Review on the Determination of Oxidant Demand for in-situ Chemical Oxidation Application
-
摘要:
原位化学氧化(ISCO)修复技术由于修复周期短、效率高等特点已被广泛应用于土壤和地下水的有机污染修复。ISCO修复中所需的氧化剂的剂量通常用氧化剂需求量来衡量，在实际应用过程中，使用的氧化剂剂量过多或过少均会产生一定的负面影响。因此，氧化剂需求量的准确测算对于获得良好的工程修复效益具有重要意义。本文在对氧化剂需求量的组成及定义进行梳理、统一的基础上，重点综述了相关测算方法的原理和应用现状。ISCO修复中总氧化剂需求量(TOD)的组成包括污染物氧化剂需求量(POD)、天然氧化剂需求量(NOD)和氧化剂分解量(DEO)。NOD和DEO的存在为有机污染物有效的修复降解和TOD的准确测算带来了挑战。氧化剂需求量的测算方法可以分为实验法和化学计量模型法两大类，实验法又可以分为批实验法、柱实验法、注抽实验法和反应动力学模型法，批实验法的是目前应用目前较为最为广泛。在实验法中，同一样品的不同时间点获得的氧化剂需求量差距可以达到37%，因此应把污染物浓度在氧化作用下降低到目标限值所需要的时间作为氧化剂需求量的测定时间，并且为了更为精准地提供氧化剂需求量，有必要使用带有测试条件的表达方式来进行表示。目前的氧化剂需求量测算方法多针对于高锰酸钾氧化剂需求量。芬顿试剂和臭氧等分解性较强的氧化剂的DEO可能达到TOD的50%以上，现有方法对DEO的准确测算仍面临困难，应予以特别关注。除了需要开发出能够准确获得DEO的测算方法，场地施工条件对TOD的影响也需要进一步探究，氧化剂需求量的测算仍需一个更为科学的工作流程或指南。
Abstract:In-situ chemical oxidation (ISCO) refers to the use of appropriate conveyance technology to transport oxidants into soil or aquifer, where the contaminants are converted to low- or non-toxic substances by chemical oxidation. ISCO has been widely used for the remediation of organic contaminants in soil and groundwater due to its high efficiency and cost effectiveness.
Oxidant demand is an important parameter in the application of ISCO. Once injected into the contaminated soil or aquifer, the oxidant reacts not only with the target contaminants, but also with natural organic matter (NOM) and reductive minerals (RM) such as Fe2+, Mn2+, S- and S2- in the medium. In addition, the oxidant may decompose naturally due to its own properties. If the amount of oxidant used is insufficient, the remediation of the contaminated site may not meet the project objectives and residual contaminants or reaction intermediates may be formed, resulting in a rebound of the contaminant concentration at the site. If too much oxidant is used, it would not only increase the cost of remediation, but also seriously damage the physical and chemical properties of soil, reducing the diversity of microbial communities. Therefore, accurate measurement of oxidant requirements is important to achieve good remediation performance.
In previous studies, the specific meaning of terms related to oxidant demand is not consistent and they are often mixed in different studies, which would lead to ambiguity.In this review the composition and definition of oxidant demand is clarified and unified. The total oxidant demand (TOD) in ISCO is composed of pollutant oxidant demand (POD, the amount of oxidant consumed by oxidative degradation of pollutants), natural oxidant demand (NOD, the amount of oxidant consumed by natural organic matter and reducing minerals in soil or aquifer media), and decomposed oxidant (DEO, the amount of oxidant naturally decomposed due to its nature and the influence of environmental conditions).
The methods for determining oxidant demand can be divided into two categories: experimental method and stoichiometric model method. The basic principle of the experimental method is to mix the treated medium sample with the oxidant in a system for a period of time, and then calculate the oxidant consumption before and after reaction to obtain the oxidant demand per unit of medium. Specifically, the experimental method can be divided into batch test, column test, push-pull test and reaction kinetics model according to the scale and dimension of the experiment. Among them, the batch test has been relatively widely used due to its excellent characteristics of simplicity and efficiency. The column test is more capable of reflecting the actual consumption of oxidant in the field medium, taking into account the transport process and interaction of oxidant in porous media. Although the push-pull test is carried out at the field scale, which can effectively overcome the error caused by the difference between laboratory conditions and field conditions, it is relatively complex to operate. Finally, the reaction kinetics model can be used to analyze the oxidant consumption in the reaction process based on experiments. This method can characterize the oxidant consumption on a longer time scale, which is of great importance for potassium permanganate or sodium persulfate oxidants with longer reaction times.
The determination of oxidant demand by experimental method is affected by factors such as the initial concentration of oxidant, reaction time, solid-to-liquid ratio and mixing conditions of the reaction. To facilitate comparison of data and costing of the project, it is necessary to incorporate experimental conditions into the expression of oxidant demand. For example, the difference of the oxidant demand obtained at different times for the same sample can be as much as 37%. Therefore, the time required for the pollutant concentration to be reduced to the target limit by oxidation should be used as the oxidant demand determination time.
Stoichiometric model method is the determination of the theoretical oxidant demand value by the establishment of the stoichiometric relationship model between the oxidant demand and the components in the medium. The stoichiometric model method was originally designed to explore the relationship between the total organic carbon in the medium and the oxidant demand. It was then developed to consider the oxidant demand of natural organic matter, other mineral ions and organic pollutants as a whole. Calculation results of the stoichiometric modelling method depend on the accuracy of the model and the precise determination of the content of relevant components in the medium.
Both experimental method and stoichiometric model method mostly take potassium permanganate oxidant as the research object, but there is a lack of research on the demand of Fenton reagent, ozone and sodium persulfate. In particular, the DEO of more decomposable oxidants such as Fenton reagent and ozone may reach more than 50% of TOD. The existing methods still face difficulties in accurately measuring DEO, which deserves special attention. As a component of TOD that is easily overlooked, the importance of DEO needs to be further clarified and more accurate measurement methods need to be explored. In the actual project, the number of injection wells, well spacing, oxidant injection rate and other design parameters will have an important impact on the total oxidant demand, which still needs to be further investigated. The remediation of contaminated sites by ISCO is a complex project and a more scientific workflow or guideline is necessary for engineers to determine oxidant demand.
-
-
表 1 氧化剂需求量相关术语及定义
Table 1. Terms and concepts related to oxidant demand
氧化剂需求量相关术语 定义 污染物氧化剂需求量
(Pollutant Oxidant Demand，POD)污染物氧化降解所消耗的氧化剂量 天然氧化剂需求量
(Natural Oxidant Demand，NOD)土壤或含水层介质中的天然有机质和还原性矿物质所消耗的氧化剂量 氧化剂分解量
(Decomposed Oxidant, DEO)氧化剂因本身的性质以及环境条件的影响而自然分解，未能参与到氧化反应过程中的那部分剂量
下载: 导出CSV
-
[1] 郑伟, 梅浩, 陈敬仁. 原位化学氧化技术在地下水修复工程中的应用[J]. 资源节约与环保, 2018(10): 23-25. doi: 10.3969/j.issn.1673-2251.2018.10.026
Zheng W, Mei H, Chen J R. Application of in situ chemical oxidation technology in groundwater remediation projects[J]. Resources Economization & Environmental Protection, 2018(10): 23-25. doi: 10.3969/j.issn.1673-2251.2018.10.026
[2] 沈宗泽, 王祺, 阎思诺, 等. 连续管式原位注入化学氧化技术对某有机污染场地地下水的修复效果[J]. 环境工程学报, 2022, 16(1): 93-100. https://www.cnki.com.cn/Article/CJFDTOTAL-HJJZ202201010.htm
Shen Z Z, Wang Q, Yan S N, et al. Pilot scale study on groundwater remediation in an organic contaminated site by coiled tubing in situ injection chemical oxidation technique[J]. Chinese Journal of Environmental Engineering, 2022, 16(1): 93-100. https://www.cnki.com.cn/Article/CJFDTOTAL-HJJZ202201010.htm
[3] 章生卫, 程小谷, 于李罡, 等. 石油烃污染地下水原位化学氧化修复研究[J]. 环境科学与技术, 2021, 44(S1): 56-60. doi: 10.19672/j.cnki.1003-6504.2021.S1.009
Zhang S W, Cheng X G, Yu L G, et al. Research on in situ chemical oxidation remediation of groundwater contaminated by petroleum hydrocarbons[J]. Environmental Science & Technology, 2021, 44(S1): 56-60. doi: 10.19672/j.cnki.1003-6504.2021.S1.009
[4] Boulangé M, Lorgeoux C, Biache C, et al. Fenton-like and potassium permanganate oxidations of PAH-contaminated soils: Impact of oxidant doses on PAH and polar PAC (polycyclic aromatic compound) behavior[J]. Chemosphere, 2019, 224: 437-444. doi: 10.1016/j.chemosphere.2019.02.108
[5] 曹兴涛, 谷广锋, 王新新, 等. 储油罐污染场地原位化学氧化修复进展[J]. 现代化工, 2017, 37(6): 20-23. doi: 10.16606/j.cnki.issn0253-4320.2017.06.005
Cao X T, Gu G F, Wang X X, et al. Progress of in situ chemical oxidation remediation of contaminated site by leaking oil storage tank[J]. Modern Chemical Industry, 2017, 37(6): 20-23. doi: 10.16606/j.cnki.issn0253-4320.2017.06.005
[6] Huling S G, Ross R R, Prestbo K M. In situ chemical oxidation: Permanganate oxidant volume design considerations[J]. Groundwater Monitoring & Remediation, 2017, 37(2): 78-86.
[7] Haselow J S, Siegrist R L, Crimi M, et al. Estimating the total oxidant demand for in situ chemical oxidation design[J]. Remediation Journal, 2003, 13(4): 5-16. doi: 10.1002/rem.10080
[8] Mumford K G, Thomson N R, Allen-King R M. Bench-scale investigation of permanganate natural oxidant demand kinetics[J]. Environmental Science & Technology, 2005, 39(8): 2835-2840.
[9] Kim U, Parker J C, Borden R C. Stochastic cost-optimization and risk assessment of in situ chemical oxidation for dense non-aqueous phase liquid (DNAPL) source remediation[J]. Stochastic Environmental Research and Risk Assessment, 2019, 33(1): 73-89. doi: 10.1007/s00477-018-1633-y
[10] Kakosová E, Hrabák P, Cerník M, et al. Effect of various chemical oxidation agents on soil microbial communities[J]. Chemical Engineering Journal, 2017, 314: 257-265. doi: 10.1016/j.cej.2016.12.065
[11] 杨乐巍, 张岳, 李书鹏, 等. 原位化学氧化高压注射修复优化设计与应用案例分析[J]. 环境工程, 2019, 37(8): 185-189. https://www.cnki.com.cn/Article/CJFDTOTAL-HJGC201908034.htm
Yang L W, Zhang Y, Li S P, et al. A case study on design and application of in situ chemical oxidation high pressure injection remediation[J]. Environmental Engineering, 2019, 37(8): 185-189. https://www.cnki.com.cn/Article/CJFDTOTAL-HJGC201908034.htm
[12] Wang N, Zheng T, Zhang G, et al. A review on Fenton-like processes for organic wastewater treatment[J]. Journal of Environmental Chemical Engineering, 2016, 4(1): 762-787. doi: 10.1016/j.jece.2015.12.016
[13] Li Y, Yang K, Liao X, et al. Quantification of oxidant demand and consumption for in situ chemical oxidation design: In the case of potassium permanganate[J]. Water, Air & Soil Pollution, 2018, 229(11): 375.
[14] Ranc B, Faure P, Croze V, et al. Selection of oxidant doses for in situ chemical oxidation of soils contaminated by polycyclic aromatic hydrocarbons (PAHs): A review[J]. Journal of Hazardous Materials, 2016, 312: 280-297. doi: 10.1016/j.jhazmat.2016.03.068
[15] ASTM. D7262-10. Standard test method for estimating the permanganate natural oxidant demand of soil and aquifer solids[S]. 2010.
[16] Mumford K G, Lamarche C S, Thomson N R. Natural oxidant demand of aquifer materials using the push-pull technique[J]. Journal of Environmental Engineering, 2004, 130(10): 1139-1146. doi: 10.1061/(ASCE)0733-9372(2004)130:10(1139)
[17] Brown R A. In situ chemical oxidation: Performance, practice, and pitfalls. AFCEE Technology Transfer Workshop[R]. San Antonio, 2003.
[18] Liang C, Chien Y C, Lin Y L. Impacts of ISCO persul-fate, peroxide and permanganate oxidants on soils: Soil oxidant demand and soil properties[J]. Soil and Sediment Contamination: An International Journal, 2012, 21(6): 701-719. doi: 10.1080/15320383.2012.691129
[19] Besha A T, Bekele D N, Naidu R, et al. Recent advances in surfactant-enhanced in situ chemical oxidation for the remediation of non-aqueous phase liquid contaminated soils and aquifers[J]. Environmental Technology & Innovation, 2018, 9: 303-322.
[20] Liu J, Liu Z, Zhang F, et al. Thermally activated persulfate oxidation of NAPL chlorinated organic compounds: Effect of soil composition on oxidant demand in different soil-persulfate systems[J]. Water Science and Technology, 2017, 75(8): 1794-1803. doi: 10.2166/wst.2017.052
[21] Huling S G, Pivetz B E. In situ chemical oxidation[R]. EPA, 2006.
[22] Hønning J, Broholm M M, Bjerg P L. Quantification of potassium permanganate consumption and PCE oxidation in subsurface materials[J]. Journal of Contaminant Hydrology, 2007, 90(3-4): 221-239. doi: 10.1016/j.jconhyd.2006.10.002
[23] Liao X, Zhao D, Yan X. Determination of potassium perman-ganate demand variation with depth for oxidation-remediation of soils from a PAHs-contaminated coking plant[J]. Journal of Hazardous Materials, 2011, 193: 164-170. doi: 10.1016/j.jhazmat.2011.07.045
[24] Siegrist R L, Crimi M, Simpkin T J. In situ chemical oxidation for groundwater remediation[M]. Springer Science & Business Media, 2011.
[25] 刘中良, 洪小峰, 舒代容. 有机污染场地氧化剂需求量及不同活化条件下氧化剂降解动力学研究[J]. 环境与发展, 2020, 32(11): 84-86. https://www.cnki.com.cn/Article/CJFDTOTAL-NMHB202011038.htm
Liu Z L, Hong X F, Shu D R. Study on oxidant demand and degradation kinetics of oxidant under different activation conditions in organic polluted sites[J]. Environment & Development, 2020, 32(11): 84-86. https://www.cnki.com.cn/Article/CJFDTOTAL-NMHB202011038.htm
[26] Costanza J, Otaño G, Callaghan J, et al. PCE oxidation by sodium persulfate in the presence of solids[J]. Environmental Science & Technology, 2010, 44(24): 9445-9450.
[27] Lee E S, Woo N C, Schwartz F W, et al. Characterization of controlled-release KMnO4 (CRP) barrier system for groundwater remediation: A pilot-scale flow-tank study[J]. Chemosphere, 2008, 71(5): 902-910. doi: 10.1016/j.chemosphere.2007.11.037
[28] Urynowicz M A, Balu B, Udayasankar U. Kinetics of natural oxidant demand by permanganate in aquifer solids[J]. Journal of Contaminant Hydrology, 2008, 96(1-4): 187-194.
[29] Tsitonaki A, Petri B, Crimi M, et al. In situ chemical oxida-tion of contaminated soil and groundwater using persulfate: A review[J]. Critical Reviews in Environmental Science and Technology, 2010, 40(1): 55-91.
[30] Cha K Y, Borden R C. Impact of injection system design on ISCO performance with permanganate-mathematical modeling results[J]. Journal of Contaminant Hydrology, 2012, 128(1): 33-46.
[31] Dangi M B, Urynowicz M A, Udayasankar U. Assessment of the experimental conditions affecting natural oxidant demand of soil by permanganate[J]. Journal of Environmental Chemical Engineering, 2018, 6(4): 5160-5166.
[32] Dangi M B, Urynowicz M A, Schultz C L, et al. A comparison of the soil natural oxidant demand exerted by permanganate, hydrogen peroxide, sodium persulfate, and sodium percarbonate[J]. Environmental Challenges, 2022, 7: 100456.
[33] Yan N, Liu F, Chen Y, et al. Influence of groundwater constituents on 1, 4-dioxane degradation by a binary oxidant system[J]. Water, Air & Soil Pollution, 2016, 227(12): 1-7.
[34] Urynowicz M A. In situ chemical oxidation with perman-ganate: Assessing the competitive interactions between target and nontarget compounds[J]. Soil & Sediment Contamination, 2007, 17(1): 53-62.
[35] Al-Shamsi M A, Thomson N R. Competition by aquifer materials in a bimetallic nanoparticle/persulfate system for the treatment of trichloroethylene[J]. Environmental Science: Processes & Impacts, 2013, 15(10): 1964-1968.
[36] Baciocchi R. Principles, developments and design criteria of in situ chemical oxidation[J]. Water, Air & Soil Pollution, 2013, 224(12): 1-11.
[37] 王文坦, 邵雁, 李社锋, 等. 一种土壤化学需氧量的测定方法: CN201610539931.8[P]. 2016-11-23.
Wang W T, Shao Y, Li S F, et al. A method for determination of chemical oxygen demand of soil: CN201610539931.8[P]. 2016-11-23.
[38] 杨勇, 张蒋维, 陈恺, 等. 化学氧化法治理焦化厂PAHs污染土壤[J]. 环境工程学报, 2016, 10(1): 427-431. https://www.cnki.com.cn/Article/CJFDTOTAL-HJJZ201601072.htm
Yang Y, Zhang J W, Chen K, et al. Chemical oxidation of coking plant soils contaminated with polycyclic aromatic hydrocarbons[J]. Chinese Journal of Environmental Engineering, 2016, 10(1): 427-431. https://www.cnki.com.cn/Article/CJFDTOTAL-HJJZ201601072.htm
[39] Huang Q, Dong H, Towne R M, et al. Permanganate diffu-sion and reaction in sedimentary rocks[J]. Journal of Contaminant Hydrology, 2014, 159: 36-46.
[40] Xu X, Thomson N R. A long-term bench-scale investi-gation of permanganate consumption by aquifer materials[J]. Journal of Contaminant Hydrology, 2009, 110(3-4): 73-86.
[41] Xu X, Thomson N R. Estimation of the maximum consum-ption of permanganate by aquifer solids using a modified chemical oxygen demand test[J]. Journal of Environmental Engineering, 2008, 134(5): 353-361.
[42] Molnár M. Hydrogen peroxide oxidation for in situ remed-iation of trichloroethylene-from the laboratory to the field[J]. Periodica Polytechnica Chemical Engineering, 2013, 57(1-2): 41-51.
[43] Thomson N, Sra K, Xu X. Improved understanding of in situ chemical oxidation. Technical objective 2: Soil reactivity[R]. 2009.
[44] Xu X. Interaction of chemical oxidants with aquifer materials[D]. Waterloo: University of Waterloo, 2006.
[45] 李旭, 苏世林, 文章, 等. 单井注抽试验测算地下水流速的数值分析[J]. 地球科学, 2022, 47(2): 633-641. https://www.cnki.com.cn/Article/CJFDTOTAL-DQKX202202019.htm
Li X, Su S L, Wen Z, et al. Numerical analysis of estimating groundwater velocity through single-well push-pull test[J]. Earth Science, 2022, 47(2): 633-641. https://www.cnki.com.cn/Article/CJFDTOTAL-DQKX202202019.htm
[46] Mathai A. Push-pull tests to support in situ chemical oxidation system design[D]. Waterloo: University of Waterloo, 2012.
[47] 尚晓伟, 姚佳斌, 田文钢, 等. 原位化学氧化技术在有机污染场地中试工程设计研究[J]. 环境与发展, 2020, 32(12): 71-72. https://www.cnki.com.cn/Article/CJFDTOTAL-NMHB202012035.htm
Shang X W, Yao J B, Tian W G, et al. Research on pilot project design of in situ chemical oxidation technology in organic contaminated site[J]. Environment and Development, 2020, 32(12): 71-72. https://www.cnki.com.cn/Article/CJFDTOTAL-NMHB202012035.htm
[48] Ko S, Ji S. In situ push-pull tests for the determination of TCE degradation and permanganate consumption rates[J]. Environmental Geology, 2007, 53(2): 359-364.
[49] Hendrych J, Kubal M, Beneš P, et al. The influence of solids characteristics on the specific oxidant consumption by in-situ chemical oxidation using potassium[J]. Acta Montanistica Slovaca, 2008, 13(3): 285-289.
[50] Bendouz M, Dionne J, Tran L H, et al. Polycyclic aromatic hydrocarbon oxidation from concentrates issued from an attrition process of polluted soil using the Fenton reagent and permanganate[J]. Water, Air & Soil Pollution, 2017, 228(3): 115.
[51] Teel A L, Elloy F C, Watts R J. Persulfate activation during exertion of total oxidant demand[J]. Chemosphere, 2016, 158: 184-192.
[52] Xu X, Thomson N R. Hydrogen peroxide persistence in the presence of aquifer materials[J]. Soil & Sediment Contamination, 2010, 19(5): 602-616.
-
