摘要:
碳酸盐岩在我国西南地区广泛分布，其溶蚀特性为工程建设带来不少阻力。为研究层状碳酸盐岩在酸性溶蚀条件下的溶蚀损伤规律，采用自制流动溶蚀系统对4种不同条件下的层理灰岩进行室内溶蚀试验，获得层理灰岩溶蚀后的质量损失、纵波波速变化量、溶液中Ca2+和Mg2+质量浓度、表面溶蚀带形态特征等状态指标。采用层理灰岩溶蚀前后质量损失率定义损伤变量，通过多元统计回归分析方法，建立起4个不同自变量（层理倾角、pH值、溶液流速、溶蚀时间）和溶蚀损伤变量之间的关系，结果表明：层理灰岩的溶蚀损伤与层理倾角、溶液pH值、溶液流速、溶蚀时间之间存在良好的数学关系；溶蚀时间对层理灰岩溶蚀损伤有显著影响，溶液流速和pH值次之；不同层理倾角的灰岩，相同酸性环境下溶蚀效应呈现出90°>0°>45°>30°>75°> 15°>60°的规律；层理倾角对灰岩溶蚀影响较其他因素小，但是对岩样表面溶蚀形态起到了决定性作用。研究结果可以为灰岩地区工程实践和地质灾害防治提供一定参考。
Abstract:In southwest China, carbonate rocks are widely distributed. It has unique dissolution features which bring a lot of resistance to engineering constructions. In order to explore the dissolution damage regular of layered carbonate rocks in acidic water, a self-made flow dissolution system was used to conduct laboratory dissolution tests on limestone cores under four different conditions. The mass loss, the change of p-wave velocity, the mass concentration of Ca2+ and Mg2+ and the morphology of the core surface were obtained. Mass loss rate after dissolution of layered limestone was used to define the damage variation. Through multivariate statistical regression analysis, the relationship between four different arguments (bedding dip Angle, pH, velocity of flow, dissolution time) and dissolution damage variation was established. The results show that the dissolution damage of layered limestone has a good mathematical relationship between the four different arguments. The following conclusions can be drawn from the analysis: The time has a significant effect on the dissolution damage of bedded limestone, followed by the velocity and pH. Under the same acidic environment, the dissolution effect shows a rule of 90° >0° >45° >30° >75° >15° >60° for limestone with different bedding inclination angles. The bedded angle has less effect on the dissolution of limestone than other factors, but plays a decisive role in the surface dissolution morphology of rock samples. The results of this study can provide some reference for engineering practice and geological disaster control in limestone areas.
-
-
表 1 试验工况对照表
Table 1. Comparison table of test conditions
试验组 pH v/（cm s−1） t/d φ/（°） pH组 2/3/4/5 2.6 14 0/45/90 v组 2 0/2.6/4.7/6.8 14 30/75 t组 2 2.6 7/14/22/31 15/60
下载: 导出CSV
表 2 不同层理倾角岩样不同反应阶段Ca2+、Mg2+质量浓度
Table 2. Ca2+/Mg2+ concentration at different reaction stages in rock samples with different bedding dips
层理倾角/（°） ρ(Mg2+)/（mg·L−1） ρ(Ca2+)/（mg·L−1） ρ(Ca2++Mg2+)/（mg·L−1） 7 d 14 d 22 d 7 d 14 d 22 d 7 d 14 d 22 d 0 34.1 45.1 71.0 765 995 2015 799.1 1040.1 2086.0 15 27.6 36.3 70.3 845 1155 2300 872.6 1191.3 2370.3 30 29.9 40.0 69.6 910 1200 2380 939.9 1240.0 2449.6 45 30.7 36.7 70.6 885 1000 2012 915.7 1036.7 2082.6 60 27.1 41.0 69.6 745 800 1720 772.1 841.0 1789.6 75 29.1 36.4 70.5 778 1190 2330 807.1 1226.4 2400.5 90 30.3 35.4 85.2 835 1145 2190 865.3 1180.4 2275.2 注：表中“ρ”为质量浓度。
下载: 导出CSV
表 3 不同层理倾角岩样不同反应阶段矿物溶解量
Table 3. Mineral dissolution amounts in different reaction stages of rock samples with different bedding dips
层理倾角/（°） m[CaMg(CO3)2+CaCO3]/g 称重法溶蚀量/g 7 d 14 d 22 d 7 d 14 d 22 d 0 2.03 2.65 5.29 2.11 2.63 5.35 15 2.21 3.01 6.00 2.30 3.08 5.97 30 2.38 3.14 6.19 2.43 3.15 6.18 45 2.32 2.63 5.28 2.32 2.65 5.31 60 1.96 2.14 4.54 1.99 2.20 4.59 75 2.05 3.10 6.07 2.14 2.96 6.00 90 2.19 2.99 5.77 2.29 2.94 5.68 注：表中“m”为质量。
下载: 导出CSV
表 4 层理灰岩溶蚀损伤回归方程式方差分析表
Table 4. Table of regression equation variance analysis of dissolution damage in bedding limestone
差异源 平方和 自由度 均方 F 显著性 回归 0.003 4 0.001 18.974 * 残差 0.002 44 0.000 总计 0.005 48
下载: 导出CSV
-
[1] 王雁冰, 付代睿. 层理角度对天然岩石材料动态断裂行为的影响研究[J]. 岩石力学与工程学报,2023,42(4):849 − 867. [WANG Yanbing, FU Dairui. Effect of bedding angle on dynamic fracture behavior of natural rock materials[J]. Chinese Journal of Rock Mechanics and Engineering,2023,42(4):849 − 867. (in Chinese with English abstract)
WANG Yanbing, FU Dairui . Effect of bedding angle on dynamic fracture behavior of natural rock materials[J]. Chinese Journal of Rock Mechanics and Engineering,2023 ,42 （4 ）:849 −867 . (in Chinese with English abstract)[2] 汤连生,王思敬,张鹏程,等. 水-岩土化学作用与地质灾害防治[J]. 中国地质灾害与防治学报,1999,10(3):61 − 70. [TANG Liansheng,WANG Sijing,ZHANG Pengcheng,et al. Mechanical properties of rock and soil influenced by hydrochemical action and geological hazard control[J]. The Chinese Journal of Geological Hazard and Control,1999,10(3):61 − 70. (in Chinese with English abstract)
TANG Liansheng, WANG Sijing, ZHANG Pengcheng, et al . Mechanical properties of rock and soil influenced by hydrochemical action and geological hazard control[J]. The Chinese Journal of Geological Hazard and Control,1999 ,10 （3 ）:61 −70 . （in Chinese with English abstract）[3] HAXAIRE A,DJERAN-MAIGRE I. Influence of dissolution on the mechanical behaviour of saturated deep argillaceous rocks[J]. Engineering Geology,2009,109(3/4):255 − 261.
[4] 邓涛, 廖军, 王陈宾, 等. 不同风化程度下灰岩抗剪强度特性及估算模型研究[J]. 水文地质工程地质,2022,49(4):71 − 80. [DENG Tao, LIAO Jun, WANG Chenbin, et al. A study of shear strength characteristics and estimation model of limestone under different weathering degrees[J]. Hydrogeology & Engineering Geology,2022,49(4):71 − 80. (in Chinese with English abstract)
DENG Tao, LIAO Jun, WANG Chenbin, et al . A study of shear strength characteristics and estimation model of limestone under different weathering degrees[J]. Hydrogeology & Engineering Geology,2022 ,49 （4 ）:71 −80 . (in Chinese with English abstract)[5] 汤连生,王思敬. 水-岩化学作用对岩体变形破坏力学效应研究进展[J]. 地球科学进展,1999,14(5):433 − 439. [TANG Liansheng,WANG Sijing. Progress in the study on mechanical effect of the chemical action of water rock on deformation and failure of rocks[J]. Advance in Earth Sciences,1999,14(5):433 − 439. (in Chinese with English abstract)
TANG Liansheng, WANG Sijing . Progress in the study on mechanical effect of the chemical action of water rock on deformation and failure of rocks[J]. Advance in Earth Sciences,1999 ,14 （5 ）:433 −439 . （in Chinese with English abstract）[6] 冯夏庭,王川婴,陈四利. 受环境侵蚀的岩石细观破裂过程试验与实时观测[J]. 岩石力学与工程学报,2002,21(7):935 − 939. [FENG Xiating,WANG Chuanying,CHEN Sili. Testing study and real-time observation of rock meso-cracking process under chemical erosion[J]. Chinese Journal of Rock Mechanics and Engineering,2002,21(7):935 − 939. (in Chinese with English abstract)
FENG Xiating, WANG Chuanying, CHEN Sili . Testing study and real-time observation of rock meso-cracking process under chemical erosion[J]. Chinese Journal of Rock Mechanics and Engineering,2002 ,21 （7 ）:935 −939 . （in Chinese with English abstract）[7] GUDBRANDSSON S,WOLFF-BOENISCH D,GISLASON S R,et al. An experimental study of crystalline basalt dissolution from 2≤pH≤11 and temperatures from 5 to 75 ℃[J]. Geochimica et Cosmochimica Acta,2011,75(19):5496 − 5509. doi: 10.1016/j.gca.2011.06.035
[8] ABBASZADEH M,NASIRI M,RIAZI M. Experimental investigation of the impact of rock dissolution on carbonate rock properties in the presence of carbonated water[J]. Environmental Earth Sciences,2016,75(9):791. doi: 10.1007/s12665-016-5624-3
[9] 刘琦,顾展飞,卢耀如,等. 贵州施秉白云岩溶蚀特性及孔隙特征实验研究[J]. 地球学报,2015,36(4):413 − 418. [LIU Qi,GU Zhanfei,LU Yaoru,et al. The experimental study of dolomite dissolution and pore characteristics in Shibing,Guizhou[J]. Acta Geoscientica Sinica,2015,36(4):413 − 418. (in Chinese with English abstract)
LIU Qi, GU Zhanfei, LU Yaoru, et al . The experimental study of dolomite dissolution and pore characteristics in Shibing, Guizhou[J]. Acta Geoscientica Sinica,2015 ,36 （4 ）:413 −418 . （in Chinese with English abstract）[10] 林云,任华鑫,武亚遵,等. 不同赋存环境下碳酸盐岩溶蚀过程试验模拟研究[J]. 水文地质工程地质,2021,48(2):15 − 26. [LIN Yun,REN Huaxin,WU Yazun,et al. Experimental simulation of the carbonate dissolution process under different occurrence conditions[J]. Hydrogeology & Engineering Geology,2021,48(2):15 − 26. (in Chinese with English abstract)
LIN Yun, REN Huaxin, WU Yazun, et al . Experimental simulation of the carbonate dissolution process under different occurrence conditions[J]. Hydrogeology & Engineering Geology,2021 ,48 （2 ）:15 −26 . （in Chinese with English abstract）[11] 乔丽苹,刘建,冯夏庭. 砂岩水物理化学损伤机制研究[J]. 岩石力学与工程学报,2007,26(10):2117 − 2124. [QIAO Liping,LIU Jian,FENG Xiating. Study on damage mechanism of sandstone under hydro-physico-chemical effects[J]. Chinese Journal of Rock Mechanics and Engineering,2007,26(10):2117 − 2124. (in Chinese with English abstract)
QIAO Liping, LIU Jian, FENG Xiating . Study on damage mechanism of sandstone under hydro-physico-chemical effects[J]. Chinese Journal of Rock Mechanics and Engineering,2007 ,26 （10 ）:2117 −2124 . （in Chinese with English abstract）[12] 张强. 金沙江观音岩电站红层钙质砂岩类岩溶发育特征及渗透稳定性研究[D]. 成都:成都理工大学,2010. [ZHANG Qiang. Semi-karst development characteristics and engineering seepage stability of the calcareous sandstone red beds of guanyinyan hydropower,Jinsha River[D]. Chengdu:Chengdu University of Technology,2010. (in Chinese with English abstract)
ZHANG Qiang. Semi-karst development characteristics and engineering seepage stability of the calcareous sandstone red beds of guanyinyan hydropower, Jinsha River[D]. Chengdu: Chengdu University of Technology, 2010. （in Chinese with English abstract） [13] 柴少波, 宋浪, 周炜, 等. 水岩作用对充填节理岩石劣化的影响[J]. 吉林大学学报(地球科学版),2023,53(5):1510 − 1520. [CHAI Shaobo, SONG Lang, ZHOU Wei, et al. Effect of water-rock interactions on the deterioration of filled jointed rock[J]. Journal of Jilin University (Earth Science Edition),2023,53(5):1510 − 1520. (in Chinese with English abstract)
CHAI Shaobo, SONG Lang, ZHOU Wei, et al . Effect of water-rock interactions on the deterioration of filled jointed rock[J]. Journal of Jilin University (Earth Science Edition),2023 ,53 （5 ）:1510 −1520 . (in Chinese with English abstract)[14] 王露. 酸性环境下层状灰岩的溶蚀损伤特性试验研究[D]. 贵阳:贵州大学,2021. [WANG Lu. Experimental study on corrosion damage characteristics of layered limestone in acidic environment[D]. Guiyang:Guizhou University,2021. (in Chinese with English abstract)
WANG Lu. Experimental study on corrosion damage characteristics of layered limestone in acidic environment[D]. Guiyang: Guizhou University, 2021. （in Chinese with English abstract） [15] 丁茜,何治亮,沃玉进,等. 高温高压条件下碳酸盐岩溶蚀过程控制因素[J]. 石油与天然气地质,2017,38(4):784 − 791. [DING Qian,HE Zhiliang,WO Yujin,et al. Factors controlling carbonate rock dissolution under high temperature and pressure[J]. Oil & Gas Geology,2017,38(4):784 − 791. (in Chinese with English abstract)
DING Qian, HE Zhiliang, WO Yujin, et al . Factors controlling carbonate rock dissolution under high temperature and pressure[J]. Oil & Gas Geology,2017 ,38 （4 ）:784 −791 . （in Chinese with English abstract）[16] 那金,许天福,魏铭聪,等. 增强地热系统热储层-盐水-CO2相互作用[J]. 吉林大学学报(地球科学版),2015,45(5):1493 − 1501. [NA Jin,XU Tianfu,WEI Mingcong,et al. Interaction of rock-brine-supercritical CO2 in CO2-EGS reservoir[J]. Journal of Jilin University (Earth Science Edition),2015,45(5):1493 − 1501. (in Chinese with English abstract)
NA Jin, XU Tianfu, WEI Mingcong, et al . Interaction of rock-brine-supercritical CO2 in CO2-EGS reservoir[J]. Journal of Jilin University （Earth Science Edition）,2015 ,45 （5 ）:1493 −1501 . （in Chinese with English abstract）[17] 盛金昌,吴彦青,白柯含,等. 不同溶液渗透溶蚀作用下碳酸盐岩渗透特性研究[J]. 岩石力学与工程学报,2019,38(增刊2):3279 − 3286. [SHENG Jinchang,WU Yanqing,BAI Kehan,et al. Study on the permeability evolution of carbonate rocks under seepage corrosion effect of different solutions[J]. Chinese Journal of Rock Mechanics and Engineering,2019,38(Sup 2):3279 − 3286. (in Chinese with English abstract)
SHENG Jinchang, WU Yanqing, BAI Kehan, et al. Study on the permeability evolution of carbonate rocks under seepage corrosion effect of different solutions[J]. Chinese Journal of Rock Mechanics and Engineering, 2019, 38（Sup 2）: 3279 − 3286. （in Chinese with English abstract） [18] 陈四利,冯夏庭,周辉. 化学腐蚀下砂岩三轴细观损伤机理及损伤变量分析[J]. 岩土力学,2004,25(9):1363 − 1367. [CHEN Sili,FENG Xiating,ZHOU Hui. Study on triaxial meso-failure mechanism and damage variables of sandstone under chemical erosion[J]. Rock and Soil Mechanics,2004,25(9):1363 − 1367. (in Chinese with English abstract)
CHEN Sili, FENG Xiating, ZHOU Hui . Study on triaxial meso-failure mechanism and damage variables of sandstone under chemical erosion[J]. Rock and Soil Mechanics,2004 ,25 （9 ）:1363 −1367 . （in Chinese with English abstract）[19] 丁梧秀,陈建平,徐桃,等. 化学溶液侵蚀下灰岩的力学及化学溶解特性研究[J]. 岩土力学,2015,36(7):1825 − 1830. [DING Wuxiu,CHEN Jianping,XU Tao,et al. Mechanical and chemical characteristics of limestone during chemical erosion[J]. Rock and Soil Mechanics,2015,36(7):1825 − 1830. (in Chinese with English abstract)
DING Wuxiu, CHEN Jianping, XU Tao, et al . Mechanical and chemical characteristics of limestone during chemical erosion[J]. Rock and Soil Mechanics,2015 ,36 （7 ）:1825 −1830 . （in Chinese with English abstract）[20] 李晓宁. 酸性环境下粉砂质泥岩宏细观损伤特性研究[D]. 成都:西南交通大学,2016. [LI Xiaoning. A study on macro-meso damage characteristics of sility mudstone under acid corrosion[D]. Chengdu:Southwest Jiaotong University,2016. (in Chinese with English abstract)
LI Xiaoning. A study on macro-meso damage characteristics of sility mudstone under acid corrosion[D]. Chengdu: Southwest Jiaotong University, 2016. （in Chinese with English abstract） [21] 卢运虎,梁川,金衍,等. 高温下页岩水化损伤的各向异性实验研究[J]. 中国科学:物理学 力学 天文学,2017,47(11):138 − 145. [LU Yunhu,LIANG Chuan,JIN Yan,et al. Experimental study on hydration damage of anisotropic shale under high temperature[J]. Scientia Sinica (Physica,Mechanica & Astronomica),2017,47(11):138 − 145. (in Chinese with English abstract)
LU Yunhu, LIANG Chuan, JIN Yan, et al. Experimental study on hydration damage of anisotropic shale under high temperature[J]. Scientia Sinica （Physica, Mechanica & Astronomica）, 2017, 47（11）: 138 − 145. （in Chinese with English abstract） [22] XU Peng,SHENG Mao,LIN Tianyi,et al. Influences of rock microstructure on acid dissolution at a dolomite surface[J]. Geothermics,2022,100:102324. doi: 10.1016/j.geothermics.2021.102324
[23] ZHANG Hao,ZHONG Ying,ZHANG Jiang,et al. Experimental research on deterioration of mechanical properties of carbonate rocks under acidified conditions[J]. Journal of Petroleum Science and Engineering,2020,185:106612. doi: 10.1016/j.petrol.2019.106612
[24] 凌斯祥,巫锡勇,孙春卫,等. 水岩化学作用对黑色页岩的化学损伤及力学劣化试验研究[J]. 实验力学,2016,31(4):511 − 524. [LING Sixiang,WU Xiyong,SUN Chunwei,et al. Experimental study of chemical damage and mechanical deterioration of black shale due to water-rock chemical action[J]. Journal of Experimental Mechanics,2016,31(4):511 − 524. (in Chinese with English abstract)
LING Sixiang, WU Xiyong, SUN Chunwei, et al . Experimental study of chemical damage and mechanical deterioration of black shale due to water-rock chemical action[J]. Journal of Experimental Mechanics,2016 ,31 （4 ）:511 −524 . （in Chinese with English abstract）[25] 苗胜军,蔡美峰,冀东,等. 酸性化学溶液作用下花岗岩损伤时效特征与机理[J]. 煤炭学报,2016,41(5):1137 − 1144. [MIAO Shengjun,CAI Meifeng,JI Dong,et al. Aging features and mechanism of Granite’s damage under the action of acidic chemical solutions[J]. Journal of China Coal Society,2016,41(5):1137 − 1144. (in Chinese with English abstract)
MIAO Shengjun, CAI Meifeng, JI Dong, et al . Aging features and mechanism of Granite’s damage under the action of acidic chemical solutions[J]. Journal of China Coal Society,2016 ,41 （5 ）:1137 −1144 . （in Chinese with English abstract)[26] 陈如冰,罗明明,罗朝晖,等. 三峡地区碳酸盐岩化学组分与溶蚀速率的响应关系[J]. 中国岩溶,2019,38(2):258 − 264. [CHEN Rubing,LUO Mingming,LUO Zhaohui. Response relationship between chemical composition and dissolution rate of carbonate rocks in the Three Gorges Area[J]. Carsologica Sinica,2019,38(2):258 − 264.(in Chinese with English abstract)
CHEN Rubing, LUO Mingming, LUO Zhaohui . Response relationship between chemical composition and dissolution rate of carbonate rocks in the Three Gorges Area[J]. Carsologica Sinica,2019 ,38 （2 ）:258 −264 .（in Chinese with English abstract）[27] 康孟羽,朱月琴,陈晨,等. 基于多元非线性回归和BP神经网络的滑坡滑动距离预测模型研究[J]. 地质通报,2022,41(12):2281 − 2289. [KANG Mengyu,ZHU Yueqin,CHEN Chen,et al. Research on landslide sliding distance prediction model based on multiple nonlinear regression and BP neural network[J]. Geological Bulletin of China,2022,41(12):2281 − 2289. (in Chinese with English abstract)
KANG Mengyu, ZHU Yueqin, CHEN Chen, et al . Research on landslide sliding distance prediction model based on multiple nonlinear regression and BP neural network[J]. Geological Bulletin of China,2022 ,41 （12 ）:2281 −2289 . （in Chinese with English abstract） -
