LITHOFACIES OF MUDSTONE AND SHALE DEPOSITS OF THE ES3Z-ES4S FORMATION IN DONGYING SAG AND THEIR DEPOSITIONAL ENVIRONMENT
-
摘要:
泥页岩的沉积环境控制了矿物、有机质特征和岩相类型。开展东营凹陷古近系沙河街组泥页岩薄片、X衍射、热解和微量元素等分析，研究各层段元素地球化学特征和岩相类型，探索沉积环境变化与岩相组合的响应关系。研究表明沙河街组沙三下-沙四上亚段泥页岩包含了均匀块状泥岩、细纹层状页岩、宽纹层状页岩、断续纹层状页岩和含石膏构造泥岩5种岩相类型。各层段沉积环境变化明显，沙四纯下次亚段沉积时期水体盐度最高，随着湖泊淡化，水体盐度降低，至沙三下亚段已演化为盐度较低且波动稳定的湖泊环境。岩石类型与沉积环境关系密切：沙四纯下次亚段浅水高盐度条件下沉积了石膏构造泥岩和少量均匀块状泥岩；沙四纯上底部高盐度水体加深的环境下沉积宽纹层页岩和少量细纹层页岩；沙四纯上次亚段上部盐度降低环境沉积均匀块状泥岩和少量宽纹层页岩；沙三下亚段深水安静且盐度较低的环境沉积细纹层页岩，充分展现了沉积环境对岩相的控制作用。因此，关注泥页岩沉积环境演变与岩相成因，探讨岩石与沉积环境响应关系，能够为非常规油气勘探提供新的思路。
Abstract:The features of mineralogy, organic matter and lithofacies of mudstones and shale are controlled by depositional environment. An amount of samples selected from the Shahejie Formation in the Dongying depression are studied by the authors by means of microscope, X-ray diffraction, pyrolytic analysis and chemical analysis. The results are used to establish the relationship between the element geochemistry and types of lithofacies, upon which the relationship between depositional environment and lithofacies is further revealed. The lithofacies of mudstone/shale includes thin laminated shale, discontinuous laminated shale, thick laminated shale, homogenous massive mudstone and the mudstone with anhydrite-relict. Their depositional environments are obviously different. During the time while the sub-member of Es4cx-Es3x was deposited, the lake evolved from deep to shallow and from saline to fresh, and was in an anoxic environment during the whole period. There is a close relationship between lithology and environment. In the early Es4c, it was a shallow and salty lake with deposition of anhydrite-relict mudstone and homogeneous massive mudstone; the upper Es4c is mainly consisting of laminated shale at the bottom and homogeneous massive mudstone on the top, as the lake changed from a salty to a brackish lake; the lower Es3 represents a deep fresh lake, rich in laminated shale. In conclusion, both the rock types and their hydrocarbon potentials are controlled by depositional environment. In this regard, further research is suggested on the relationship between lithofacies of mudstone/shale and their depositional environment.
-
-
表 1 各构造类型泥页岩矿物与热解特征
Table 1. Characteristics of mineral and pyrolysis of samples
沙三下亚段 沙四上亚段 沙四纯上 沙四纯下 矿物特征 黏土矿物/% 21.2 20. 1 30.2 碳酸盐矿物/% 43.3 49.7 33.4 碎屑矿物/% 27.9 26.3 27.2 硬石膏/% 0.0 0.1 5.0 热解特征 TOC/% 3.92 3.34 2.13 HI/(mg/g) 513 450 213 Ol/(mg/g） 39 47 121 Tmax/℃ 439 439 426
下载: 导出CSV
表 2 泥页岩岩相特征与成因
Table 2. Characteristics and origin of mudstones/shales
岩相类型 纹层类型 矿物类型 有机质特征 成因分析 沉积作用 细纹层页岩 亮色泥质纹层 集黏土矿物、少量碎屑矿物 生物勃发时期产生的富有机质纹层 物理-化学作用沉淀 静水生物勃发时期形成的岩石 暗色富有机质纹层 富集黏土矿物 化学-生物作用沉淀 亮晶方解石脉 亮晶方解石 成岩作用成因 宽纹层页岩 泥质纹层 富集黏土矿物、少量碎屑矿物 砂泥质纹层中微小植物残片；
碳酸盐纹层中浮游藻微体化石物理一化学作用沉淀 水体安静且矿化度较高环境下沉积形成的岩石 少量粉砂质纹层 富集碎屑矿物 少量富有机质纹层 富黏土矿物 生物作用诱发的沉淀 隐晶质碳酸盐纹层 隐晶质方解石 断续纹层页岩 碳质纹层 与黏土矿物和碎屑矿物共生 粪球粒、藻团块及微小的植物残片 机械一生物作用沉淀 水体相对较浅，浮游生物勃发时期形成的岩石 泥质基底 富集黏土矿物 化学作用沉淀 透镜状隐晶质碳酸盐 隐晶质方解石 生物作用诱发的沉淀 均匀块状泥岩 泥灰质基底 黏土矿物与隐晶质碳酸盐 微小的植物残片 生物一化学作用沉淀 水体相对动荡环境下形成的岩石 含碎屑块状泥岩 分散状碎屑颗粒 石英、长石颗粒 红色高等植物残片 机械作用主导的沉淀 水体较浅环境下，外源物质输入丰富时期形成 泥质基底 富集黏土矿物 生物作用诱发的沉淀 少量碳酸盐斑块 隐晶质碳酸盐 含石膏构造泥岩 硬石膏脉 硬石膏 黑色不透明颗粒 蒸发环境机械一化学作用沉淀 蒸发深缩环境 泥质基底 富集黏土矿物
下载: 导出CSV
-
[1] Schieber J, Bose P K, Eriksson P G, et al. Atlas of Microbial Mat Features Preserved within the Siliciclastic Rock Record[M]. Amsterdam: Elsevier, 2007.
[2] Schieber J, Southard J B, Schimmelmann A. Lenticular shale fabrics resulting from intermittent erosion of water-rich muds—interpreting the rock record in the light of recent flume experiments[J]. Journal of Sedimentary Research, 2010, 80(1): 119-128. doi: 10.2110/jsr.2010.005
[3] 刘传联, 徐金鲤, 汪品先.藻类勃发——湖相油源岩形成的一种重要机制[J].地质论评, 2001, 47(2): 207-210. doi: 10.3321/j.issn:0371-5736.2001.02.015
LIU Chuanlian, XU Jinli, WANG Pinxian. Algal blooms: The primary mechanism in the formation of lacustrine petroleum source rocks[J]. Geological Review, 2001, 47(2): 207-210. doi: 10.3321/j.issn:0371-5736.2001.02.015
[4] 王冠民, 任拥军, 钟建华, 等.济阳坳陷古近系黑色页岩中纹层状方解石脉的成因探讨[J].地质学报, 2005, 79(6): 834-838. doi: 10.3321/j.issn:0001-5717.2005.06.012
WANG Guanmin, REN Yongjun, ZHONG Jianhua, et al. Genetic analysis on lamellar calcite veins in Paleogene black shale of the Jiyang Depression[J]. Acta Geologica Sinica, 2005, 79(6): 834-838. doi: 10.3321/j.issn:0001-5717.2005.06.012
[5] 张林晔, 李政, 朱日房, 等.济阳坳陷古近系存在页岩气资源的可能性[J].天然气工业, 2008, 28(12): 26-29. doi: 10.3787/j.issn.1000-0976.2008.12.006
ZHANG Linye, LI Zheng, ZHU Rifang, et al. Resource potential of shale gas in Paleogene in Jiyang depression[J]. Natural Gas Industry, 2008, 28(12): 26-29. doi: 10.3787/j.issn.1000-0976.2008.12.006
[6] Wang B H, Qian K. Research and Practice of Geology in Shengli Oilfield[M]. Dongying: Petroleum University Press, 1992.
[7] 张林晔, 孔祥星, 张春荣, 等.济阳坳陷下第三系优质烃源岩的发育及其意义[J].地球化学, 2003, 32(1): 35-42. doi: 10.3321/j.issn:0379-1726.2003.01.005
ZHANG Linye, KONG Xiangxing, ZHANG Chunrong, et al. High-quality oil-prone source rocks in Jiyang Depression[J]. Geochimica, 2003, 32(1): 35-42. doi: 10.3321/j.issn:0379-1726.2003.01.005
[8] 侯读杰, 张善文, 肖建新, 等.济阳坳陷优质烃源岩特征与隐蔽油气藏的关系分析[J].地学前缘, 2008, 15(2): 137-146. doi: 10.3321/j.issn:1005-2321.2008.02.016
HOU Dujie, ZHANG Shanwen, XIAO Jianxin, et al. The excellent source rocks and accumulation of stratigraphic and lithologic traps in the Jiyang Depression, Bohai Bay Basin, China[J]. Earth Science Frontiers, 2008, 15(2): 137-146. doi: 10.3321/j.issn:1005-2321.2008.02.016
[9] 李丕龙.济阳坳陷"富集有机质"烃源岩及其资源潜力[J].地学前缘, 2004, 11(1): 317-322. doi: 10.3321/j.issn:1005-2321.2004.01.030
LI Pilong. The organic-rich hydrocarbon source rocks and their resource potentials in Jiyang Depression[J]. Earth Science Frontiers, 2004, 11(1): 317-322. doi: 10.3321/j.issn:1005-2321.2004.01.030
[10] 朱光有, 金强, 张水昌, 等.济阳坳陷东营凹陷古近系沙河街组深湖相油页岩的特征及成因[J].古地理学报, 2005, 7(1): 59-69. doi: 10.3969/j.issn.1671-1505.2005.01.006
ZHU Guangyou, JIN Qiang, ZHANG Shuichang, et al. Characteristics and origin of deep lake oil shale of the Shahejie Formation of Paleogene in Dongying sag, Jiyang depression[J]. Journal of Palaeogeography, 2005, 7(1): 59-69. doi: 10.3969/j.issn.1671-1505.2005.01.006
[11] 朱光有, 金强, 周建林.东营凹陷旋回式深湖相烃源岩研究[J].地质科学, 2003, 38(2): 254-262. doi: 10.3321/j.issn:0563-5020.2003.02.012
ZHU Guangyou, JIN Qiang, ZHOU Jianlin. Source rock characters of cyclic deep-lake facies in the Dongying Depression[J]. Chinese Journal of Geology, 2003, 38(2): 254-262. doi: 10.3321/j.issn:0563-5020.2003.02.012
[12] 姜福杰, 庞雄奇, 姜振学, 等.东营凹陷沙四上亚段烃源岩排烃特征及潜力评价[J].地质科技情报, 2007, 26(2): 69-74. doi: 10.3969/j.issn.1000-7849.2007.02.013
JIANG Fujie, PANG Xiongqi, JIANG Zhenxue, et al. Hydrocarbon-expulsion characters and the potential resource evaluation of hydrocarbon source rocks from the Upper Section of 4th member of Shahejie Formation in Dongying Depression[J]. Geological Science and Technology Information, 2007, 26(2): 69-74. doi: 10.3969/j.issn.1000-7849.2007.02.013
[13] 蔡希源.湖相烃源岩生排烃机制及生排烃效率差异性——以渤海湾盆地东营凹陷为例[J].石油与天然气地质, 2012, 33(3): 329-334, 345. doi: 10.11743/ogg20120301
CAI Xiyuan. Hydrocarbon generation-expulsion mechanisms and efficiencies of lacustrine source rocks: A case study from the Dongying sag, Bohai Bay Basin[J]. Oil and Gas Geology, 2012, 33(3): 329-334, 345. doi: 10.11743/ogg20120301
[14] 张海峰, 刘庆, 张林晔, 等.山东东营凹陷古近系沙河街组湖盆演化及烃源岩赋存相带[J].古地理学报, 2005, 7(3): 383-397. doi: 10.3969/j.issn.1671-1505.2005.03.009
ZHANG Haifeng, LIU Qing, ZHANG Linye, et al. Lacustrine basin evolution and favorable sedimentary facies belt for source rocks abounding in the Shahejie formation of Paleogene in Dongying Sag, Shandong Province[J]. Journal of Palaeogeography, 2005, 7(3): 383-397. doi: 10.3969/j.issn.1671-1505.2005.03.009
[15] 曾翔, 蔡进功, 董哲, 等.泥页岩沉积特征与生烃能力——以东营凹陷沙河街组三段中亚段-沙河街组四段上亚段为例[J].石油学报, 2017, 38(1): 31-43. doi: 10.7623/syxb201701004
ZENG Xiang, CAI Jingong, DONG Zhe, et al. Sedimentary characteristics and hydrocarbon generation potential of mudstone and shale: A case study of Middle Submember of Member 3 and Upper Submember of Member 4 in Shahejie Formation in Dongying sag[J]. Acta Petrolei Sinica, 2017, 38(1): 31-43. doi: 10.7623/syxb201701004
[16] 王爱华.不同形态锶钡比的沉积环境判别效果比较[J].沉积学报, 1996, 14(4): 168-173. CNKI:SUN:CJXB.0.1996-04-022
WANG Aihua. Discriminant effect of sedimentary environment by the Sr/Ba ratio of different exising forms[J]. Acta Sedimentologica Sinica, 1996, 14(4): 168-173. CNKI:SUN:CJXB.0.1996-04-022
[17] 史忠生, 陈开远, 史军, 等.运用锶钡比判定沉积环境的可行性分析[J].断块油气田, 2003, 10(2): 12-16. doi: 10.3969/j.issn.1005-8907.2003.02.004
SHI Zhongsheng, CHEN Kaiyuan, SHI Jun, et al. Feasibility analysis of the application of the ratio of Strontium to Barium on the identifying sedimentary environment[J]. Fault-Block Oil & Gas Field, 2003, 10(2): 12-16. doi: 10.3969/j.issn.1005-8907.2003.02.004
[18] Abanda P A, Hannigan R E. Effect of diagenesis on trace element partitioning in shales[J]. Chemical Geology, 2006, 230(1-2): 42-59. doi: 10.1016/j.chemgeo.2005.11.011
[19] Tribovillard N, Algeo T J, Lyons T, et al. Trace metals as paleoredox and paleoproductivity proxies: An update[J]. Chemical Geology, 2006, 232(1-2): 12-32. doi: 10.1016/j.chemgeo.2006.02.012
[20] Dean W E, Gardner J V, Piper D Z. Inorganic geochemical indicators of glacial-interglacial changes in productivity and anoxia on the California continental margin[J]. Geochimica et Cosmochimica Acta, 1997, 61(21): 4507-4518. doi: 10.1016/S0016-7037(97)00237-8
[21] 乔锦琪, 刘洛夫, 尚晓庆, 等.泥页岩中微量元素V、Ni、V/Ni与有机质丰度及成岩演化关系研究——以准噶尔盆地阜康凹陷为例[J].矿物岩石地球化学通报, 2016, 35(4): 756-768. doi: 10.3969/j.issn.1007-2802.2016.04.016
QIAO Jinqi, LIU Luofu, SHANG Xiaoqing, et al. The relationship between V, Ni or V/Ni ratio and each of organic matter abundance and diagenetic evolution stages in shales: taking the shales in Fukang Sag of Junggar Basin for example[J]. Bulletin of Mineralogy, Petrology and Geochemistry, 2016, 35(4): 756-768. doi: 10.3969/j.issn.1007-2802.2016.04.016
-
