DISCOVERY OF PERMIAN-TRIASSIC AMMONOIDS IN THE CENTRAL UPLIFT OF THE SOUTH YELLOW SEA AND ITS GEOLOGICAL IMPLICATIONS
-
摘要:
大陆架科学钻探CSDP-2井，是南黄海中部隆起上的唯一深钻，是揭示中-古生代海相地层时代，恢复沉积和构造环境的基准井。菊石是二叠纪至三叠纪的重要古生物，在指示地层时代和恢复古地理环境方面，都具有重要价值。在CSDP-2井岩心中发现多块菊石化石，其中的两块化石具有重要意义。根据菊石形态特征，取自1 475.2 m岩心中的Roadoceras cf. sinense 时代被鉴定为二叠纪罗德阶(Roadian)—吴家坪阶(Wuchiapingian)，属于近20年来建立起来的菊石属Roadoceras，其古地理分布位于古赤道及双温区，此次发现的样品则来自华南北缘，拓展了该属的古地理分布范围。另外，在851.9 m处岩心中，发现了蛇菊石Ophiceratidae，其为早三叠世格里斯巴赫阶(Griesbachian)分子，非常接近三叠系的底部，为CSDP-2井二叠纪和三叠纪界线的划分提供了重要证据。上述菊石的发现，有助于厘定南黄海中部隆起二叠系-三叠系海相地层发育时代，恢复古地理环境，亦为南黄海进一步的沉积、构造和油气资源研究奠定重要基础。
Abstract:The Borehole CSDP-2 of the Continental Shelf Drilling Program (CSDP) is the only deep hole ever drilled on the central uplift of the South Yellow Sea (SYS). As a reference well, it is critical important to the dating of marine Paleo-Mesozoic deposits and reconstruction of the paleo-environmental pattern and paleo-tectonic settings of the SYS region. Ammonites are recognized as excellent index fossils for approaching the above objectives. So far, many ammonite fossils have been found in the core of CSDP-2, of which two, namely Roadoceras cf. sinense and Ophiceratidae, are specifically significant. The fossil of Roadoceras cf. sinense was discovered at the depth of 1475.2 meters. It is an index fossil distributed from Late Roadian to Wuchiapingian temporally and in the palaeoequatorial and bi-temperate regions spatially. The new finding of Roadocerascf. sinense from CSDP-2 extended the distribution area of this genus to the further north. On the other hand, Ophiceratidae, which is found at a depth of 851.9 meters and belongs to Griesbachian, is very close to the bottom of Triassic, and valuable for study of Permian and Triassic boundary. The discovery of the ammonites is important for confirming the stratigraphic age of the Permian and Triassic marine formations on the central uplift of the SYS region, recovering the paleo - environmental pattern, and providing the foundation for the future study of sedimentation, tectonic and petroleum resources.
-
Key words:
- South Yellow Sea /
- Continental Shelf Drilling Program /
- Ammonoid /
- Wuchiapingian /
- Griesbachian
-
-
[1] 姚永坚, 冯志强, 郝天珧, 等.对南黄海盆地构造层特征及含油气性的新认识[J].地学前缘, 2008, 15(6): 232-240. doi: 10.3321/j.issn:1005-2321.2008.06.030
YAO Yongjian, FENG Zhiqiang, HAO Tianyao, et al. A new understanding of the structural layers in the South Yellow Sea Basin and their hydrocarbon-bearing characteristics[J]. Earth Science Frontiers, 2008, 15(6): 232-240. doi: 10.3321/j.issn:1005-2321.2008.06.030
[2] 祁江豪, 温珍河, 张训华, 等.南黄海地区与上扬子地区海相中—古生界岩性地层对比[J].海洋地质与第四纪地质, 2013, 33(1): 109-119.
QI Jianghao, WEN Zhenhe, ZHANG Xunhua, et al. Lithostratigraphic correlation of Mesozoic and Palaeozoic Marine strata between South Yellow Sea and Upper Yangtze Region[J]. Marine Geology and Quaternary Geology, 2013, 33(1): 109-119.
[3] 刘光鼎.中国油气资源企盼二次创业[J].地球物理学进展, 2001, 16(4): 1-3. doi: 10.3969/j.issn.1004-2903.2001.04.001
LIU Guangding. The second exploitation of the oil and gas resources in China[J]. Progress in Geophysics, 2001, 16(4): 1-3. doi: 10.3969/j.issn.1004-2903.2001.04.001
[4] 牟林.中国下、中二叠统界线附近菊石生物群及其生物地层意义[J].古生物学报, 2011, 50(4): 439-449. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=gswxb201104003
MU Lin. Ammonoid Faunas around the Early and Middle Permian boundary in china and their biostratigraphic implications[J]. Acta Palaeontologica Sinica, 2011, 50(4): 439-449. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=gswxb201104003
[5] Leonova T B. Permian ammonoids: biostratigraphic, biogeographical, and ecological analysis[J]. Paleontological Journal, 2011, 45(10): 1206-1312. doi: 10.1134/S0031030111100029
[6] Zhou Z R. Several problems on the Early Permian ammonoids from South China[J]. Palaeontologia Cathayana, 1985(2): 179-210. http://ir.nigpas.ac.cn/handle/332004/5878
[7] Chao J. Lower Triassic Ammonoids from Western Kwangsi, China[M]. Beijing: Science Press, 1959.
[8] Brayard A, Bucher H. Smithian (Early Triassic) ammonoid faunas from northwestern Guangxi (South China): taxonomy and biochronology[J]. Fossils and Strata, 2008, 55: 1-179. http://d.old.wanfangdata.com.cn/NSTLQK/NSTL_QKJJ0214759408/
[9] 胡芬, 江东辉, 周兴海.南黄海盆地中、古生界油气地质条件研究[J].海洋石油, 2012, 32(2): 9-15. doi: 10.3969/j.issn.1008-2336.2012.02.009
HU Fen, JIANG Donghui, ZHOU Xinghai. Study on the petroleum geologic conditions in Mesozoic-Paleozoic Strata in the South Yellow Sea basin[J]. Offshore Oil, 2012, 32(2): 9-15. doi: 10.3969/j.issn.1008-2336.2012.02.009
[10] 杨艳秋, 李刚, 易春燕.南黄海盆地海相地层地震反射特征及地震层序地质时代[J].东北石油大学学报, 2015, 39(3): 50-59, 124. doi: 10.3969/j.issn.2095-4107.2015.03.007
YANG Yanqiu, LI Gang, YI Chunyan. Characteristics of seismic reflection and geological ages of seismic sequences for marine strata in the South Yellow Sea basin[J]. Journal of Northeast Petroleum University, 2015, 39(3): 50-59, 124. doi: 10.3969/j.issn.2095-4107.2015.03.007
[11] 杨长清, 董贺平, 李刚.南黄海盆地中部隆起的形成与演化[J].海洋地质前沿, 2014, 30(7): 17-21, 33. http://d.old.wanfangdata.com.cn/Periodical/hydzdt201407003
YANG Changqing, DONG Heping, LI Gang. Formation and tectonic evolution of the Central Uplift of the South Yellow Sea basin[J]. Marine Geology Frontiers, 2014, 30(7): 17-21, 33. http://d.old.wanfangdata.com.cn/Periodical/hydzdt201407003
[12] 张训华, 杨金玉, 李刚, 等.南黄海盆地基底及海相中、古生界地层分布特征[J].地球物理学报, 2014, 57(12): 4041-4051. doi: 10.6038/cjg20141216
ZHANG Xunhua, YANG Jinyu, LI Gang, et al. Basement structure and distribution of Mesozoic-Paleozoic marine strata in the South Yellow Sea basin[J]. Chinese Journal of Geophysics, 2014, 57(12): 4041-4051. doi: 10.6038/cjg20141216
[13] 侯方辉, 田振兴, 张训华, 等.南黄海盆地两条地震剖面的重磁数据联合反演效果[J].石油地球物理勘探, 2012, 47(5): 808-814. http://www.ogp-cn.com.cn/CN/article/searchArticle.do
HOU Fanghui, TIAN Zhenxing, ZHANG Xunhua, et al. Joint inversion of gravity, magnetic and seismic data of the South Yellow Sea basin[J]. Oil Geophysical Prospecting, 2012, 47(5): 808-814. http://www.ogp-cn.com.cn/CN/article/searchArticle.do
[14] 李强, 温珍河.南黄海盆地成因机制及其构造意义[J].海洋地质前沿, 2014, 30(10): 14-17. http://d.old.wanfangdata.com.cn/Periodical/hydzdt201410003
LI Qiang, WEN Zhenhe. Origin of the South Yellow Sea basin and its tectonic implication[J]. Marine Geology Frontiers, 2014, 30(10): 14-17. http://d.old.wanfangdata.com.cn/Periodical/hydzdt201410003
[15] 冯志强, 陈春峰, 姚永坚, 等.南黄海北部前陆盆地的构造演化与油气突破[J].地学前缘, 2008, 15(6): 219-231. doi: 10.3321/j.issn:1005-2321.2008.06.029
FENG Zhiqiang, CHEN Chunfeng, YAO Yongjian, et al. Tectonic evolution and exploration target of the northern foreland basin of the South Yellow Sea[J]. Earth Science Frontiers, 2008, 15(6): 219-231. doi: 10.3321/j.issn:1005-2321.2008.06.029
[16] 高顺莉, 谭思哲, 侯凯文, 等.南黄海海域侏罗系分布与构造意义[J].海洋地质前沿, 2015, 31(4): 7-12. doi: 10.16028/j.1009-2722.2015.04002
GAO Shunli, TAN Sizhe, HOU Kaiwen, et al. Distribution pattern of the Jurassic in the South Yellow Sea and its tectonic implications[J]. Marine Geology Frontiers, 2015, 31(4): 7-12. doi: 10.16028/j.1009-2722.2015.04002
[17] 徐学思.江苏省岩石地层[M].北京:中国地质大学出版社, 1997.
XU Xuesi. Stratigraphy (Lithostratic) of Jiangsu Province[M]. Beijing: China University of Geosciences Press, 1997.
[18] B?se E. The Permo-Carboniferous ammonoids of the Glass Mountains, West Texas, and their stratigraphic significance[J]. University of Texas Bulletin, 1917, 1762(5): 1-241. doi: 10.1086/622647
[19] Miller A K, Furnish W M. Permian ammonoids of the Guadalupe Mountain region and adjacent areas[J]. GSA Special Papers, 1940, 26: 1-238.
[20] Plummer F B, Scott G. Upper Paleozoic ammonites in Texas[J]. The Geology of Texas Bulletin of Texas University, 1937, 3701(3): 1-516.
[21] Ruzhencev V E. Late Permian ammonoids in the Russian Far East[J]. Palaeontology Zhurnal, 1976, 3: 36-50.
[22] Kotlyar G V, Zahkarov Y D, Popeko L L, et al. Layers with Timorites in East Asia[J]. Geology of the Pacific Ocean, 1999, 14: 361-380.
[23] Zhou Z R. Early Permian ammonite fauna from southeastern Hunan[C]//Collections of Postgraduate Theses. Nanjing: Jiangsu Science and Technology Publisher, 1987: 285-348.
[24] Mei S L, Jin Y G, Wardlaw B R. Conodont succession of the Guadalupian-Lopingian Boundary strata in Laibin of Guangxi, China and west Texas, USA[J]. Palaeoworld, 1998, 9: 53-76.
[25] Henderson C M, Mei S L, Wardlaw B R. New conodont definitions at the Guadalupian-Lopingian boundary[C]//Hills L V, Henderson C M, Bamber E W. Carboniferous and Permian of the World. Canadian Society of Petroleum Geologist Memoir, 2002, 19: 725-735.
[26] Jin Y G, Henderson C M, Wardlaw B R, et al. Proposal for the global stratotype section and point (GSSP) for the Guadalupian-Lopingian boundary[J]. Permophiles, 2001, 39: 32-42.
[27] Jin Y G, Wardlaw B R, Glenister B F, et al. Permian chronostratigraphic subdivisions[J]. Episodes, 1997, 20(1): 10-15. doi: 10.18814/epiiugs/1997/v20i1/003
[28] Jin Y G, Shang Q H, Wang X D, et al. Chronostratigraphic subdivision and correlation of the Permian in China[J]. Acta Geologica Sinica, 1999, 73(2): 127-138. doi: 10.1111/j.1755-6724.1999.tb00820.x
[29] Haniel C A. Die Cephalopoden der Days von Timor[M]//Wanner J. Paläontologie von Timor. Stuttgart: E. Schweizerbart'sche Verlagsbuchhandlung, 1915: 1-153.
[30] Liang X L. New material of Permian ammonoids with discussion on the origin, migration of Araxoceratidae and the horizon of the Paratirolites[J]. Acta Palaeontologica Sinica, 1983, 22(6): 606-615.
[31] Ehiro M. Ammonoid biostratigraphy of the Middle Permian in the South Kitakami Belt, Japan, and correlation with the reference sections in the Tethyan region and North America[J]. Proceedings of the Royal Society of Victoria, 1998, 110(1-2): 147-156.
[32] Spinosa C, Furnish W M, Glenister B F. Araxoceratidae, Upper Permian ammonoids, from the Western Hemisphere[J]. Journal of Paleontology, 1970, 44(4): 730-736. doi: 10.2307/1302664
[33] Hayasaka I. Younger Paleozoic cephalopods from the Kitakami Mountains, Japan[J]. Journal of the Faculty of Science, Hokkaido University, 1954, 8(4): 361-374.
[34] Ehiro M, Shimoyama D, Murata M. Some Permian cyclolobacear from the Southern Kitakami Massif, Northeast Japan[J]. Transactions and Proceedings of the Palaeontological Society of Japan New, 1986, 142.
[35] Zakharov Y D, Pavlov A M. Permskie cephalopody Primorya I problema zonalnogo raschleneniya Permi Teticheskoj obasti (Permian cephalopods of Primorye region and the problem of Permian zonal stratigraphy in Tethys)[M]//Zakharov Y D, Onoperienko Y I. Korrelyatsiya Permo-Triasovykh otlozhenij vostoka SSSR (Correlation of Permo-Triasssic sediments of East USSR). Acad. Vladivostok: Naulk SSSR Dalneostachnyi Nauchnyi Tscentr, 1986: 5-32.
[36] Shen S Z, Mu L, Zakharov Y D. Roadoceras (Permian Ammonoidea) from the Qubuerga Formation in the Mt. Everest Area in Southern Tibet[J]. Gondwana Research, 2004, 7(3): 863-869. doi: 10.1016/S1342-937X(05)71070-4
[37] Kiparisova L D, Popov Y N. Subdivision of the Lower series of the Triassic System into stages[J]. Doklady Akademiya Nauk USSR Seriya Geologicheskaya, 1956, 109(4): 842-845.
[38] Kiparisova L D, Popov Y N. The project of subdivision of the Lower Triassic into stages[C]//XXII International Geological Congress, Reports of Soviet Geologists. 1964, 16: 91-99.
[39] Diener C. Die marinen Reiche der Triasperiode[J]. Denkschriften der Kaiserlichen Akademie der Wissenschaften, Mathematisch-naturwissenschaftliche Klasse, 1916, 92: 405-549.
[40] Tozer E T. Triassic Ammonoidea: classification, evolution and relationship with Permian and Jurassic forms[M]//House M R, Senior J R. The Ammonoidea. Systematics Association Special. London: Academic Press, 1981, 18: 66-100.
[41] Dagys A S. Major features of the geographic differentiation of Triassic ammonoids[M]//Wiedmann J, Kullmann J. Cephalopods present and past. E. Stuttgart: Schweizerbart'sche Verlagshandlung, 1988: 341-349.
[42] Brayard A, Escarguel G, Bucher H. The biogeography of Early Triassic ammonoid faunas: clusters, gradients, and networks[J]. Geobios, 2007, 40(6): 749-765. doi: 10.1016/j.geobios.2007.06.002
[43] Griesbach C L. Paleontological notes on the Lower Trias of the Himalayas[J]. Records of the Geological Survey of India, 1880, 13: 94-113.
[44] Mojsisovics E, Waagen W H, Diener C. Entwurf einer Gliederung der pelagischen Sediments des Trias-Systems[J]. Sitzungsberichte Akademie Wissenschaft Wien, Mathematische-naturwissenschaftliche Klasse, 1985, 104: 1271-1302.
[45] Orchard M J, Tozer E T. Triassic conodont biochronology and intercalibration with the Canadian ammonoid sequence[J]. Albertiana, 1998, 20: 33-44.
[46] Orchard M J, Tozer E T. Triassic conodont biochronology, its intercalibration with the ammonoid standard, and a biostratigraphic summary for the western Canada sedimentary basin[J]. Canadian Society of Petroleum Geologists Bulletin, 1997, 45(4): 675-692.
-
