固相萃取掺氧空气-乙炔火焰原子吸收光谱法测定水和植物样品中的痕量镓

叶陆芳; 宋小华; 余代顺; 杨小慢; 谢文根; 吴少尉

doi:10.15898/j.cnki.11-2131/td.201905280073

固相萃取掺氧空气-乙炔火焰原子吸收光谱法测定水和植物样品中的痕量镓

湖北民族大学化学与环境工程学院, 湖北恩施 445000

基金项目:
国家自然科学基金项目（21565013）；大学生创新创业训练项目

详细信息

作者简介: 叶陆芳, 在读本科生, 从事痕量分析及样品前处理技术研究。E-mail:2530335171@qq.com

通讯作者: 吴少尉, 博士, 教授, 从事原子光谱/质谱联用分析技术研究。E-mail:2361130534@qq.com

中图分类号: O657.31

收稿日期: 2019-05-28

修回日期: 2019-09-11

录用日期: 2019-12-16

Determination of Trace Ga in Water and Plant Samples by O₂-doped Air-Acetylene FAAS with Solid Phase Extraction Preconcentration

College of Chemistry and Environmental Engineering, Hubei University for Nationalities, Enshi 445000, China

More Information

Corresponding author: Shao-wei WU, 2361130534@qq.com

Received Date: 28 May 2019

Revised Date: 11 September 2019

Accepted Date: 16 December 2019

摘要

摘要: 目前研究萃取分离富集镓大多偏向在强酸性体系中，一定程度上给操作带来安全风险，另需耐酸器皿设备，易污染，空白背景值高。本文开发了一种在弱酸性条件下萃取分离富集痕量镓的方法。以大孔吸附树脂为载体，十六烷基三甲基溴化铵调节其表面极性，热固化负载2-乙基己基磷酸（2-乙基己基）酯，制备了镓的萃取树脂。动态考察了固相萃取镓的吸附容量，优化选择固相萃取分离富集条件，实验表明萃取条件温和，分离富集痕量镓效果理想。当溶液酸度为pH 2.5时，Ga（Ⅲ）达到最大的回收率99%，并确定了掺氧空气乙炔火焰原子吸收光谱法（FAAS）测定镓的最佳参数，提升了常规空气乙炔FAAS测定镓的灵敏度。方法检出限（3σ）为2.6ng/mL，相对标准偏差（RSD，n=7）为2.87%，加标回收率在95.7%~102.0%之间，理论富集倍数为40。本方法已应用于自来水、中药材和水培蔬菜样品中痕量镓的测定，简便、快速、可靠。
- 水 /
- 植物 /
- 镓 /
- 固相萃取 /
- 掺氧空气乙炔火焰 /
- 原子吸收光谱法
Abstract: BACKGROUNDAt present, research on the extraction separation and enrichment of gallium is mostly biased to the strong acidic system, which brings a safety risk to the operation and needs acid-proof apparatus. Furthermore, the procedure is easily contaminated, resulting in high background values. OBJECTIVESTo develop a method for extraction separation and preconcentration of trace Ga under weakly acidic condition. METHODSSolid phase extraction medium for Ga was prepared by using modified large porous adsorption resin with cetyl-trimethyl-ammonium bromide and loading it with 2-ethylhexyl phosphonic acid-2-ethylhexyleste. The separation and enrichment conditions of solid phase extraction were studied in detail. RESULTSExperiments showed that the separation and enrichment of trace gallium was ideal when the extraction conditions were mild. The maximum recovery (99%) of Ga was achieved in sample solution with pH of 2.5. The determination parameters of gallium were optimized for oxygen doped air-acetylene flame atomic absorption spectrometry (FAAS), and the sensitivity was improved on that of the current method. The detection limit of the overall method (3σ) was 2.6ng/mL by IUPAC definition and the relative standard deviation (RSD, n=7) was 2.87%. The recoveries for spiked solution ranged from 95.7% to 102.0%, and a theory enrichment factor of 40 was obtained. CONCLUSIONSThis method has been successfully applied to the determination of trace gallium in tap water, Chinese medicine and hydroponic vegetable samples. It is simple, quick and reliable.
- water /
- plant /
- Ga /
- solid phase extraction /
- oxygen doped air acetylene flame /
- atomic absorption spectrometry

HTML全文

图 1 镓固相萃取条件的选择

Figure 1.

下载: 全尺寸图片幻灯片

表 1 本文与文献报道固相萃取分析镓的方法性能比较

Table 1. Comparison of the method with those reported in the literature for Ga(Ⅲ)

吸附剂	方法	富集倍数	检出限	样品	文献
聚氨酯塑料	SPE-ICP-MS	-	22ng/g	稀土矿石	[24]
改性胺基硅胶	SPE-FAAS	200	4.1ng/mL	水，沉积物	[25]
Amberlite XAD-4树脂	SPE-UV-Vis	500	3.1ng/mL	水，生物	[26]
聚氨酯泡沫体强酸阳离子交换纤维	SPE-FAAS SPE-ICP-AES	40 -	6.0ng/mL 3.9ng/mL	铝合金，尿液铝土岩	[27] [28]
离子印迹多壁碳纳米管	SPE-FAAS	43	3.03ng/mL	飞灰	[29]
磷酸三丁酯纤维棉	SPE-ICP-AES	5	65ng/mL	地质样品	[30]
改性大孔树脂	SPE-掺氧空气乙炔FAAS	40	2.6ng/mL	水，植物	本研究

下载: 导出CSV

表 2 样品测定分析结果(n=3)

Table 2. Analytical results for Ga(Ⅲ) in water solution and solid samples (n=3)

样品	样品含量水样(μg/L) 植物(μg/g)	平均值水样(μg/L) 植物(μg/g)	加标量水样(μg/L)	测定值水样(μg/L)	回收率 (%)	ICP-MS法水样(μg/L) 植物(μg/g)
自来水	20.9，20.3, 19.1	20.1	15 25	33.6 46.0	95.7 102.0	19.3
何首乌	1.27，1.29, 1.36	1.31	-	-	-	1.27
花生芽	61.3, 61.9, 60.5	61.2	-	-	-	62.3
注：标注“-”为植物固体样未做加标回收实验。

下载: 导出CSV

参考文献(31)

[1]	Takekawa F, Kuroda R.Determination of gallium in geological materials by graphite-furnace atomic absorption spectrometry[J].Talanta, 1988, 35(9):737-739. doi: 10.1016/0039-9140(88)80174-7
[2]	Kamat J V, Guin S K, Pillai J S, et al.Scope of detection and determination of gallium(Ⅲ) in industrial ground water by square wave anodic stripping voltammetry on bismuth film electrode[J].Talanta, 2011, 86:256-265. doi: 10.1016/j.talanta.2011.09.010
[3]	郑路, 王治伦, 陈群, 等."有机镓胶囊"治疗成人大骨节病的效果研究[J].中国地方病防治杂志, 2014, 29(4):249-251. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=zgdfbfzzz201404004 Zheng L, Wang Z L, Chen Q, et al.Treatment effect of organic gallium capsule on the adult KBD[J].Chinese Journal of Control of Endemic Diseases, 2014, 29(4):249-251. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=zgdfbfzzz201404004
[4]	Thangavel S, Dash K, Dhavile S M, et al.Determination of traces of As, B, Bi, Ga, Ge, P, Pb, Sb, Se, Si and Te in high-purity nickel using inductively coupled plasma-optical emission spectrometry (ICP-OES)[J].Talanta, 2015, 131:505-509. doi: 10.1016/j.talanta.2014.08.026
[5]	Santanade F A, Barbosa J T P, Matos G D, et al.Direct determination of gallium in bauxite employing ICP-OES using the reference element technique for interference elimination[J].Microchemical Journal, 2013, 110:198-201. doi: 10.1016/j.microc.2013.03.011
[6]	文加波, 商丹, 宋婉虹, 等.电感耦合等离子体发射光谱法测定铝土矿中镓——酸溶和碱熔预处理方法比较[J].岩矿测试, 2011, 30(4):481-485. doi: 10.3969/j.issn.0254-5357.2011.04.019 http://www.ykcs.ac.cn/article/id/ykcs_20110418 Wen J B, Shang D, Song W H, et al.Quantification of gallium in bauxites by inductively coupled plasma-atomic emission spectrometry-Comparison of sample pretreatment methods between alkali fusion and acid dissolution[J].Rock and Mineral Analysis, 2011, 30(4):481-485. doi: 10.3969/j.issn.0254-5357.2011.04.019 http://www.ykcs.ac.cn/article/id/ykcs_20110418
[7]	周含英, 周方钦, 白祖海, 等.镓-槲皮素的分光光度法研究与应用[J].分析科学学报, 2005, 21(1):107-108. doi: 10.3969/j.issn.1006-6144.2005.01.033 Zhou H Y, Zhou F Q, Bai Z H, et al.Study on gallium-quercetin complex spectrophotometry for the determination of gallium in Chinese herhal medicine[J].Journal of Analytical Science, 2005, 21(1):107-108. doi: 10.3969/j.issn.1006-6144.2005.01.033
[8]	乐淑葵.催化分光光度法测定地质样品中微量镓[J].中国无机分析化学, 2018, 8(3):12-15. doi: 10.3969/j.issn.2095-1035.2018.03.004 Le S K.Determination of trace gallium in geological samples by catalytic photometric method[J].Chinese Journal of Inorganic Analytical Chemistry, 2018, 8(3):12-15. doi: 10.3969/j.issn.2095-1035.2018.03.004
[9]	罗道成, 罗铸.萃取富集-8-羟基喹啉显色光度法测定赤泥中微量Ga(Ⅲ)[J].分析科学学报, 2015, 31(6):805-808. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=fxkxxb201506014 Luo D C, Luo Z.Spectrophotometric determination of micro Ga in red mud[J].Journal of Analytical Science, 2015, 31(6):805-808. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=fxkxxb201506014
[10]	米瑞华.稼的原子吸收光谱分析进展[J].岩矿测试, 1996, 15(1):53-55. http://www.ykcs.ac.cn/article/id/ykcs_19960115 Mi R H.Advances in AAS determination of gallium[J].Rock and Mineral Analysis, 1996, 15(1):53-55. http://www.ykcs.ac.cn/article/id/ykcs_19960115
[11]	Ma D, Okamoto Y, Kumamaru T, et al.Determination of gallium by graphite furnace atomic absorption spectrometry with combined use of a tungsten-coated L'vov platform tube and a chemical modification technique[J].Analytical Chimica Acta, 1999(390):201-206. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=d366cfbac24fe8f046cecef08ef67eec
[12]	Lopez-Garcia I, Campillo N, Arnau-Jerez I, et al.ETAAS determination of gallium in soils using slurry sampling[J].Journal of Analytical Atomic Spectrometry, 2004, 19(7):935-937. doi: 10.1039/B401317D
[13]	Nie X D, Liang Y Z, Tang Y G, et al.Determination of trace elements in high purity nickel by high resolution inductively coupled plasma mass spectrometry[J].Journal of Central South University, 2012, 19(9):2416-2420. doi: 10.1007/s11771-012-1290-0
[14]	唐碧玉, 施意华, 杨仲平, 等.灰化酸溶-电感耦合等离子体质谱法测定煤炭中的镓锗铟[J].岩矿测试, 2018, 37(4):371-378. http://www.ykcs.ac.cn/article/id/fe82630d-e20b-4e8f-91c5-62bbbfdd66b3 Tang B Y, Shi Y H, Yang Z P, et al.Determination of gallium, germanium and indium in coal by inductively coupled plasma-mass spectrometry with ashing acid digestion[J].Rock and Mineral Analysis, 2018, 37(4):371-378. http://www.ykcs.ac.cn/article/id/fe82630d-e20b-4e8f-91c5-62bbbfdd66b3
[15]	Filella M, Rodushkin I.A concise guide for the determination of less-studied technology-critical elements (Nb, Ta, Ga, In, Ge, Te) by inductively coupled plasma mass spectrometry in environmental samples[J].Spectrochimica Acta Part B:Atomic Spectroscopy, 2018, 141:80-84. doi: 10.1016/j.sab.2018.01.004
[16]	Chevallier E, Chekri R, Zinck J, et al.Simultaneous determination of 31 elements in foodstuffs by ICP-MS after closed-vessel microwave digestion:Method validation based on the accuracy profile[J].Journal of Food Composition and Analysis, 2015, 41:35-41. doi: 10.1016/j.jfca.2014.12.024
[17]	高贺凤, 王超, 张立纲.电感耦合等离子体质谱法精确测定地质样品中的微量元素镓[J].岩矿测试, 2013, 32(5):709-714. doi: 10.3969/j.issn.0254-5357.2013.05.006 http://www.ykcs.ac.cn/article/id/82ad3852-981b-4492-b2fb-b90cd0051388 Gao H F, Wang C, Zhang L G.Accurate determination of trace gallium in geological samples by inductively coupled plasma-mass spectrometry[J].Rock and Mineral Analysis, 2013, 32(5):709-714. doi: 10.3969/j.issn.0254-5357.2013.05.006 http://www.ykcs.ac.cn/article/id/82ad3852-981b-4492-b2fb-b90cd0051388
[18]	李国榕, 王亚平, 孙元方, 等.电感耦合等离子体质谱法测定地质样品中稀散元素铬镓铟碲铊[J].岩矿测试, 2010, 29(3):255-258. doi: 10.3969/j.issn.0254-5357.2010.03.012 http://www.ykcs.ac.cn/article/id/ykcs_20100312 Li G R, Wang Y P, Sun Y F, et al.Determination of Cr, Ga, In, Te and Tl in geological samples by inductively coupled plasma-mass spectrometry[J].Rock and Mineral Analysis, 2010, 29(3):255-258. doi: 10.3969/j.issn.0254-5357.2010.03.012 http://www.ykcs.ac.cn/article/id/ykcs_20100312
[19]	Filatova D G, Seregina I F, Foteeva L S, et al. Determination of gallium originated from a gallium-based anticancer drug in human urine using ICP-MS[J].Analytical and Bioanalytical Chemistry, 2011, 400(3):709-714. doi: 10.1007/s00216-011-4791-z
[20]	邱德仁.原子光谱分析[M].上海:复旦大学出版社, 2002:367. Qiu D R.Atomic Spectrometry Analysis[M].Shanghai:Fudan University Press, 2002:367.
[21]	Wu S W, Zheng X X.Measurement of the O₂-air-C₂H₂ flame temperature by a two-line atomic absorption way of gallium[J].Metallurgical Analysis, 2010, 30(12):26-29.
[22]	武新宇.酸性介质中镓的吸附和萃取性质及回收工艺研究[D].西安: 长安大学, 2014.http://cdmd.cnki.com.cn/Article/CDMD-10710-1014071245.htm Wu X Y.Study on the Sorption and Extraction Properties of Gallium in Acidic Medium and Its Recovery Technology[D].Xi'an: Chang'an University, 2014.
[23]	Hasanin T H A, Okamoto Y, Fujiwara T.A flow method based on solvent extraction coupled on-line to a reversed micellar mediated chemiluminescence detection for selective determination of gold(Ⅲ) and gallium(Ⅲ) in water and industrial samples[J].Talanta, 2016, 148:700-706. doi: 10.1016/j.talanta.2015.04.045
[24]	董学林, 何海洋.泡沫塑料吸附分离富集-电感耦合等离子体质谱法测定稀土矿石中的镓[J].岩矿测试, 2016, 35(1):42-47. http://www.ykcs.ac.cn/article/id/e76ed280-4f23-43e2-a99e-bc8be6fc79f4 Dong X L, He H Y.Determination of gallium in rare earth ore by inductively coupled plasma-mass spectrometry using polyurethane foam pre-concentration/separation[J].Rock and Mineral Analysis, 2016, 35(1):42-47. http://www.ykcs.ac.cn/article/id/e76ed280-4f23-43e2-a99e-bc8be6fc79f4
[25]	Hassanien M M, Mortada W I, Kenawy I M, et al.Solid phase extraction and preconcentration of trace gallium, indium, and thallium using new modified amino silica[J].Applied Spectroscopy, 2017, 71(2):288-299. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=bea527debf8d91e10e65f8b97d347921
[26]	Amin A S, Moalla S M N.Utility of solid phase extraction for UV-visible spectrophotometric determination of gallium in environmental and biological samples[J].RSC Advances, 2016, 6(3):1938-1944. doi: 10.1039/C5RA21368A
[27]	Anthemidis A.Gallium trace on-line preconcentration/separation and determination using a polyurethane foam mini-column and flame atomic absorption spectrometry:Application in aluminum alloys, natural waters and urine[J].Talanta, 2003, 60(5):929-936. doi: 10.1016/S0039-9140(03)00156-5
[28]	Gong Q, Wei X L, Wu J N, et al.A solid phase extraction method for determination of trace gallium in aluminum-iron samples by atomic spectrometry[J].Journal of Analytical Atomic Spectrometry, 2012, 27(11):1920-1927. doi: 10.1039/c2ja30208j
[29]	Zhang Z H, Zhang H B, Hu Y F, et al.Novel surface molecularly imprinted material modified multi-walled carbon nanotubes as solid-phase extraction sorbent for selective extraction gallium ion from fly ash[J].Talanta, 2010, 82(1):304-311. doi: 10.1016/j.talanta.2010.04.038
[30]	班俊生, 任俊涛.地质样品中痕量镓的磷酸三丁酯纤维棉富集及其在电感耦合等离子体原子发射光谱法测定中的应用[J].冶金分析, 2013, 33(8):68-71. doi: 10.3969/j.issn.1000-7571.2013.08.015 Ban J S, Ren J T.Enrichment of trace gallium in geological sample by tributyl phosphate cellucotton and its application in ICP-AES determination[J].Metallurgical Analysis, 2013, 33(8):68-71. doi: 10.3969/j.issn.1000-7571.2013.08.015
[31]	《岩石矿物分析》编委会.岩石矿物分析(第四版第一分册)[M].北京: 地质出版社, 2011: 724. The Editorial Committee of < Rock and Mineral Analysis>.Rock and Mineral Analysis (The Fourth Edition: Vol.Ⅰ)[M].Beijing: Geological Publishing House, 2011: 724.
