2017, 8(6):2277-2281. http://kns.cnki.net/KCMS/detail/detail.aspx?filename=spaj201706063&dbname=CJFD&dbcode=CJFQ
[8] 聂黎行, 张烨, 朱俐, 等.便携式X射线荧光光谱快速无损分析牛黄清心丸(局方)中汞、砷含量及均匀度[J].光谱学与光谱分析, 2017, 37(10):3225-3228. http://manu13.magtech.com.cn/gpx/CN/abstract/abstract9441.shtml
Ni L X, Zhang Y, Zhu L, et al.Fast and nondestructive analysis of content of mercury and arsenic and homogeneity of Niuhuang Qingxin pills by portable X-ray fluorescence spectrometry[J].Spectroscopy and Spectral Analysis, 2017, 37(10):3225-3228. http://manu13.magtech.com.cn/gpx/CN/abstract/abstract9441.shtml
[9] 蒋小良, 兰丽丽, 叶丽贞, 等.便携式能量色散X射线荧光光谱法快速检测玩具中5种元素[J].皮革与化工, 2016, 33(6):12-14. http://kns.cnki.net/KCMS/detail/detail.aspx?filename=pghg201606003&dbname=CJFD&dbcode=CJFQ
Jiang X L, Lan L L, Ye L Z, et al.Rapid determination of 5 elements in toys by portable energy dispersion X-ray flourescence spectrometry[J].Leather and Chemicals, 2016, 33(6):12-14. http://kns.cnki.net/KCMS/detail/detail.aspx?filename=pghg201606003&dbname=CJFD&dbcode=CJFQ
[10] Arne D C, Mackie R A, Jones S A.The use of property-scale portable X-ray fluorescence data in gold exploration:Advantages and limitations[J].Geochemistry:Exploration, Environment, Analysis, 2014, 14(3):233-244. doi: 10.1144/geochem2013-233
[11] Sarala P.Comparison of different portable XRF methods for determining till geochemistry[J].Geochemistry:Exploration, Environment, Analysis, 2016, 16(3-4):181-192. doi: 10.1144/geochem2012-162
[12] le Vaillant M, Barnes S J, Fisher L, et al.Use and calibration of portable X-ray fluorescence analysers:Application to lithogeochemical exploration for komatiite-hosted nickel sulphide deposits[J].Geochemistry:Exploration, Environment, Analysis, 2014, 14(3):199-209. doi: 10.1144/geochem2012-166
[13] 李向超.便携式X射线荧光光谱仪现场测定地质样品中钛[J].冶金分析, 2014, 34(4):32-36. http://d.wanfangdata.com.cn/Periodical_yjfx201404007.aspx
Li X C.On-site determination of titanium in geological samples by portable X-ray fluorescence spectrometer[J].Metallurgical Analysis, 2014, 34(4):32-36. http://d.wanfangdata.com.cn/Periodical_yjfx201404007.aspx
[14] Uvarova Y A, Gazley M F, Cleverley J S, et al.Representative, high-spatial resolution geochemistry from diamond drill fines (powders):An example from Brukunga, Adelaide, South Australia[J].Journal of Geochemical Exploration, 2016, 170:1-9. doi: 10.1016/j.gexplo.2016.08.010
[15] Young K E, Evans C A, Hodges K V, et al.A review of the handheld X-ray fluorescence spectrometer as a tool for field geologic investigations on Earth and in planetary surface exploration[J].Applied Geochemistry, 2016, 72:77-87. doi: 10.1016/j.apgeochem.2016.07.003
[16] Hall G E M, McClenaghan M B, Page L.Application of portable XRF to the direct analysis of till samples from various deposit types in Canada[J].Geochemistry:Exploration, Environment, Analysis, 2016, 16(1):62-84. doi: 10.1144/geochem2015-371
[17] 杨桂兰, 商照聪, 李良君, 等.便携式X射线荧光光谱法在土壤重金属快速检测中的应用[J].应用化工, 2016, 45(8):1586-1591. http://www.cnki.com.cn/Article/CJFDTotal-TURA201503025.htm
Yang G L, Shang Z C, Li L J, et al.Application of portable-XRF spectrometry for rapid determination of common heavy metals in soil[J].Applied Chemical Industry, 2016, 45(8):1586-1591. http://www.cnki.com.cn/Article/CJFDTotal-TURA201503025.htm
[18] 邝荣禧, 胡文友, 何跃, 等.便携式X射线荧光光谱法(PXRF)在矿区农田土壤重金属快速检测中的应用研究[J].土壤, 2015, 47(3):589-595. http://www.cnki.com.cn/Article/CJFDTotal-TURA201503025.htm
Kuang R X, Hu W Y, He Y, et al.Application of portable X-ray fluorescence (PXRF) for rapid analysis of heavy metals in agricultural soils around mining area[J].Soils, 2015, 47(3):589-595. http://www.cnki.com.cn/Article/CJFDTotal-TURA201503025.htm
[19] 冉景, 王德建, 王灿, 等.便携式X射线荧光光谱法与原子吸收/原子荧光法测定土壤重金属的对比研究[J].光谱学与光谱分析, 2014, 34(11):3113-3118. doi: 10.3964/j.issn.1000-0593(2014)11-3113-06
Ran J, Wang D J, Wang C, et al.Comparison of soil heavy metals determined by AAS/AFS and portable X-ray fluorescense analysis[J].Spectroscopy and Spectral Analysis, 2014, 34(11):3113-3118. doi: 10.3964/j.issn.1000-0593(2014)11-3113-06
[20] 杨帆, 郝志红, 刘华忠, 等.便携式能量色散X射线荧光光谱仪在新疆东天山浅钻化探异常查证中的应用[J].岩矿测试, 2015, 34(6):665-671. http://www.cnki.net/kcms/doi/10.15898/j.cnki.11-2131/td.2015.06...
Yang F, Hao Z H, Liu H Z, et al.Application of Minipal 4 portable energy dispersive X-ray fluorescence spectrometer in the verification of geochemical anomaly delineated by shallow hole drill core in Eastern Tianshan[J].Rock and Mineral Analysis, 2015, 34(6):665-671. http://www.cnki.net/kcms/doi/10.15898/j.cnki.11-2131/td.2015.06...
[21] 龙灵利, 王京彬, 王玉往, 等.东天山卡拉塔格矿集区赋矿火山岩地层时代探讨——SHRIMP锆石U-Pb年龄证据[J].矿产勘查, 2016, 7(1):31-37. http://kns.cnki.net/KCMS/detail/detail.aspx?filename=ysjs201601004&dbname=CJFD&dbcode=CJFQ
Long L L, Wang J B, Wang Y W, et al.Discussion on the age of ore-host volcanic strata in the Kalatage ore concentration area, Eastern Tianshan:Evidence from SHRIMP zircon U-Pb dating[J].Mineral Exploration, 2016, 7(1):31-37. http://kns.cnki.net/KCMS/detail/detail.aspx?filename=ysjs201601004&dbname=CJFD&dbcode=CJFQ
[22] 于明杰, 王京彬, 毛启贵, 等.东天山卡拉塔格地区梅岭铜(金)矿床M1号矿体黄铁矿热电性特征及其地质意义[J].矿产勘查, 2016, 7(1):149-156. http://kns.cnki.net/KCMS/detail/detail.aspx?filename=ysjs201601018&dbname=CJFD&dbcode=CJFQ
Yu M J, Wang J B, Mao Q G, et al.Pyroelectricitical characteristics of pyrite from the No.M1 orebody in Meiling copper-gold deposit and its geological significance in the Kalatage area, Eastern Tianshan[J].Mineral Exploration, 2016, 7(1):149-156. http://kns.cnki.net/KCMS/detail/detail.aspx?filename=ysjs201601018&dbname=CJFD&dbcode=CJFQ
[23] 于明杰. 东天山卡拉塔格矿集区梅岭铜锌(金)矿床成矿作用[D]: 北京: 中国地质大学(北京), 2016.
http: //cdmd. cnki. com. cn/Article/CDMD-11415-1016184117. htm Yu M J. Metellogeneses in Relation to the Meiling Cu-Zn (Au) Deposit in the Kalatage Ore Concentration Area, Eastern Tianshan Mountain, Xinjiang, NW China[D]. Beijing: China University of Geosciences (Beijing), 2016.
[24] Zhu Y, Weindorf D C, Zhang W.Characterizing soils using a portable X-ray fluorescence spectrometer:1.Soil texture[J].Geoderma, 2011, 167-168(Supplement C):167-177. https://www.sciencedirect.com/science/article/pii/S0016706111002527
[25] 马德锡, 杨进, 陈孝强, 等.便携式X荧光仪在多金属矿区的应用[J].物探与化探, 2013, 37(1):63-66. doi: 10.11720/wtyht.2013.1.11
Ma D X, Yang J, Chen X Q, et al.The application of portable X-ray fluorescence instrument to the polymetallic ore district[J].Geophysical & Geochemical Exploration, 2013, 37(1):63-66. doi: 10.11720/wtyht.2013.1.11
[26] Fisher L, Gazley M F, Baensch A, et al.Resolution of geochemical and lithostratigraphic complexity:A workflow for application of portable X-ray fluorescence to mineral exploration[J].Geochemistry:Exploration, Environment, Analysis, 2014, 14(2):149-159. doi: 10.1144/geochem2012-158
[27] 董天宇, 王海江, Yunger J A, 等.便携式X射线荧光光谱仪实验室异位检测法的实用性研究[J].土壤, 2017, 49(4):853-857. http://www.opticsjournal.net/Journals/gpxygpfx.htm?action=index
Dong T Y, Wang H J, Yunger J A, et al.Practicality validation of portable X-ray fluorescence for ex-situ measuring soil heavy metals in laboratory[J].Soils, 2017, 49(4):853-857. http://www.opticsjournal.net/Journals/gpxygpfx.htm?action=index
[28] Gazley M F, Bonnett L C, Fisher L A, et al.A workflow for exploration sampling in regolith-dominated terranes using portable X-ray fluorescence:Comparison with laboratory data and a case study[J].Australian Journal of Earth Sciences, 2017, 64(7):903-917. doi: 10.1080/08120099.2017.1367721
-
