摘要:
粒度是第四纪古气候与古环境重建的常用替代指标，目前通常采用Mastersizer2000激光粒度仪进行分析，该测试仪器优点是速度快、精度高、重复性好，缺点是进样过程未实现定量化，对部分沉积样品的分析结果出现一定的随机性和不确定性，分析结果易产生人为误差。为探究样品量和进样方法对测试结果可能造成的影响，本研究选取6类代表性第四纪松散沉积物，预处理后分别采用倾倒法、吸管法及定量进样法进行多次重复实验。结果显示：粒度组分越单一，不同进样方法造成的结果误差越小；如果沉积物含有多个粒度组分，而预处理样品量过多，倾倒法容易造成粒度结果偏细，吸管法往往造成实验结果偏粗，定量进样法实验结果居于前两者之间。采用烧失量法计算沉积物中碳酸盐、有机质含量，结合马尔文激光粒度仪测试原理及多次定量重复实验结果，计算了一次实验所需样品量，发现其与中值粒径和碳酸盐、有机质（合称杂质）含量呈线性正相关。根据该线性关系式，在分析第四纪沉积物中值粒径范围及杂质含量的前提下，可计算一次测试所需样品量，将全部预处理后样品倒入测试烧杯中，可有效避免样品量和进样方法对样品粒度实验结果造成的误差。
Abstract:Grain size is a proxy commonly used for Quaternary paleoclimate and paleoenvironment reconstruction. The Mastersizer 2000 laser analyzer is widely adopted to measure the grain size. The facility is advantaged by fast speed, high precision and good repeatability. However, the sampling introduction of it is not quantified and there may occur great randomness and uncertainty prone to human errors. In order to study the possible influences of sample amount and sample introduction methods on the test results, six types of representative Quaternary sediments were selected for repeated experiments, respectively with methods of dumping, pipette and quota sample introduction after pretreatment. The results show that the more uniform the grain size component, the smaller the difference in various sample introduction methods. If the sediment contained multiple types of grain size components and the pretreated sample amount was much enough, the grain size result of the dumping method was prone to be finer, while that of the pipette method was often coarser, and the quota sample introduction method resulted in between. Loss-of-ignition was used to calculate the content of carbonate and organic matter in the sediments. Upon the principle of the Mastersizer 2000 laser grain size analyzer and the results of repeated quantification experiments, we calculate the sample amount needed for one test. It is found that the needed amount has positive linear correlation with median grain size and impurity content. Afterwards the linear relation was calculated. Based on the universal linear relation, the median diameter range and the content of carbonate and organic matter and other impurities in the Quaternary sediments, the sample amount needed for one test could be calculated. Pouring all the pretreated samples into the test beaker could effectively avoid the unknown impacts on experimental results caused by sample amount and sample introduction methods.
-
Key words:
- Quaternary sediments /
- grain size /
- sample amount /
- sampling method /
- quantitative experiment /
- MS2000 laser analyzer
-
-
表 1 三轮实验砂含量及中值粒径标准偏差
Table 1. Standard deviation of the median grain size and sand contents of the three rounds of experiments
沉积物类型 砂含量标准偏差/% 中值粒径标准偏差/μm 第一轮实验 第二轮实验 第三轮实验 第一轮实验 第二轮实验 第三轮实验 深湖相 0.66 − 0.43 1.33 − 0.40 黄土 0.54 0.40 0.32 0.48 0.85 0.49 河流相 22.79 0.24 0.00 103.16 2.28 1.60 浅海相 44.26 11.46 3.80 142.57 100.71 2.22 风成沙 34.70 2.09 8.55 64.70 3.99 19.42 三角洲相 31.76 5.24 0.84 66.23 24.72 3.70
下载: 导出CSV
表 2 第三轮实验数据和测试结果
Table 2. Results of the third round of experiments
沉积物类型 样品量/g 溶剂量/mL 遮光度/% 中值粒径/μm 砂含量/% 系数a 深湖相 0.12 1 000 10.83 7.55 1.60 17.49 0.17 1 000 14.22 8.27 1.16 17.24 0.24 1 000 19.98 7.60 2.01 17.59 黄土 0.18 1 000 10.48 14.11 2.60 15.40 0.29 1 000 16.48 13.97 3.20 15.44 0.36 1 000 20.37 13.20 2.70 15.71 河流相 4.11 1 000 9.61 279.33 100 7.22 6.21 1 000 12.52 276.18 100 7.49 8.22 1 000 17.09 277.31 100 7.42 浅海相 0.49 1 000 12.23 35.95 53.64 12.58 0.71 1 000 17.67 38.94 47.69 12.23 0.99 1 000 20.86 34.61 46.55 12.98 风成沙 0.42 1 000 10.94 85.52 59.94 8.80 0.62 1 000 14.78 68.48 52.29 9.90 0.84 1 000 25.92 46.78 42.88 11.16 三角洲相 0.50 1 000 11.64 92.61 55.11 8.59 0.75 1 000 16.63 85.75 53.64 9.00 1.08 1 000 24.30 86.83 53.67 8.93 注：a为等式系数，后文介绍。
下载: 导出CSV
表 3 6类沉积物烧失量数据及结果
Table 3. Results of loss of ignition of the 6 kinds of sediments
样品类型 M1/g M2/g M3/g 有机质含量/% M4/g 碳酸盐含量/% 深湖相 12.39 12.67 12.66 3.27 12.65 2.18 黄土 12.19 12.48 12.47 3.69 12.46 4.70 河流相 12.31 12.72 12.72 0.00 12.72 0.49 浅海相 12.45 12.77 12.76 3.22 12.74 4.18 风成沙 12.58 12.95 12.93 3.51 12.93 1.35 三角洲相 12.44 12.77 12.76 3.10 12.75 3.10
下载: 导出CSV
-
[1] 舒培仙, 李保生, 牛东风, 等. 毛乌素沙漠东南缘滴哨沟湾剖面DGS1层段粒度特征及其指示的全新世气候变化[J]. 地理科学, 2016, 36(3):448-457
SHU Peixian, LI Baosheng, NIU Dongfeng, et al. Climate variations recorded by the grain-size from the DGS1 segment in the Southeast of China’s Mu Us Desert During the Holocene [J]. Scientia Geographica Sinica, 2016, 36(3): 448-457.
[2] Újvári G, Kok J F, Varga G, et al. The physics of wind-blown loess: implications for grain size proxy interpretations in Quaternary paleoclimate studies [J]. Earth-Science Reviews, 2016, 154: 247-278. doi: 10.1016/j.earscirev.2016.01.006
[3] 孙华杰, 臧淑英, 孙德尧, 等. 呼伦湖沉积物粒度特征及其环境指示意义[J]. 地理科学, 2018, 38(9):1570-1578
SUN Huajie, ZANG Shuying, SUN Deyao, et al. Grain-size characteristics and their environmental significance of Hulun Lake sediments [J]. Scientia Geographica Sinica, 2018, 38(9): 1570-1578.
[4] Yu S Y, Colman S M, Li L X. BEMMA: a hierarchical Bayesian end-member modeling analysis of sediment grain-size distributions [J]. Mathematical Geosciences, 2016, 48(6): 723-741. doi: 10.1007/s11004-015-9611-0
[5] Qin X G, Cai B G, Liu T S. Loess record of the aerodynamic environment in the east Asia monsoon area since 60, 000 years before present [J]. Journal of Geophysical Research, 2005, 110(B1): B01204.
[6] Zhang X D, Ji Y, Yang Z S, et al. End member inversion of surface sediment grain size in the South Yellow Sea and its implications for dynamic sedimentary environments [J]. Science China Earth Sciences, 2016, 59(2): 258-267. doi: 10.1007/s11430-015-5165-8
[7] 程良清, 宋友桂, 李越, 等. 粒度端元模型在新疆黄土粉尘来源与古气候研究中的初步应用[J]. 沉积学报, 2018, 36(6):1148-1156
CHENG Liangqing, SONG Yougui, LI Yue, et al. Preliminary application of grain size end member model for dust source tracing of Xinjiang Loess and paleoclimate reconstruction [J]. Acta Sedimentologica Sinica, 2018, 36(6): 1148-1156.
[8] 雷国良, 张虎才, 张文翔, 等. Mastersize 2000型激光粒度仪分析数据可靠性检验及意义——以洛川剖面S4层古土壤为例[J]. 沉积学报, 2006, 24(4):531-539 doi: 10.3969/j.issn.1000-0550.2006.04.010
LEI Guoliang, ZHANG Hucai, ZHANG Wenxiang, et al. The reliability and significance of the grain-size obtained by Mastersize 2000 laser analyzer: a case study on the typical S4 from Luochuan section [J]. Acta Sedimentologica Sinica, 2006, 24(4): 531-539. doi: 10.3969/j.issn.1000-0550.2006.04.010
[9] 陈莹璐, 张玉柱, 谭子辉, 等. MS2000和LS13320激光粒度仪测定沉积物粒度结果的差异[J]. 中山大学学报: 自然科学版, 2018, 57(4):48-55
CHEN Yinglu, ZHANG Yuzhu, TAN Zihui, et al. Comparison of particle-size results of sediments measured by the MS2000 and LS13320 laser diffraction particle-size analyzers [J]. Acta Scientiarum Naturalium Universitatis Sunyatseni, 2018, 57(4): 48-55.
[10] 战庆, 王张华, 陈勇, 等. 长江口水下三角洲沉积物粒度组成及其在减沙背景下的响应[J]. 地质通报, 2016, 35(10):1715-1723 doi: 10.3969/j.issn.1671-2552.2016.10.019
ZHAN Qing, WANG Zhanghua, CHEN Yong, et al. Grain size of recent sediments in Yangtze River subaqueous delta and its response to sediments supply decline [J]. Geological Bulletin of China, 2016, 35(10): 1715-1723. doi: 10.3969/j.issn.1671-2552.2016.10.019
[11] 刘静玲, 李毅, 史璇, 等. 海河流域典型河流沉积物粒度特征及分布规律[J]. 水资源保护, 2017, 33(6):9-19 doi: 10.3880/j.issn.1004-6933.2017.06.02
LIU Jingling, LI Yi, SHI Xuan, et al. Grain size characteristics and distribution regularities of typical river sediments in Haihe River Basin [J]. Water Resources Protection, 2017, 33(6): 9-19. doi: 10.3880/j.issn.1004-6933.2017.06.02
[12] 杨冰洁, 余凤玲, 郑卓, 等. 南澳岛青澳湾沉积物粒度与烧失量指示的全新世沉积环境变化[J]. 海洋地质与第四纪地质, 2015, 35(6):41-51
YANG Bingjie, YU Fengling, ZHENG Zhuo, et al. Changes in Holocene depositional environment of Qin’ao embayment on Nan’ao island inferred from sediment grain-size and loss-on-ignition [J]. Marine Geology & Quaternary Geology, 2015, 35(6): 41-51.
[13] 王兆夺, 黄春长, 周亚利, 等. 关中东部全新世黄土-古土壤序列粒度组分变化特征及古气候意义[J]. 地球科学进展, 2018, 33(3):293-304 doi: 10.11867/j.issn.1001-8166.2018.03.0293
WANG Zhaoduo, HUANG Chunchang, ZHOU Yali, et al. Characteristics of holocene Loess-Palaeosol particle size composition and Paleoclimatic significance in East Guanzhong, Shaanxi Province [J]. Advances in Earth Science, 2018, 33(3): 293-304. doi: 10.11867/j.issn.1001-8166.2018.03.0293
[14] 吕安琪, 鹿化煜, 曾琳, 等. 1. 08 Ma以来中国东北赤峰地区黄土粒度变化及其揭示的沙地扩张事件[J]. 中国沙漠, 2017, 37(4):659-665 doi: 10.7522/j.issn.1000-694X.2017.00048
LYU Anqi, LU Huayu, ZENG Lin, et al. Evolution of Horqin and Otindag dune fields since 1. 08 Ma recorded by grain size of loess in Chifeng, Northeastern China [J]. Journal of Desert Research, 2017, 37(4): 659-665. doi: 10.7522/j.issn.1000-694X.2017.00048
[15] 吴旭东, 刘国旭, 沈吉. 湛江湖光岩玛珥湖全新世粒度变化特征及古气候意义[J]. 湖泊科学, 2016, 28(5):1115-1122 doi: 10.18307/2016.0522
WU Xudong, LIU Guoxu, SHEN Ji. Grain size variation and its environmental significance from Huguangyan Maar Lake, Zhanjiang since the Holocene [J]. Journal of Lake Sciences, 2016, 28(5): 1115-1122. doi: 10.18307/2016.0522
[16] 鹿化煜, 安芷生. 洛川黄土粒度组成的古气候意义[J]. 科学通报, 1997, 42(1):66-69 doi: 10.3321/j.issn:0023-074X.1997.01.020
LU Huayu, AN Zhisheng. Paleoclimate significance of grain size composition of Luochuan Loess [J]. Chinese Science Bulletin, 1997, 42(1): 66-69. doi: 10.3321/j.issn:0023-074X.1997.01.020
[17] 王则宇, 崔向新, 蒙仲举, 等. 风水复合侵蚀下锡林河流域不同管理方式草地表土粒度特征[J]. 土壤, 2018, 50(4):819-825
WANG Zeyu, CUI Xiangxin, MENG Zhongju, et al. Soil particle size distributions of different management styles under complex wind and water erosion in Xilin River Basin [J]. Soils, 2018, 50(4): 819-825.
[18] 李华勇, 张虎才, 陈光杰, 等. 云南高原湖泊表层沉积物粒度特征及环境指示意义[J]. 沉积学报, 2017, 35(3):499-507
LI Huayong, ZHANG Hucai, CHEN Guangjie, et al. The grain size distribution characteristics of surface sediments from plateau lakes in Yunnan Province and their environmental significances [J]. Acta Sedimentologica Sinica, 2017, 35(3): 499-507.
[19] 陈松, 陈剑, 刘宏, 等. 堰塞湖溃坝堆积物的粒度特征及其沉积环境——以雪隆囊古堰塞湖为例[J]. 冰川冻土, 2016, 38(2):509-516
CHEN Song, CHEN Jian, LIU Hong, et al. Grain size features and sedimentary environment of the sediments caused by outburst of barrier lake: a case study of the ancient barrier lake (Xuelongnang Lake) [J]. Journal of Glaciology and Geocryology, 2016, 38(2): 509-516.
[20] 张笑辰, 张文强, 田元, 等. 西南印度洋中脊表层生源沉积物粒度组成及其影响因素[J]. 海洋湖沼通报, 2016(3):39-45
ZHANG Xiaochen, ZHANG Wenqiang, TIAN Yuan, et al. Grain size composition of biogenic sediments in Southwest Indian ridge and its Influence factors [J]. Transactions of Oceanology and Limnology, 2016(3): 39-45.
[21] 孟洁, 温小浩, 李保生, 等. 腾格里沙漠南缘土门剖面末次冰消期层段粒度特征及其反映的古气候[J]. 海洋地质与第四纪地质, 2016, 36(1):165-176
MENG Jie, WEN Xiaohao, LI Baosheng, et al. Grain-size distribution along the Tumen section of southern Tengger Desert, Northwestern China and its paleoclimatic implications during the Last Deglacial [J]. Marine Geology & Quaternary Geology, 2016, 36(1): 165-176.
[22] 喻薛凝, 战庆, 王张华. 长江口各地貌单元沉积构造和粒度分区特征[J]. 海洋地质与第四纪地质, 2016, 36(4):1-11
YU Xuening, ZHAN Qing, WANG Zhanghua. Sedimentary structures and grain size patterns of the geomorphic units in the Yangtze River Mouth [J]. Marine Geology & Quaternary Geology, 2016, 36(4): 1-11.
[23] Qiang M R, Chen F H, Zhang J W, et al. Grain size in sediments from Lake Sugan: a possible linkage to dust storm events at the northern margin of the Qinghai-Tibetan Plateau [J]. Environmental Geology, 2007, 51(7): 1229-1238. doi: 10.1007/s00254-006-0416-9
[24] 王兆夺, 黄春长, 杨红瑾, 等. 六盘山东麓晚更新世以来黄土粒度指示的物源特征及演变[J]. 地理科学, 2018, 33(5):818-826
WANG Zhaoduo, HUANG Chunchang, YANG Hongjin, et al. Characteristics of holocene loess-palaeosol particle size composition and paleoclimatic significance in East Guanzhong, Shaanxi Province [J]. Scientia Geographica Sinica, 2018, 33(5): 818-826.
[25] 章婷曦, 文莹亭, 董丹萍, 等. 太湖西北部表层沉积物粒度特征与沉积环境[J]. 湖泊科学, 2018, 30(3):836-846 doi: 10.18307/2018.0325
ZHANG Tingxi, WEN Yingting, DONG Danping, et al. Grain size features and sedimentary environment of surficial sediments in the northwest Lake Taihu [J]. Journal of Lake Sciences, 2018, 30(3): 836-846. doi: 10.18307/2018.0325
[26] 杨石岭, 丁仲礼. 黄土高原黄土粒度的空间变化及其古环境意义[J]. 第四纪研究, 2017, 37(5):934-944 doi: 10.11928/j.issn.1001-7410.2017.05.02
YANG Shiling, DING Zhongli. Spatial changes in grain size of loess deposits in the Chinese Loess Plateau and implications for palaeoenvironment [J]. Quaternary Sciences, 2017, 37(5): 934-944. doi: 10.11928/j.issn.1001-7410.2017.05.02
[27] 潘峰, 林春明, 李艳丽, 等. 钱塘江南岸SE2孔晚第四纪以来沉积物粒度特征及环境演化[J]. 古地理学报, 2011, 13(2):236-244 doi: 10.7605/gdlxb.2011.02.012
PAN Feng, LIN Chunming, LI Yanli, et al. Sediments grain-size characteristics and environmental evolution of Core SE2 in southern bank of Qiangtang River since the Late Quaternary [J]. Journal of Palaeogeography, 2011, 13(2): 236-244. doi: 10.7605/gdlxb.2011.02.012
[28] Vasskog K, Kvisvik B C, Paasche Ø. Effects of hydrogen peroxide treatment on measurements of lake sediment grain-size distribution [J]. Journal of Paleolimnology, 2016, 56(4): 365-381. doi: 10.1007/s10933-016-9924-0
[29] 赵寿刚, 张学义, 杨小平, 等. MS2000激光粒度仪与密度计法的土工颗分对比试验[J]. 南水北调与水利科技, 2008, 6(5):70-72 doi: 10.3969/j.issn.1672-1683.2008.05.019
ZHAO Shougang, ZHANG Xueyi, YANG Xiaoping, et al. Soil granulometric grading comparative experiments of MS2000 laser and densimeter methods [J]. South-to-North Water Transfers and Water Science & Technology, 2008, 6(5): 70-72. doi: 10.3969/j.issn.1672-1683.2008.05.019
-
