Research on early-warning prediction model of critical slide of creep landslide based on the MACD index
-
摘要:
滑坡的临滑预警预报研究一直以来都是热点也是难点。速度倒数模型是目前广泛使用的临滑预报模型，选择恰当的拟合曲线起始点将提高预报模型的精度。利用经济学上非常成熟的平滑异同平均线指标（MACD）快速寻找速度倒数模型拟合曲线的起始点，也就是滑坡临滑加速变形阶段开始加速（Onset of Acceleration，OOA）点，并以云南省会泽县的区布嘎滑坡为例，使用该指标对滑坡体进行临滑预报，并对该模型准确性进行了评估。结果表明：当变形速度的MACD值在−1~1的区间时，代表滑坡变形速度虽然有所增加，但变形趋势并未整体改变；当MACD值超过−1~1的区间，代表滑坡变形趋势整体发生改变，可将此阶段短期平均线上穿长期平均线的点（同时也是MACD值由负转正的点），作为滑坡OOA点。利用MACD指标能够快速有效的寻找拟合曲线起始点，利用指数平滑函数（ESF）处理的监测数据，拟合曲线的确定系数最高，误差率最低，误差率低于2%，模型预测结果随着数据的更新，将不断逼近真实结果，具有较高的准确率。
Abstract:The forecast of landslide’s early-warning prediction is always a hot and difficult issue. The inverse velocity method is wildly used for the landslide forecast, while the accuracy of the prediction is directly affected by the appropriate starting point of the fitting curve. This paper introduces the moving average convergence divergence (MACD) index, which is a mature forecasting method in the financial filed, to quickly search the start point of fitting curve (that is, onset of acceleration during the stage of accelerated deformation). The accuracy of the model is evaluated by the case of the Qubuga landslide in Huize County, Yunnan Province. The study results show that when the MACD index of deformation rate is in the range of −1 to 1, the deformation trend of landslide does not change. When the MACD index exceeds the range of −1 to 1, the deformation tendency radically changes and the point at which the short-term average line crosses the long-term average line and the MACD index changes from negative to positive can be regarded as the onset of acceleration. The starting point of the fitting curve is quickly and effectively found by the MACD index, and the monitoring data processed by the exponential smoothing function (ESF) has a higher certainty coefficient and lower rate of deviation, less than 2%. With the update of the data, the prediction results of the model approach the actual time of failure and has higher accuracy.
-
-
表 1 预测时间与真实滑动时间误差表
Table 1. Error rates of predicted time and real landslide time of GNSS-1 and GNSS-2
监测仪编号 监测时间/d 预测时间/d 滑动时间/d 预测与滑动时间之差/d 误差率/% GNSS-1 100 104.88 107 −2.12 1.98 101 106.90 107 −0.10 0.09 102 107.22 107 0.22 0.21 103 106.66 107 −0.34 0.32 104 106.56 107 −0.44 0.41 105 106.74 107 −0.26 0.25 106 107.04 107 0.04 0.04 GNSS-2 102 105.29 107 −1.71 1.60 103 105.59 107 −1.41 1.32 104 105.71 107 −1.29 1.20 105 106.08 107 −0.92 0.86 106 106.52 107 −0.48 0.45
下载: 导出CSV
-
[1] 房浩,李媛,杨旭东,等. 2010—2015年全国地质灾害发育分布特征分析[J]. 中国地质灾害与防治学报,2018,29(5):1 − 6. [FANG Hao,LI Yuan,YANG Xudong,et al. Distribution characters of geo-hazards in China during the period of 2010—2015[J]. The Chinese Journal of Geological Hazard and Control,2018,29(5):1 − 6. (in Chinese with English abstract)
[2] 刘传正,陈春利. 中国地质灾害防治成效与问题对策[J]. 工程地质学报,2020,28(2):375 − 383. [LIU Chuanzheng,CHEN Chunli. Achievements and countermeasures in risk reduction of geological disasters in China[J]. Journal of Engineering Geology,2020,28(2):375 − 383. (in Chinese with English abstract)
[3] 李滨,殷跃平,高杨,等. 西南岩溶山区大型崩滑灾害研究的关键问题[J]. 水文地质工程地质,2020,47(4):5 − 13. [LI Bin,YIN Yueping,GAO Yang,et al. Critical issues in rock avalanches in the karst mountain areas of Southwest China[J]. Hydrogeology & Engineering Geology,2020,47(4):5 − 13. (in Chinese with English abstract)
[4] 解明礼,巨能攀,刘蕴琨,等. 崩塌滑坡地质灾害风险排序方法研究[J]. 水文地质工程地质,2021,48(5):184 − 192. [XIE Mingli,JU Nengpan,LIU Yunkun,et al. A study of the risk ranking method of landslides and collapses[J]. Hydrogeology & Engineering Geology,2021,48(5):184 − 192. (in Chinese with English abstract)
[5] 许强,董秀军,李为乐. 基于天-空-地一体化的重大地质灾害隐患早期识别与监测预警[J]. 武汉大学学报(信息科学版),2019,44(7):957 − 966. [XU Qiang,DONG Xiujun,LI Weile. Integrated space-air-ground early detection,monitoring and warning system for potential catastrophic geohazards[J]. Geomatics and Information Science of Wuhan University,2019,44(7):957 − 966. (in Chinese with English abstract)
[6] 许强. 对滑坡监测预警相关问题的认识与思考[J]. 工程地质学报,2020,28(2):360 − 374. [XU Qiang. Understanding the landslide monitoring and early warning:Consideration to practical issues[J]. Journal of Engineering Geology,2020,28(2):360 − 374. (in Chinese with English abstract)
[7] 何满潮,任树林,陶志刚. 滑坡地质灾害牛顿力远程监测预警系统及工程应用[J]. 岩石力学与工程学报,2021,40(11):2161 − 2172. [HE Manchao,REN Shulin,TAO Zhigang. Remote monitoring and forecasting system of Newton force for landslide geological hazards and its engineering application[J]. Chinese Journal of Rock Mechanics and Engineering,2021,40(11):2161 − 2172. (in Chinese with English abstract)
[8] 林剑,张奇飞,龙万学,等. 基于预警隶属度函数多模型融合的滑坡预警方法[J]. 吉林大学学报(地球科学版),2019,49(2):477 − 484. [LIN Jian,ZHAN Qifei, LONG Wanxue, et al. Multi-model fusion mothed for landslide early warning based on early warning membership function[J]. Journal of Jilin University (Earth Science Edition),2019,49(2):477 − 484. (in Chinese with English abstract)
[9] 马娟,张鸣之,冯振,等. 适用于地质灾害调查的微型无人机航线控制系统设计与实现[J]. 水文地质工程地质,2019,46(2):37 − 41. [MA Juan,ZHANG Mingzhi,FENG Zhen,et al. Design and implementation of a micro-UAV route control system for geological hazard investigation[J]. Hydrogeology & Engineering Geology,2019,46(2):37 − 41. (in Chinese with English abstract)
[10] 张鸣之,湛兵,赵文祎,等. 基于虚拟参考站技术的滑坡高精度位移监测系统设计与实践[J]. 中国地质灾害与防治学报,2020,31(6):54 − 59. [ZHANG Mingzhi,ZHAN Bing,ZHAO WenYi,et al. Design and practice of high precision landslide displacement monitoring system based on VRS[J]. The Chinese Journal of Geological Hazard and Control,2020,31(6):54 − 59. (in Chinese with English abstract)
[11] 何朝阳,许强,巨能攀,等. 滑坡实时监测预警模型调度算法优化研究[J]. 武汉大学学报(信息科学版),2021,46(7):970 − 982. [HE Chaoyang,XU Qiang,JU Nengpan,et al. Optimization of model scheduling algorithm in real-time monitoring and early warning of landslide[J]. Geomatics and Information Science of Wuhan University,2021,46(7):970 − 982. (in Chinese with English abstract)
[12] SAITO M. Forecasting the time of occurrence of a slope failure[C]//Proceedings of the 6th International Conference on Soil Mechanics and Foundation Engineering. Oxford: Pergamon Press, 1965: 537 − 541.
[13] 许强, 黄润秋, 李秀珍. 滑坡时间预测预报研究进展[J]. 地球科学进展, 2004（3）: 478 − 483
XU Qiang, HUANG Runqiu, LI Xiuzhen. Research progress in time forecast and prediction of landslides[J]. Advance in Earth Sciences, 2004, 19（3）: 478 − 483. （in Chinese with English abstract）
[14] 许强, 汤明高, 徐开祥, 等. 滑坡时空演化规律及预警预报研究[J]. 岩石力学与工程学报, 2008（6）: 1104 − 1112
XU Qiang, TANG Minggao, XU Kaixiang, et al. Research on space-time evolution laws and early warning-prediction of landslides[J]. Chinese Journal of Rock Mechanics and Engineering, 2008, 27（6）: 1104 − 1112. （in Chinese with English abstract）
[15] 董秀军, 许强, 唐川, 等. 滑坡位移-时间曲线特征的物理模拟试验研究[J]. 工程地质学报, 2015, 23（3）: 401 − 407
DONG Xiujun, XU Qiang, TANG Chuan, et al. Characteristics of landslide displacement-time curve by physical simulation experiment[J]. Journal of Engineering Geology, 2015, 23（3）: 401 − 407. （in Chinese with English abstract）
[16] FUKUZONO T. A new method for predicting the failure time of a slope [C]//Proceedings of the 4th international conference and field workshop on landslides. Tokyo: Japan Landslide Society, 1985, 145-150.
[17] SEGALINI A,VALLETTA A,CARRI A. Landslide time-of-failure forecast and alert threshold assessment:A generalized criterion[J]. Engineering Geology,2018,245:72 − 80. doi: 10.1016/j.enggeo.2018.08.003
[18] CARLÀ T,INTRIERI E,DI TRAGLIA F,et al. Guidelines on the use of inverse velocity method as a tool for setting alarm thresholds and forecasting landslides and structure collapses[J]. Landslides,2017,14(2):517 − 534. doi: 10.1007/s10346-016-0731-5
[19] 马海涛, 张亦海, 于正兴. 滑坡速度倒数法预测模型加速开始点识别及临滑时间预测研究[J]. 岩石力学与工程学报, 2021, 40（2）: 355 − 364
MA Haitao, ZHANG Yihai, YU Zhengxing. Research on the identification of acceleration starting point in inverse velocity method and the prediction of sliding time[J]. Chinese Journal of Rock Mechanics and Engineering, 2021, 40（2）: 355 − 364. （in Chinese with English abstract）
[20] KILBURN C R J,PETLEY D N. Forecasting giant,catastrophic slope collapse:Lessons from Vajont,Northern Italy[J]. Geomorphology,2003,54(1/2):21 − 32.
[21] PETLEY D N. The evolution of slope failures:mechanisms of rupture propagation[J]. Natural Hazards and Earth System Science,2004,4:147 − 152. doi: 10.5194/nhess-4-147-2004
[22] PETLEY D,BULMER M,MURPHY W. Patterns of movement in rotational and translational landslides[J]. Geology,2002,30:719 − 722.
[23] ROSE N D,HUNGR O. Forecasting potential rock slope failure in open pit mines using the inverse-velocity method[J]. International Journal of Rock Mechanics and Mining Sciences,2007,44(2):308 − 320. doi: 10.1016/j.ijrmms.2006.07.014
[24] DICK G J,EBERHARDT E,CABREJO-LIÉVANO A G,et al. Development of an early-warning time-of-failure analysis methodology for open-pit mine slopes utilizing ground-based slope stability radar monitoring data[J]. Can Geotech J,2014,52:515 − 529.
[25] CARLÀ T,FARINA P,INTRIERI E,et al. On the monitoring and early-warning of brittle slope failures in hard rock masses:Examples from an open-pit mine[J]. Engineering Geology,2017,228:71 − 81. doi: 10.1016/j.enggeo.2017.08.007
[26] 许强. 滑坡的变形破坏行为与内在机理[J]. 工程地质学报,2012,20(2):145 − 151. [XU Qiang. Theoretical studies on prediction of landslides using slope deformation process data[J]. Journal of Engineering Geology,2012,20(2):145 − 151. (in Chinese with English abstract)
[27] 周越,曾昭发,唐海燕,等. 公路勘察中滑坡体的地球物理特征与分析—以张榆线公路勘察为例[J]. 吉林大学学报(地球科学版),2021,51(2):638 − 644. [ZHOU Yue,ZENG Zhaofa,TANG Haiyan,et al. Geophysical characteristics of landslide body in highway reconnaissance: A case study in highway prospecting of Zhangyu Line[J]. Journal of Jilin University (Earth Science Edition),2021,51(2):638 − 644.
[28] 唐军峰,唐雪梅,周基,等. 滑坡堆积体变形失稳机制—以贵州剑河县东岭信滑坡为例[J]. 吉林大学学报(地球科学版),2022,52(2):503 − 516. [TANG Junfeng,TANG Xuemei,ZHOU Ji,et al. Deformation and instability mechanism of landslide accumulation: A case study of Donglingxin landslide accumulation in Jianhe County, Guizhou Province[J]. Journal of Jilin University (Earth Science Edition),2022,52(2):503 − 516. (in Chinese with English abstract)
[29] JU N P,HUANG J,HE C Y,et al. Landslide early warning,case studies from Southwest China[J]. Engineering Geology,2020,279:105917. doi: 10.1016/j.enggeo.2020.105917
[30] 白洁,巨能攀,张成强,等. 贵州兴义滑坡特征及成功预警研究[J]. 工程地质学报,2020,28(6):1246 − 1258. [BAI Jie,JU Nengpan,ZHANG Chengqiang,et al. Characteristics and successful early warning case of Xingyi landslide in Guizhou Province[J]. Journal of Engineering Geology,2020,28(6):1246 − 1258. (in Chinese with English abstract)
[31] ROBERT H. Some new pre-warning criteria for creep slope failure[J]. Science China (Technological Sciences),2011,54(Sup1):210 − 220. doi: 10.1007/s11431-011-4640-5
[32] WANG J,KIM J. Predicting stock price trend using MACD optimized by historical volatility[J]. Mathematical Problems in Engineering,2018,2018:9280590.
-
