Stability of dangerous rockmasses and prediction of rockfall trajectory: A case study at Wansui Mountain in Ganzi County of Sichuan Province
-
摘要:
甘孜县甘孜镇万岁山斜坡危岩带多年来时常有落石发生，严重威胁到了下方居民的生命财产安全，因此对万岁山斜坡进行危岩带稳定性分析与落石轨迹预测尤为重要。以万岁山斜坡的危岩带为对象，利用无人机倾斜摄影结合现场调查获取了危岩带几何尺寸和三维形态，分析了危岩带的发育特征和危岩体的分布特征，对危岩稳定性进行了分析；基于RAMMS-ROCKFALL考虑了危岩体的几何形状和三维地形，模拟了危岩体崩塌后可能的落石运动路径。结果表明：（1）斜坡整体性较完整，受风化作用主要失稳模式为坠落式和倾倒式，共发育有7处危岩带，地震工况下为不稳定状态； （2）通过模拟得到了滚落弹跳高度、速度、动能和轨迹、位置的关系，并通过预测落石运动轨迹得到了危岩带的威胁范围、威胁对象，预测结果表明万岁山斜坡对下方居民房屋和街道行人产生的威胁较大，应该尽快采取治理措施。研究成果表明无人机倾斜摄影的利用，有利于斜坡危岩体的稳定性分析，弥补了传统调查的盲区，提高了调查的效率与质量，对危岩体的调查与落石轨迹分析提供了一个新思路，对于减灾技术研究与危岩体的治理有积极意义。
-
关键词:
- RAMMS-ROCKFALL /
- 危岩体 /
- 数值模拟 /
- 稳定性评价 /
- 落石轨迹
Abstract:The hazardous rock zone on the Wansui Mountain slope in Ganzi Town, Ganzi County, has experienced frequent rockfalls over the years, posing a serious threat to the lives and property of residents below. Therefore, it is crucial to conduct stability analysis of the hazardous rock zone and rockfall trajectory prediction for the Wansui Mountain slope. Focusing on the dangerous rock zone of Wansui Mountain's slope, the geometric dimensions and 3D morphology of the zone were obtained using drone oblique photography combined with field surveys. The development characteristics of the dangerous rock zone and the distribution characteristics of the dangerous rock bodies were analyzed, and the stability of the dangerous rocks was assessed. Based on RAMMS-ROCKFALL, considering the geometric shapes of the dangerous rocks and the 3D terrain, potential rockfall trajectories after the collapse of the dangerous rocks were simulated.The results show that:The slope is generally intact, with the main instability modes being falling and toppling due to weathering. A total of seven dangerous rock zones have developed, which are in an unstable state under seismic conditions; the simulation provided the relationships between rolling and bouncing heights, speeds, kinetic energy, trajectories, and positions. By predicting the rockfall trajectories, the threat range and targets of the dangerous rock zone were determined. The prediction results indicate a significant threat to the houses and pedestrians on the streets below the slope of Wansui Mountain, and remedial measures should be taken as soon as possible.The research results indicate that the use of drone oblique photography is beneficial for the stability analysis of dangerous rock bodies on slopes, compensating for the blind spots of traditional surveys, and improving the efficiency and quality of the investigation. This provides a new approach for the investigation of dangerous rock bodies and rockfall trajectory analysis, which has positive significance for disaster mitigation technology research and the management of dangerous rock bodies.
-
-
表 1 基本特征表
Table 1. Basic characteristics table
编号 长度/m 分布高程/m 平均宽度/m 面积/m2 平均厚度/m 体积/m3 物质组成 WY01 35 3355～3366 10 358.7 3.5 1255.45 由碎裂状砂岩、板岩组成 WY02 105 3340～3370 30 328.1 3 9849.3 WY03 45 3341～3368 20 907.4 3.5 3174.9 WY04 50 3363～3391 12 607.4 3 1822.2 WY05 70 3360～3382 18 1215.2 3.5 4253.2 WY06 40 3365～3380 10 396.1 3.5 1291.85 WY07 60 3343～3354 5 252.7 3.5 989.45
下载: 导出CSV
表 2 节理裂隙特征表
Table 2. Joint fracture characteristics table
编号 平均坡度/（°） 坡向/（°） 岩层产状 岩性 节理裂隙 失稳模式 WY01 70 85 210°∠30° 薄-中厚层
状板岩①组：210°∠30°，裂隙延伸长度
约0.5～1.0 m，局部张开度1 cm②组：310°∠45°，裂隙延伸长度
约0.4～0.9 m，局部张开度2 cm倾倒式 WY02 70 92 180°∠20° ①组：205°∠34°，裂隙延伸长度
约0.6～1.2 m，局部张开度1.5 cm②组：306°∠44°，裂隙延伸长度
约0.5～1.0 m，局部张开度3 cm坠落式 WY03 70 92 180°∠20° ①组：205°∠32°，裂隙延伸长度
约1.1～1.5 m，局部张开度1.5 cm②组：304°∠40°，裂隙延伸长度
约1～2.0 m，局部张开度5 cm坠落式 WY04 70 92 180°∠20° ①组：209°∠31°，裂隙延伸长度
约0.8～1.2 m，局部张开度3 cm②组：308°∠41°，裂隙延伸长度
约0.9～2.1 m，局部张开度4 cm坠落式 WY05 72 101 180°∠20° ①组：207°∠33°，裂隙延伸长度
约0.6～1.2 m，局部张开度4 cm②组：306°∠45°，裂隙延伸长度
约1.3～2.7 m，局部张开度6 cm坠落式 WY06 76 107 180°∠20° ①组：211°∠32°，裂隙延伸长度
约0.7～1.5 m，局部张开度5 cm②组：312°∠41°，裂隙延伸长度
约0.8～2.2 m，局部张开度6 cm倾倒式 WY07 72 101 180°∠20° ①组：201°∠34°，裂隙延伸长度
约0.5～1.2 m，局部张开度4 cm②组：308°∠44°，裂隙延伸长度
约1.2～2.5 m，局部张开度4 cm倾倒式
下载: 导出CSV
表 3 岩土物理力学参数取值
Table 3. Values of geotechnical physical and mechanical parameters
岩土层 重度指标 抗剪强度指标 天然状态
/（kN·m−3）饱水状态
/（kN·m−3）天然状态 暴雨状态 黏聚力
/kPa内摩擦角
/（°）黏聚力
/kPa内摩擦角
/（°）粉质黏土 19.0 20.5 19 20 15 17 碎石土 20.5 21.5 12 32 10 28.5 强风化板岩 23.9 24.1 - - - - 中风化板岩 24.9 25.8 425 38.2 - -
下载: 导出CSV
表 4 危岩稳定性系数及稳定性评价
Table 4. Stability coefficients and stability evaluation of hazardous rocks
编号 WY01 WY02 WY03 WY04 WY05 WY06 WY07 天然状态 稳定系数 1.35 0.92 1.11 0.71 1.14 0.71 1.17 稳定性评价 基本稳定 不稳定 欠稳定 不稳定 欠稳定 不稳定 欠稳定 暴雨状态 稳定系数 1.31 0.90 1.10 0.69 1.09 0.69 1.11 稳定性评价 基本稳定 不稳定 欠稳定 不稳定 欠稳定 不稳定 欠稳定 地震状态 稳定系数 1.12 0.76 0.97 0.53 0.91 0.53 0.92 稳定性评价 欠稳定 不稳定 不稳定 不稳定 不稳定 不稳定 不稳定
下载: 导出CSV
表 5 阻力特征系数K值计算公示表
Table 5. Calculation table for coefficient K of resistance characteristic
顺序 山坡坡度角/（°） K值计算公式 1 0～30 0.41+0.0043ɑ 2 30～60 0.543-0.0048ɑ+0.000162ɑ2 3 60～90 1.05−0.0125ɑ+0.0000025ɑ2
下载: 导出CSV
表 6 落石威胁对象和到达威胁区概率
Table 6. Rockfall threat object and probability of arrival at threat zones
编号 威胁对象 到达威胁区概率/% 合计/% WY01 居民房屋 41.33 96.8 院内人员 55.47 WY02 居民房屋 88.32 95.62 院内人员 7.30 WY03 居民房屋 11.25 96.91 院内人员 85.66 WY04 居民房屋 26.66 26.66 WY05 居民房屋 81.78 97.23 街道行人和汽车 15.45 WY06 居民房屋 35.19 57.56 街道行人和汽车 22.37 WY07 居民房屋 99.51 99.51
下载: 导出CSV
-
[1] VOLKWEIN A,SCHELLENBERG K,LABIOUSE V,et al. Rockfall characterisation and structural protection–a review[J]. Natural Hazards and Earth System Sciences,2011,11(9):2617 − 2651. doi: 10.5194/nhess-11-2617-2011
[2] FITYUS S G,GIACOMINI A,BUZZI O. The significance of geology for the morphology of potentially unstable rocks[J]. Engineering Geology,2013,162:43 − 52. doi: 10.1016/j.enggeo.2013.05.007
[3] LEINE R I,SCHWEIZER A,CHRISTEN M,et al. Simulation of rockfall trajectories with consideration of rock shape[J]. Multibody System Dynamics,2014,32(2):241 − 271. doi: 10.1007/s11044-013-9393-4
[4] HARVEY G J M. Rock-shape and its role in rockfall dynamics[D]. Durham,North East England,UK:Durham University,2015
[5] KIM D H,GRATCHEV I,BERENDS J,et al. Calibration of restitution coefficients using rockfall simulations based on 3D photogrammetry model:A case study[J]. Natural Hazards,2015,78(3):1931 − 1946. doi: 10.1007/s11069-015-1811-x
[6] CROSTA G B,AGLIARDI F,FRATTINI P,et al. Key issues in rock fall modeling,hazard and risk assessment for rockfall protection[M]. Engineering Geology for Society and Territory - Volume 2. Cham:Springer International Publishing,2015:43 − 58.
[7] LAN Hengxing,LI Langping,WU Yuming. Stochasticity of rockfall tracjectory revealed by a field experiment repeated on a single sample[M]//Engineering Geology for Society and Territory - Volume 2. Cham:Springer International Publishing,2015:1713 − 1721.
[8] 周游,黄静美,谢红强. 西南地区某高速公路边坡危岩体稳定可靠性评价[J]. 地下空间与工程学报,2020,16(增刊2):1022 − 1029. [ZHOU You,HUANG Jingmei,XIE Hongqiang. Reliability evaluation of stability of dangerous rock mass on a highway slope in southwest China[J]. Chinese Journal of Underground Space and Engineering,2020,16(Sup 2):1022 − 1029. (in Chinese with English abstract)]
ZHOU You, HUANG Jingmei, XIE Hongqiang. Reliability evaluation of stability of dangerous rock mass on a highway slope in southwest China［J］. Chinese Journal of Underground Space and Engineering, 2020, 16（Sup 2）: 1022 − 1029. （in Chinese with English abstract）
[9] 贺凯,高杨,殷跃平,等. 基于岩体损伤的大型高陡危岩稳定性评价方法[J]. 水文地质工程地质,2020,47(4):82 − 89. [HE Kai,GAO Yang,YIN Yueping,et al. Stability assessment methods for huge high-steep unstable rock mass based on damage theory[J]. Hydrogeology & Engineering Geology,2020,47(4):82 − 89. (in Chinese with English abstract)]
HE Kai, GAO Yang, YIN Yueping, et al. Stability assessment methods for huge high-steep unstable rock mass based on damage theory［J］. Hydrogeology & Engineering Geology, 2020, 47（4）: 82 − 89. （in Chinese with English abstract）
[10] 孙琪皓,马凤山,刘港,等. G109国道拉萨—羊八井段喀努纳危岩体变形破坏模式及稳定性分析[J]. 工程地质学报,2021,29(2):495 − 507. [SUN Qihao,MA Fengshan,LIU Gang,et al. Deformation failure mode and stability analysis of Kanuna unstable rock mass in Lhasa-Yangbajing section of G109 national highway[J]. Journal of Engineering Geology,2021,29(2):495 − 507. (in Chinese with English abstract)]
SUN Qihao, MA Fengshan, LIU Gang, et al. Deformation failure mode and stability analysis of Kanuna unstable rock mass in Lhasa-Yangbajing section of G109 national highway［J］. Journal of Engineering Geology, 2021, 29（2）: 495 − 507. （in Chinese with English abstract）
[11] 张继旭,王林峰,夏万春. 基于模糊失效准则的危岩稳定可靠度计算[J]. 防灾减灾工程学报,2022,42(4):695 − 704. [ZHANG Jixu,WANG Linfeng,XIA Wanchun. Reliability calculation of perilous rock stability based on fuzzy failure criterion[J]. Journal of Disaster Prevention and Mitigation Engineering,2022,42(4):695 − 704. (in Chinese with English abstract)]
ZHANG Jixu, WANG Linfeng, XIA Wanchun. Reliability calculation of perilous rock stability based on fuzzy failure criterion［J］. Journal of Disaster Prevention and Mitigation Engineering, 2022, 42（4）: 695 − 704. （in Chinese with English abstract）
[12] 马显东,周剑,张路青,等. 基于崩塌滚石运动特征的防护网动态响应规律[J]. 地球科学,2022,47(12):4559 − 4573. [MA Xiandong,ZHOU Jian,ZHANG Luqing,et al. Dynamic response laws of flexible rockfall barriers based on movement characteristics of rockfall[J]. Earth Science,2022,47(12):4559 − 4573. (in Chinese with English abstract)]
MA Xiandong, ZHOU Jian, ZHANG Luqing, et al. Dynamic response laws of flexible rockfall barriers based on movement characteristics of rockfall［J］. Earth Science, 2022, 47（12）: 4559 − 4573. （in Chinese with English abstract）
[13] 马显东,周剑,张路青,等. 强震区公路沿线崩塌危岩体特征提取及失稳分析[J]. 岩石力学与工程学报,2022,41(增刊1):2901 − 2914. [MA Xiandong,ZHOU Jian,ZHANG Luqing,et al. Feature extraction and instability analysis of collapse rock mass along highway in strong earthquake area[J]. Chinese Journal of Rock Mechanics and Engineering,2022,41(Sup 1):2901 − 2914. (in Chinese with English abstract)]
MA Xiandong, ZHOU Jian, ZHANG Luqing, et al. Feature extraction and instability analysis of collapse rock mass along highway in strong earthquake area［J］. Chinese Journal of Rock Mechanics and Engineering, 2022, 41（Sup 1）: 2901 − 2914. （in Chinese with English abstract）
[14] 姚富潭,吴明堂,董秀军,等. 基于贴近摄影测量技术的高陡危岩体结构面调查方法[J]. 成都理工大学学报(自然科学版),2023,50(2):218 − 228. [YAO Futan,WU Mingtang,DONG Xiujun,et al. Investigation method of discontinuity in high and steep dangerous rock mass based on nap of the object photogrammetry[J]. Journal of Chengdu University of Technology (Science & Technology Edition),2023,50(2):218 − 228. (in Chinese with English abstract)]
YAO Futan, WU Mingtang, DONG Xiujun, et al. Investigation method of discontinuity in high and steep dangerous rock mass based on nap of the object photogrammetry［J］. Journal of Chengdu University of Technology （Science & Technology Edition）, 2023, 50（2）: 218 − 228. （in Chinese with English abstract）
[15] 谢金,杨根兰,覃乙根,等. 基于无人机与Rockfall的危岩体结构特征识别与运动规律模拟[J]. 河南理工大学学报(自然科学版),2021,40(1):55 − 64. [XIE Jin,YANG Genlan,QIN Yigen,et al. Structural feature recognition and motion law simulation of dangerous rock mass based on UAV and Rockfall[J]. Journal of Henan Polytechnic University (Natural Science),2021,40(1):55 − 64. (in Chinese with English abstract)]
XIE Jin, YANG Genlan, QIN Yigen, et al. Structural feature recognition and motion law simulation of dangerous rock mass based on UAV and Rockfall［J］. Journal of Henan Polytechnic University （Natural Science）, 2021, 40（1）: 55 − 64. （in Chinese with English abstract）
[16] 刘福臻,李旭德,王军朝,等. 基于无人机和Rockfall Analyst的崩塌落石特征分析与运动学模拟——以察雅县崩塌落石为例[J]. 自然灾害学报,2021,30(3):171 − 180. [LIU Fuzhen,LI Xude,WANG Junchao,et al. Characteristic analysis and kinematic simulation of rockfall based on UAV and Rockfall Analyst:A case study of rockfall in Chaya County[J]. Journal of Natural Disasters,2021,30(3):171 − 180. (in Chinese with English abstract)]
LIU Fuzhen, LI Xude, WANG Junchao, et al. Characteristic analysis and kinematic simulation of rockfall based on UAV and Rockfall Analyst: A case study of rockfall in Chaya County［J］. Journal of Natural Disasters, 2021, 30（3）: 171 − 180. （in Chinese with English abstract）
[17] 康尘云. 基于倾斜摄影的高位危岩特征获取和稳定性评价——以重庆万州观音山危岩带为例[J]. 中国地质灾害与防治学报,2022,33(5):66 − 75. [KANG Chenyun. Feature acquisition and stability evaluation of high dangerous rock mass based on oblique photography:A case study at Guanyinshan in Wanzhou,Chongqing Province[J]. The Chinese Journal of Geological Hazard and Control,2022,33(5):66 − 75. (in Chinese with English abstract)]
KANG Chenyun. Feature acquisition and stability evaluation of high dangerous rock mass based on oblique photography: A case study at Guanyinshan in Wanzhou, Chongqing Province［J］. The Chinese Journal of Geological Hazard and Control, 2022, 33（5）: 66 − 75. （in Chinese with English abstract）
[18] 何宇航,裴向军,梁靖,等. 基于Rockfall的危岩体危险范围预测及风险评价——以九寨沟景区悬沟危岩体为例[J]. 中国地质灾害与防治学报,2020,31(4):24 − 33. [HE Yuhang,PEI Xiangjun,LIANG Jing,et al. Risk assessment and range prediction of dangerous rockmass based on rockfall:A case study of the Xuangou Collapse[J]. The Chinese Journal of Geological Hazard and Control,2020,31(4):24 − 33. (in Chinese with English abstract)]
HE Yuhang, PEI Xiangjun, LIANG Jing, et al. Risk assessment and range prediction of dangerous rockmass based on rockfall: A case study of the Xuangou Collapse［J］. The Chinese Journal of Geological Hazard and Control, 2020, 31（4）: 24 − 33. （in Chinese with English abstract）
[19] 张永海,谢武平,罗忠行,等. 四川名山白马沟危岩体稳定性评价与落石轨迹分析[J]. 中国地质灾害与防治学报,2022,33(4):37 − 46. [ZHANG Yonghai,XIE Wuping,LUO Zhongxing,et al. Stability evaluation and rockfall trajectory analysis of the Baimagou dangerous rock mass in Mingshan County of Sichuan Province[J]. The Chinese Journal of Geological Hazard and Control,2022,33(4):37 − 46. (in Chinese with English abstract)]
ZHANG Yonghai, XIE Wuping, LUO Zhongxing, et al. Stability evaluation and rockfall trajectory analysis of the Baimagou dangerous rock mass in Mingshan County of Sichuan Province［J］. The Chinese Journal of Geological Hazard and Control, 2022, 33（4）: 37 − 46. （in Chinese with English abstract）
[20] 黄海宁,黄健,周春宏,等. 无人机影像在高陡边坡危岩体调查中的应用[J]. 水文地质工程地质,2019,46(6):149 − 155. [HUANG Haining,HUANG Jian,ZHOU Chunhong,et al. Application of UAV images to rockfall investigation at the high and steep slope[J]. Hydrogeology & Engineering Geology,2019,46(6):149 − 155. (in Chinese with English abstract)]
HUANG Haining, HUANG Jian, ZHOU Chunhong, et al. Application of UAV images to rockfall investigation at the high and steep slope［J］. Hydrogeology & Engineering Geology, 2019, 46（6）: 149 − 155. （in Chinese with English abstract）
[21] 汪莹鹤, 李时亮, 李炜, 等. 张吉怀铁路土峪隧道危岩落石特征及防护措施研究[J]. 铁道标准设计,2023,67(11):126 − 133. [WANG Yinghe, LI Shiliang, LI Wei, et al. Study on the characteristics and protection design of Tuyu tunnel rockfall on Zhangjiajie-Jishou-Huaihua railway[J]. Railway Standard Design,2023,67(11):126 − 133. (in Chinese with English abstract)]
WANG Yinghe, LI Shiliang, LI Wei, et al. Study on the characteristics and protection design of Tuyu tunnel rockfall on Zhangjiajie-Jishou-Huaihua railway［J］. Railway Standard Design, 2023, 67（11）: 126 − 133. （in Chinese with English abstract）
[22] 庞鑫, 袁明, 卢渊, 等. 基于无人机LiDAR仿地飞行技术的高陡边坡危岩体快速识别方法[J]. 地质科技通报,2023,42(6):21 − 30. [PANG Xin, YUAN Ming, LU Yuan, et al. Rapid identification method for the dangerous rock mass of a high-steep slope based on UAV LiDAR and ground imitation flight[J]. Bulletin of Geological Science and Technology,2023,42(6):21 − 30. (in Chinese with English abstract)]
PANG Xin, YUAN Ming, LU Yuan, et al. Rapid identification method for the dangerous rock mass of a high-steep slope based on UAV LiDAR and ground imitation flight［J］. Bulletin of Geological Science and Technology, 2023, 42（6）: 21 − 30. （in Chinese with English abstract）
[23] 王朋伟, 安玉科. 基于倾斜摄影与InSAR技术的高位崩塌风险识别[J]. 水文地质工程地质,2023,50(5):169 − 180. [WANG Pengwei, AN Yuke. High-level collapse risk identification based on oblique photography and InSAR technology[J]. Hydrogeology & Engineering Geology,2023,50(5):169 − 180. (in Chinese with English abstract)]
WANG Pengwei, AN Yuke. High-level collapse risk identification based on oblique photography and InSAR technology［J］. Hydrogeology & Engineering Geology, 2023, 50（5）: 169 − 180. （in Chinese with English abstract）
[24] 曾启强, 王立朝, 刘伟, 等. 广州地区岩质边坡崩塌影响范围计算方法初探[J]. 水文地质工程地质,2023,50(5):159 − 168. [ZENG Qiqiang, WANG Lichao, LIU Wei, et al. Calculation methods of the collapse influence range of a simple rock slope in the Guangzhou Area[J]. Hydrogeology & Engineering Geology,2023,50(5):159 − 168. (in Chinese with English abstract)]
ZENG Qiqiang, WANG Lichao, LIU Wei, et al. Calculation methods of the collapse influence range of a simple rock slope in the Guangzhou Area［J］. Hydrogeology & Engineering Geology, 2023, 50（5）: 159 − 168. （in Chinese with English abstract）
[25] 胡厚田. 崩塌与落石[M]. 北京:中国铁道出版社,1989. [HU Houtian. Collapse and falling rocks[M]. Beijing:China Railway Publishing House,1989. (in Chinese)]
HU Houtian. Collapse and falling rocks［M］. Beijing: China Railway Publishing House, 1989. （in Chinese）
-
