基于CNN神经网络的煤层底板突水预测

陈建平; 王春雷; 王雪冬

doi:10.16031/j.cnki.issn.1003-8035.2021.01.07

基于CNN神经网络的煤层底板突水预测

辽宁工程技术大学矿业学院，辽宁阜新　123000

基金项目: 国家自然科学基金项目(51604140)

详细信息

作者简介: 陈建平(1971-)，男，山西保德人，博士，副教授，主要从事矿山水文地质等方面的教学和科研工作。E-mail：chenjianp123000@163.com

中图分类号: TD76

收稿日期: 2020-03-10

修回日期: 2020-04-23

刊出日期: 2021-02-25

Coal mine floor water inrush prediction based on CNN neural network

College of Mining ,Liaoning Technical University, Fuxin, Liaoning　123000, China

Received Date: 10 March 2020

Revised Date: 23 April 2020

Publish Date: 25 February 2021

摘要

摘要:
为了提高煤层底板突水预测的准确性，建立了基于卷积神经网络的煤层底板突水预测模型。通过综合分析，确定了15个影响煤层底板突水的因素，将这些影响因素进行拼接组合，运用建立的深度计算结构模型对影响因素及其相互联系进行特征提取。用已知的115组数据对模型进行学习训练，并进行了预测。为验证模型的准确性，利用相同的数据对BP神经网络模型和LeNet-5模型进行训练，将建立的模型与BP神经网络模型和LeNet-5模型进行对比。结果表明：该模型通过加深模型的计算深度，综合考虑了影响底板突水因素间的相互联系，提高了突水预测准确性。基于卷积神经网络构建的模型可以对煤层底板突水进行预测，并且准确率相对较高。
- 卷积神经网络 /
- 深度学习 /
- 煤层底板 /
- 突水预测 /
- 数据拼接组合
Abstract:
With a view to improving the accuracy of water bursting prediction in coal seam floor, a model based on Convolutional Neural Network (CNN) was established. Through comprehensive analysis of water bursting in coal seam floor, 15 factors affecting water bursting prediction were determined and these factors were combined to stimulate the partial correlation among these factors. These factors and their interrelation on water bursting prediction in coal seam floor were simulated by using the structure model established for depth calculation. Training and prediction were performed by using the known 115 sets of data. To verify the model efficiency, the BP neural network model and the LeNet-5 model were trained by using the same data, and then the established BP neural network model was compared with the LeNet-5 model. The result indicates that the interrelation between factors affecting water bursting prediction is considered comprehensively by deepening the calculation depth of the model, and the accuracy of water bursting prediction is improved. The prediction model of water bursting prediction in coal seam floor based on Convolutional Neural Network (CNN) has high accuracy and small standard error, which improves the accuracy of prediction effectively.
- convolutional neural network /
- deep learning /
- coal seam floor /
- water inrush prediction /
- data stitching combination

HTML全文

图 1 BP神经网络与卷积神经网络连接方式示意图

Figure 1.

下载: 全尺寸图片幻灯片

图 2 卷积神经网络结构示意图

Figure 2.

下载: 全尺寸图片幻灯片

图 3 模型结构示意图

Figure 3.

下载: 全尺寸图片幻灯片

图 4 接触概率设置对比实验结果

Figure 4.

下载: 全尺寸图片幻灯片

图 5 数据拼接组合过程示意图

Figure 5.

下载: 全尺寸图片幻灯片

图 6 CNN模型在训练集和测试集上的正确率

Figure 6.

下载: 全尺寸图片幻灯片

图 7 测试集上的预测值与实际值对比

Figure 7.

下载: 全尺寸图片幻灯片

表 1 影响煤层底板突水的因素

Table 1. Factors affecting water inrush from coal floor

一级指标	二级指标
含水层因素	单位涌水量(x₁)
	水压(x₂)
	含水层厚度(x₃)
隔水层因素	隔水层厚度(x₄)
	隔水层岩石饱和单轴抗压强度(x₅)
	隔水层岩体完整性指数(x₆)
构造因素	单位面积断层条数(x₇)
	大断层条数(x₈)
	裂隙发育程度(x₉)
煤层因素	煤层埋深(x₁₀)
煤层因素	煤层倾角(x₁₁)
开采因素	底板破坏带深度(x₁₂)
	工作面长度(x₁₃)
	采高(x₁₄)
	开采面积(x₁₅)

下载: 导出CSV

表 2 不同卷积层的预测结果

Table 2. Prediction results of different convolution layers

编号	卷积层数量/个	准确率/%	标准误差
1	1	67	0.492
2	2	93	0.268
3	3	80	0.385
4	4	73	0.436

下载: 导出CSV

表 3 部分样本数据

Table 3. Part of the sample data

序号	x₁/(L·s⁻¹·m⁻¹)	x₂/MPa	x₃/m	x₄/m	x₅/MPa	x₆	x₇/(条·km⁻²)	x₈/条	x₉/%	x₁₀/m	x₁₁/(°)	x₁₂/m	x₁₃/m	x₁₄/m	x₁₅/m²	是否突水
1	3.4	2.80	14.35	39.17	34.28	0.64	34.2	4	14.52	347	12	24.33	150	2.75	5 240	是
2	3.5	2.95	14.35	36.11	34.28	0.64	34.2	4	14.52	380	12	24.61	150	2.55	4 260	是
17	0.15	0.73	15	79	42.00	0.80	0.44	1	5	178	13	20.90	200	3.08	8100	否
18	0.15	1.00	15	51	37.12	0.80	0.44	1	5	202	13	18.95	180	1.80	7800	否
53	2.5	1.37	12.54	50.92	38.30	0.53	42.5	5	18.22	332	14	33.17	200	3.50	5 900	是
54	2.6	1.45	13.02	46.23	38.30	0.53	42.5	5	18.22	352	15	33.50	200	3.50	5 400	是
88	1.8	2.25	35.15	30.00	17.38	0.60	21.6	4	16.53	289	13	19.69	100	3.00	1 530	否
89	1.8	2.35	35.15	30.00	17.38	0.60	21.6	4	16.53	323	16	20.47	100	2.75	1 535	否
95	0.16	1.02	70	52	34.60	0.75	0.52	6	11	370	9	12.15	110	2.76	23500	否
111	2.12	2.89	85	67	46.12	0.55	36.11	4	29	351	9	9.84	90	1.56	4180	是
114	0.29	0.84	31	121	38.13	0.80	0.14	1	13	270	4	14.79	150	3.12	8510	否
115	0.29	1.08	31	97	41.89	0.80	0.14	1	13	295	4	15.00	150	1.97	8510	否

下载: 导出CSV

表 4 实验参数

Table 4. Experimental parameters

实验参数	数值
Learning rate	0.00001
Epochs	1800
Batch size	10
Dropout	0.5

下载: 导出CSV

表 5 各个模型的正确率

Table 5. Accuracy of the predicted results

预测模型	训练集准确/%	测试集准确/%	标准误差
BP	74	67	0.450
LeNet-5	83	80	0.430
本文CNN模型	96	100	0.135

下载: 导出CSV

表 6 各个模型的预测结果

Table 6. Testresults of the forecast model

序号	实际情况	BP预测	LeNet-5预测	本文CNN模型
1	不突水	突水	不突水	不突水
2	突水	突水	不突水	突水
3	突水	突水	突水	突水
4	突水	突水	突水	突水
5	不突水	突水	不突水	不突水
6	不突水	突水	不突水	不突水
7	突水	突水	突水	突水
8	突水	突水	突水	突水
9	不突水	不突水	不突水	不突水
10	不突水	不突水	不突水	不突水
11	突水	突水	不突水	突水
12	突水	突水	不突水	突水
13	不突水	突水	不突水	不突水
14	不突水	不突水	不突水	不突水
15	不突水	突水	不突水	不突水

下载: 导出CSV
