BEACH EVOLUTION AND SPACE-TIME DISCREPANCY OF EROSION INTENSITY AFTER NOURISHMENT——Taking Langtaosha Beach of Qinhuangdao as an example
-
摘要:
海滩养护是修复受侵蚀海滩最快捷而有效的方法，在国内外已得到了大量的工程应用。工程后，海滩地貌形态为适应新的地形、水动力和沉积物条件而调整到新的平衡状态的过程中，海滩剖面发生了先急后缓的形态变化。对秦皇岛浪淘沙浴场养滩工程后连续36个月的海滩形态监测数据进行分析，结果表明海滩单宽体积平均增加约63.87 m3/m，岸线平均向海推进约14 m，海滩填沙保存量占填沙总量的79.16%，达到工程目标，养滩效果良好。海滩形态演化过程中，侵蚀强度呈明显的时空差异性：养滩初期海滩侵蚀严重，之后侵蚀强度呈减弱趋势。受波浪、水位、风向等因素的季节性变化影响，平均海滩侵蚀量夏秋季明显高于冬春季。受东侧基岩岬头和填沙量差异的影响，东段位于遮蔽段内，且相对凹岸，利于淤积，而西侧位于切线段，且相对凸岸，侵蚀强烈。
Abstract:Beach nourishment is a convenient and effective way to fight with coastal erosion, and there has been a large number of projects at home and abroad for nourishment. After every nourishment, the beach profiles will change obviously after or within three years to approach a hydrodynamic balance. In this case, we studied the natural evolution of the Langtaosha beach for two years of time after a nourishment. In the two years, the beach volume increased about 63.87m3/m, the shoreline moved seawards for about 14m, and the ratio of sand preservation of the beach reached 79.16%. The project is respected as a great success. In the process of natural evolution, the erosion intensity is significantly changed in different seasons and from place to place. Immediately after the beach nourishment, the beach erosion was very strong. It became weaker as time went on. As a result of the seasonal variation in wave direction, sea level and wind direction, the erosion intensity in summer is stronger than that in winter. Because of the headland on the eastern side of the beach and difference in sediment nourishment, the eastern part of beach, which is located at a relative concave bank and shielded from wave action, is more inclined to deposition. But the western section, which is located at a relative convex bank, is eroded seriously.
-
Key words:
- beach nourishment /
- morphological evolution /
- erosion intensity /
- space-time discrepancy
-
-
表 1 海滩养护后变化情况
Table 1. Changes of beach after nourishment projects
剖面 项目 竣工初期 6个月 12个月 18个月 24个月 30个月 36个月 J1 单宽变化/(m3/m) 90. 0 -14. 7 -2. 2 —5. 0 —5.7 —4.9 —7.3 0m线/m 38. 6 -7. 3 -14.1 14.3 —15.5 0.9 —6.5 滩肩顶/m/ 28. 3 -4.0 0.7 —4.8 —0.4 —2.9 —2.1 滩面坡度/ °) 3.4 3.9 10.8 3.3 7.4 5.6 7.7 J2 单宽变化/ (m3/m) 141.5 -10.8 — 10. 9 4.8 —11.7 —2.2 —4.1 0m线/m 51. 7 -10.1 -14.0 18.0 —18.9 14.0 —18.8 滩肩顶/m 36.9 -2.7 -0.7 —4.9 —0.1 —2.8 —3.6 滩面坡度/°) 3. 0 4.0 9.5 2.8 6.7 3.0 6.0 J3 单宽变化/(m3/m) 75.9 -10.3 0. 7 —3.6 —2.8 —6.2 1.3 0m线/m 31.9 -10.0 -5.6 16.7 —18.2 12.9 —13.2 滩肩顶/m 22.9 -3.7 0.1 —2.2 —0.4 —1.8 —0.6 滩面坡度/°) 4. 0 5.5 8.4 3.1 7.7 3.4 6.6 J4 单宽变化/(m3/m) 31.4 -4.1 30. 1 —7.3 16.6 —10.8 6.4 0m线/m 13.3 -0.5 4.8 4.2 —12.4 —1.7 1.0 滩肩顶/m 5.1 -12.6 16.5 1.0 —3.0 —3.3 5.7 滩面坡度/°) 4. 0 2.6 3.9 3.4 5.3 4.9 6.5 J5 单宽变化/(m3/m) 20. 9 30.6 —2. 6 —32.3 16.4 —1.9 10.1 0m线/m 7.2 3.8 -0.3 7.4 —12.7 1.1 5.1 滩肩顶/m 1.6 0.2 5.8 —1.6 1.5 —3.4 5.6 滩面坡度/°) 4.0 3.5 4.5 3.1 6.1 4.7 4.8
下载: 导出CSV
表 2 海滩侵蚀强度
Table 2. Intensity of beach erosion
剖面 岸线后退速率S/(m/a) 海滩宽度侵蚀模数W/% J1 50 6.10 J2 4.90 5.72 J3 2.84 5.79 平均 4.08 5.87 J4 —1.42 —3.28 J5 —2.69 —6.55 平均 —2.06 —4.91 注：“一”表示淤积
下载: 导出CSV
表 3 海岸侵蚀强度分级方案
Table 3. Classification scheme of beach erosion intensity
强度级别 后退速率S/(m/a) 侵蚀宽度模数W/% 淤积 < 0 < 0 微侵蚀 0~1 0~2 侵蚀 1~2 2~5 强侵蚀 2~3 5~10 严重侵蚀 "3 "10
下载: 导出CSV
-
[1] 庄振业, 印萍, 吴建政, 等.鲁南沙质海岸的侵蚀量及其影响因素[J].海洋地质与第四纪地质, 2000, 20(3): 15-21. http://d.old.wanfangdata.com.cn/Periodical/hydzydsjdz200003003
ZHUANG Zhenye, YIN Ping, WU Jianzheng, et al. Coastal erosion and its influence on southern Shandong sandy coast[J]. Marine Geology and Quaternary Geology, 2000, 20(3): 15-21. http://d.old.wanfangdata.com.cn/Periodical/hydzydsjdz200003003
[2] 左其华, 窦希萍, 段子冰.我国海岸工程技术展望[J].海洋工程, 2015, 33(1): 1-13. http://d.old.wanfangdata.com.cn/Periodical/hygc201501001
ZUO Qihua, DOU Xiping, DUAN Zibing. Prospects of coastal engineering technology in China[J]. The Ocean Engineering, 2015, 33(1): 1-13. http://d.old.wanfangdata.com.cn/Periodical/hygc201501001
[3] 庄振业, 王永红, 包敏, 等.海滩养护过程和工程技术[J].中国海洋大学学报, 2009, 39(5): 1019-1024. doi: 10.3969/j.issn.1672-5174.2009.05.025
ZHUANG Zhenye, WANG Yonghong, BAO Min, et al. Beach nourishment process and engineering technology[J]. Periodical of Ocean University of China, 2009, 39(5): 1019-1024. doi: 10.3969/j.issn.1672-5174.2009.05.025
[4] 庄振业, 曹立华, 李兵, 等.我国海滩养护现状[J].海洋地质与第四纪地质, 2011, 31(3): 133-139. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=hydzydsjdz201103017
ZHUANG Zhenye, CAO Lihua, LI Bing, et al. An overview of beach nourishment in China[J]. Marine Geology and Quaternary Geology, 2011, 31(3): 133-139. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=hydzydsjdz201103017
[5] 吴建, 拾兵.近岸补沙养护海滩研究综述[J].海洋科学, 2011, 35(8): 108-112. http://qdhys.ijournal.cn/hykx/ch/reader/key_query.aspx
WU Jian, SHI Bing. A review of the shoreface nourishment for beach protection[J]. Marine Sciences, 2011, 35(8): 108-112. http://qdhys.ijournal.cn/hykx/ch/reader/key_query.aspx
[6] Climate Change Information Resources-New York Metropolitan Region (CCIR-NYC). What are the projected costs of climate change in the region's coastal communities and coastal environments?[Z]. CCIR-NYC, 2005: 1-2.
[7] Valverde H R, Trembanis A C, Pilkey O H. Summary of beach nourishment episodes on the U.S. East Coast Barrier Islands[J]. Journal of Coastal Research, 1999, 15(4): 1100-1118. doi: 10.1142/S0218127499001371
[8] Hanson H, Brampton A, Capobianco M, et al. Beach nourishment projects, practices, and objectives—a European overview[J]. Coastal Engineering, 2002, 47(2): 81-111. doi: 10.1016/S0378-3839(02)00122-9
[9] 刘修锦, 王永红, 杨燕雄, 等.海滩养护后剖面变化过程研究——以北戴河西海滩和中海滩为例[J].海洋地质前沿, 2013, 29(2): 53-61. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=hydzdt201302008
LIU Xiujin, WANG Yonghong, YANG Yanxiong, et al. Changes in beach profile morphology after nourishment——a case from western and middle Beidaihe beaches[J]. Marine Geology Frontiers, 2013, 29(2): 53-61. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=hydzdt201302008
[10] 刘修锦, 庄振业, 谢亚琼, 等.秦皇岛金梦湾海滩侵蚀和海滩养护[J].海洋地质前沿, 2014, 30(3): 71-79. http://d.old.wanfangdata.com.cn/Periodical/hydzdt201403009
LIU Xiujin, ZHAUNG Zhenye, XIE Yaqiong, et al. Beach erosion and beach nourishment of Jinmeng Bay Beach in Qinhuangdao[J]. Marine Geology Frontiers, 2014, 30(3): 71-79. http://d.old.wanfangdata.com.cn/Periodical/hydzdt201403009
[11] 雷刚, 刘根, 蔡锋.厦门岛会展中心海滩养护及其对我国海岸防护的启示[J].应用海洋学学报, 2013, 32(3): 305-315. doi: 10.3969/J.ISSN.2095-4972.2013.03.002
LEI Gang, LIU Gen, CAI Feng. Enlightenment to China's coastal protection from the coast beach nourishment at Huizhan Zhongxin of Xiamen Island[J]. Journal of Applied Oceanography, 2013, 32(3): 305-315. doi: 10.3969/J.ISSN.2095-4972.2013.03.002
[12] 匡翠萍, 单云驰, 顾杰, 等.海坛湾龙凤头海滩养护工程方案[J].同济大学学报:自然科学版, 2015, 43(5): 714-721. doi: 10.11908/j.issn.0253-374x.2015.05.010
KUANG Cuiping, SHAN Yunchi, GU Jie, et al. Beach nourishment in Longfengtou Beach of Haitan Bay[J]. Journal of Tongji University: Natural Science, 2015, 43(5): 714-721. doi: 10.11908/j.issn.0253-374x.2015.05.010
[13] 王中起, 韩志远, 严冰.秦皇岛海域水文泥沙特征分析[J].水道港口, 2010, 31(4): 247-252. doi: 10.3969/j.issn.1005-8443.2010.04.004
WANG Zhongqi, HAN Zhiyuan, YAN Bing. Hydrographic and sediment characteristics in Qinhuangdao sea area[J]. Journal of Waterway and Harbor, 2010, 31(4): 247-252. doi: 10.3969/j.issn.1005-8443.2010.04.004
[14] 尉建功, 冯秀丽, 林霖, 等.秦皇岛附近海域表层沉积物粒度分布特征及运移趋势分析[J].中国海洋大学学报, 2013, 43(7): 66-71. http://d.old.wanfangdata.com.cn/Periodical/qdhydxxb201307012
WEI Jiangong, FENG Xiuli, LIN Lin, et al. Grain-size characteristic of the sediments and transport patterns in Qinhuangdao offshore area[J]. Periodical of Ocean University of China, 2013, 43(7): 66-71. http://d.old.wanfangdata.com.cn/Periodical/qdhydxxb201307012
[15] 张彦龙.秦皇岛港附近海域潮汐、波浪和海流特征[J].海洋通报, 1997, 16(3): 21-27. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=QK199700250308
ZHANG Yanlong. Characteristics of tides, waters and currents in the sea area near Qinhuangdao Harbour[J]. Marine Science Bulletin, 1997, 16(3): 21-27. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=QK199700250308
[16] 郑冬梅, 王志斌, 张书颖, 等.渤海海冰的年际和年代际变化特征与机理[J].海洋学报, 2015, 37(6): 12-20. doi: 10.3969/j.issn.0253-4193.2015.06.002
ZHENG Dongmei, WANG Zhibin, ZHANG Shuying, et al. Interannual and interdecadal variations of the sea ice in Bohai Sea and its mechanisms[J]. Acta Oceanologica Sinica, 2015, 37(6): 12-20. doi: 10.3969/j.issn.0253-4193.2015.06.002
[17] 丰爱平, 夏东兴.海岸侵蚀灾情分级[J].海岸工程, 2003, 22(2): 60-66. doi: 10.3969/j.issn.1002-3682.2003.02.009
FENG Aiping, XIA Dongxing. Grading of coastal erosion disaster situation[J]. Coastal Engineering, 2003, 22(2): 60-66. doi: 10.3969/j.issn.1002-3682.2003.02.009
[18] 陈子燊.海滩剖面时空变化过程分析[J].海洋通报, 2000, 19(2): 42-48. doi: 10.3969/j.issn.1001-6392.2000.02.008
CHEN Zishen. Analysis on spatial and temporal processes of Beach profile variations[J]. Marine Science Bulletin, 2000, 19(2): 42-48. doi: 10.3969/j.issn.1001-6392.2000.02.008
[19] Kana T W, Mohan R K. Analysis of nourished profile stability following the fifth Hunting Island (SC) beach nourishment project[J]. Coastal Engineering, 1998, 33(2-3): 117-136. doi: 10.1016/S0378-3839(98)00005-2
[20] Dean R G. Beach Nourishment: Theory and Practice[M]. New Jersey: World Scientific, 2002.
[21] 王颖, 吴小根.海平面上升与海滩侵蚀[J].地理学报, 1995, 50(2): 118-127. doi: 10.3321/j.issn:0375-5444.1995.02.003
WANG Ying, WU Xiaogen. Sea level rise and beach response[J]. Acta Geographica Sinica, 1995, 50(2): 118-127. doi: 10.3321/j.issn:0375-5444.1995.02.003
[22] 蒋昌波, 伍志元, 陈杰, 等.波浪动力因素变化对沙质岸滩演变的影响[J].海洋学报, 2015, 37(3): 106-113. doi: 10.3969/j.issn.0253-4193.2015.03.011
JIANG Changbo, WU Zhiyuan, CHEN Jie, et al. Effects of wave dynamic factors on the evolution of sandy beach[J]. Acta Oceanologica Sinica, 2015, 37(3): 106-113. doi: 10.3969/j.issn.0253-4193.2015.03.011
[23] 陈子燊, 李志龙, 陈建耀, 等.常波况下前滨剖面地形动力过程分析[J].海洋通报, 2007, 26(3): 12-18. doi: 10.3969/j.issn.1001-6392.2007.03.002
CHEN Zishen, LI Zhilong, CHEN Jianyao, et al. Analysis on morphodynamic processes of foreshore profile under normal wave conditions[J]. Marine Science Bulletin, 2007, 26(3): 12-18. doi: 10.3969/j.issn.1001-6392.2007.03.002
[24] 陈子燊.海滩剖面形态与地形动态研究的进展[J].海洋通报, 1997, 16(1): 86-91. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=QK199700250293
CHEN Zishen. Progress in studies on the shapes and dynamics of beach profiles[J]. Marine Science Bulletin, 1997, 16(1): 86-91. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=QK199700250293
[25] 陈子燊.海南岛新海湾海滩地貌状态与海岸泥沙纵向运动特征[J].海洋与湖沼, 1993, 24(5): 467-476.
CHEN Zishen. Geomorphological types of beach and the characteristics of sediments longshore movement in arc-shaped bay of Xinhai Bay, Hainan Island[J]. Oceanologia et Limnologia Sinica, 1993, 24(5): 467-476.
[26] Thomas T, Phillips M R, Williams A T, et al. Medium timescale beach rotation; gale climate and offshore island influences[J]. Geomorphology, 2011, 135(1-2): 97-107. doi: 10.1016/j.geomorph.2011.08.002
[27] Silvester R. Coastal Engineering[M]. Amsterdam: Elsevier, 1974: 71-83.
[28] 李志龙, 陈子燊.岬间海湾平面平衡形态研究进展[J].海洋工程, 2006, 24(1): 155-160. doi: 10.3969/j.issn.1000-9620.2007.01.009
LI Zhilong, CHEN Zishen. Studies on the equilibrium shape of headland-bay[J]. The Ocean Engineering, 2006, 24(1): 155-160. doi: 10.3969/j.issn.1000-9620.2007.01.009
[29] 杨燕雄, 张甲波.静态平衡岬湾海岸理论及其在黄、渤海海岸的应用[J].海岸工程, 2007, 26(2): 38-46. doi: 10.3969/j.issn.1002-3682.2007.02.006
YANG Yanxiong, ZHANG Jiabo. Static equilibrium Headland-bay coast theory and its application to coasts of the Yellow and Bohai Seas[J]. Coastal Engineering, 2007, 26(2): 38-46. doi: 10.3969/j.issn.1002-3682.2007.02.006
-
