PORE STRUCTURE AND PERMEABILITY OF LOW PERMEABILITY RESERVOIR BASED ON CONSTANT SPEED MERCURY INJECTION TECHNOLOGY:TAKING ZHUHAI FORMATION IN WENCHANG A SAG OF ZHUJIANGKOU BASIN AS AN EXAMPLE
-
摘要:
目前南海西部各典型低渗透油气藏普遍存在微观渗流规律认识不清、油气开发潜力模糊的问题,严重制约了低渗油气田的后续开发部署。通过应用恒速压汞技术对珠江口盆地文昌A凹陷珠海组低渗凝析气藏储层孔隙结构及渗流潜力进行分析,结果表明:①渗透率不同的岩心样品孔隙半径差别很小,喉道是决定研究区储层渗透率的主要因素,主流喉道半径可以作为评价低渗透储层渗流能力和开发难度的关键物性参数;②在渗透率>1×10-3 μm2的气藏范围内,文昌A凹陷珠海组开发难度较小;而渗透率在0.1×10-3 μm2附近的特低—极特低渗透油藏范围内,文昌A凹陷珠海组(文昌WC-Y1井ZH3)开发难度很大。
Abstract:Characteristics of pore structures and development difficulties of the low-permeability gas reservoirs in the Zhuhai Formation in Wenchang A Sag of the Zhujiangkou Basin were studied with the method of constant speed mercury injection. Results show that: ① pore radius are similar for the cores with different permeability, throat is the main factor determining the reservoir permeability in the study area. The mainstream throat radius is the key physical parameter to be used to evaluate percolation ability and development difficulty of a low permeability reservoir; ②1×10-3μm2 is is a critical value for a low permeability gas reservoir. While the permeability of gas reservoir is higher than 1×10-3μm2, the development difficulty of Zhuhai Formation in Wenchang A Sag is getting smaller; and while the permeability of super-low permeability reservoirs near is lower than 0.1×10-3μm2, the development difficulty of Zhuhai Formation in Wenchang A Sag (ZH3 of Wenchang WC-Y1 well) is greater.
-
图 9 岩心中喉道粗细的分类(据文献[22])
Figure 9.
图 10 不同气田主流喉道半径对比(苏里格气田数据引自[23])
Figure 10.
表 1 实验岩心基本资料
Table 1. Basic data of cores
区块 样品编号 井号 层位 深度/m 孔隙度/% 渗透率/10-3 μm2 岩性描述 X区 2 WC-X1 ZH3 4 211.71~4 211.88 7.33 0.213 中砂岩 1 WC-Y1 ZH3 3 765.65 11.07 0.124 粉砂岩 Y区 3 WC-Y1 ZH2 3 342.07 8.38 0.623 细砂岩 4 WC-Y2 ZH3 3 686.87 10.22 1.78 中砂岩 5 WC-Y1 ZH1 3 332.41 12.48 5.61 细砂岩 表 2 恒速压汞测试结果
Table 2. Test result of constant speed mercury injection
样品编号 渗透率/10-3μm2 最大喉道半径/μm 平均喉道半径/μm 主流喉道半径/μm 方差 分选系数 均质系数 1 0.124 1.4 0.294 0.282 0.098 0.334 0.199 2 0.213 3.9 0.656 0.658 0.211 0.321 0.16 3 0.623 7 1.43 1.606 0.669 0.468 0.182 4 1.78 8.4 2.051 2.887 1.211 0.591 0.202 5 5.61 9.9 2.467 3.267 1.296 0.525 0.215 表 3 不同区块喉道粗细分类
Table 3. The classification results of throat thickness of different block reservoir cores
区块 层位 平均渗透率/10-3μm2 平均喉道半径/μm 分级 X区 ZH3 0.213 0.656 微细 ZH1 5.61 2.467 中 Y区 ZH2 0.623 1.430 细 ZH3 0.951 1.172 细 表 4 不同区块主流喉道半径
Table 4. The mainstream throat radius of different block reservoir cores
区块 层位 平均孔隙度/% 平均渗透率/10-3μm2 主流喉道半径/μm X区 ZH3 7.33 0.213 0.658 ZH1 12.48 5.61 3.267 Y区 ZH2 8.38 0.623 1.606 ZH3 10.65 0.951 1.585 -
