Inter-Laboratory Comparison of Measuring Organic Carbon and Stable Nitrogen Isotopes in Marine Sediments by Elemental Analysis-Isotope Ratio Mass Spectrometry
-
摘要: 海洋沉积物中有机碳、氮稳定同位素（δ13C、δ15N）作为一种有效指标，可对不同地质时期空气、温度、降水等参数的变化进行标记。元素分析-同位素比值质谱法是一种测量海洋沉积物有机碳、氮稳定同位素组成的合理、有效的方法。目前我国有诸多实验室使用元素分析仪（EA）与稳定同位素比值质谱仪（IRMS）联用的方法对沉积物中的有机碳、氮稳定同位素进行测试。各实验室之间测试技术及数据稳定性缺少比对依据，测试结果缺乏有效的溯源，使用过程中缺乏规范和统一。本文选取了我国2018年研制的三个国家一级海洋沉积物碳氮稳定同位素标准物质（GBW04701、GBW04702、GBW04703）及两个国际标准物质（EMA-B2152、EMA-B2151），在我国十家实验室对EA-IRMS在线技术测试方法进行实验室间的测量比对实验，以验证方法的稳定性、精密度和准确度。测试结果表明：各家协作实验室的数据准确、稳定，方法的重复性和再现性良好，测得的δ13C和δ15N精密度分别好于0.10‰、0.14‰。通过比对研究，同时证明了EA-IRMS在线技术适用于海洋沉积物中的有机碳、氮稳定同位素的测定，初步建立了一套适合海洋沉积物样品分析的方法。
-
关键词:
- 元素分析-同位素比值质谱法 /
- 海洋沉积物 /
- 有机碳稳定同位素 /
- 氮稳定同位素 /
- 比对研究
Abstract:BACKGROUNDOrganic carbon and nitrogen stable isotopes (δ13C, δ15N) in marine sediments are used as effective indicators to trace the changes of air, temperature, precipitation and other parameters in different geological time. Elemental analysis-isotope ratio mass spectrometry is a reasonable and effective method to measure the composition of organic carbon and nitrogen stable isotopes in marine sediments. At present, many domestic laboratories use the method of element analyzer (EA) and stable isotope ratio mass spectrometer (IRMS) to analyze the stable isotopes of organic carbon and nitrogen. However, the comparison of analytical method and data stability between different laboratories is lacking. The analytical results lack effective traceability, and the process lacks standardization and unification. OBJECTIVESTo develop a method for determining organic carbon and nitrogen stable isotopes in marine sediments. METHODSThree newly developed national first-class standard materials (GBW04701, GBW04702, GBW04703) and two international standard materials (EMA-B2152, EMA-B2151) were sent to 10 domestic laboratories, in order to verify the stability, precision and accuracy of EA-IRMS online technology test method through the comparative measurement between laboratories. RESULTSThe data of each collaborative laboratory was accurate and stable, and the method had good repeatability and reproducibility. The results showed that precisions of 13C and 15N were better than 0.10‰ and 0.14‰, respectively. CONCLUSIONSThrough comparative study, it has been proved that EA-IRMS online technology is suitable for the determination of organic carbon and nitrogen stable isotopes in marine sediments. A suitable method for the determination of marine sediment samples has been preliminarily established. -
-
表 1 协作实验样品类型和δ13C和δ15N值的范围
Table 1. Sample type of the collaboration experiment and the range of δ13C and δ15N values
样品编号 样品类型 标准物质编号 δ13C (‰) δ15N (‰) 水平1 沉积物 GBW04701 -20.9~-20.7 3.7~4.0 水平2 沉积物 GBW04702 -23.8~-23.6 6.3~6.7 水平3 沉积物 GBW04703 -22.8~-22.4 4.5~5.0 水平4 土壤 EMA-B2152 -27.4~-27.2 7.0~7.3 水平5 沉积物 EMA-B2151 -26.4~-26.2 4.1~4.5
下载: 导出CSV
表 2 协作试验δ13C和δ15N测定准确度数据
Table 2. Accuracy data of δ13C and δ15N in the cooperative experiment
实验室编号 GBW04701 GBW04702 GBW04703 EMA-B2152 EMA-B2151 δ13C (‰) δ15N (‰) δ13C (‰) δ15N (‰) δ13C (‰) δ15N (‰) δ13C (‰) δ15N (‰) δ13C (‰) δ15N (‰) A 0.16 0.07 -0.10 0.07 -0.02 0.22 0.05 0.03 0.01 0.12 0.15 0.12 -0.03 0.11 -0.02 0.15 0.03 -0.02 0.01 0.13 0.21 0.12 -0.03 0.00 0.01 0.28 0.08 - 0.03 0.18 0.19 0.16 -0.07 0.17 -0.03 0.16 0.04 - 0.05 0.18 0.15 0.09 -0.05 0.15 -0.05 0.12 0.06 0.28 0.04 0.10 0.18 -0.01 -0.06 0.01 -0.04 0.29 0.04 0.14 0.05 0.12 标准偏差(‰) 0.02 0.05 0.02 0.06 0.02 0.06 0.02 0.12 0.02 0.03 B 0.15 0.06 -0.08 0.09 -0.23 -0.02 0.02 0.05 -0.08 0.04 0.10 -0.04 0.00 0.07 -0.32 0.01 0.12 0.11 -0.06 0.09 0.09 -0.06 0.05 0.06 -0.15 0.09 0.08 0.15 -0.07 -0.08 0.12 0.10 -0.19 -0.04 -0.14 0.03 0.11 0.14 -0.09 -0.08 - 0.06 - 0.06 - -0.15 - - - - - 0.06 - -0.03 - 0.01 - - - - 标准偏差(‰) 0.02 0.06 0.09 0.05 0.07 0.07 0.04 0.04 0.01 0.07 C 0.37 -0.09 0.01 -0.03 0.21 0.19 -0.01 0.08 0.01 0.03 0.28 -0.10 0.12 -0.11 0.13 0.11 -0.18 0.09 -0.04 0.06 0.26 -0.03 0.12 0.20 0.18 0.21 -0.13 0.14 0.03 0.12 0.34 0.10 -0.08 0.12 0.18 0.21 -0.07 0.03 0.02 0.17 0.36 -0.13 0.14 0.04 0.10 0.27 - - - - 0.32 -0.15 0.12 0.17 0.20 0.22 - - - - 标准偏差(‰) 0.04 0.08 0.08 0.11 0.04 0.05 0.06 0.04 0.03 0.05 D 0.20 0.06 -0.07 -0.19 -0.07 -0.03 -0.10 -0.01 -0.14 - 0.13 0.15 -0.10 -0.22 0.04 -0.09 -0.15 0.19 -0.11 -0.01 0.19 0.12 -0.20 -0.09 -0.02 -0.08 -0.09 -0.02 -0.05 -0.17 0.21 -0.04 -0.26 -0.01 -0.19 -0.11 -0.22 -0.03 -0.08 - 0.19 - -0.19 -0.03 -0.11 -0.07 -0.10 0.06 - - 0.20 - -0.04 -0.13 -0.17 -0.09 -0.15 0.21 - - 标准偏差(‰) 0.03 0.07 0.08 0.08 0.08 0.02 0.05 0.10 0.03 0.08 E 0.24 -0.01 0.09 -0.15 0.03 0.01 -0.04 - -0.01 0.06 0.10 0.04 0.02 0.06 0.09 0.27 0.03 - 0.05 0.10 0.20 0.01 -0.04 -0.02 0.08 0.17 -0.11 - 0.11 0.07 0.22 0.17 -0.08 -0.15 0.04 -0.04 0.10 0.13 0.04 0.24 0.15 0.05 0.05 -0.05 0.05 0.04 0.01 0.14 - - 0.08 0.11 0.07 -0.12 0.06 0.28 -0.03 - - - 标准偏差(‰) 0.06 0.06 0.06 0.08 0.02 0.13 0.06 0.00 0.04 0.07 F 0.12 -0.17 -0.03 -0.12 -0.12 -0.35 0.07 0.12 -0.08 0.09 0.13 -0.11 -0.09 -0.13 -0.11 -0.26 0.12 0.11 -0.07 0.15 0.06 -0.04 -0.11 -0.12 -0.26 -0.28 0.10 0.23 -0.12 -0.02 0.06 -0.25 -0.05 -0.03 -0.28 -0.31 0.08 0.09 -0.09 0.10 0.10 -0.11 -0.16 0.00 -0.22 - 0.05 0.11 - - -0.03 -0.11 -0.18 -0.24 -0.15 - - - - - 标准偏差(‰) 0.05 0.06 0.05 0.08 0.07 0.03 0.02 0.05 0.02 0.06 G 0.33 0.26 0.06 -0.03 -0.01 0.10 -0.28 0.15 0.02 -0.03 0.30 0.13 -0.04 -0.02 0.13 0.11 -0.10 0.01 0.14 0.05 0.27 0.14 0.02 -0.02 0.06 0.10 -0.14 -0.02 0.06 0.07 0.12 0.22 0.16 -0.04 -0.04 0.14 -0.03 -0.05 0.04 0.26 0.27 0.23 0.10 0.03 0.01 0.05 -0.05 -0.17 - - - - - - - -0.08 - - - - 标准偏差(‰) 0.07 0.05 0.07 0.02 0.06 0.07 0.09 0.10 0.05 0.11 H 0.21 0.00 -0.03 -0.23 0.07 -0.32 0.00 -0.19 -0.07 -0.07 0.27 -0.07 0.05 -0.27 0.04 -0.07 0.09 -0.07 -0.11 0.03 0.19 -0.12 0.04 -0.25 0.06 -0.11 0.09 -0.09 -0.05 -0.05 0.22 -0.01 0.07 -0.08 0.06 -0.22 0.11 -0.05 0.03 0.02 0.24 -0.07 0.06 -0.16 0.05 -0.31 0.15 -0.11 -0.01 -0.04 0.31 -0.20 - - - - - - - - 标准偏差(‰) 0.04 0.07 0.04 0.07 0.01 0.10 0.05 0.05 0.05 0.04 I 0.04 -0.14 0.11 0.18 0.12 0.18 0.12 -0.10 -0.11 0.14 0.09 -0.05 0.15 0.22 0.03 0.02 0.13 -0.11 -0.10 0.08 0.07 -0.06 0.05 0.14 0.22 0.18 0.25 -0.20 -0.05 0.13 0.09 -0.11 -0.07 0.14 0.18 0.08 -0.03 -0.25 -0.13 0.14 0.14 -0.10 0.04 - 0.16 0.25 0.11 -0.08 -0.09 0.28 0.16 -0.17 0.09 - 0.09 0.06 0.13 0.05 - - 标准偏差(‰) 0.04 0.04 0.07 0.03 0.06 0.08 0.08 0.09 0.03 0.07 J 0.19 - -0.06 - -0.06 - 0.05 - - - 0.09 - -0.19 - -0.25 - 0.09 - - - 0.11 - -0.10 - -0.16 - 0.00 - - - 0.09 - -0.16 - -0.03 - -0.14 - - - 0.09 - -0.06 - -0.13 - 0.06 - - - 标准偏差(‰) 0.04 - 0.05 - 0.08 - 0.08 - - - 注：“-”表示未得到测试结果，不参与统计计算。
下载: 导出CSV
表 3 δ13C和δ15N测定的重复性与再现性统计结果
Table 3. Statistical results of repeatability and reliability of δ13C and δ15N
参数 统计参数 GBW04701 GBW04702 GBW04703 EMA-B2152 EMA-B2151 δ13C(‰) 有效实验室数目(p) 10 10 10 10 9 总平均值(m) -20.79 -23.65 -22.58 -27.29 -26.33 重复性标准差(Sr) 0.049 0.070 0.062 0.067 0.037 再现性标准差(SR) 0.091 0.104 0.141 0.112 0.072 重复性限(r) 0.139 0.199 0.175 0.190 0.104 再现性限(R) 0.258 0.295 0.399 0.317 0.205 r/R与m的关系 重复性限r与测试值m的关系：r=0.0066m；再现性限r与测试值m的关系：R=0.012m δ15N(‰) 有效实验室数目(p) 9 9 9 9 9 总平均值(m) 3.80 6.46 4.81 7.18 4.37 重复性标准差(Sr) 0.069 0.078 0.084 0.089 0.075 再现性标准差(SR) 0.125 0.131 0.184 0.128 0.100 重复性限(r) 0.195 0.221 0.237 0.253 0.213 再现性限(R) 0.352 0.371 0.520 0.363 0.284 r/R与m的关系 重复性限r与测试值m的关系：r=0.0694m；再现性限r与测试值m的关系：R=0.1068m
下载: 导出CSV
表 4 δ13C和δ15N测量方法偏倚的估计
Table 4. Estimation of measurement method bias of δ13C and δ15N
统计参数 δ13C (‰) δ15N (‰) GBW04701 GBW04702 GBW04703 EMA-B2152 EMA-B2151 GBW04701 GBW04702 GBW04703 EMA-B2152 EMA-B2151 γ(SR/Sr) 1.861 1.481 2.277 1.672 1.975 1.807 1.677 2.191 1.435 1.334 A 0.635 0.643 0.630 0.638 0.633 0.635 0.638 0.630 0.644 0.648 A×SR 0.058 0.067 0.089 0.072 0.046 0.079 0.084 0.116 0.083 0.065 总平均值(m) -20.79 -23.65 -22.58 -27.29 -26.33 3.80 6.46 4.81 7.18 4.37 标准值(μ) -20.79 -23.63 -22.57 -27.29 -26.27 3.80 6.48 4.78 7.18 4.42 测量方法偏倚(δ) -0.004 -0.022 -0.013 -0.002 -0.057 0.002 -0.020 0.032 0.001 -0.046 δ-A×SR -0.062 -0.089 -0.101 -0.073 -0.103 -0.078 -0.104 -0.084 -0.082 -0.111 δ+A×SR 0.054 0.045 0.076 0.070 -0.011 0.081 0.063 0.148 0.084 0.019 注：A为标准物质认定值的估计值不确定度的系数；A×SR为测量方法的偏倚的95%的置信区间；GBW04701、GBW04702、GBW04703的标准值(μ)为该标准物质的认定值，EMA-B2152的标准值(μ)为各比对实验室测量获得的平均值。
下载: 导出CSV
-
[1] Molero G, Aranjuelo I, Teixidor P, et al.Measurement of 13C and 15N isotope labeling by gas chromatography/combustion/isotope ratio mass spectrometry to study amino acid fluxes in a plant-microbe symbiotic association[J].Rapid Communications in Mass Spectrometry, 2011, 25:599-607. doi: 10.1002/rcm.4895
[2] 张咏华, 吴自军.陆架边缘海沉积物有机碳矿化及其对海洋碳循环的影响[J].地球科学进展, 2019, 34(2):202-209. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dqkxjz201902010
Zhang Y H, Wu Z J.Sedimentary organic carbon mineralization and its contribution to the marine carbon cycle in the marginal seas[J].Advances in Earth Science, 2019, 34(2):202-209. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dqkxjz201902010
[3] 葛晨东, 王颖, Pedersen T F, 等.海南岛万泉河口沉积物有机碳、氮同位素的特征及其环境意义[J].第四纪研究, 2007, 27(5):845-852. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dsjyj200705026
Ge C D, Wang Y, Pedersen T F, et al.Variability of organic carbon isotope, nitrogen isotope, and C/N in the Wanquan River Estuary, eastern Hainan Island, China and its environmental implications[J].Quaternary Sciences, 2007, 27(5):845-852. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dsjyj200705026
[4] Volvoikar S P, Nayak G N, Mazumdar A, et al.Recon-struction of depositional environment of a tropical estuary and response of δ13Corg and TOC/TN signatures to changing environmental conditions[J].Estuarine, Coastal and Shelf Science, 2014(139):137-147. https://www.sciencedirect.com/science/article/abs/pii/S0272771414000080
[5] 高艺珅, 王红亚, 程颖, 等.太白山西佛爷池沉积物有机碳、氮同位素记录的过去1800多年的气候-环境变化[J].北京大学学报(自然科学版), 2014, 35(5):1-11. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=bjdxxb201801010
Gao Y S, Wang H Y, Cheng Y, et al.Climatic and environmental changes in more than the past 1800 years as recorded by isotopic carbon and nitrogen in organic matter of sediments from Western Foye Chi (Buddha Pond) on Taibai Mountain[J].Acta Scientiarum Naturalium Universitatis Pekinensis, 2014, 35(5):1-11. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=bjdxxb201801010
[6] Vaalgamaa S, Sonninen E, Korhola A, et al.Identifying recent sources of organic matter enrichment and eutrophication trends at coastal sites using stable nitrogen and carbon isotope ratios in sediment cores[J].Original Paper, 2013, 50:191-206. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=eeff38de40f6208cbc64d7a9243988dd
[7] Sun W W, Shen J, Zhang E L, et al.Stable nitrogen isotope record of lacustrine sediments in Lake Onuma (northern Japan) indicates regional hydrological variability during the past four centuries[J].Quaternary International, 2016, 397:307-316. doi: 10.1016/j.quaint.2015.07.036
[8] 王毛兰, 艾永平, 张丁苓.鄱阳湖三江口柱状沉积物有机氮同位素特征及其环境指示意义[J].中国环境科学, 2015, 35(2):558-564. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=zghjkx201502031
Wang M L, Ai Y P, Zhang D L.Stable organic nitrogen isotope in core sediments of the Three Rivers Estuary, Poyang Lake and its environmental implications[J].China Environmental Science, 2015, 35(2):558-564. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=zghjkx201502031
[9] Brodie C R, Leng M J, Casford J S L, et al.Evidence for bias in C and N concentrations and δ13C composition of terrestrial and aquatic organic materials due to pre-analysis acid preparation methods[J].Chemical Geology, 2011, 282:67-83. doi: 10.1016/j.chemgeo.2011.01.007
[10] 张凌, 陈繁荣, 殷克东, 等.珠江口及近海表层沉积有机质的特征和来源[J].环热带海洋学报, 2010, 29(1):98-103. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=rdhy201001015
Zhang L, Chen F R, Yin K D, et al.The characteristics and sources of surface sediments in the Pearl River Estuary and its adjacent shelves[J].Journal of Tropical Oceanoraphy, 2010, 29(1):98-103. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=rdhy201001015
[11] 王毛兰, 赖建平, 胡珂图, 等.鄱阳湖表层沉积物有机碳、氮同位素特征及其来源分析[J].中国环境科学, 2014, 34(4):1019-1025. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=zghjkx201404042
Wang M L, Lai J P, Hu K T, et al.Compositions and sources of stable organic carbon and nitrogen isotopes in surface sediments of Poyang Lake[J].China Environmental Science, 2014, 34(4):1019-1025. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=zghjkx201404042
[12] 冀文豪, 郭匿春, 徐军, 等.长江中游浅水湖泊沉积物碳氮同位素特征及其来源分析[J].水生态学杂志, 2018, 39(6):8-15. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=sstxzz201806002
Ji W H, Guo N C, Xu J, et al.Carbon and nitrogen isotope characterization and source analysis of sediments from shallow lakes in the middle of Yangtze River[J].Journal of Hydroecology, 2018, 39(6):8-15. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=sstxzz201806002
[13] Mishraa S, Jhab N, Stebbinsc A, et al.Palaeoenvironments, flora, and organic carbon and nitrogen isotope changes across the non-marine Permian-Triassic boundary at Wybung Head, Australia[J].Palaeogeography, Palaeoclimatology, Palaeoecology, 2019, 534:1-21.
[14] 于广磊, 李斌, 李凡, 等.黄河口附近海域沉积物中碳氮元素地球化学特征及有机质来源研究[J].海洋环境科学, 2019, 38(6):862-867. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=hyhjkx201906007
Yu G L, Li B, Li F, et al.Carbon, nitrogen geochemical character and organic matter source study in the coastal sediment of Yellow River Estuary[J].Marine Environmental Science, 2019, 8(6):862-867. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=hyhjkx201906007
[15] 梁越, 肖化云, 刘小真, 等.δ13C和δ15N指示不同生态类型湖泊无机氮及有机质来源[J].湖泊科学, 2014, 26(5):691-697. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=hpkx201405006
Liang Y, Xiao H Y, Liu X Z, et al.Identifying provenance of inorganic nitrogen and organic matter in different ecotype lakes using δ13C and δ15N[J].Journal of Lake Sciences, 2014, 26(5):691-697. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=hpkx201405006
[16] 金贵善, 刘汉彬, 张建锋, 等.EA-IRMS测定有机及无机氮同位素条件探讨[J].地质学报, 2015, 89(增刊1):85-86. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=8771779
Jin G S, Liu H B, Zhang J F, et al.Discussion on the determination of organic and inorganic nitrogen isotopes with EA-IRMS[J].Acta Geological Sinica, 2015, 89(Supplement 1):85-86. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=8771779
[17] 孟宪菁, 杨斌, 李安, 等.具有动态稀释功能的EA-IRMS联机系统在δ13C和δ15N测定中的应用[J].质谱学报, 2018, 39(6):746-753. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=zpxb201806012
Meng X J, Yang B, Li A, et al.Application of dynamic dilution on δ13C and δ15N measurements using EA-IRMS system[J].Journal of Chinese Mass Spectrometry Society, 2018, 39(6):746-753. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=zpxb201806012
[18] 白亚之, 刘季花, 张辉, 等.海洋沉积物有机碳和总氮分析方法[J].海洋环境科学, 2013, 32(3):444-459. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=hyhjkx201303026
Bai Y Z, Liu J H, Zhang H, et al.The analysis of organic carbon and total nitrogen in marine sediments[J].Marine Environmental Science, 2013, 32(3):444-459. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=hyhjkx201303026
[19] 孙萱, 宋金明, 于颖, 等.元素分析仪快速测定海洋沉积物TOC和TN的条件优化[J].海洋科学, 2014, 38(7):14-19. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=hykx201407003
Sun X, Song J M, Yu Y, et al.A rapid method for determing the total organic carbon and total nitrogen in marine sediments with an elemental analyzer[J].Marine Sciences, 2014, 38(7):14-19. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=hykx201407003
[20] 秦德谛, 贺行良, 张媛媛, 等.渤海东海海洋沉积物中碳氮稳定同位素标准物质研制[J].岩矿测试, 2017, 36(1):857-862. http://www.ykcs.ac.cn/article/doi/10.15898/j.cnki.11-2131/td.2017.01.011
Qin D D, He X L, Zhang Y Y, et al.The preparation of carbon and nitrogen stable isotopes reference materials using sediments from the Bohai and East China Sea[J].Rock and Mineral Analysis, 2017, 36(1):857-862. http://www.ykcs.ac.cn/article/doi/10.15898/j.cnki.11-2131/td.2017.01.011
[21] 彭亚君, 王玉珏, 刘东艳, 等.酸化过程对海洋沉积物中有机碳同位素分析的影响[J].海洋学报, 2015, 37(12):85-92. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=hyxb201512009
Peng Y J, Wang Y J, Liu D Y, et al.Acid treatment effects on the carbon stable isotope values of marine sediments[J].Acta Oceanologica Sinica, 2015, 37(12):85-92. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=hyxb201512009
[22] 谭扬, 吴学丽, 侯立杰.样品处理方法对海洋沉积物有机碳稳定同位素测定的影响[J].海洋环境科学, 2017, 36(4):388-395. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=hyhjkx201805023
Tan Y, Wu X L, Hou L J.The effects of sample treatment methods on marine sediment organic carbon stable isotope[J].Marine Environmental Science, 2017, 36(4):388-395. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=hyhjkx201805023
[23] 曹建, 黄奕普, 刘广山, 等.海洋悬浮颗粒物中氮同位素的EA-IRMS法测定[J].台湾海峡, 2003, 22(1):1-8. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=twhx200301001
Cao J, Huang Y P, Liu G S, et al.Determination of 15N in marine suspended particulate matter using EA-IRMS technique[J].Journal of Oceanography in Taiwan Strait, 2003, 22(1):1-8. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=twhx200301001
[24] Brodie C R, Casford J S L, Lloyd J M, et al.Evidence for bias in C/N, δ13C and δ15N values of bulk organic matter, and on environmental interpretation, from a lake sedimentary sequence by pre-analysis acid treatment methods[J].Quaternary Science Reviews, 2011, 30:3076-3087. doi: 10.1016/j.quascirev.2011.07.003
[25] 陈立雷, 张媛媛, 贺行良, 等.海洋沉积物有机碳和稳定氮同位素分析的前处理影响[J].沉积学报, 2014, 32(6):1046-1051. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=cjxb201406006
Chen L L, Zhang Y Y, He X L, et al.The research on sample-pretreatment of organic carbon and stable nitrogen isotopes in marine sediments[J].Acta Sedimentologica Sinica, 2014, 32(6):1046-1051. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=cjxb201406006
[26] Gentile N, Rossi M J, Delémont O, et al.δ15N measure-ment of organic and inorganic substances by EA-IRMS:A speciation-dependent procedure[J].Analytical and Bioanalytical Chemistry, 2013, 405:159-176. doi: 10.1007/s00216-012-6471-z
[27] 张媛媛, 贺行良, 孙书文, 等.元素分析仪-同位素比值质谱仪测定海洋沉积物有机碳稳定同位素方法初探[J].岩矿测试, 2014, 32(6):1046-1051. http://www.ykcs.ac.cn/article/id/ykcs_20120413
Zhang Y Y, He X L, Sun S W, et al.A preliminary study on the determination of organic carbon stable isotope of marine sediment by element analyzer-isotope ratio mass spectrometer[J].Rock and Mineral Analysis, 2014, 32(6):1046-1051. http://www.ykcs.ac.cn/article/id/ykcs_20120413
[28] 徐丽, 邢蓝田, 王鑫, 等.元素分析仪-同位素比值质谱测量碳氮同位素比值最佳反应温度和进样量的确定[J].岩矿测试, 2018, 37(1):15-20. http://www.ykcs.ac.cn/article/doi/10.15898/j.cnki.11-2131/td.201701130005
Xu L, Xing L T, Wang X, et al.Study on the optimal reaction temperature and sampling weight for measurement of carbon and nitrogen isotope ratio by elemental analyzer-isotope ratio mass spectrometer[J].Rock and Mineral Analysis, 2018, 37(1):15-20. http://www.ykcs.ac.cn/article/doi/10.15898/j.cnki.11-2131/td.201701130005
[29] 蓝高勇, 吴夏, 杨会, 等.激光同位素光谱法测量水中氢氧同位素组成的实验室间比对研究[J].岩矿测试, 2017, 36(5):460-467. http://www.ykcs.ac.cn/article/doi/10.15898/j.cnki.11-2131/td.201704060049
Lan G Y, Wu X, Yang H, et al.Inter-laboratory comparison of analysis for hydrogen and oxygen stable isotope ratios in water samples by laser absorption spectroscopy[J].Rock and Mineral Analysis, 2017, 36(5):460-467. http://www.ykcs.ac.cn/article/doi/10.15898/j.cnki.11-2131/td.201704060049
[30] 王华, 吴夏, 蓝高勇, 等.GasBench Ⅱ-IRMS稳定同位素质谱法高精度测定环境水体中δD, δ18O和δ13CDIC[J].地质学报, 2015, 89(10):1804-1813. http://www.cqvip.com/QK/95080X/201510/666332910.html
Wang H, Wu X, Lan G Y, et al.High precision measurement of hdrogen oxygen and dissolve inorganic carbon isotope in water samples by GasBenchⅡ-IRMS:An interlaboratory comparison study[J].Acta Geologica Sinica, 2015, 89(10):1804-1813. http://www.cqvip.com/QK/95080X/201510/666332910.html
-
