西南印度洋中脊玄武岩地球化学特征及其对岩浆过程的指示意义

韩宗珠; 孙苑高; 王传; 孙晓霞; 刘明; 来志庆

doi:10.16028/j.1009-2722.2020.045

西南印度洋中脊玄武岩地球化学特征及其对岩浆过程的指示意义

1.
中国海洋大学海洋地球科学学院，青岛 266100

2.
海底科学与探测技术教育部重点实验室，青岛 266100

基金项目: 国家自然科学基金（41376053）；山东省自然科学基金（ZR2017PD002）

详细信息

作者简介: 韩宗珠（1964—），男，教授，主要从事岩石学和地球化学方面的研究工作. E-mail：hanzongzhu@ouc.edu.cn

中图分类号: P736.4；P595

收稿日期: 2020-05-06

刊出日期: 2021-01-31

GEOCHEMICAL CHARACTERISTICS OF THE MORBS OF THE SWIR AND THEIR IMPLICATIONS FOR MAGMATIC PROCESS

1.
College of Marine Geosciences, Ocean University of China, Qingdao 266100, China

2.
Key Laboratory of Submarine Geosciences and Prospecting Techniques, Qingdao 266100, China

Received Date: 06 May 2020

Publish Date: 31 January 2021

摘要

摘要:
对采自西南印度洋中脊（SWIR）50°E附近5个站位的玄武岩样品进行了岩石学和元素地球化学研究。样品主量元素、TAS分类图解和AFM图解显示，SWIR研究区样品类型主要为低钾拉斑玄武岩。相对原始地幔SWIR区玄武岩具有Ba、Nb、Sr负异常，K表现为正异常。稀土元素分配模式均为左倾型，具有轻微的Eu、Ce正异常；SWIR区玄武岩都起源于上地幔，SWIR玄武岩则明显向EMⅡ端元偏移。SWIR玄武岩地幔源区相对最为富集，可能为DM和EMⅡ的混合源区，存在少量的陆壳成分。研究区玄武质岩浆起源深度为尖晶石橄榄岩区域处于中度还原环境下，经历了明显的橄榄石+单斜辉石+斜长石的分离结晶。
- 西南印度洋中脊 /
- 地球化学 /
- 玄武岩 /
- 岩浆过程 /
- 结晶分异
Abstract:
Five fresh MORBs samples collected from the 50°E of the SWIR have been studied for petrology and geochemistry. The major elements, TAS and AFM diagrams suggest that the samples from the SWIR are dominated by low potassic tholeiite. The primitive mantle-normalized sprider diagram shows negative anomalies of Ba, Nb and Sr, while K is positive in all of the samples. The MORBs of the SWIR show a depleted pattern of light REE in chondrite-normalized REE diagram, with slightly positive Eu and Ce anomalies; The MORBs from the SWIR are all derived from the upper mantle and obviously migrate to the end member of EMII. Most of the SWIR basalts enriched in the region are sourced from mantle. It is composed of both DM and EMII, includes small amount of continental crustal components. The basaltic magmas of SWIR are originated from the spinel peridotite zone. The samples of the SWIR are formed under a moderate reducing environment, experienced obvious fractional crystallization from olivine, clinopyroxene to plagioclase.
- SWIR /
- Geochemistry /
- basalt /
- magmatic processes /
- crystallization differentiation

HTML全文

图 1 西南印度洋洋中脊岩石类型分布图^[12]

Figure 1.

下载: 全尺寸图片幻灯片

图 2 SWIR研究区玄武岩代表性样品偏光镜下特征

Figure 2.

下载: 全尺寸图片幻灯片

图 3 SWIR研究区玄武岩TAS分类图

Figure 3.

下载: 全尺寸图片幻灯片

图 4 SWIR研究区玄武岩AFM图解

Figure 4.

下载: 全尺寸图片幻灯片

图 5 稀土元素球粒陨石标准化配分模式及微量元素原始地幔标准化蛛网图

Figure 5.

下载: 全尺寸图片幻灯片

图 6 SWIR研究区玄武岩Nb*-Ta*、εNd-⁸⁷Sr/⁸⁶Sr图解

Figure 6.

下载: 全尺寸图片幻灯片

图 7 SWIR玄武岩εNd-²⁰⁶Pb/²⁰⁴Pb、²⁰⁶Pb/²⁰⁴Pb -⁸⁷Sr/⁸⁶Sr、²⁰⁷Pb/²⁰⁴Pb-²⁰⁶Pb/²⁰⁴Pb图解

Figure 7.

下载: 全尺寸图片幻灯片

图 8 SWIR玄武岩（Tb/Yb）_N-（La/Sm）_N图解^[29]

Figure 8.

下载: 全尺寸图片幻灯片

图 9 ¹⁴³Nd/¹⁴⁴Nd-⁸⁷Sr/⁸⁶Sr图解^[27]

Figure 9.

下载: 全尺寸图片幻灯片

图 10 SWIR玄武岩（La/Yb）_N-（Dy/Yb）_N和La/Yb-Yb图解

Figure 10.

下载: 全尺寸图片幻灯片

图 11 SWIR玄武岩CaO/Al₂O₃-Na₈图解

Figure 11.

下载: 全尺寸图片幻灯片

表 1 SWIR研究区样品采样位置及采样方法

Table 1. Sample locations from SWIR and sampling methods

样品编号	经度	纬度	采样方式
B01	50.42585°E	37.60980°S	电视抓斗
B03	50.37599°E	37.552317°S
B04	50.46777°E	37.67918°S
B05	50.47244°E	37.67936°S
S31	48.5802°E	38.13244°S

下载: 导出CSV

表 2 SWIR研究区玄武岩元素地球化学数据分析结果

Table 2. Element geochemistry of the basalt in the study area

元素/指标		B01	B03	B04	B05	S31
主量元素/%	SiO₂	47.13	43.72	48.93	48.4	48.04
	TiO₂	1.52	1.41	1.4	1.43	1.14
	Fe₂O₃	14.67	12.72	12.83	13.57	14.62
	MgO	8.36	5.96	7.76	8.63	10.98
	Al₂O₃	12.21	14.94	14.57	13.61	13.36
	Na₂O	3.33	3.46	3.35	3.67	3.43
	CaO	10.77	12.48	11.13	11.29	10.65
	K₂O	0.28	0.35	0.37	0.28	0.31
	MnO	0.21	0.45	0.19	0.21	0.37
	P₂O₅	0.15	0.22	0.15	0.17	0.13
	Total	98.63	95.71	100.68	101.26	103.03
	Mg#	53	48	55	56	60
微量元素/10⁻⁶	Ba	14.4	21	25.07	26.95	17.1
	Cr	231.85	248.65	290.85	326.87	576.19
	Ni	89.14	95.99	114.65	117.82	220.23
	Sr	111.27	226.37	96.58	96.38	94.72
	V	431.92	426.03	393.05	411.36	346.54
	Nb	1.89	3.73	2.82	3.66	4.84
	Ta	0.13	0.12	0.15	0.15	0.16
	Hf	3.78	7.08	2.23	2.15	1.74
	Zr	89.67	78.96	78.6	74.9	57.4
稀土元素/10⁻⁶	La	2.84	7.49	2.14	2.32	3.48
	Ce	8.77	27.6	7.22	7.42	14.6
	Pr	1.62	2.47	1.41	1.46	1.39
	Nd	8.9	12.24	8.12	8.28	7.35
	Sm	3.21	3.78	3.04	3.1	2.54
	Eu	1.22	1.36	1.16	1.17	0.98
	Gd	3.69	4.37	3.54	3.49	3.02
	Tb	0.81	0.91	0.78	0.78	0.65
	Dy	5.72	6.3	5.52	5.64	4.54
	Ho	1.29	1.41	1.25	1.27	1.02
	Er	3.57	3.92	3.52	3.57	2.83
	Tm	0.57	0.61	0.56	0.57	0.45
	Yb	3.54	3.89	3.6	3.67	2.91
	Lu	0.57	0.64	0.59	0.58	0.47
	∑REE	46.31	76.99	42.45	43.32	46.22
	LREE/HREE	1.34	2.49	1.19	1.21	1.91
	La_N/Yb_N	0.54	1.3	0.4	0.43	0.81
	δEu	1.08	1.02	1.08	1.08	1.08
	δCe	0.97	1.54	0.97	0.94	1.6

下载: 导出CSV

表 3 SWIR研究区玄武岩Sr-Nd-Pb同位素分析结果

Table 3. The analysis results of Sr-Nd-Pb isotope on the SWIR

同位素	B04	B05	S31	DM	EM	HIMU	N-MORB
²⁰⁸Pb/²⁰⁴Pb	38.282 1	38.529 4	38.746 3	37.2～37.4	38～38.2		37.891
2SE	0.005 5	0.001 9	0.002
²⁰⁷Pb/²⁰⁴Pb	15.563 2	15.623 6	15.649 8	15.4	15.46～15.49		15.485
2SE	0.002	0.000 7	0.000 7
²⁰⁶Pb/²⁰⁴Pb	18.327 2	18.377 6	18.706 1	17.2～17.7	17.6～17.7	>20.8	18.6
2SE	0.002 2	0.000 7	0.000 8
²⁰⁸Pb/²⁰⁶Pb	2.088 81	2.096 5	2.071 2
2SE	0.000 07	0.000 05	0.000 04
²⁰⁷Pb/²⁰⁶Pb	0.849 19	0.850 1	0.836 5
2SE	0.000 02	0.000 01	0.000 01
⁸⁷Sr/⁸⁶Sr	0.702 692	0.702 7	0.704 1	0.702～0.702 4	0.704 5～0.706	0.702 9	0.702 84
±2σ	14	15	12
¹⁴³Nd/¹⁴⁴Nd	0.513 126	0.513 1	0.512 9	0.513 1～0.513 3	0.511 2	<0.512 8	0.513 13
±2σ	6	14	8
εNd（t）	9.519 388	9.285 3	5.715 5
注：DM、EM、HIMU数据来自ZINDLER等^[17]和WEAVER^[18]；N-MORB数据来自ITO和李彬贤^[19]。

下载: 导出CSV

表 4 SWIR玄武岩部分熔融程度

Table 4. The partial melting of the SWIR basalt

/%
采样位置	样品号	Na₈	Ca₈	Al₈	F
SWIR	B01	3.39	10.57	11.89	15.45
	B03	3.03	14.29	16.78	16.76
	B04	3.31	11.28	14.79	13.95
	B05	3.78	10.98	13.07	12.69
	S31	3.95	10.64	11.97	12.57

下载: 导出CSV

参考文献(38)

[1]	徐夕生, 丘检生. 火成岩岩石学[M]. 北京: 科学出版社, 2010: 185-186.
[2]	张国良. 东太平洋海隆13°N附近玄武岩特征及其对岩浆作用的指示意义[D]. 青岛: 中国科学院海洋研究所, 2010.
[3]	王妍. 中国东部苏北-合肥新生代大陆玄武岩地球化学研究[D]. 合肥: 中国科学技术大学, 2011.
[4]	PATRIAT P,SAUTER D,MUNSCHY M,et al. A survey of the southwest Indian ridge axis between Atlantis II fracture zone and the Indian ocean triple junction:regional setting and large scale segmentation[J]. Marine Geophysical Researches,1997,19(6):457-480. doi: 10.1023/A:1004312623534
[5]	MARKS K M,TIKKU A A. Cretaceous reconstructions of East Antarctica,Africa and Madagascar[J]. Earth and Planetary Science Letters,2001,186(3/4):479-495.
[6]	DICK H J B,LIN J,SCHOUTEN H. An ultraslow-spreading class of ocean ridge[J]. Nature,2003,426(6965):405-412. doi: 10.1038/nature02128
[7]	CHU D Z,GORDON R G. Evidence for motion between Nubia and Somalia along the Southwest Indian Ridge[J]. Nature,1999,398(6722):64-67. doi: 10.1038/18014
[8]	SCLATER J G,FISHER R L,PATRIAT P,et al. Eocene to recent development of the South-west Indian Ridge,a consequence of the evolution of the Indian Ocean triple junction[J]. Geophysical Journal of the Royal Astronomical Society,1981,64(3):587-604. doi: 10.1111/j.1365-246X.1981.tb02686.x
[9]	DE RIBET B,PATRIAT P. The axial region of the Southwest Indian ridge between 53°E and 59°E:evolution during the last 10 Ma[J]. Marine Geophysical Researches,1988,10(3/4):139-156.
[10]	BAKER E T, GERMAN C R. On the global distribution of hydrothermal vent fields[M]//GERMAN C R, LIN J, PARSON L M. Mid-Ocean Ridges: Hydrothermal Interactions between the Lithosphere and Oceans. Washington: American Geophysical Union, 2004: 245-266.
[11]	FONT L,MURTON B J,ROBERTS S,et al. Variations in melt productivity and melting conditions along SWIR (70°E–49°E):evidence from olivine-hosted and plagioclase-hosted melt inclusions[J]. Journal of Petrology,2007,48(8):1471-1494. doi: 10.1093/petrology/egm026
[12]	ZHOU H Y,DICK H J B. Thin crust as evidence for depleted mantle supporting the Marion Rise[J]. Nature,2013,494(7436):195-200. doi: 10.1038/nature11842
[13]	SEYLER M,BRUNELLI D,TOPLIS M J,et al. Multiscale chemical heterogeneities beneath the eastern Southwest Indian Ridge(52°E-68°E):trace element compositions of along-axis dredged peridotites[J]. Geochemistry,Geophysics,Geosystems,2011,12(9):Q0AC15.
[14]	BACH W,BANERJEE N R,DICK H J B,et al. Discovery of ancient and active hydrothermal systems along the ultra-slow spreading Southwest Indian Ridge 10°–16°E[J]. Geochemistry,Geophysics,Geosystems,2002,3(7):1044.
[15]	JANNEY P E,LE ROEX A P,CARLSON R W. Hafnium isotope and trace element constraints on the nature of mantle heterogeneity beneath the central Southwest Indian Ridge (13°E to 47°E)[J]. Journal of Petrology,2005,46(12):2427-2464. doi: 10.1093/petrology/egi060
[16]	SUN S S,MCDONOUGH W F. Chemical and isotopic systematics of oceanic basalts:implications for mantle composition and processes[J]. Geological Society,London,Special Publications,1989,42(1):313-345. doi: 10.1144/GSL.SP.1989.042.01.19
[17]	ZINDLER A,HART S. Chemical geodynamics[J]. Annual Review of Earth and Planetary Sciences,1986,14:493-571. doi: 10.1146/annurev.ea.14.050186.002425
[18]	WEAVER B L. The origin of ocean island basalt end-member compositions:trace element and isotopic constraints[J]. Earth and Planetary Science Letters,1991,104(1/4):381-397.
[19]	ITO E,李彬贤. 大洋中脊玄武岩氧、锶、钕、铅同位素地球化学[J]. 地质科学译丛,1988(3):54-64.
[20]	CANNAT M,SAUTER D,MENDEL V,et al. Modes of seafloor generation at a melt-poor ultraslow-spreading ridge[J]. Geology,2006,34(7):605-608. doi: 10.1130/G22486.1
[21]	HOFMANN A W. Chemical differentiation of the Earth:the relationship between mantle,continental crust,and oceanic crust[J]. Earth and Planetary Science Letters,1988,90(3):297-314. doi: 10.1016/0012-821X(88)90132-X
[22]	赵慧静. 东太平洋海隆13°N附近洋中脊玄武岩的研究[D]. 青岛: 中国科学院海洋研究所, 2013.
[23]	NIU Y L,COLLERSON K D,BATIZA R,et al. Origin of enriched-type mid-ocean ridge basalt at ridges far from mantle plumes:the East Pacific Rise at 11°20′N[J]. Journal of Geophysical Research,1999,104(B4):7067-7087. doi: 10.1029/1998JB900037
[24]	WILSON M,DOWNES H. Tertiary-quaternary extension-related alkaline magmatism in western and central Europe[J]. Journal of Petrology,1991,32(4):811-849. doi: 10.1093/petrology/32.4.811
[25]	ZARTMAN R E. Lead, strontium, and neodymium isotopic characterization of mineral deposits relative to their geologic environments[C]//Proceedings of the 27th Int Geol CongrMoscow. Utrecht: VNUK Science Press, 1984: 83-106.
[26]	ALLÈGRE C L,LEWIN E,DUPRÉ B. A coherent crust-mantle model for the uranium-thorium-lead isotopic system[J]. Chemical Geology,1988,70(3):211-234. doi: 10.1016/0009-2541(88)90094-0
[27]	HAWKESWORTH C J,KEMPTON P D,ROGERS N W,et al. Continental mantle lithosphere,and shallow level enrichment processes in the Earth’s mantle[J]. Earth and Planetary Science Letters,1990,96(3/4):256-268.
[28]	KLEIN E M,LANGMUIR C H. Global correlations of ocean ridge basalt chemistry with axial depth and crustal thickness[J]. Journal of Geophysical Research,1987,92(B8):8089-8115. doi: 10.1029/JB092iB08p08089
[29]	WANG K,PLANK T,WALKER J D,et al. A mantle melting profile across the Basin and Range,SW USA[J]. Journal of Geophysical Research,2002,107(B1):2017.
[30]	SHAW J E,BAKER J A,MENZIES M A,et al. Petrogenesis of the largest intraplate volcanic field on the Arabian Plate (Jordan):a mixed lithosphere-asthenosphere source activated by lithospheric extension[J]. Journal of Petrology,2003,44(9):1657-1679. doi: 10.1093/petrology/egg052
[31]	NIU Y L,BATIZA R. In situ densities of Morb melts and residual mantle:implications for buoyancy forces beneath mid-ocean ridges[J]. The Journal of Geology,1991,99(5):767-775. doi: 10.1086/629538
[32]	NIU Y L,BATIZA R. DENSCAL:program for calculating densities of silicate melts and mantle minerals as a function of pressure,temperature,and composition in melting range[J]. Computers & Geosciences,1991,17(5):679-687.
[33]	NIU Y L,BATIZA R. An empirical method for calculating melt compositions produced beneath mid-ocean ridges:application for axis and off-axis (seamounts) melting[J]. Journal of Geophysical Research,1991,96(B13):21753-21777. doi: 10.1029/91JB01933
[34]	NIU Y L,WAGGONER D G,SINTON J M,et al. Mantle source heterogeneity and melting processes beneath seafloor spreading centers:the East Pacific Rise,18°-19°S[J]. Journal of Geophysical Research,1996,101(B12):27711-27733. doi: 10.1029/96JB01923
[35]	于淼. 快、慢速扩张洋中脊玄武岩特征对比及意义[D]. 北京: 中国地质大学（北京）, 2013.
[36]	LE ROEX A P,DICK H J B,FISHER R L. Petrology and geochemistry of MORB from 25°E to 46°E along the southwest Indian Ridge:evidence for contrasting styles of mantle enrichment[J]. Journal of Petrology,1989,30(4):947-986. doi: 10.1093/petrology/30.4.947
[37]	刘豇瑜. 内蒙古赤峰地区汉诺坝玄武岩岩石类型及其地球化学特征[D]. 成都: 西南石油大学, 2012.
[38]	PANDEY S K,PAL S,SHRIVASTAVA J P,et al. Trace elements geochemistry and petrogenesis of basalt from the southern part of the East Pacific Rise[J]. Journal of the Geological Society of India,2013,81(1):91-100. doi: 10.1007/s12594-013-0008-8
