Experimental investigation on same diameter sealing and stratified pumping of hard rock hydrogeological parameter well
-
摘要:
针对传统施工程序无法解决坚硬岩石止水环隙很小（仅3 mm）钻孔的同径止水及分层抽水试验问题，以山西某水文地质参数井为研究对象，采用现场和室内综合试验的方法,对同径止水方案、材料、技术、分层抽水等工艺进行研究。结果表明：（1） 同径止水装置经过特殊的“外掏内缩”设计与制作，使止水外环间隙由3 mm增大到8.5 mm，解决了“极小止水环隙”下的同径止水问题；经抽水检验，止水效果良好。（2） 在孔外一系列试验的基础上，定制的止水材料和选择的止水组合与本孔的适应性强，下管风险小，实施过程相当顺利。（3）专门设计的分层导水管路，其上串接的隔离封水胶球与止水套管柱内设置的锥形隔水接头相互契合，封水可靠，形成了两套独立的导水管路，满足了上、下含水层分层抽水试验的工况。研究结果可为类似水文地质参数井开展同径止水或分层抽水试验研究提供参考。
Abstract:On account of the problem of the same diameter sealing and stratified pumping test in a hard rock borehole with very small water-sealing ring gap (only 3 mm) unsolved by traditional construction procedures, taking the hydrogeological parameter well located in Shanxi Province as the research object, the in-situ and laboratory comprehensive tests are employed to implement the research on the construction process of same diameter water sealing plans, materials, technology, as well as the stratified pumping test. Results show that, (1) as for the water sealing device with the same diameter, the outer of the water sealing ring gap is increased from 3 mm to 8.5 mm by special design and manufacture of “cut out and shrink in” to solve the problem of same diameter water-sealing under the situation of extremely small water sealing ring gap, which performs well via the pumping test inspection. (2)Based on the series of tests research outside the bore hole, the custom-made “sealing material” and selected “water sealing combination” have strong adaptability with the hole, and the implementation of down-pipe goes rather smooth with low risk. (3)The stratified aqueduct is specially designed, on which the concatenated isolation sealing rubber ball fit well with the conical water isolating joint set in the waterproof casing pipe. The water sealing is reliable, and two sets of independent aqueduct are formed to meet the stratified pumping test of the upper and lower aquifers. The research results can provide reference for the same diameter water sealing or stratified pumping test of similar hydrogeological parameter wells.wells.
-
-
表 1 3种止水方案试验项目与可行性评价结果
Table 1. Test items and feasibility evaluation results of three water-stopping schemes
方案 理论孔径/mm 装配外径/mm 膨胀外径/mm 充盈比/% 组合特征 实施可行性 A方案 95 111 131 138 胶带+海带 装配外径超径无法入孔 B方案 95 93 140 147 胶带+海带 装配外径比较合适 C方案 95 93 145 153 胶带+胶粒 水泥伞装配整型困难
下载: 导出CSV
表 2 3种膨胀止水材料室内浸泡试验性能数据
Table 2. Indoor immersion test performance data of three kinds of expansive water-stopping materials
材料名称 规格 形状 浸泡/h 膨胀率/% 性状描述 膨胀胶带 宽100 mm、
厚10 mm（定制）矩形条带状 36 厚200，宽120 形状不变，体积增大，边界规整，有些类似产品
呈絮状边界，不适宜优质食用海带 无 薄片状 8 200 体积净增加1倍，形状仍为薄片状，无絮状边界，具有一定的强度 吸水膨胀胶粒 无 颗粒状形态直径，约1.0 mm 6 200 体积净增加1倍，形状仍为粒状，无絮状边界，强度很弱，靠其膨胀后溢出伞体外形成环状体进行止水
下载: 导出CSV
表 3 水文参数井分层抽水数据表
Table 3. Summary of layered pumping data of hydrological parameter well
抽次 控制流量/（m3∙h−1） 降深/m 单位涌水量/（L∙s−1∙m−1） 影响半径/m 渗透系数/（m∙d−1） 静止水位/m 最高水温/°C 第一次（下层） 15.26 92.79 0.0457 156.50 0.0285 20.71 46.5 10.07 61.15 0.0457 100.40 0.0270 46.0 5.90 35.70 0.0459 56.47 0.0250 45.5 第二次（上层） 20.69 31.30 0.1836 123.70 0.1561 20.30 46.0 15.26 23.00 0.1843 89.02 0.1498 45.5 10.07 15.10 0.1853 56.71 0.1411 45.0 第三次（混合） 30.71 30.05 0.2839 92.53 0.0948 20.45 46.5 22.12 21.05 0.2918 64.04 0.0926 46.0 13.03 13.03 0.2992 35.66 0.0869 45.5
下载: 导出CSV
-
[1] 中国地质调查局. 水文地质手册[M]. 2版. 北京: 地质出版社, 2012: 434 − 438
China Geological Survey. Handbook of hydrogeology[M]. 2 ed. Beijing: Geological Publishing House, 2012: 434 − 438. （in Chinese）
[2] 王达, 何远信. 地质钻探手册[M]. 长沙: 中南大学出版社, 2014: 323 − 343
WANG Da, HE Yuanxin. Geological drilling handbook[M]. Changsha: Central South University Press, 2014: 323 − 343. （in Chinese）
[3] 王明明,解伟,安永会,等. 封隔注浆分层成井技术在水文地质勘查中的应用研究[J]. 水文地质工程地质,2019,46(1):50 − 55. [WANG Mingming,XIE Wei,AN Yonghui,et al. Application of the technology of injecting cement for the stratified well completion to hydrogeological exploration[J]. Hydrogeology & Engineering Geology,2019,46(1):50 − 55. (in Chinese with English abstract)
WANG Mingming, XIE Wei, AN Yonghui, et al. Application of the technology of injecting cement for the stratified well completion to hydrogeological exploration[J]. Hydrogeology & Engineering Geology, 2019, 46（1）: 50-55. （in Chinese with English abstract）
[4] 地热钻探技术规程: DZ/T 0260—2014[S]. 北京: 中华人民共和国国土资源部, 2014
Technical specification for geothermal drilling: DZ/T 0260—2014[S]. Beijing: Ministry of Land and Resources of the People's Republic of China. （in Chinese）
[5] 《地质管材手册》编写组. 地质、水文、石油钻探管材手册[M]. 北京: 地质出版社, 1975: 59 − 67
Geological Pipe Manual Compilation Group. Geological, hydrological and petroleum drilling pipe manual[M]. Beijing: Geological Publishing House, 1975: 59 − 67. （in Chinese）
[6] 张建良,李文鹏,孙梓航,等. 集束式监测井成井工艺研究[J]. 水文地质工程地质,2021,48(1):44 − 48. [ZHANG Jianliang,LI Wenpeng,SUN Zihang,et al. A study of the well-forming technology of a cluster monitoring well[J]. Hydrogeology & Engineering Geology,2021,48(1):44 − 48. (in Chinese with English abstract)
ZHANG Jianliang, LI Wenpeng, SUN Zihang, et al. A study of the well-forming technology of a cluster monitoring well[J]. Hydrogeology & Engineering Geology, 2021, 48（1）: 44-48. （in Chinese with English abstract）
[7] 杨联锋,段云星. 新型同径分层止水工艺在地热探采深井的应用[J]. 钻探工程,2021,48(8):33 − 39. [YANG Lianfeng,DUAN Yunxing. Application of new single diameter multi-level water sealing technology in geothermal exploration and production wells[J]. Drilling Engineering,2021,48(8):33 − 39. (in Chinese with English abstract)
YANG Lianfeng, DUAN Yunxing. Application of new single diameter multi-level water sealing technology in geothermal exploration and production wells[J]. Drilling Engineering, 2021, 48（8）: 33-39. （in Chinese with English abstract）
[8] 叶成明, 邢卫国, 冯志仁. 新型的地下水监测井——多级完整监测井[C]//严重缺水地区地下水勘查论文集（第二集）. 北京: 地质出版社, 2004: 197 − 200
YE Chengming, XING Weiguo, FENG Zhiren. A new type of groundwater monitoring well: Multi-level complete monitoring well[C]//Syposium of groundwater exploration in severely water shortage areas （Volume II）. Beijing: Geological Publishing House, 2004: 197 − 200. （in Chinese）
[9] 齐治虎,刘国卫. 岩芯钻探中复杂地层的护孔工艺[J]. 西部探矿工程,2021,33(11):49 − 52+57. [QI Zhihu,LIU Guowei. Hole protection technology for complex strata in core drilling[J]. West-China Exploration Engineering,2021,33(11):49 − 52+57. (in Chinese) doi: 10.3969/j.issn.1004-5716.2021.11.017
QI Zhihu, LIU Guowei. Hole protection technology for complex strata in core drilling[J]. West-China Exploration Engineering, 2021, 33（11）: 49-52. （in Chinese） doi: 10.3969/j.issn.1004-5716.2021.11.017
[10] 刘鑫. 高温大温差低密度水泥浆体系的室内研究[J]. 西部探矿工程,2021,33(11):65 − 67. [LIU Xin. Laboratory study on low density cement slurry system with high temperature and large temperature difference[J]. West-China Exploration Engineering,2021,33(11):65 − 67. (in Chinese) doi: 10.3969/j.issn.1004-5716.2021.11.023
LIU Xin. Laboratory study on low density cement slurry system with high temperature and large temperature difference[J]. West-China Exploration Engineering, 2021, 33（11）: 65-67. （in Chinese） doi: 10.3969/j.issn.1004-5716.2021.11.023
[11] 邓德龙,鲍立新,罗京元. 单井分层抽水试验井结构设计与成井工艺[J]. 东北水利水电,2019,37(1):26 − 28. [DENG Delong,BAO Lixin,LUO Jingyuan. Structure design and completion technology of single well completed stratified pumping test[J]. Water Resources & Hydropower of Northeast China,2019,37(1):26 − 28. (in Chinese)
DENG Delong, BAO Lixin, LUO Jingyuan. Structure design and completion technology of single well completed stratified pumping test[J]. Water Resources & Hydropower of Northeast China, 2019, 37（1）: 26-28. （in Chinese）
[12] 郝国利,于建丛,李国民,等. 新型分层抽水管内止水装置的研制[J]. 探矿工程(岩土钻掘工程),2017,44(3):39 − 43. [HAO Guoli,YU Jiancong,LI Guomin,et al. Development of a new type of intra-tube sealing device for stratified water pumping[J]. Exploration Engineering (Rock & Soil Drilling and Tunneling),2017,44(3):39 − 43. (in Chinese with English abstract)
HAO Guoli, YU Jiancong, LI Guomin, et al. Development of a new type of intra-tube sealing device for stratified water pumping[J]. Exploration Engineering （Rock & Soil Drilling and Tunneling）, 2017, 44（3）: 39-43. （in Chinese with English abstract）
[13] 李晓龙,董书宁,刘恺德. 多层含水层分层止水技术研究进展[J]. 煤矿安全,2020,51(2):84 − 90. [LI Xiaolong,DONG Shuning,LIU Kaide. Research progress of stratified water stop technology for multilayer aquifer[J]. Safety in Coal Mines,2020,51(2):84 − 90. (in Chinese with English abstract)
LI Xiaolong, DONG Shuning, LIU Kaide. Research progress of stratified water stop technology for multilayer aquifer[J]. Safety in Coal Mines, 2020, 51（2）: 84-90. （in Chinese with English abstract）
[14] 万亿,韩柳. 基于胶塞法的一孔多层抽水试验分层止水技术及应用[J]. 地下水,2017,39(3):248 − 249. [WAN Yi,HAN Liu. One hole multi-layer pumping test layered water stop technology based on rubber plug method and its application[J]. Ground Water,2017,39(3):248 − 249. (in Chinese) doi: 10.3969/j.issn.1004-1184.2017.03.097
WAN Yi, HAN Liu. One hole multi-layer pumping test layered water stop technology based on rubber plug method and its application[J]. Ground Water, 2017, 39（3）: 248-249. （in Chinese） doi: 10.3969/j.issn.1004-1184.2017.03.097
[15] 张建良. 关于分层抽水试验的技术改进[J]. 探矿工程(岩土钻掘工程),2009,36(4):16 − 19. [ZHANG Jianliang. Technical improvement on stratified pumping test[J]. Exploration Engineering (Rock & Soil Drilling and Tunneling),2009,36(4):16 − 19. (in Chinese with English abstract)
ZHANG Jianliang. Technical improvement on stratified pumping test[J]. Exploration Engineering （Rock & Soil Drilling and Tunneling）, 2009, 36（4）: 16-19. （in Chinese with English abstract）
[16] 张云峰,孙增兵,王斌斌,等. 单孔分层抽水法的改进及在准东煤田的应用[J]. 煤田地质与勘探,2016,44(3):92 − 96. [ZHANG Yunfeng,SUN Zengbing,WANG Binbin,et al. Amelioration of hierarchical method of single borehole pumping test and its application in Zhundong coalfield[J]. Coal Geology & Exploration,2016,44(3):92 − 96. (in Chinese with English abstract) doi: 10.3969/j.issn.1001-1986.2016.03.017
ZHANG Yunfeng, SUN Zengbing, WANG Binbin, et al. Amelioration of hierarchical method of single borehole pumping test and its application in Zhundong coalfield[J]. Coal Geology & Exploration, 2016, 44（3）: 92-96. （in Chinese with English abstract） doi: 10.3969/j.issn.1001-1986.2016.03.017
[17] 周群道,康凤新,刘志涛,等. 抽水试验方法和成井工艺类型对热储层水文地质参数的影响[J]. 山东国土资源,2018,34(10):106 − 114. [ZHOU Qundao,KANG Fengxin,LIU Zhitao,et al. Influence of pumping test method and well completion technology type on hydrogeological parameters of thermal reservoir[J]. Shandong Land and Resources,2018,34(10):106 − 114. (in Chinese with English abstract)
ZHOU Qundao, KANG Fengxin, LIU Zhitao, et al. Influence of pumping test method and well completion technology type on hydrogeological parameters of thermal reservoir[J]. Shandong Land and Resources, 2018, 34（10）: 106-114. （in Chinese with English abstract）
-
