Influence mechanism of vegetation infiltration effect on shallow landslides of granite residual soil
-
摘要:
华南地区台风暴雨诱发的滑坡往往呈浅层、流态化、群发性等特征，大量调查发现植被增渗效应对花岗岩残积土滑坡的形成具有显著影响，但目前研究大多探讨植被根系对土体渗透性的影响，未能揭示植被增渗效应对浅层滑坡的影响机理。基于此，以“2019.6.9”广东省龙川县群发性滑坡灾害为例，通过大量现场勘查，查明滑坡区域地质环境条件与植被发育情况，分析植被对浅层滑坡的增渗效应；采用“双环入渗法”测得不同植被样地的入渗速率，分析其下渗过程和渗透规律；选取典型滑坡剖面，建立地质模型，运用Geo-Studio软件对强降雨条件下浅层滑坡渗流规律和土体应力-应变特征进行模拟；最后结合模拟结果和现场调查情况，分析强降雨条件下植被增渗效应对浅层滑坡的影响机理。结果表明：植被能够有效地增强土壤渗透能力，渗透能力大小依次为针叶林地、灌木林地、裸土地；在植被增渗效应影响下，雨水入渗到根土复合层底部会发生滞水现象，浅层土体迅速趋于饱和，土体中孔隙水压力及渗流力瞬时剧增，土体饱水使得残积土发生软化，同时边坡自重增加，最终导致斜坡失稳。研究结果可为华南地区暴雨群发性滑坡的形成机理、预警预报等提供科学依据，具有重要的意义。
Abstract:The landslides induced by typhoons and rainstorms in Southern China are often shallow, fluidized and clustered. A large number of investigations have shown that vegetation infiltration has a significant impact on the formation of granite residual soil landslides. However, most of the current studies have focused on the effect of vegetation roots on soil infiltration. The influence mechanism of vegetation infiltration enhancement effect on shallow landslides has not been revealed. Therefore, the mass landslide disaster on September 9, 2019 in Longchuan County in Guangdong is taken as an example, and a large number of landslide site investigations are made to identify the geological environment conditions and vegetation development in the landslide area and analyze the infiltration effect of vegetation on shallow landslides. The “double-ring method” is used to measure infiltration rate of different vegetation types, and to analyze the infiltration process and infiltration law of different vegetation types. A typical landslide profile is selected to establish a geological model, and the Geo-Studio software is used to simulate the seepage law of shallow landslide and the stress-strain characteristics of the soil under heavy rainfall conditions (250 mm/d). Finally, combined with the simulation results and field investigations, the infiltration effects of vegetation and their response mechanisms to shallow landslides under heavy rainfall are analyzed. The results show that vegetation can effectively enhance the permeability of soil, and the order of permeability is coniferous forest land, shrub forest land and bare land. Under the influence of vegetation infiltration effect, rainwater infiltration to the bottom of the root-soil composite layer will cause water stagnation, the shallow soil tends to be saturated rapidly, the pore water pressure and seepage force in the soil increase instantaneously, the soil is saturated with water, the residual soil softens, and the weight of the slope increases, which eventually leads to the overall instability of the slope. The research results explain the formation mechanism of granite residual soil landslide in high vegetation covered area under heavy rainfall in Southern China, and provide scientific basis for early warning and prediction of such disasters, which are of great significance.
-
-
表 1 岩土体相关物理力学参数
Table 1. Physical and mechanical parameters of soil and rockmass
层序号 岩土体名称 重度/（kN·m−3） 黏聚力/kPa 内摩擦角/（°） 渗透系数/（m·s−1） 饱和含水率/% 弹性模量/MPa 泊松比 1 根土复合层 19.1/19.6 45.8/25.7 22.3/19.5 3.78×10−4 27.7 22.6 0.31 2 砂质黏土 19.1/19.6 36.4/16.3 22.3/19.5 2.34×10−5 27.7 22.6 0.31 3 全风化花岗岩 19.1/19.6 34.2/18.8 21.8/17.6 6.59×10−6 26.8 26.1 0.29 4 强风化花岗岩 19.8/20.6 43.4/25.6 27.4/21.9 5.50×10−6 25.3 39.4 0.27 5 中风化花岗岩 22.0/22.2 200.0/140.0 35.0/30.0 1.23×10−7 5.0 1 000.0 0.31 注：19.1/19.6，斜线左为天然条件下的参数，斜线右为饱和条件下的参数。
下载: 导出CSV
表 2 3种不同植被样地入渗性能比较
Table 2. Comparison of infiltration performance of three different vegetation plots
样地类型 初渗速率/（mm·min−1） 稳渗速率/（mm·min−1） 样地1 样地2 样地3 样地1 样地2 样地3 针叶林地 36.24 35.05 34.87 6.38 5.70 5.62 灌木林地 22.82 22.75 25.02 2.91 3.08 3.05 裸土地 15.49 16.13 14.77 1.67 1.81 1.81
下载: 导出CSV
-
[1] 谭银龙,许万忠,曹家菊,等. 基于Midas-GTS的三峡库区金鸡岭滑坡成因机制与稳定性分析[J]. 水文地质工程地质,2023,50(1):113 − 121. [TAN Yinlong,XU Wanzhong,CAO Jiaju,et al. Mechanisms and stability analysis of the Jinjiling landslide in the Three Gorges Reservoir area based on Midas-GTS[J]. Hydrogeology & Engineering Geology,2023,50(1):113 − 121. (in Chinese with English abstract) doi: 10.16030/j.cnki.issn.1000-3665.202204054
[2] 张勇,温智,程英建. 四川巴中市滑坡灾害与降雨雨型关系探讨[J]. 水文地质工程地质,2020,47(2):178 − 182. [ZHANG Yong,WEN Zhi,CHENG Yingjian. A discussion of the relationship between landslide disaster and rainfall types in Bazhong of Sichuan[J]. Hydrogeology & Engineering Geology,2020,47(2):178 − 182. (in Chinese with English abstract)
[3] 卫童瑶,殷跃平,高杨,等. 三峡库区巫山县塔坪H1滑坡变形机制[J]. 水文地质工程地质,2020,47(4):73 − 81. [WEI Tongyao,YIN Yueping,GAO Yang,et al. Deformation mechanism of the Taping H1 landslide in Wushan County in the Three Gorges Reservoir area[J]. Hydrogeology & Engineering Geology,2020,47(4):73 − 81. (in Chinese with English abstract)
[4] 邹凤钗,冷洋洋,陶小郎,等. 基于斜坡单元的滑坡风险识别—以贵州万山浅层土质斜坡为例[J]. 中国地质灾害与防治学报,2022,33(3):114 − 122. [ZOU Fengchai,LENG Yangyang,TAO Xiaolang,et al. Landslide hazard identification based on slope unit:A case study of shallow soil slope in Wanshan,Guizhou Province[J]. The Chinese Journal of Geological Hazard and Control,2022,33(3):114 − 122. (in Chinese with English abstract)
[5] 张家明,徐则民,裴银鸽. 植被发育斜坡非饱和带大孔隙[J]. 山地学报,2012,30(4):439 − 449. [ZHANG Jiaming,XU Zemin,PEI Yinge. Macropores in vadose zone of well vegetated slopes[J]. Journal of Mountain Science,2012,30(4):439 − 449. (in Chinese with English abstract) doi: 10.3969/j.issn.1008-2786.2012.04.009
[6] 戚国庆,胡利文. 植被护坡机制及应用研究[J]. 岩石力学与工程学报,2006,25(11):2220 − 2225. [QI Guoqing,HU Liwen. Study on mechanism and application of slope protection with vegetation[J]. Chinese Journal of Rock Mechanics and Engineering,2006,25(11):2220 − 2225. (in Chinese with English abstract) doi: 10.3321/j.issn:1000-6915.2006.11.009
[7] 肖本林,罗寿龙,陈军,等. 根系生态护坡的有限元分析[J]. 岩土力学,2011,32(6):1881 − 1885. [XIAO Benlin,LUO Shoulong,CHEN Jun,et al. Finite element analysis of eco-protection slope through roots[J]. Rock and Soil Mechanics,2011,32(6):1881 − 1885. (in Chinese with English abstract) doi: 10.3969/j.issn.1000-7598.2011.06.046
[8] GRAY D H,OHASHI H. Mechanics of fiber reinforcement in sand[J]. Journal of Geotechnical Engineering,1983,109(3):335 − 353. doi: 10.1061/(ASCE)0733-9410(1983)109:3(335)
[9] 许增旺. 香港大屿山岛自然滑坡的空间分布与影响因子浅析[J]. 自然灾害学报,2001,10(4):76 − 83. [XU Zengwang. Analysis of spatial distribution and contribution factors of natural landslides in Lantau Island of Hong Kong[J]. Journal of Natural Disasters,2001,10(4):76 − 83. (in Chinese with English abstract) doi: 10.3969/j.issn.1004-4574.2001.04.014
[10] CARDINALI M,GALLI M,GUZZETTI F,et al. Rainfall induced landslides in December 2004 in south-western Umbria,central Italy:Types,extent,damage and risk assessment[J]. Natural Hazards and Earth System Sciences,2006,6(2):237 − 260. doi: 10.5194/nhess-6-237-2006
[11] CHIGIRA M. Micro-sheeting of granite and its relationship with landsliding specifically after the heavy rainstorm in June 1999,Hiroshima Prefecture,Japan[J]. Engineering Geology,2001,59(3/4):219 − 231.
[12] 徐宗恒,徐则民,李凌旭. 植被发育斜坡非饱和带土体优先域及其对水分入渗的贡献—以云南省呈贡和昭通玄武岩质斜坡为例[J]. 地理科学,2017,37(5):783 − 791. [XU Zongheng,XU Zemin,LI Lingxu. Preferential domain types of basalt slope unsaturated zone soil and the contribution to water infiltration: A case study of basalt slope in Chenggong and Zhaotong of Yunnan Province[J]. Scientia Geographica Sinica,2017,37(5):783 − 791. (in Chinese with English abstract)
[13] 王志良,年玉泽,申林方,等. 植被发育斜坡土体大孔隙三维重构模型渗流场的LBM数值模拟[J]. 岩土力学,2018,39(10):3821 − 3829. [WANG Zhiliang,NIAN Yuze,SHEN Linfang,et al. Numerical simulation of macropores seepage field in the 3D reconstruction model of well vegetated slope soil based on LBM[J]. Rock and Soil Mechanics,2018,39(10):3821 − 3829. (in Chinese with English abstract)
[14] ZHAN T L,NG C W,FREDLUND D G. Field study of rainfall infiltration into a grassed unsaturated expansive soil slope[J]. Canadian Geotechnical Journal,2007,44(4):392 − 408. doi: 10.1139/t07-001
[15] 徐则民,黄润秋. 山区流域高盖度斜坡对极端降雨事件的地下水响应[J]. 地球科学进展,2011,26(6):598 − 607. [XU Zemin,HUANG Runqiu. The response of the groundwater in vegetated slopes in mountainous catchments to heavy rain events[J]. Advances in Earth Science,2011,26(6):598 − 607. (in Chinese with English abstract)
[16] 徐则民,黄润秋,唐正光,等. 植被护坡的局限性及其对深层滑坡孕育的贡献[J]. 岩石力学与工程学报,2005,24(3):438 − 450. [XU Zemin,HUANG Runqiu,TANG Zhengguang,et al. Limitations of biotechnical slope protection and contribution of vegetation to deep seated landslide preparation[J]. Chinese Journal of Rock Mechanics and Engineering,2005,24(3):438 − 450. (in Chinese with English abstract)
[17] 彭书生, 王永波, 盛谦, 等. 植被增加边坡降雨入渗对边坡稳定性影响研究[J]. 地下空间与工程学报, 2007, 3（增刊1）: 1274 − 1278
PENG Shusheng, WANG Yongbo, SHENG Qian, et al. Study on enhancement of precipitation infiltration by vegetation and its effect on slope stability[J]. Chinese Journal of Underground Space and Engineering, 2007, 3（Sup 1）: 1274 − 1278. （in Chinese with English abstract）
[18] MCDONNELL J J. The influence of macropores on debris flow initiation[J]. Quarterly Journal of Engineering Geology,1990,23(4):325 − 331. doi: 10.1144/GSL.QJEG.1990.023.04.06
[19] 黄月华,周成,李红梅. 降雨中有植被覆盖土坡大孔隙结构对边坡稳定性的影响[J]. 水利与建筑工程学报,2018,16(3):132 − 137. [HUANG Yuehua,ZHOU Cheng,LI Hongmei. Combined effects of trees and macropores on slope stability subjected to rainfall[J]. Journal of Water Resources and Architectural Engineering,2018,16(3):132 − 137. (in Chinese with English abstract)
[20] 宋享桦,谭勇,张生杰. 暴雨气候下砂土边坡植被护坡模型试验研究[J]. 哈尔滨工业大学学报,2021,53(5):123 − 133. [SONG Xianghua,TAN Yong,ZHANG Shengjie. Investigation on effects of vegetations on stability of sandy slope by indoor rainfall model test[J]. Journal of Harbin Institute of Technology,2021,53(5):123 − 133. (in Chinese with English abstract)
[21] 李牧阳,王云琦,王玉杰,等. 甘肃天水浅表层滑坡易发区滑坡分布与植被根系特征[J]. 水土保持学报,2020,34(6):101 − 109. [LI Muyang,WANG Yunqi,WANG Yujie,et al. Landslide distribution and vegetation root characteristics in shallow landslide-prone area of Tianshui,Gansu[J]. Journal of Soil and Water Conservation,2020,34(6):101 − 109. (in Chinese with English abstract) doi: 10.13870/j.cnki.stbcxb.2020.06.016
[22] 祝小辉. 广东省龙川县地质灾害特征及影响因素分析[J]. 西部资源,2021(2):106 − 108. [ZHU Xiaohui. Analysis on the characteristics and influencing factors of geological disasters in Longchuan County,Guangdong Province[J]. Western Resources,2021(2):106 − 108. (in Chinese with English abstract) doi: 10.16631/j.cnki.cn15-1331/p.2021.02.038
[23] WU T H. Root reinforcement of soil:Review of analytical models,test results,and applications to design[J]. Canadian Geotechnical Journal,2013,50(3):259 − 274. doi: 10.1139/cgj-2012-0160
[24] 中华人民共和国水利部. 水利水电工程注水试验规程: SL 345—2007[S]. 北京: 中国标准出版社, 2007
Ministry of Water Resources of the People’s Republic of China. Code of water injection test for water resources and hydropower engineering: SL 345—2007 [S]. Beijing: Standards Press of China, 2007. （in Chinese with English abstract）
[25] WU T H,MCKINNELL W P,SWANSTON D N. Strength of tree roots and landslides on Prince of Wales Island,Alaska[J]. Canadian Geotechnical Journal,1979,16(1):19 − 33. doi: 10.1139/t79-003
[26] 朱锦奇,王云琦,王玉杰,等. 基于植物生长过程的根系固土机制及Wu模型参数优化[J]. 林业科学,2018,54(4):49 − 57. [ZHU Jinqi,WANG Yunqi,WANG Yujie,et al. Analyses on root reinforcement mechanism based on plant growth process and parameters optimization of Wu model[J]. Scientia Silvae Sinicae,2018,54(4):49 − 57. (in Chinese with English abstract)
[27] 刘洁,李贤伟,纪中华,等. 元谋干热河谷三种植被恢复模式土壤贮水及入渗特性[J]. 生态学报,2011,31(8):2331 − 2340. [LIU Jie,LI Xianwei,JI Zhonghua,et al. Soil water holding capacities and infiltration characteristics of three vegetation restoration models in dry-hot valley of Yuanmou[J]. Acta Ecologica Sinica,2011,31(8):2331 − 2340. (in Chinese with English abstract)
[28] FREDLUND D G,XING Anqing. Equations for the soil-water characteristic curve[J]. Canadian Geotechnical Journal,1994,31(4):521 − 532. doi: 10.1139/t94-061
[29] 徐则民. 植被与斜坡非饱和带大空隙[J]. 地学前缘,2007,14(6):134 − 142. [XU Zemin. Vegetation and macropores in vadose zones of hill slopes[J]. Earth Science Frontiers,2007,14(6):134 − 142. (in Chinese with English abstract) doi: 10.3321/j.issn:1005-2321.2007.06.017
[30] VINTHER F P,EILAND F,LIND A M,et al. Microbial biomass and numbers of denitrifiers related to macropore channels in agricultural and forest soils[J]. Soil Biology and Biochemistry,1999,31(4):603 − 611. doi: 10.1016/S0038-0717(98)00165-5
[31] PASSIOURA J B. ‘Soil conditions and plant growth’[J]. Plant,Cell & Environment,2002,25(2):311 − 318.
[32] PETH S,HORN R,BECKMANN F,et al. Three-dimensional quantification of intra-aggregate pore-space features using synchrotron-radiation-based microtomography[J]. Soil Science Society of America Journal,2008,72(4):897 − 907. doi: 10.2136/sssaj2007.0130
-
