A statistical damage constitutive rock model based on elastic energy release rate
-
摘要:
为了揭示岩石变形的破坏机理以及岩石材料产生损伤的本质原因，文章对岩石材料变形规律和力学特性进行分析后，再以损伤变量作为影响岩石变形和力学性能变化的内变量，采用能量原理、有效应力原理和统计损伤理论构建了一种基于弹性能释放率的新型岩石统计损伤本构模型。该损伤模型进一步完善了岩石损伤本构模型的理论体系，弥补了传统损伤模型无法合理解释引发岩石破坏原因的不足。利用岩石试验数据对损伤模型的参数进行确定，并将损伤演化模型代入弹性能-应变模型中，分析在加载过程中岩石弹性能变化的规律。结果表明：模型曲线与试验曲线在峰前变形阶段几乎重合，说明损伤模型可以很好地反映岩石的变形特性；在初始加载阶段，岩石的损伤变量随着轴向应变的增大而增大，说明在荷载作用下，岩石内部裂隙逐渐发展发育，使得岩石材料的损伤逐步积累；在围压达到10 MPa以上时，损伤-应变曲线基本重合。同时，在初始加载时刻，损伤-应变曲线增长率急剧上升，大约在岩石应变为0.01%时，损伤-应变曲线趋于平稳变化状态；且由于岩石在峰值应力点附近损伤迅速累积，进而使得损伤变量在数值上快速增大到1，这说明了围压的增大使得岩石破坏极限得到显著的提升。
Abstract:In order to truly reveal the mechanism of rock deformation and failure and the nature of rock material damage, based on the analysis of rock material deformation law and mechanical characteristics, a rock damage constitutive model based on elastic energy release rate is established using the energy principle. Taking the damage variable as an internal variable that affected the change of rock performance, a new type of statistical damage constitutive model for rock is established based on the effective stress principle and statistical damage theory. It further improves the theoretical system of rock damage constitutive model and mades up for the shortcomings that traditional damage models cannot reasonably explain the causes of rock failure. The parameters of the damage model are determined using the rock test data, and the feasibility and applicability of the damage model are verified through a comparative analysis of the model curve and the test curve. The damage evolution model is substituted into the elastic energy-strain model to analyze the law of rock elastic energy change during loading. The results show that the model curve and the test curve almost coincide in the deformation phase before the peak, indicating that the damage model perfectly reflects the linear elastic deformation characteristics of the rock. The model curve and the test curve do not agree well at the post-peak stage, but they also have a good description of the nonlinear deformation law of the rock. The damage model also better reflectes the relationship between the accumulation and release of elastic energy and the damage and destruction of rocks, and the characteristics of the degree of rock damage increases with the increasing confining pressure. At the same time, in the initial loading stage, the damage variable of the rock increases with the increasing axial strain. This shows that under the load, the internal cracks in the rock gradually develop, so that the damage of the rock material is gradually accumulated. When the confining pressure reaches above 10 MPa, the damage-strain curves basically coincide. The growth rate of the damage-strain curve rises sharply at the moment of initial loading. When the strain of the rock is about 0.01%, the damage-strain curve changes from rapid growth to steady growth. Because the damage quickly accumulates near the peak stress point of the rock, the damage variable rapidly increases to 1 in value.
-
Key words:
- rock /
- elastic energy release rate /
- statistical damage /
- stress-strain /
- elastic energy /
- damage variable
-
-
表 1 三轴压缩试验结果
Table 1. Triaxial compression test results
围压（σ3）/ MPa 峰值应力（σ1c）/ MPa 峰值应变（ε1c） 0 49.96 0.00542 10 75.95 0.00555 20 100.27 0.00657 30 132.63 0.00737
下载: 导出CSV
表 2 参数计算值
Table 2. Parameter values
围压（σ3）/ MPa 0 10 20 30 m 0.429 0.478 0.509 0.534 F0 1.280 1.340 1.630 1.760 R2 0.956 0.967 0.957 0.978
下载: 导出CSV
-
[1] 贾逸, 魏良帅, 黄安邦, 等. 高应力区岩石统计损伤本构模型研究[J]. 水文地质工程地质, 2019, 46(2): 118−124.
JIA Yi, WEI Liangshuai, HUANG Anbang, et al. A study of the statistical damage constitutive model of rock in high stress areas[J]. Hydrogeology & Engineering Geology, 2019, 46(2): 118−124. (in Chinese with English abstract)
[2] 曹文贵, 张升. 基于Mohr-Coulomb准则的岩石损伤统计分析方法研究[J]. 湖南大学学报(自然科学版), 2005, 32(1): 43−47.
CAO Wengui, ZHANG Sheng. Study on the statistical analysis of rock damage based on Mohr-coulomb criterion[J]. Journal of Hunan University (Natural Sciences), 2005, 32(1): 43−47. (in Chinese with English abstract)
[3] 曹文贵, 杨尚, 张超. 考虑弹性模量变化的岩石统计损伤本构模型[J]. 水文地质工程地质, 2017, 44(3): 42−48.
CAO Wengui, YANG Shang, ZHANG Chao. A statistical damage constitutive model of rocks considering the variation of the elastic modulus[J]. Hydrogeology & Engineering Geology, 2017, 44(3): 42−48. (in Chinese with English abstract)
[4] 王松鹤, 刘奉银, 齐吉琳. 考虑冻融的粉质黏土统计损伤本构关系研究[J]. 西北农林科技大学学报(自然科学版), 2016, 44(12): 226−234.
WANG Songhe, LIU Fengyin, QI Jilin. Statistical damage constitutive model for silty clay after freeze-thaw cycling[J]. Journal of Northwest A & F University (Natural Science Edition), 2016, 44(12): 226−234. (in Chinese with English abstract)
[5] 崔宏环, 刘建坤, 张立群, 等. 寒区路基改良土冻融循环与荷载耦合作用下损伤力学研究[J]. 冰川冻土, 2016, 38(4): 1183−1188.
CUI Honghuan, LIU Jiankun, ZHANG Liquan et al. Research on damage mechanics of modified-soil in cold regions subgrade coupling action of freeze-thaw and load[J]. Journal of Glaciology and Geocryology, 2016, 38(4): 1183−1188. (in Chinese with English abstract)
[6] 张嘉威, 章杨松, 李晓昭. 考虑渐进性破坏的岩石损伤本构模型研究[J]. 地下空间与工程学报, 2015, 11(6): 1528−1532.
ZHANG Jiawei, ZHANG Yangsong, LI Xiaozhao. Study on damage constitutive model of rock considering progressive failure[J]. Chinese Journal of Underground Space and Engineering, 2015, 11(6): 1528−1532. (in Chinese with English abstract)
[7] 曹文贵, 赵明华, 唐学军. 岩石破裂过程的统计损伤模拟研究[J]. 岩土工程学报,2003,25(2):184 − 187. [CAO Wengui, ZHAO Minghua, TANG Xuejun. Study on simulation of statistical damage in the full process of rock failure[J]. Chinese Journal of Geotechnical Engineering,2003,25(2):184 − 187. (in Chinese with English abstract) doi: 10.3321/j.issn:1000-4548.2003.02.013
[8] LIU Enlong, YU Haisui, ZHOU Cheng, et al. A binary-medium constitutive model for artificially structured soils based on the disturbed state concept and homogenization theory[J]. International Journal of Geomechanics,2017,17(7):04016154. doi: 10.1061/(ASCE)GM.1943-5622.0000859
[9] 王凯, 郑吉玉, 朱奎胜. 两种应力路径下无烟煤的变形破坏特征及能量分析[J]. 岩土力学, 2015, 36(增刊2): 259−266.
WANG Kai, ZHENG Jiyu, ZHU Kuisheng. Study on deformation and failure of anthracite under two stress paths and energy analysis [J]. Rock and Soil Mechanics, 2015, 36(Sup2): 259−266. (in Chinese with English abstract)
[10] LAI Yuanming,LI Jing,LI Qingze. Study on damage statistical constitutive model and stochastic simulation for warm ice-rich frozen silt[J]. Cold Regions Science and Technology,2012,71:102 − 110. doi: 10.1016/j.coldregions.2011.11.001
[11] LI Shuangyang, LAI Yuanming, ZHANG Shujuan, et al. An improved statistical damage constitutive model for warm frozen clay based on Mohr-coulomb criterion[J]. Cold Regions Science and Technology,2009,57(2/3):154 − 159.
[12] 张德, 刘恩龙, 刘星炎, 等. 基于修正Mohr-Coulomb屈服准则的冻结砂土损伤本构模型[J]. 岩石力学与工程学报, 2018, 37(4): 978−986.
ZHANG De, LIU Enlong, LIU Xingyan, et al. A damage constitutive model for frozen sandy soils based on modified Mohr-Coulomb yield criterion[J]. Chinese Journal of Rock Mechanics and Engineering, 2018, 37(4): 978−986. (in Chinese with English abstract)
[13] 王苏生, 徐卫亚, 王伟, 等. 岩石统计损伤本构模型与试验[J]. 河海大学学报(自然科学版), 2017, 45(5): 464−470.
WANG Susheng, XU Weiya, WANG Wei, et al. The statistical damage constitutive model of rocks and its experiment[J]. Journal of Hohai University (Natural Sciences), 2017, 45(5): 464−470. (in Chinese with English abstract)
[14] 王凯, 蒋一峰, 徐超. 不同含水率煤体单轴压缩力学特性及损伤统计模型研究[J]. 岩石力学与工程学报, 2018, 37(5): 1070−1079.
WANG Kai, JIANG Yifeng, XU Chao. Mechanical properties and statistical damage model of coal with different moisture contents under uniaxial compression[J]. Chinese Journal of Rock Mechanics and Engineering, 2018, 37(5): 1070−1079. (in Chinese with English abstract)
[15] 曹文贵, 张超, 贺敏, 等. 考虑空隙压密阶段特征的岩石应变软化统计损伤模拟方法[J]. 岩土工程学报,2016,38(10):1754 − 1761. [CAO Wengui, ZHANG Chao, HE Min, et al. Statistical damage simulation method of strain softening deformation process for rocks considering characteristics of void compaction stage[J]. Chinese Journal of Geotechnical Engineering,2016,38(10):1754 − 1761. (in Chinese with English abstract) doi: 10.11779/CJGE201610002
[16] ZHOU Shuwei, XIA Caichu, ZHAO Haibin, et al. Statistical damage constitutive model for rocks subjected to cyclic stress and cyclic temperature[J]. Acta Geophysica,2017,65(5):893 − 906. doi: 10.1007/s11600-017-0073-2
[17] 谢和平, 鞠杨, 黎立云. 基于能量耗散与释放原理的岩石强度与整体破坏准则[J]. 岩石力学与工程学报,2005,24(17):3003 − 3010. [XIE Heping, JU Yang, LI Liyun. Criteria for strength and structural failure of rocks based on energy dissipation and energy release principles[J]. Chinese Journal of Rock Mechanics and Engineering,2005,24(17):3003 − 3010. (in Chinese with English abstract) doi: 10.3321/j.issn:1000-6915.2005.17.001
[18] 谢和平, 鞠杨, 黎立云, 等. 岩体变形破坏过程的能量机制[J]. 岩石力学与工程学报,2008,27(9):1729 − 1740. [XIE Heping, JU Yang, LI Liyun, et al. Energy mechanism of deformation and failure process of rock masses[J]. Chinese Journal of Rock Mechanics and Engineering,2008,27(9):1729 − 1740. (in Chinese with English abstract) doi: 10.3321/j.issn:1000-6915.2008.09.001
[19] HUANG Shibing, LIU Quansheng, CHENG Aiping, et al. A statistical damage constitutive model under freeze-thaw and loading for rock and its engineering application[J]. Cold Regions Science and Technology,2018,145:142 − 150. doi: 10.1016/j.coldregions.2017.10.015
[20] KACHANOV M. Effective elastic properties of cracked solids: critical review of some basic concepts[J]. Applied Mechanics Reviews,1992,45(8):304 − 335. doi: 10.1115/1.3119761
[21] 温韬, 唐辉明, 刘佑荣, 等. 考虑裂纹闭合效应的岩石损伤力学模型及耗散能量分析[J]. 长江科学院院报,2016,33(5):69 − 75. [WEN Tao, TANG Huiming, LIU Yourong, et al. A rock damage mechanics model and analysis on damage energy dissipation in consideration of crack closure effect[J]. Journal of Yangtze River Scientific Research Institute,2016,33(5):69 − 75. (in Chinese with English abstract) doi: 10.11988/ckyyb.20150138
[22] 蒋维, 邓建, 李隐. 基于对数正态分布的岩石损伤本构模型研究[J]. 地下空间与工程学报, 2010, 6(6): 1190−1194.
JIANG Wei, DENG Jian, LI Yin. Study on constitutive model of rock damage based on lognormal distribution[J]. Chinese Journal of Underground Space and Engineering, 2010, 6(6): 1190−1194. (in Chinese with English abstract)
[23] 张彪, 张遂安, 夏立满, 等. 煤岩破坏过程中的统计损伤模型研究[J]. 煤矿安全, 2017, 48(11): 13−16.
ZHANG Biao, ZHANG Sui'an, XIA Liman, et al. Study on statistical damage model of coal rock destruction process[J]. Safety in Coal Mines, 2017, 48(11): 13−16. (in Chinese with English abstract)
[24] 杨明辉, 孙龙, 赵明华, 等. 基于统计损伤理论的非饱和土简易本构模型[J]. 水文地质工程地质, 2015, 42(3): 43−48.
YANG Minghui, SUN Long, ZHAO Minghua, et al. A simplified unsaturated soil constitutive model based on statistical damage theory[J]. Hydrogeology & Engineering Geology, 2015, 42 (3): 43−48. (in Chinese with English abstract)
-
