Geochemical characteristics and paleoenvironmental significance of the major elements in the sediments of Core TS6 from the southern part of Southwest Taiwan Basin of the South China Sea
-
摘要:
通过对南海台西南盆地南部海域TS6柱状样沉积物样品常量元素地球化学特征的分析，结合粒度和AMS14C测年分析结果，探讨了研究区末次冰消期以来的沉积环境及气候变化特征。常量元素垂向序列显示元素Mn在沉积物近表层大量自生富集，指示近现代底层水高度富氧，表明研究区水体环境条件十分有利于水成成因的铁锰结核发育；常量元素统计分析表明，Al、Fe、Mg、K、Ti代表了陆源元素组合；陆源常量元素比值Al2O3/TiO2、TFe2O3/TiO2、MgO/TiO2和MgO/Al2O3记录了研究区末次冰消期以来的部分气候波动事件，其中全新世9.8～9.4 kaBP和6.5～5.8 kaBP阶段发生了两次气候变冷事件，指示东亚夏季风强度明显减弱，并且6.5～5.8 kaBP阶段冷事件表现出“双峰”特征。各常量元素比值指示末次冰消期18.5和15.8 kaBP左右可能也出现了气候变冷事件，其中15.8 kaBP出现的冷事件应该对应于H1事件。
Abstract:Geochemical characteristics of major elements from the column sample TS6 in the southern part of Southwest Taiwan Basin, together with the grain size and AMS14C dating data are studied for both the changes in depositional environment and climate of the area since the last deglaciation. Vertical distribution of the major elements shows that Mn is autogenous and abundantly enriched near the surface of sediments, suggesting that the modern bottom water is highly oxygen-enriched. The water environmental conditions of the study area, therefore, are very beneficial for the deposition of hydrogenic ferromanganese nodules. Statistical analysis of major elements suggests that the major elements of Al, Fe, Mg, K and Ti represent the terrigenous element association. The ratios of these terrigenous elements, such as Al2O3/TiO2, Fe2O3/TiO2, MgO/TiO2 and MgO/Al2O3, are closely related to climatic fluctuations since the last deglaciation. Two climatic cooling events are observed in the periods of 9.8 kaBP~9.4 kaBP and 6.5 kaBP~5.8 kaBP respectively, indicating that the intensity of East Asian summer monsoon was significantly weakened then. The cooling event happened during the period of 6.5 kaBP ~5.8 kaBP showed a pattern of "double peaks". The ratios of major elements further indicate that there may also be some climatic cooling events around 18.5 kaBP and 15.8 kaBP in the last deglaciation, and the cold event at 15.8 kaBP should correspond to the event of Heinrich 1.
-
-
表 1 TS6柱状样浮游有孔虫AMS14C年龄
Table 1. AMS14C dating results of column sample TS6
柱状样 深度/cm 样品种类 AMS14C年龄/aBP 日历年龄/ cal aBP TS6 30～31 G.menardii 3 220±30 3 169～2 752 130～131 G.menardii 9 210±40 10 167～9 634 232～233 G.menardii 13 020±40 15 169～14 309 287～288 G.menardii 13 980±40 16 585～16 000 397～398 混合种 16 070±40 19 048～18 663
下载: 导出CSV
表 2 TS6柱状样沉积物粒度参数与组分
Table 2. Grain size composition and parameters of sediments of the column sample TS6
粒度参数/组分 Mz Md σi Ski Kg 砂/% 粉砂/% 黏土/% 平均值 0.005 0.006 1.408 0.103 1.040 0.84 62.29 36.87 最大值 0.008 0.008 1.613 0.249 1.400 5.19 78.56 46.26 最小值 0.004 0.004 1.162 −0.079 0.878 0 53.32 21.31
下载: 导出CSV
表 3 TS6柱状样沉积物常量元素（氧化物）含量（%）
Table 3. Content of major elements（oxides）in the sediments of column sample TS6（%）
常量元素（氧化物） 平均值 最高值 最低值 标准偏差 分异系数 A12O3 13.85 16.43 12.15 0.95 0.07 CaO 6.34 8.74 1.80 1.52 0.24 TFe2O3 5.35 7.06 4.51 0.49 0.09 MgO 2.47 2.98 2.12 0.18 0.07 Na2O 3.22 3.75 2.74 0.18 0.06 K2O 2.5 3.09 2.25 0.13 0.05 TiO2 0.57 0.66 0.51 0.03 0.05 P2O5 0.11 0.16 0.10 0.01 0.11 MnO 0.20 4.20 0.08 0.40 2.01
下载: 导出CSV
表 4 TS6柱状样常量元素因子载荷
Table 4. Factor loading of major elements in the sediments of column sample TS6
因子 Al2O3 CaO TFe2O3 MgO Na2O K2O TiO2 P2O5 MnO F1 0.977 0.137 0.874 0.908 0.056 0.871 0.917 0.538 0.084 F2 0.110 −0.507 0.321 0.203 −0.033 −0.163 0.181 0.759 0.877 F3 −0.075 −0.624 −0.114 0.070 0.912 0.100 −0.063 −0.126 0.158
下载: 导出CSV
-
[1] 赵泉鸿, 汪品先. 南海第四纪古海洋学研究进展[J]. 第四纪研究, 1999, 19(6):481-501 doi: 10.3321/j.issn:1001-7410.1999.06.001
ZHAO Quanhong, WANG Pinxian. Progress in Quaternary paleoceanography of the South China Sea: a review [J]. Quaternary Sciences, 1999, 19(6): 481-501. doi: 10.3321/j.issn:1001-7410.1999.06.001
[2] 周航, 刘乐军, 徐元芹, 等. 南海北部陆坡区DLW3101孔沉积物特征及古环境意义[J]. 海洋学报, 2018, 40(7):103-115
ZHOU Hang, LIU Lejun, XU Yuanqin, et al. Sediment characteristics and paleoenvironmental significance of Core DLW3101 from northern slope of the South China Sea [J]. Acta Oceanologic Sinica, 2018, 40(7): 103-115.
[3] 田成静, 钟和贤, 徐子英, 等. 南海北部陆架海域表层沉积物黏土矿物分布特征及物源分析[J]. 地质学刊, 2018, 42(1):131-136 doi: 10.3969/j.issn.1674-3636.2018.01.018
TIAN Chengjing, ZHONG Hexian, XU Ziying, et al. Distribution characteristics and source analysis of clay minerals in the surface sediments from the shelf of the northern South China Sea [J]. Journal of Geology, 2018, 42(1): 131-136. doi: 10.3969/j.issn.1674-3636.2018.01.018
[4] 田旭, 徐方建, 徐微, 等. 近4 400 a南海北部陆架沉积物的东亚季风记录[J]. 海洋科学, 2015, 39(9):62-68 doi: 10.11759/hykx20140423004
TIAN Xu, XU Fangjian, XU Wei, et al. 4 400 a East Asian monsoon record from sediments in the continental shelf of the northern South China Sea [J]. Marine Sciences, 2015, 39(9): 62-68. doi: 10.11759/hykx20140423004
[5] 徐方建, 陈世悦, 操应长, 等. 近4 400年来南海北部陆架沉积地球化学记录及其地质意义[J]. 沉积学报, 2010, 28(6):1198-1205
XU Fangjian, CHEN Shiyue, CAO Yingchang, et al. Geochemical records and geological significance of the continental shelf sediments in the northern south China Sea since 4 400 a [J]. Acta Sedimentologica Sinica, 2010, 28(6): 1198-1205.
[6] Wei G J, Liu Y, Li X H, et al. Major and trace element variations of the sediments at ODP Site 1144, South China Sea, during the last 230 ka and their paleoclimate implications [J]. Palaeogeography, Palaeoclimatology, Palaeoecology, 2004, 212(3-4): 331-342. doi: 10.1016/S0031-0182(04)00329-3
[7] 刘坚, 陆红锋, 苏新, 等. 南海北部BY1钻孔沉积物元素地球化学特征及其古环境意义[J]. 热带海洋学报, 2012, 31(5):6-11 doi: 10.3969/j.issn.1009-5470.2012.05.002
LIU Jian, LU Hongfeng, SU Xin, et al. Element geochemistry of Core BY1 from the northern South China Sea and its paleoenvironmental implication [J]. Journal of Tropical Oceanography, 2012, 31(5): 6-11. doi: 10.3969/j.issn.1009-5470.2012.05.002
[8] 万世明, 李安春, Jan-Berend W S, et al. 南海北部ODP1146站粒度揭示的近20Ma以来东亚季风演化[J]. 中国科学 D辑: 地球科学, 2007, 50(10):1536-1547 doi: 10.1007/s11430-007-0082-0
WAN Shiming, LI Anchun, Jan-Berend W S, et al. Grain-size records at ODP site 1146 from the northern South China Sea: implications on the East Asian monsoon evolution since 20 Ma [J]. Science in China Series D: Earth Sciences, 2007, 50(10): 1536-1547. doi: 10.1007/s11430-007-0082-0
[9] 杨文光, 郑洪波, 王可, 等. 南海东北部MD05-2905站36 ka BP以来的陆源碎屑沉积特征与东亚季风的演化[J]. 地球科学进展, 2007, 22(10):1012-1018 doi: 10.3321/j.issn:1001-8166.2007.10.004
YANG Wenguang, ZHENG Hongbo, WANG Ke, et al. Sedimentary characteristic of terrigenous clast of Site MD05-2905 in the northeastern part of South China Sea after 36ka and evolution of East Asian monsoon [J]. Advances in Earth Science, 2007, 22(10): 1012-1018. doi: 10.3321/j.issn:1001-8166.2007.10.004
[10] 李小洁, 梁莲姬, 吴枫, 等. 南海北部沉积物常量元素变化、碳酸盐旋回及其古环境意义[J]. 第四纪研究, 2015, 35(2):411-421 doi: 10.11928/j.issn.1001-7410.2015.02.16
LI Xiaojie, LIANG Lianji, WU Feng, et al. Variations of major elements and carbonate cycle of the northern South China Sea sediments and their paleoenvironmental significance [J]. Quaternary Sciences, 2015, 35(2): 411-421. doi: 10.11928/j.issn.1001-7410.2015.02.16
[11] 黄元辉, 黄玥, 蒋辉. 南海北部15 kaBP以来表层海水温度变化: 来自海洋硅藻的记录[J]. 海洋地质与第四纪地质, 2007, 27(5):65-74
HUANG Yuanhui, HUANG Yue, JIANG Hui. Surface water temperature changes in the Northern South China sea over last CA. 15 000 years: evidence from marine diatoms [J]. Marine Geology & Quaternary Geology, 2007, 27(5): 65-74.
[12] 郝鹏, 李铁刚, 常凤鸣, 等. 末次盛冰期以来南海西南海区对快速气候变化的响应特征[J]. 海洋地质与第四纪地质, 2007, 34(4):83-91
HAO Peng, LI Tiegang, CHANG Fengming, et al. Response of the Southwestern South China Sea to the rapid climate changes since the last glacial maximum [J]. Marine Geology & Quaternary Geology, 2007, 34(4): 83-91.
[13] 梅西, 张训华, 李日辉, 等. 南黄海北部晚更新世以来常量元素记录的化学风化作用[J]. 沉积学报, 2014, 32(5):846-854
MEI Xi, ZHANG Xunhua, LI Rihui, et al. Chemical weathering recorded by major element of Northern South Yellow Sea since Late Pleistocene [J]. Acta Sedimentologica Sinica, 2014, 32(5): 846-854.
[14] Wei G J, Li X H, Liu Y, et al. Geochemical record of chemical weathering and monsoon climate change since the early Miocene in the South China Sea [J]. Paleoceanography, 2006, 21(4): PA4214.
[15] 张俊, 孟宪伟, 王湘芹. 晚第四纪南海北部陆坡沉积物常量元素比值对气候变冷事件的指示意义[J]. 海洋学报, 2013, 35(4):106-111
ZHANG Jun, MENG Xianwei, WANG Xiangqin. The record of major element ratios in Late Quaternary at northern slope of the South China Sea and its indicative significance on the cooling events [J]. Acta Oceanologica Sinica, 2013, 35(4): 106-111.
[16] Wan S M, Clift P D, Zhao D B, et al. Enhanced silicate weathering of tropical shelf sediments exposed during glacial lowstands: a sink for atmospheric CO2 [J]. Geochimica et Cosmochimica Acta, 2017, 200: 123-144. doi: 10.1016/j.gca.2016.12.010
[17] Nesbitt H W, Markovics G, Price R C. Chemical processes affecting alkalis and alkaline earths during continental weathering [J]. Geochimica et Cosmochimica Acta, 1980, 44(11): 1659-1666. doi: 10.1016/0016-7037(80)90218-5
[18] 葛倩. 晚末次冰期以来南海古环境和古气候记录[D]. 武汉: 中国地质大学博士学位论文, 2010: 127 .
GE Qian. Paleoenvironmental and paleoclimatic records from the south China sea since the late last glaical period[D]. Wuhan: Doctor Dissertation of China University of Geosciences, 2010: 127 .
[19] Berger A, Loutre M F. Insolation values for the climate of the last 10 million years [J]. Quaternary Science Reviews, 1991, 10(4): 297-317. doi: 10.1016/0277-3791(91)90033-Q
[20] 韦刚健, 李献华, 陈毓蔚, 等. NS93-5钻孔沉积物高分辨率过渡金属元素变化及其古海洋记录[J]. 地球化学, 2001, 30(5):450-458 doi: 10.3321/j.issn:0379-1726.2001.05.007
WEI Gangjian, LI Xianhua, CHEN Yuwei, et al. High-resolution records of transitive metals of sediments from Core NS93-5 and their paleoceanography implications [J]. Geochimica, 2001, 30(5): 450-458. doi: 10.3321/j.issn:0379-1726.2001.05.007
[21] Rosenthal Y, Lam P, Boyle E A, et al. Authigenic cadmium enrichments in suboxic sediments: precipitation and postdepositional mobility [J]. Earth and Planetary Science Letters, 1995, 132(1-4): 99-111. doi: 10.1016/0012-821X(95)00056-I
[22] Wedepohl K H. The composition of the continental crust [J]. Geochimica et Cosmochimica Acta, 1995, 59(7): 1217-1232. doi: 10.1016/0016-7037(95)00038-2
[23] Calvert S E, Pedersen T F. Geochemistry of Recent oxic and anoxic marine sediments: implications for the geological record [J]. Marine Geology, 1993, 113(1-2): 67-88. doi: 10.1016/0025-3227(93)90150-T
[24] 陈忠, 杨慧宁, 颜文, 等. 中国海域固体矿产资源分布及其区划——砂矿资源和铁锰(微)结核—结壳[J]. 海洋地质与第四纪地质, 2006, 26(5):101-108
CHEN Zhong, YANG Huining, YAN Wen, et al. Distributions and divisions of mineral resources in the sea areas of China: Placer deposit and ferromanganese nodule/crust [J]. Marine Geology & Quaternary Geology, 2006, 26(5): 101-108.
[25] 仲义, 陈忠, 莫爱彬, 等. 南海北部铁锰结核成因及元素的赋存状态[J]. 热带海洋学报, 2017, 36(2):48-59
ZHONG Yi, CHEN Zhong, MO Aibin, et al. Genetic types and elemental occurrence phases of ferromanganese nodules in the northern South China Sea [J]. Journal of Tropical Oceanography, 2017, 36(2): 48-59.
[26] 韦刚健, 刘颖, 李献华, 等. 南海沉积物中过剩铝问题的探讨[J]. 矿物岩石地球化学通报, 2003, 22(1):23-25 doi: 10.3969/j.issn.1007-2802.2003.01.005
WEI Gangjian, LIU Ying, LI Xianhua, et al. Excess al in the sediments from south China Sea [J]. Bulletin of Mineralogy, Petrology and Geochemistry, 2003, 22(1): 23-25. doi: 10.3969/j.issn.1007-2802.2003.01.005
[27] Wei G J, Liu Y, Li X H, et al. Climatic impact on Al, K, Sc and Ti in marine sediments: evidence from ODP site 1144, South China Sea [J]. Geochemical Journal, 2003, 37(5): 593-602. doi: 10.2343/geochemj.37.593
[28] Shen G T, Campbell T M, Dunbar R B, et al. Paleochemistry of manganese in corals from the Galapagos Islands [J]. Coral Reefs, 1991, 10(2): 91-100. doi: 10.1007/BF00571827
[29] Delaney M L, Linn L J, Druffel E R M. Seasonal cycles of manganese and cadmium in coral from the Galapagos islands [J]. Geochimica et Cosmochimica Acta, 1993, 57(2): 347-354. doi: 10.1016/0016-7037(93)90436-Z
[30] 束振华, 杨守业, 窦衍光, 等. 冲绳海槽DGKS9604孔酸不溶相中常量元素组成及环境指示意义[J]. 热带地理, 2009, 29(3):236-240, 273 doi: 10.3969/j.issn.1001-5221.2009.03.006
SHU Zhenhua, YANG Shouye, DOU Yanguang, et al. Geochemical compositions and paleoenvironmental implication of the residual fractions of core DGkS9604 sediments in the middle Okinawa trough [J]. Tropical Geography, 2009, 29(3): 236-240, 273. doi: 10.3969/j.issn.1001-5221.2009.03.006
[31] 徐兆凯, 李安春, 李铁刚, 等. 东菲律宾海表层沉积物常量元素组成及地质意义[J]. 海洋地质与第四纪地质, 2010, 30(6):43-48
XU Zhaokai, LI Anchun, LI Tiegang, et al. Major element compositions of surface sediments in the East Philippine Sea and its geological implication [J]. Marine Geology & Quaternary Geology, 2010, 30(6): 43-48.
[32] 刘英俊, 曹励明, 李兆麟, 等. 元素地球化学[M]. 北京: 科学出版社, 1984: 6-40.
LIU Yingjun, CAO Liming, LI Zhaolin, et al. Elemental Geochemistry[M]. Beijing: Science Press, 1984: 6-40.
[33] 蒋富清, 李安春, 李铁刚. 冲绳海槽南部柱状沉积物地球化学特征及其古环境意义[J]. 海洋地质与第四纪地质, 2002, 22(3):11-17
JIANG Fuqing, LI Anchun, LI Tiegang. Geochemical characteristics for core sediments of the southern Okinawa trough and their Paleoenvironment implication [J]. Marine Geology & Quaternary Geology, 2002, 22(3): 11-17.
[34] 赵一阳, 鄢明才. 中国浅海沉积物地球化学[M]. 北京: 科学出版社, 1994: 174 .
ZHAO Yiyang, YAN Mingcai. Geochemistry of Sediments of the China Shelf Sea[M]. Beijing: Science Press, 1994: 174 .
[35] Sun Y B, Wu F, Clemens S C, et al. Processes controlling the geochemical composition of the South China Sea sediments during the last climatic cycle [J]. Chemical Geology, 2008, 257(3-4): 240-246. doi: 10.1016/j.chemgeo.2008.10.002
[36] Tian J, Xie X, Ma W T, et al. X‐ray fluorescence core scanning records of chemical weathering and monsoon evolution over the past 5 Myr in the southern South China Sea [J]. Paleoceanography, 2011, 26(4): PA4202.
[37] Asahara Y, Tanaka T, Kamioka H, et al. Provenance of the north Pacific sediments and process of source material transport as derived from Rb–Sr isotopic systematics [J]. Chemical Geology, 1999, 158(3-4): 271-291. doi: 10.1016/S0009-2541(99)00056-X
[38] 刘芳, 杨楚鹏, 常晓红, 等. 南海东北部下陆坡20 ka以来稀土元素沉积地球化学特征变化及其对物源的指示[J]. 海洋学报, 2018, 40(9):148-158
LIU Fang, YANG Chupeng, CHANG Xiaohong, et al. Sedimentary geochemistry properties of rare earth elements from the continental lower slope of the northeastern South China Sea over the last 20 ka and its implication for provenance [J]. Acta Oceanologic Sinica, 2018, 40(9): 148-158.
[39] Bond G, Kromer B, Beer J, et al. Persistent solar influence on north Atlantic climate during the Holocene [J]. Science, 2001, 294(5549): 2130-2136. doi: 10.1126/science.1065680
[40] 颜文, 古森昌, 陈忠, 等. 南海97-37柱样的主元素特征及其潜在的古环境指示作用[J]. 热带海洋学报, 2002, 21(2):75-83 doi: 10.3969/j.issn.1009-5470.2002.02.009
YAN Wen, GU Senchang, CHEN Zhong, et al. Characteristics of major elements of sediments in core 97-37 from Southern South China Sea and its potential implications to Paleoenvironment [J]. Journal of Tropical Oceanography, 2002, 21(2): 75-83. doi: 10.3969/j.issn.1009-5470.2002.02.009
[41] 覃嘉铭, 袁道先, 林玉石, 等. 末次冰消期以来气候期划分的准确定位与定年[J]. 地球学报, 2005, 26(S1):209-212
QIN Jiaming, YUAN Daoxian, LIN Yushi, et al. Accurate locating and dating for division of climate periods since the last deglaciation stage [J]. Acta Geoscientica Sinica, 2005, 26(S1): 209-212.
[42] Cosford J, Qing H R, Mattey D, et al. Climatic and local effects on stalagmite δ13C values at Lianhua Cave, China [J]. Palaeogeography, Palaeoclimatology, Palaeoecology, 2009, 280(1-2): 235-244. doi: 10.1016/j.palaeo.2009.05.020
[43] Zhang W C, Yan H, Dodson J, et al. The 9.2 ka event in Asian summer monsoon area: the strongest millennial scale collapse of the monsoon during the Holocene [J]. Climate Dynamics, 2018, 50(7-8): 2767-2782. doi: 10.1007/s00382-017-3770-2
[44] Risebrobakken B, Jansen E, Andersson C, et al. A high-resolution study of Holocene paleoclimatic and paleoceanographic changes in the Nordic Seas [J]. Paleoceanography, 2003, 18(1): 1017.
[45] Moros M, Emeis K, Risebrobakken B, et al. Sea surface temperatures and ice rafting in the Holocene North Atlantic: climate influences on northern Europe and Greenland [J]. Quaternary Science Reviews, 2004, 23(20-22): 2113-2126. doi: 10.1016/j.quascirev.2004.08.003
[46] Magny M, Haas J N. A major widespread climatic change around 5300 cal. yr BP at the time of the Alpine Iceman [J]. Journal of Quaternary Science, 2004, 19(5): 423-430. doi: 10.1002/jqs.850
[47] 孔兴功, 汪永进, 吴江滢, 等. 南京葫芦洞石笋δ13C对冰期气候的复杂响应与诊断[J]. 中国科学 D辑: 地球科学, 2005, 48(12):2174-2181 doi: 10.1360/04yd0140
KONG Xinggong, WANG Yongjin, WU Jiangying, et al. Complicated responses of stalagmite δ 13C to climate change during the last glaciation from Hulu Cave, Nanjing, China [J]. Science in China Series D: Earth Sciences, 2005, 48(12): 2174-2181. doi: 10.1360/04yd0140
-
