Distribution and origination of heavy metal pollution in bays of northern Hainan Island
-
摘要:
伴随社会经济的发展，海南岛附近海域出现不同程度的重金属污染。2019年我们采集了位于海南岛北部的铺前湾、澄迈湾、后水湾、洋浦湾的表层沉积物，对照国家海洋沉积物质量标准（GB18668—2002），使用地累积指数、重金属污染指数、重金属污染程度指数以及潜在生态风险指数等多种参数评价了各海湾重金属分布及污染状况。结果显示，砷（As）是各海湾中污染最明显的重金属元素。澄迈湾及铺前湾总体污染状况较为严重，洋浦湾总体污染状况较轻。船舶燃油燃烧、水产养殖、化肥施用、矿业废水等人类活动都会带来不同程度的重金属污染，需采取适当措施，有针对性地对海南岛北部海湾重金属污染进行防治。
Abstract:Hainan Island has been developing rapidly in recent years. Accompanied with the development of social economy, various degrees of heavy metal pollution has become an issue of pollution to the sea areas around the Hainan Island especially in the bays to the north of the island. To better understand the heavy metal pollution at present in those bays, surface sediments were sampled in Puqian Bay, Chengmai Bay, Houshui Bay, and Yangpu Bay in 2019. According to the China’s national standard on marine sediment quality （GB18668—2002）, using multiple parameters including the index of geo-accumulation （Igeo）, contamination factor （Cf）, the degree of contamination （Cd）, and ecological risk factor （Er）, the heavy metal pollution status in different those bays were evaluated. Results show that arsenic （As） was the common heavy metal pollutant among the bays. The pollution status in Chengmai Bay and Puqian Bay were relatively more serious than in Yangpu Bay. Anthropogenic activities such as fuel combustion by marine vessels, fertilizer application, and waste water discharge from mining could cause different levels of heavy metal pollution. Countermeasures shall be taken for the environmental protection by the local managements to prevent and control heavy metal pollution in the bays to the north of Hainan Island.
-
-
表 1 重金属分析方法及检出限
Table 1. Analytical methods and detection limits of different heavy metals
项目 检出限/（mg/kg） 分析方法 检测仪器 Zn 1 电感耦合等离子体质谱法 电感耦合等离子体质谱仪/7900 ICP-MS Cu 0.6 Pb 2 Cd 0.09 Cr 2 Hg 0.002 微波消解/原子荧光法 原子荧光分光光度计/
AFS-930As 0.01
下载: 导出CSV
表 2 各海湾重金属平均含量对比
Table 2. Average heavy metal concentration in different bays
μg/g 位置 Cu Pb Zn Cd Cr Hg As 文献 铺前湾 12.04 23.08 57.68 0.04 39.44 0.06 26.37 本文 澄迈湾 13.62 24.71 66.18 0.03 41.12 0.07 28.45 后水湾 17.21 28.56 86.45 0.07 64.16 0.10 19.89 洋浦湾 6.71 23.96 59.24 0.04 39.45 0.04 15.18 东寨港 3.60 10.59 33.25 0.01 - - 16.81 [7] 三亚湾 8.92 20.61 29.13 0.06 45.76 0.02 9.70 [8] 海南东部陆架 29.40 19.20 81.40 0.19 57.30 - 7.60 [14] 海南河流沉积物 33.35 43.44 102.10 0.33 56.48 0.05 8.79 [4] 注：“-”为无数据
下载: 导出CSV
表 3 我国海洋沉积物重金属质量标准（根据GB18668—2002）
Table 3. China’s national standard （GB18668—2002） on marine sediment quality for heavy metal
10−6 项目 第1类 第2类 第3类 Hg 0.2 0.5 1 Cd 0.5 1.5 5 Pb 60 130 250 Zn 150 350 600 Cu 35 100 200 Cr 80 150 270 As 20 65 93
下载: 导出CSV
Igeo 污染程度 Igeo≤0 无 0＜Igeo≤1 轻度—中度 1＜Igeo≤2 中度 2＜Igeo≤3 中度—强 3＜Igeo≤4 强 4＜Igeo≤5 强—极严重 5＜Igeo≤10 极严重
下载: 导出CSV
表 5 Cf污染程度分级[19]
Table 5. The pollution levels of Cf
Cf 污染程度 1 ≤Cf < 3 中等 3 ≤Cf< 6 较严重 Cf≥6 非常严重
下载: 导出CSV
表 6 Cd污染程度分级[19]
Table 6. The pollution levels of Cd
Cd 污染程度 Cd <7 低污染 7≤ Cd <14 中等程度污染 14≤ Cd <28 污染较严重 Cd ≥ 28 重度污染
下载: 导出CSV
Er 生态风险 Er < 40 轻微 40 ≤ Er < 80 中等 80 ≤ Er < 160 强 160 ≤ Er < 320 很强 Er ≥ 320 极强
下载: 导出CSV
表 8 铺前湾重金属及平均粒径Mz主成分分析
Table 8. The Principal Component Analysis of heavy metals and the mean particle size in the Puqian Bay
重金属 主成分1 Cu 0.97 Pb 0.95 Zn 0.96 Cd 0.74 Cr 0.94 Hg 0.99 As 0.79 Mz 0.87
下载: 导出CSV
-
[1] 谢文平,覃顺枫,马丽莎,等. 海南淡水养殖环境中有机氯农药及重金属残留情况分析[J]. 环境化学,2017,36(6):1407-1416. doi: 10.7524/j.issn.0254-6108.2017.06.2016093003
[2] 张钦洲,刁晓平,谢嘉,等. 海南东部海水养殖区水体,沉积物中微塑料的分布特征[J]. 海南大学学报(自然科学版),2020,38(2):159-165.
[3] XU F J,HU B Q,LI J,et al. Reassessment of heavy metal pollution in riverine sediments of Hainan Island,China:sources and risks[J]. Environmental Science & Pollution Research,2018,25(1/3):1766-1772.
[4] ZHAO D B,WAN S M,YU Z J,et al. Distribution,enrichment and sources of heavy metals in surface sediments of Hainan Island rivers,China[J]. Environmental Earth Sciences,2015,74(6):1-14.
[5] ONWULI D O,GOSPEL A,BROWN H,et al. The concentration of Lead in Periwinkle (Tympanotonosfuscatus) and River sediments in Eagle Island River,Port Harcourt,Rivers State Nigeria[J]. American Journal of Environmental Protection,2014,2(2):37-40. doi: 10.12691/env-2-2-2
[6] HU B Q,CUI R Y,LI J,et al. Occurrence and distribution of heavy metals in surface sediments of the Changhua River Estuary and adjacent shelf (Hainan Island)[J]. Marine Pollution Bulletin,2013,76(1-2):400-405. doi: 10.1016/j.marpolbul.2013.08.020
[7] YANG J,ZHANG B X,PENG X J,et al. Sediment Quality Assessment for Heavy Metal Contamination in the Dongzhai Harbor (Hainan Island,China) with Pollution Indice Approach[J]. Open Chemical Engineering Journal,2014,8(1):32-37. doi: 10.2174/1874123101408010032
[8] ZHAO L,LIU J Q,CAI G Q,et al. Distribution,source,and pollution assessment of heavy metals in Sanya offshore area,south Hainan Island of China[J]. Marine Pollution Bulletin,2020,160:111561. doi: 10.1016/j.marpolbul.2020.111561
[9] DOU Y G,LI J,ZHAO J T,et al. Distribution,enrichment and source of heavy metals in surface sediments of the eastern Beibu Bay,South China Sea[J]. Marine Pollution Bulletin,2013,67(1-2):137-145. doi: 10.1016/j.marpolbul.2012.11.022
[10] 中华人民共和国国家质量监督检验检疫总局. GB18668—2002, 海洋沉积物质量标准 [S]. 北京: 中国标准出版社.
[11] 国家海洋局. HY/T 147.2—2013, 海洋监测技术规程 第2部分: 沉积物 [S]. 北京: 中国标准出版社.
[12] 环境保护部. HJ 680—2013, 土壤和沉积物汞、砷、硒、铋、锑的测定 微波消解/原子荧光法 [S]. 北京: 中国环境科学出版社.
[13] 中华人民共和国国家质量监督检验检疫总局 中国国家标准化管理委员会. GB/T 12763.8—2007 , 海洋调查规范 第8部分: 海洋地质地球物理调查[S]. 北京: 中国标准出版社.
[14] 徐方建,闫慧梅,田旭,等. 海南岛东部陆架表层沉积物重金属污染评价[J]. 中国环境科学,2016,36(5):1530-1539. doi: 10.3969/j.issn.1000-6923.2016.05.036
[15] MULLER G. Index of geoaccumulation in sediments of the Rhine River[J]. Geojournal,1969,3(2):108-118.
[16] MULLER G. Schwermetalle in den sedimenten des Rheins-Vervänderungen seit 1971[J]. Umschau,1979,79:778-783.
[17] RUDINICK R L, GAO S. Composition of the continental crust[J]. The Crust 3, 2003: 1–64.
[18] MULLER G. Die Schwermetallbelastung der sedimente des Neckars und seiner Nebenflusse:eine Bestandsaufnahme[J]. Chem Zeitung,1981,105:157-164.
[19] HAKANSON S L. An ecological risk index for aquatic pollution control:a sedimentological approach[J]. Water Research,1980,14(8):975-1001. doi: 10.1016/0043-1354(80)90143-8
[20] LI T,CAI G Q,ZHANG M H,et al. The response of benthic foraminifera to heavy metals and grain sizes:A case study from Hainan Island,China[J]. Marine Pollution Bulletin,2021,167:112328. doi: 10.1016/j.marpolbul.2021.112328
[21] ZHANG H,SHAN B Q. Historical records of heavy metal accumulation in sediments and the relationship with agricultural intensification in the Yangtze-Huaihe region,China[J]. The Science of the Total Environment,2008,399(1/3):113-120. doi: 10.1016/j.scitotenv.2008.03.036
[22] XIA P,MENG X W,YIN P,et al. Eighty-year sedimentary record of heavy metal inputs in the intertidal sediments from the Nanliu River Estuary,Beibu Gulf of South China Sea[J]. Environmental Pollution,2011,159(1):92-99. doi: 10.1016/j.envpol.2010.09.014
[23] 吴钟解,陈石泉,蔡泽富,等. 海南八门湾沿岸表层沉积物重金属分布特征及污染评价[J]. 环境监测管理与技术,2019,31(6):28-32. doi: 10.19501/j.cnki.1006-2009.20191122.007
[24] 陈石泉,蔡泽富,吴钟解,等. 海南花场湾表层沉积物重金属分布特征及污染评价[J]. 应用海洋学学报,2018,37(1):85-93.
-
