Adsorption and diffusion behavior of ammonium on bentonite modified loess liners
-
摘要:
膨润土改性黄土可以用作生活垃圾填埋场底部衬垫层。然而，污染物在膨润土改性黄土衬垫层中的吸附和扩散行为尚不明晰，无法对该类衬垫层的截污性能进行准确评价。研究向黄土中掺入质量占比为15%和30%的膨润土，通过开展批式吸附试验和扩散试验，研究氨氮在改性衬垫层中的吸附和扩散行为。研究结果显示：当膨润土的掺入量为15%时，氨氮在改性衬垫层上的吸附量与纯黄土衬垫层相比没有明显变化，但扩散速率下降了400%；当膨润土的掺入量达到30%时，氨氮在改性衬垫层上的吸附量增加了1.25倍，而扩散速率下降了420%。Pollute v7.0的模拟计算结果表明，在对膨润土改性黄土衬垫层的截污性能进行评价时，如果不考虑污染物的扩散行为，评价结果将产生3.50～4.75倍误差；而不考虑污染物的吸附行为，则将产生334～382倍误差。研究成果可为膨润土改性黄土衬垫层的截污性能评价提供理论依据。
Abstract:Bentonite-modified loess has been used as bottom liner material for municipal waste landfills. However, because the diffusion and adsorption behavior of pollutants was not determined, the performance of the bentonite-modified losses could not evaluated. Two bentonite-modified loess liners were tested in the present study, containing 15% bentonite and 30% (by weight) bentonite, respectively. A series of batch adsorption and diffusion tests were conducted to examine the adsorption and diffusion behavior of ammonium in bentonite-modified loess liner. The test results show that the addition of 15% bentonite could not increase the adsorption capacity of ammonium on the modified liner, whereas it could decrease the diffusion coefficients of ammonium in the modified loess liner by about 400%. When 30% bentonite was added, the adsorption capacity of ammonium on the modified liner increased by a factor of 1.25, whereas, the diffusion coefficient dropped by about 420%. Pollute v7.0 model results show that it would produce 3.50～4.75 times errors if the diffusion behavior of pollutants were not taken into account when estimating the performance of the bentonite-modified liner. Whereas, there would be 334～382 times errors in the estimating of the modified liner performance if the adsorption behavior of pollutant was not considered. The results of the present study provide parameters for the evaluation of bentonite-modified loess liner performance.
-
Key words:
- loess /
- bentonite /
- ammonium /
- adsorption /
- diffusion
-
-
表 1 黄土及膨润土基本性质
Table 1. The characteristics of loess and bentonite
土样 含水率/% 土粒密度
/（g·cm−3）阳离子交换容量
/（meq·0.01 g−1）液限
/%塑限
/%黄土 22.32 2.69 8.42 30.2 17.8 膨润土 6.56 2.65 91.00 314.0 40.0
下载: 导出CSV
表 2 扩散试验试样基本性质
Table 2. The characteristic of soil specimens used in the diffusion test
试样名称 试样组成 试样高度/cm 含水率/% 密度/（kg·m−3） 孔隙率/% 渗透系数/（m·s−1） H0 黄土+0%膨润土 4.0 18 1.54 29.60 3.06×10−9 H15 黄土+15%膨润土 4.0 20 1.61 16.57 2.35×10−10 H30 黄土+30%膨润土 4.0 23 1.50 24.14 2.40×10−10
下载: 导出CSV
表 3 吸附试验数据拟合结果
Table 3. The model result of adsorption test
样品 衬垫层材料 Henry模型 Freundlich模型 Langmuir模型 Kd/（L·g−1） R2 KF/（L·g−1） n R2 KL/（L·g−1） Qm/（mg·g−1） R2 H0 黄土+0%膨润土 0.056 0.997 0.085 1.040 0.953 0.002 82.382 0.887 H15 黄土+15%膨润土 0.055 0.994 0.103 1.066 0.932 0.001 95.280 0.887 H30 黄土+30%膨润土 0.070 0.997 0.105 1.049 0.988 0.002 73.830 0.854
下载: 导出CSV
表 4 输入到Pollute v7.0的参数
Table 4. The parameter used in Pollute v7.0
参数 H15 H30 填埋场长度/m 100.00 100.00 填埋场宽度/m 50.00 50.00 含水层厚度/m 3.00 3.00 地下水流速/（m·a−1） 0.10 0.10 渗滤液深度/m 20.00 20.00 渗滤液中氨氮质量浓度/（mg·L−1） 2000.00 2000.00 L/m 2.00 2.00 衬垫层干密度/（g·cm−3） 1.61 1.55 衬垫层孔隙率/% 16.57 24.14 k/（m·s−1） 2.35×10−10 2.40×10−10 D/（m2·s−1） 4.5×10−11 4.3×10−11 Kd/（L·g−1） 0.055 0.070
下载: 导出CSV
表 5 不同情形下氨氮击穿衬垫层的时间
Table 5. The breakthrough time of ammonium in liners
/a 试样 工况（1）
对流工况（2）
对流+扩散工况（3）
对流+扩散+吸附H15 24.53 5.16 1 969 H30 24.02 6.86 2294
下载: 导出CSV
-
[1] 陈云敏,谢海建,张春华. 污染物击穿防污屏障与地下水土污染防控研究进展[J]. 水利水电科技进展,2016,36(1):1 − 10. [CHEN Yunmin,XIE Haijian,ZHANG Chunhua. Review on penetration of barriers by contaminants and technologies for groundwater and soil contamination control[J]. Advances in Science and Technology of Water Resources,2016,36(1):1 − 10. (in Chinese with English abstract)]
CHEN Yunmin, XIE Haijian, ZHANG Chunhua. Review on penetration of barriers by contaminants and technologies for groundwater and soil contamination control[J]. Advances in Science and Technology of Water Resources, 2016, 36（1）: 1 − 10. （in Chinese with English abstract）
[2] 冯世进,高丽亚,王印. 垃圾填埋场边坡上土工膜的受力分析[J]. 岩土工程学报,2008,30(10):1484 − 1489. [FENG Shijin,GAO Liya,WANG Yin. Analysis of tension of geomembranes placed on landfill slopes[J]. Chinese Journal of Geotechnical Engineering,2008,30(10):1484 − 1489. (in Chinese with English abstract)]
FENG Shijin, GAO Liya, WANG Yin. Analysis of tension of geomembranes placed on landfill slopes[J]. Chinese Journal of Geotechnical Engineering, 2008, 30（10）: 1484 − 1489. （in Chinese with English abstract）
[3] 张虎元,赵天宇,吴军荣,等. 膨润土改性黄土衬里防渗性能室内测试与预测[J]. 岩土力学,2011,32(7):1963 − 1969. [ZHANG Huyuan,ZHAO Tianyu,WU Junrong,et al. Laboratory measurement and prediction to the permeability of bentonite-modified loess as a landfill liner[J]. Rock and Soil Mechanics,2011,32(7):1963 − 1969. (in Chinese with English abstract)]
ZHANG Huyuan, ZHAO Tianyu, WU Junrong, et al. Laboratory measurement and prediction to the permeability of bentonite-modified loess as a landfill liner[J]. Rock and Soil Mechanics, 2011, 32（7）: 1963 − 1969. （in Chinese with English abstract）
[4] WU Jiawei,XIE Haijian,ZHANG Chunhua,et al. Adsorption behavior of bisphenol A on bentonite-loess mixtures[J]. Environmental Science and Pollution Research International,2022,29(4):6360 − 6374. doi: 10.1007/s11356-021-15888-x
[5] CHALERMYANONT T,ARRYKUL S,CHAROENTHAISONG N. Potential use of lateritic and marine clay soils as landfill liners to retain heavy metals[J]. Waste Management,2009,29(1):117 − 127. doi: 10.1016/j.wasman.2008.03.010
[6] LAKE C B,ROWE R K. Volatile organic compound diffusion and sorption coefficients for a needle-punched GCL[J]. Geosynthetics International,2004,11(4):257 − 272. doi: 10.1680/gein.2004.11.4.257
[7] 唐晓武,罗春泳,陈云敏,等. 粘土环境岩土工程特性对填埋场衬垫防渗标准的影响[J]. 岩石力学与工程学报,2005,24(8):1396 − 1401. [TANG Xiaowu,LUO Chunyong,CHEN Yunmin,et al. Effect of geoenvironmental characteristics of clay on standard of landfill liner[J]. Chinese Journal of Rock Mechanics and Engineering,2005,24(8):1396 − 1401. (in Chinese with English abstract)]
TANG Xiaowu, LUO Chunyong, CHEN Yunmin, et al. Effect of geoenvironmental characteristics of clay on standard of landfill liner[J]. Chinese Journal of Rock Mechanics and Engineering, 2005, 24（8）: 1396 − 1401. （in Chinese with English abstract）
[8] DU Yanjun,LIU Songyu,LIN Chongde. Some factors controlling diffusive transport of potassium ion through clayey soils[J]. Journal of Southeast University (English Edition),2006,22(1):106 − 111.
[9] 张春华,吴家葳,陈赟,等. 基于污染物击穿时间的填埋场复合衬垫厚度简化设计方法[J]. 岩土工程学报,2020,42(10):1841 − 1848. [ZHANG Chunhua,WU Jiawei,CHEN Yun,et al. Simplified method for determination of thickness of composite liners based on contaminant breakthrough time[J]. Chinese Journal of Geotechnical Engineering,2020,42(10):1841 − 1848. (in Chinese with English abstract)]
ZHANG Chunhua, WU Jiawei, CHEN Yun, et al. Simplified method for determination of thickness of composite liners based on contaminant breakthrough time[J]. Chinese Journal of Geotechnical Engineering, 2020, 42（10）: 1841 − 1848. （in Chinese with English abstract）
[10] TONG Shan,SAMPLE-LORD K M. Coupled solute transport through a polymer-enhanced bentonite[J]. Soils and Foundations,2022,62:101235. doi: 10.1016/j.sandf.2022.101235
[11] SHACKELFORD C D. Transit-time design of earthen barriers[J]. Engineering Geology,1990,29(1):79 − 94. doi: 10.1016/0013-7952(90)90083-D
[12] LIU Yangsheng,BAI Qingzhong,NIE Yongfeng. Properties of bentonite enhanced loess and laterite[J]. Chinese Journal of Chemical Engineering,2004,12(1):43 − 47.
[13] 周睿,吴玲,簿丝,等. 深圳简易垃圾填埋场水土环境污染指标识别[J]. 中国环境科学,2022,42(3):1287 − 1294. [ZHOU Rui,WU Ling,BO Si,et al. Pollutant identification of water and soil of uncontrolled landfills in Shenzhen[J]. China Environmental Science,2022,42(3):1287 − 1294. (in Chinese with English abstract)]
ZHOU Rui, WU Ling, BO Si, et al. Pollutant identification of water and soil of uncontrolled landfills in Shenzhen[J]. China Environmental Science, 2022, 42（3）: 1287 − 1294. （in Chinese with English abstract）
[14] 韩智勇,许模,刘国,等. 生活垃圾填埋场地下水污染物识别与质量评价[J]. 中国环境科学,2015,35(9):2843 − 2852. [HAN Zhiyong,XU Mo,LIU Guo,et al. Pollutant identification and quality assessment of groundwater near municipal solid waste landfills in China[J]. China Environmental Science,2015,35(9):2843 − 2852. (in Chinese with English abstract)]
HAN Zhiyong, XU Mo, LIU Guo, et al. Pollutant identification and quality assessment of groundwater near municipal solid waste landfills in China[J]. China Environmental Science, 2015, 35（9）: 2843 − 2852. （in Chinese with English abstract）
[15] 孙启明,高茂生,党显璋. 垃圾填埋场渗滤液变密度地下水溶质运移模拟[J]. 吉林大学学报(地球科学版),2022,52(4):1265 − 1274. [SUN Qiming,GAO Maosheng,DANG Xianzhang. Simulation of solute transport in variable-density groundwater for landfill leachate[J]. Journal of Jilin University (Earth Science Edition),2022,52(4):1265 − 1274. (in Chinese with English abstract)]
SUN Qiming, GAO Maosheng, DANG Xianzhang. Simulation of solute transport in variable-density groundwater for landfill leachate[J]. Journal of Jilin University （Earth Science Edition）, 2022, 52（4）: 1265 − 1274. （in Chinese with English abstract）
[16] 刘学浩,邹金,易秤云,等. 基于地下水分层技术刻画污染场地水化学空间分布特征——以湖北某垃圾填埋场为例[J]. 中国地质,2023:1−19. [LIU Xuehao,ZOU Jin,YI Chengyun,et al. Spatial distribution characteristics of hydrochemistry in contaminated sites based on groundwater stratification technology:A case study of a landfill in Hubei Province[J]. Geology in China,2023:1−19. (in Chinese with English abstract)]
LIU Xuehao, ZOU Jin, YI Chengyun, et al. Spatial distribution characteristics of hydrochemistry in contaminated sites based on groundwater stratification technology: A case study of a landfill in Hubei Province[J]. Geology in China, 2023: 1−19. （in Chinese with English abstract）
[17] GUPT C B,BORDOLOI S,SEKHARAN S,et al. Adsorption characteristics of Barmer bentonite for hazardous waste containment application[J]. Journal of Hazardous Materials,2020,396:122594. doi: 10.1016/j.jhazmat.2020.122594
[18] ASTM International. Standard test method for 24 h batch type measurement of contaminant sorption by soils and sediments:D 4646—03[S]. West Conshohocken:ASTM International,2008.
[19] 环境保护部. 水质 氨氮的测定 纳氏试剂分光光度法:HJ 535—2009[S]. 北京:中国环境科学出版社,2010. [Ministry of Environment of the People’s Republic of China. Water quality-determination of ammonia nitrogen-nessler’s reagent spectrophotometry:HJ 535—2009[S]. Beijing:China Environmental Science Press,2010. (in Chinese)]
Ministry of Environment of the People’s Republic of China. Water quality-determination of ammonia nitrogen-nessler’s reagent spectrophotometry: HJ 535—2009[S]. Beijing: China Environmental Science Press, 2010. （in Chinese）
[20] 王宝,王泽峰,窦桐桐,等. 氨氮在土工合成黏土衬垫中的扩散行为研究[J]. 岩土工程学报,2021,43(1):140 − 146. [WANG Bao,WANG Zefeng,DOU Tongtong,et al. Diffusion of ammonium through a geosynthetic clay liner[J]. Chinese Journal of Geotechnical Engineering,2021,43(1):140 − 146. (in Chinese with English abstract)]
WANG Bao, WANG Zefeng, DOU Tongtong, et al. Diffusion of ammonium through a geosynthetic clay liner[J]. Chinese Journal of Geotechnical Engineering, 2021, 43（1）: 140 − 146. （in Chinese with English abstract）
[21] 王泽峰. 干湿循环作用下膨润土改良黄土劣化特性研究[D]. 西安:西安建筑科技大学,2021. [WANG Zefeng. Study on bentonite modified loess degradation characteristics under dry-wet cycles[D]. Xi’an:Xi’an University of Architecture and Technology,2021. (in Chinese with English abstract)]
WANG Zefeng. Study on bentonite modified loess degradation characteristics under dry-wet cycles[D]. Xi’an: Xi’an University of Architecture and Technology, 2021. （in Chinese with English abstract）
[22] 陈延君,王红旗,赵勇胜,等. 用改性膨润土作垃圾填埋场底部衬里的试验[J]. 中国环境科学,2005,25(4):437 − 440. [CHEN Yanjun,WANG Hongqi,ZHAO Yongsheng,et al. Test studies on using modified bentonite as the base bottom liner in the garbage landfill[J]. China Environmental Science,2005,25(4):437 − 440. (in Chinese with English abstract)]
CHEN Yanjun, WANG Hongqi, ZHAO Yongsheng, et al. Test studies on using modified bentonite as the base bottom liner in the garbage landfill[J]. China Environmental Science, 2005, 25（4）: 437 − 440. （in Chinese with English abstract）
[23] XIE Haijian,WANG Shaoyi,QIU Zhanhong,et al. Adsorption of NH4+-N on Chinese loess:Non-equilibrium and equilibrium investigations[J]. Journal of Environmental Management,2017,202:46 − 54.
[24] ALSHAMERI A,HE Hongping,ZHU Jianxi,et al. Adsorption of ammonium by different natural clay minerals:Characterization,kinetics and adsorption isotherms[J]. Applied Clay Science,2018,159:83 − 93. doi: 10.1016/j.clay.2017.11.007
[25] LAKE C B,ROWE R K. Diffusion of sodium and chloride through geosynthetic clay liners[J]. Geotextiles and Geomembranes,2000,18(2):103 − 131.
[26] 詹良通,刘伟,曾兴,等. 垃圾填埋场污染物击穿竖向防渗帷幕时间的影响因素分析及设计厚度的简化计算公式[J]. 岩土工程学报,2013,35(11):1988 − 1996. [ZHAN Liangtong,LIU Wei,ZENG Xing,et al. Parametric study on breakthrough time of vertical cutoff wall for MSW landfills and simplified design formula for wall thickness[J]. Chinese Journal of Geotechnical Engineering,2013,35(11):1988 − 1996. (in Chinese with English abstract)]
ZHAN Liangtong, LIU Wei, ZENG Xing, et al. Parametric study on breakthrough time of vertical cutoff wall for MSW landfills and simplified design formula for wall thickness[J]. Chinese Journal of Geotechnical Engineering, 2013, 35（11）: 1988 − 1996. （in Chinese with English abstract）
[27] 张文杰,刘颖,贾文强. 氯离子在黏土-膨润土屏障中迁移的离心试验研究[J]. 岩土力学,2015,36(8):2237 − 2242. [ZHANG Wenjie,LIU Ying,JIA Wenqiang. Centrifuge study of migration of Cl− in clay-bentonite barriers[J]. Rock and Soil Mechanics,2015,36(8):2237 − 2242. (in Chinese with English abstract)]
ZHANG Wenjie, LIU Ying, JIA Wenqiang. Centrifuge study of migration of Cl− in clay-bentonite barriers[J]. Rock and Soil Mechanics, 2015, 36（8）: 2237 − 2242. （in Chinese with English abstract）
-
