THE CONCENTRATION CHANGE AND TRANSPORT MECHANISM OF SUSPENDED SEDIMENTS IN SOUTHWESTERN LAIZHOU BAY
-
摘要:
根据2015年6月莱州湾西南部海域5个站位大小潮25 h海流连续同步观测及悬浮泥沙取样资料，分析了研究区悬浮泥沙浓度的时空变化规律；结合通量机制分解法，研究了悬浮泥沙输运机制，并探讨了悬浮泥沙浓度变化的影响因素。结果表明，莱州湾西南部海域悬浮泥沙浓度整体具有由北向南逐渐减小、由表层向底层逐渐增加的趋势；底层悬浮泥沙浓度在涨、落急时段出现峰值；潮周期内悬浮泥沙输运表现出不对称性，并且平流输运在悬浮泥沙输运中起到主导作用；水动力是影响悬浮泥沙浓度变化的主要因素，悬浮泥沙浓度与流速变化基本呈正相关关系，但浓度峰大多滞后流速峰1~2 h。
Abstract:Observations for 25 hours during a spring and neap tide cycle were carried ut at five sites of the southwestern Laizhou Bay on June 2015, together with suspended sediment sampling. Temporal and spatial changes in suspended sediment concentration were studied. The method of flux mechanism analysis was then adopted to study the transport mechanism of the suspended matter and the influence factors of concentration changes. Results show that the concentration of suspended sediment in the southwestern area of Laizhou Bay has a decreasing tendency from north to south and an increasing trend from surface to bottom. The concentration of suspended matter near the bottom peaked in both the ebb and flood tides, which is several times as high as the normal. The sediment transport during a tide cycle is asymmetry, and the advection transport dominates the suspended matter. Facts suggest that hydrodynamics is the principal factor affecting the change in suspended sediment concentration. The suspended sediment concentration has a positive correlation with flow rate. However, the peak concentration is mostly delayed by 1-2 h.
-
Key words:
- The southwestern Laizhou Bay /
- suspended sediment /
- flux mechanism
-
-
表 1 研究区大小潮悬浮泥沙浓度特征值
Table 1. Suspended sediment concentration during a spring and neap tide period in the study area
站位 大潮 小潮 水深/m 悬浮泥沙浓度/(mg/L) 水深/m 悬浮泥沙浓度/(mg/L) 表层 中层 底层 垂向平均 表层 中层 底层 垂向平均 1# 4.9 34.8 - 47.1 41.0 4.6 25.2 - 35.6 30.4 2# 6.6 24.2 26.5 27.4 26.0 6.1 19.1 19.3 21.2 19.6 3# 5.7 46.6 48.0 59.5 49.9 5.5 34.2 34.5 39.8 35.5 4# 9.1 36.2 37.6 48.3 39.3 8.3 21.8 23.0 25.2 23.1 5# 7.9 22.9 26.1 29.6 25.9 7.6 14.4 14.9 15.2 14.8
下载: 导出CSV
表 2 潮周期单宽平均输水量
Table 2. Average transport discharge per unit width
/(m3·(s·m)-1) 测站 大潮 小潮 QE QS QL QE QS QL 1# 0.101 0.039 0.140 0.071 0.030 0.101 2# 0.087 0.027 0.114 0.079 0.020 0.099 3# 0.081 0.038 0.119 -0.075 -0.057 -0.133 4# 0.373 -0.117 0.256 0.371 -0.069 0.302 5# 0.347 0.018 0.365 0.243 0.017 0.261
下载: 导出CSV
表 3 大潮期间单宽悬浮泥沙输运通量机制分解
Table 3. Analysis of suspended sediment transport per unit width during a spring tide
/(g·s-1·m-1) 测站 1# 2# 3# 4# 5# T1 3.46 2.06 4.04 14.47 8.82 T2 1.32 0.64 1.88 -4.55 0.46 T3 -0.05 0.02 -0.02 0.17 -0.01 T4 -3.36 -1.26 -3.42 3.75 2.02 T5 0.31 -0.15 1.32 -1.98 0.29 T6 -1.06 -0.23 -0.27 -2.01 -0.50 T7 -0.28 0.04 -0.04 -0.09 -0.03 T总 0.34 1.14 3.50 13.72 11.06 T绝对值 9.84 5.54 10.99 27.02 12.13
下载: 导出CSV
表 4 小潮期间单宽悬浮泥沙输运通量机制分解
Table 4. Analysis of suspended sediment transport per unit width during a neap tide
/(g·s-1·m-1) 测站 1# 2# 3# 4# 5# T1 1.91 1.44 -2.54 8.07 3.53 T2 0.81 0.37 -1.93 -1.51 0.25 T3 0.01 -0.01 0.01 -0.07 -0.03 T4 3.72 -0.07 -1.51 -3.95 3.04 T5 0.41 -0.06 -0.23 0.41 0.03 T6 0.21 0.36 0.31 0.29 0.09 T7 -0.01 0.01 0.01 0.01 -0.01 T总 7.06 2.04 -5.88 3.25 6.90 T绝对值 7.08 2.32 6.31 14.30 7.00
下载: 导出CSV
表 5 各测站大小潮期间悬浮泥沙输运对比
Table 5. Comparison between suspended sediment transports of a spring tide and a neap tide
测站 大潮 小潮 T1+T2 T3+T4+T5 平流比 T1+T2 T3+T4+T5 平流比 1# 4.78 -3.10 1.540 2.72 4.13 0.658 2# 2.70 -1.38 1.953 1.81 -0.14 1.953 3# 5.92 -2.12 2.793 -4.47 -1.73 2.590 4# 9.93 5.90 1.682 6.56 -3.61 1.820 5# 9.28 2.31 4.023 3.78 3.05 1.242
下载: 导出CSV
-
[1] Milliman J D, Shen H T, Yang Z S, et al. Transport and deposition of river sediment in the Changjiang Estuary and adjacent continental shelf[J].Continental Shelf Research, 1985, 4: 37-45. doi: 10.1016/0278-4343(85)90020-2
[2] Webster T, Lemckert C J. Sediment resuspension within a microtidal estuary/embayment and the implication to channel management[J]. Journal of Coastal Research, 2002, SI36(4): 753-759. doi: 10.2112/1551-5036-36.sp1.753
[3] Hu R J, Wu J Z, Zhu L H, et al. Suspended Sediment Transport and Deposition in the Zhoushan Archipelago Sea Area[J]. Journal of Ocean University of China: Oceanic and Coastal Sea Research, 2009, 8(4): 343-351.doi:10.1007/s11802-009-0343-y.
[4] Le V S, Yamashita T, Okunishi T, et al.Characteristics of suspended sediment material transport in the Ishikari Bay in snowmelt season[J]. Applied Ocean Reseach, 2006, 28:275-289. doi: 10.1016/j.apor.2006.11.001
[5] 万新宁, 李九发, 沈焕庭, 等.长江口外海滨悬沙分布及扩散特征[J].地理研究, 2006, 36(3):68-75. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dlyj200602013
[6] 陈沈良.杭州湾口南汇咀近岸水域水沙特征与通量[J].海洋科学, 2004, 28(3):18-22. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=hykx200403005
[7] 唐建华, 梁斌, 季若华.强潮河口悬浮泥沙浓度垂向结构分析——以杭州湾乍浦水域大潮期为例[J].水利水运工程学报, 2009, 6(2):39-43. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=slsykxyj200902007
[8] 刘桂卫, 黄海军, 丘仲锋.大风浪影响下海域泥沙输运异变数值模拟[J].水科学进展, 2010, 21(5):701-707. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=skxjz201005017
[9] 计建强, 汪一航, 王新怡, 等.夏季黄河入海泥沙的数值模拟研究[J].海洋科学, 2016, 40(3):118-127. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=hykx201603017
[10] 刘艳霞, 黄海军.基于遥感反演的莱州湾悬沙分布及其沉积动力分析[J].海洋学报, 2013, 35(6):43-53. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=hyxb201306005
[11] 崔廷伟, 张杰, 马毅, 等.渤海悬浮物分布的遥感研究[J].海洋学报, 2009, 31(5):10-18. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=hyxb200905002
[12] 刘晓, 黄海军, 刘艳霞, 等.黄河三角洲附近海域悬浮泥沙浓度估算[J].人民黄河, 2013, 35(2):10-12. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=rmhh201302005
[13] 堵盘军, 张蓓, 费岳军, 等.温州瓯飞浅滩海域悬沙输运特征及其来源探讨[J].泥沙研究, 2012(6):65-74. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=nsyj201206010
[14] 杨晓东, 姚炎明, 蒋国俊, 等.乐清湾悬沙输移机制分析[J].海洋通报, 2011, 30(1):53-59. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=hytb201101009
[15] 杜家笔, 裴艳东, 高建华, 等.弱动力浅海中的悬沙输运机制:以天津港附近海域为例[J].海洋学报, 2012, 34(1):136-144.
[16] 刘高峰, 朱建荣.河口涨落潮槽水沙输运机制研究[J].泥沙研究, 2005(5):51-57. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=nsyj200505009
[17] Dyer K R. Estuaries: A Physical Introduction [M]. 2nd ed. Singapore: John Wiley & Sons, 1997: 195.
[18] 宋永港, 卢永金, 刘新成.黄浦江河口水沙输运机制研究[J].华东师范大学学报, 2016(3):136-145. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=hdsfdxxb201603015
[19] 李殿魁, 杨玉珍, 等.延长黄河口清水沟流路行水年限的研究[M].郑州:黄河水利出版社, 2002:42-86.
[20] 陈斌, 刘健.莱州湾悬沙输运机制研究[J].水科学进展, 2005, 26(6):857-866. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=skxjz201506012
[21] 陈文良, 郑世民, 朱龙海, 等.莱州湾西部海域表层沉积物运移趋势[J].海洋地质前沿, 2016, 32(11):12-17. http://www.jhyqy.com.cn/cn/article/doi/10.16028/j.1009-2722.2016.11002
[22] 江文胜, 王厚杰.莱州湾悬浮泥沙分布形态及其与底质分布的关系[J].海洋与湖沼, 2005, 36(2):97-103. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=hyyhz200502001
-
