Characteristics of the structural transfer zone of northern Tiantai slope in Xihu Sag of the East China Sea Basin and their petroleum geological significances
-
摘要:
天台斜坡带北部紧邻平湖斜坡带平湖油气田，是西湖凹陷重要的油气勘探接替区。通过西湖凹陷天台斜坡带北部构造特征梳理，解析构造变换带样式、演变，并探讨其油气地质意义。研究结果表明，在结构特征上，天台斜坡带北部构造变换带整体处于NWW向基底舟山-国头断裂带上，是凹陷“南北分块”的重要体现，发育有独特的反向断阶；在构造样式上，天台斜坡带北部扭动变换断裂组合可分为北段缓冲式和南段传递式两个次级变换区，顺NWW向基底断裂的扭动变换作用南强北弱，在断裂组合上分别表现为“网格式”和“马尾式”；在成因演化上，天台斜坡带北部构造变换在早期伸展断陷及后期挤压反转中均有发育，自下而上具有持续递进的演变特征，调节南北两侧NE-NNE向断裂系伸展和挤压强度的差异，并使部分断裂改变原有的延伸方向。天台斜坡带北部与构造变换作用相关的断裂组合不仅利于控制各类扭动圈闭的发育，也利于油气顺扭动相关断裂垂向运移充注，此外，在构造变换带控制背景下该区亦是有利的前平湖组优质砂体富集区带。
Abstract:The northern Tiantai slope of the Xihu Sag, next to the Pinghu oil and gas field, is an important exploration target for future replacement. After a through review of the structural characteristics of the slope, this paper is devoted to the analysis of structural styles and evolutionary process of the transfer zone and their significance to petroleum accumulation. The results show that, in terms of structural characteristics, the structural transfer zone of the northern Tiantai Slope is developed upon the NWW Zhoushan-Guotou basement fault zone under the control of the “North-south Blocking”, where a special reverse fault terrace occurs. The northern Tiantai slope can be further divided into two secondary transfer types: the buffering type in the north and the transferring in the south. The torsional transfer structure, along the NWW basement fault, is strong in the south but weak in the north, which is called the faults of "reticulation type" and "horsetail type" respectively in this paper in view of the fault combination. In terms of genetic evolution, the structural transfer zone of the northern Tiantai Slope is developed in the early period of fault subsiding up to late compression and reversal period, showing a continuous and progressive evolutionary process, which adjusts the difference of extension and compression strength of NE-NNE fault system between the north and the south and by which the original extension direction of some faults is changed. Finally, it is revealed that the fault combination under the control of structural transfer in the northern Tiantai slope area is not only favorable to the forming of various twisted trap, but also favorable to the vertical migration and recharge of oil-gas along the twisted faults. Under the control of structural transfer zone, the northern Tiantai slope is also a favorable area for the deposition of Pre-Pinghu high-quality sandy deposits.
-
-
[1] Dahlstrom C D A. Structural geology in the eastern margin of the Canadian Rocky Mountain [J]. Bulletin of Canadian Petroleum Geology, 1970, 187(3): 332-406.
[2] Moustafa A R. Controls on the development and evolution of transfer zones: The influence of basement structure and sedimentary thickness in the Suez Rift and Red Sea [J]. Journal of Structural Geology, 1997, 19(6): 755-768. doi: 10.1016/S0191-8141(97)00007-2
[3] 邬光辉, 漆家福. 黄骅盆地一级构造变换带的特征与成因[J]. 石油与天然气地质, 1999, 20(2):125-128 doi: 10.3321/j.issn:0253-9985.1999.02.006
WU Guanghui, QI Jiafu, et al. Characteristics and origin of first order transfer zone in Huanghua Basin [J]. Oil & Gas Geology, 1999, 20(2): 125-128. doi: 10.3321/j.issn:0253-9985.1999.02.006
[4] 孙冬胜, 刘池阳, 杨明慧, 等. 渤海湾盆地冀中坳陷中区中新生代复合伸展构造[J]. 地质论评, 2004, 50(5):484-491 doi: 10.3321/j.issn:0371-5736.2004.05.006
SUN Dongsheng, LIU Chiyang, YANG Minghui, et al. Study on complex extensional structures in middle Jizhong Depression in the Bohai Bay Basin [J]. Geological Review, 2004, 50(5): 484-491. doi: 10.3321/j.issn:0371-5736.2004.05.006
[5] 漆家福. 裂陷盆地中的构造变换带及其石油地质意义[J]. 海相油气地质, 2007, 12(2):43-50
QI Jiafu. Structural transfer zones and significance for hydrocarbon accumulation in rifting basin [J]. Marine Origin Petroleum Geology, 2007, 12(2): 43-50.
[6] 陈发景, 贾庆素, 张洪年. 传递带及其在砂体发育中的作用[J]. 石油与天然气地质, 2004, 25(2):144-148 doi: 10.3321/j.issn:0253-9985.2004.02.005
CHEN Fajing, JIA Qingsu, ZHANG Hongnian. Transfer zone and its relation with distribution of sand bodies [J]. Oil & Gas Geology, 2004, 25(2): 144-148. doi: 10.3321/j.issn:0253-9985.2004.02.005
[7] 余一欣, 周心怀, 魏刚, 等. 渤海湾地区构造变换带及油气意义[J]. 古地理学报, 2008, 10(5):555-560 doi: 10.7605/gdlxb.2008.05.013
YU Yixin, ZHOU Xinhuai, WEI Gang, et al. Structural transfer zone and their hydrocarbon significances in Bohai Bay area [J]. Journal of Palaeogeography, 2008, 10(5): 555-560. doi: 10.7605/gdlxb.2008.05.013
[8] Cukur D, Horozal S, Kim D, et al. Seismic stratigraphy and structural analysis of the Northern East China Sea Shelf Basin interpreted from multi-channel seismic reflection data and cross-section restoration [J]. Marine and Petroleum Geology, 2011, 28(5): 1003-1022. doi: 10.1016/j.marpetgeo.2011.01.002
[9] 任建业. 中国近海海域新生代成盆动力机制分析[J]. 地球科学, 2018, 43(10):3337-3361
REN Jianye. Genetic dynamics of China offshore Cenozoic basins [J]. Earth Science, 2018, 43(10): 3337-3361.
[10] 林长松, 高金耀. 东海微板块的南北分块与水平运动[J]. 海洋学报, 1999, 21(1):80-89
LIN Changsong, GAO Jinyao. North-south segmentation and horizontal movement of the East China Sea micro-plate [J]. Acta Oceanologica Sinica, 1999, 21(1): 80-89.
[11] 张绍亮, 张建培, 唐贤君, 等. 东海西湖凹陷断裂系统几何学特征及其成因机制[J]. 海洋地质与第四纪地质, 2014, 34(1):91-98
ZHANG Shaoliang, ZHANG Jianpei, TANG Xianjun, et al. Geometry characteristic of the fault system in Xihu Sag in East China Sea and its formation mechanism [J]. Marine Geology and Quaternary Geology, 2014, 34(1): 91-98.
[12] 胡望水, 蔡峰, 胡芳, 等. 东海西湖凹陷平湖斜坡带裂陷期变换构造特征及其演化规律[J]. 石油天然气学报, 2010, 32(3):7-12 doi: 10.3969/j.issn.1000-9752.2010.03.002
HU Wangshui, CAI Feng, HU Fang, et al. The characteristics of tectonic transform evolutional rules of chasmic cycles in Pinghu slope of Xihu Depression of East China Sea [J]. Journal of Oil and Gas Technology, 2010, 32(3): 7-12. doi: 10.3969/j.issn.1000-9752.2010.03.002
[13] 张建培. 东海西湖凹陷平湖斜坡带断裂系统特征及成因机制探讨[J]. 地质科学, 2013, 48(1):291-303 doi: 10.3969/j.issn.0563-5020.2013.01.020
ZHANG Jianpei. Fault system and its genetic mechanism in the Pinghu slope of the Xihu Sag in the East China Sea Shelf Basin [J]. Chinese Journal of Geology, 2013, 48(1): 291-303. doi: 10.3969/j.issn.0563-5020.2013.01.020
[14] 杨丽娜, 王丽顺. 西湖凹陷保俶斜坡断裂特征及与油气成藏的关系[J]. 海洋石油, 2007, 27(1):19-24 doi: 10.3969/j.issn.1008-2336.2007.01.004
YANG Lina, WANG Lishun. The effect of rupture on oil accumulation in Baochu slope of Xihu Sag [J]. Offshore Oil, 2007, 27(1): 19-24. doi: 10.3969/j.issn.1008-2336.2007.01.004
[15] 刘金水, 廖宗廷, 贾健谊, 等. 东海陆架盆地地质结构及构造演化[J]. 上海地质, 2003, 3:1-6
LIU Jinshui, LIAO Zongting, JIA Jianyi, et al. The geological structure and tectonic evlolution of the East China Sea Shelf Basin [J]. Shanghai Geology, 2003, 3: 1-6.
[16] 杨文达, 崔征科, 张异彪, 等. 东海地质与矿产[M]. 北京: 海洋出版社, 2010.
YANG Wenda, CUI Zhengke, ZHANG Yibiao, et al. Geology and Mineral Resources of the East China Sea [M]. Beijing: China Ocean Press, 2010.
[17] 焦荣昌. 论舟山-国头断裂带的性质及其向陆区的延伸[J]. 物探与化探, 1988, 12(4):249-255
JIAO Rongchang. On properties of Zhoushan-Guotou fault zone and its extension towards the continent [J]. Geophysical and Geochemical Exploration, 1988, 12(4): 249-255.
[18] 张卫华, 郭全仕. 平南地区火成岩分布特征及其对圈闭形成的影响[J]. 勘探地球物理进展, 2004, 27(5):359-362
ZHANG Weihua, GUO Quanshi. The distributional characteristics of igneous rock and effect on the formation of traps in Pingnan area [J]. Progress in Exploration Geophysics, 2004, 27(5): 359-362.
[19] 苏程, 李春峰, 葛和平. 东海陆架盆地西湖凹陷渐中新世异常反射体的特征与成因[J]. 海洋学研究, 2010, 28(4):14-21 doi: 10.3969/j.issn.1001-909X.2010.04.002
SU Cheng, LI Chunfeng, GE Heping. Characteristic and formation cause of anomalous reflection on Oligocene and Miocene transition in Xihu Depression, East China Sea Basin [J]. Journal of Marine Sciences, 2010, 28(4): 14-21. doi: 10.3969/j.issn.1001-909X.2010.04.002
[20] 张建培, 唐贤君, 张田, 等. 平衡剖面技术在东海西湖凹陷构造演化研究中的应用[J]. 海洋地质前沿, 2012, 28(8):31-37
ZHANG Jianpei, TANG Xianjun, ZHANG Tian, et al. Application of balanced cross section technique to the research of tectonic evolution of Xihu Sag in the East China Sea [J]. Marine Geology Frontiers, 2012, 28(8): 31-37.
[21] 谢瑞征, 朱永正, 裘然忠. 江苏地震构造特征[C]//第二届全国构造地质学会议论文选集(第三卷). 北京: 科学出版社, 1982.
XIE Ruizheng, ZHU Yongzheng, QIU Ranzhong. Characteristics of seismic structure in Jiangsu Province [C]//Selected papers of the second National Conference on Structural Geology (Volume 3). Beijing: Science Press, 1982.
[22] 孙岩, 沈修志. 苏南地区NW向压性构造的确立[C]//中国地质科学院综562综合大队集刊. 1987, 6: 105-115.
SUN Yan, SHEN Xiuzhi. The determination of NW compressive structures in south Jiangsu [C]//Bulletin of the 562 Comprehensive Geological Brigade Chinese Academy of Geological Sciences. 1987, 6: 105-115.
[23] 周祖翼. 下扬子区印支期以来主要构造运动性质、表现及其对油气藏形成与改造的作用[R]. 中石化勘探南方分公司, 2001.
ZHOU Zuyi. The nature and performance of the main tectonic movements since the Indosinian in the lower Yangtze region and their effects on the formation and transformation of oil and gas reservoirs [R]. Sinopec Exploration South Company, 2001.
[24] 李祖武. 中国东部NW向构造[M]. 北京: 地震出版社, 1992.
LI Zuwu. NW Trending Structures in Eastern China [M]. Beijing: Seismological Press, 1992.
[25] 杨明桂, 王光辉. 华南陆区板块活动与构造体系的形成演化[J]. 地质学报, 2019, 93(3):528-544
YANG Minggui, WANG Guanghui. Formation and evolution of plate activity and the structural system in the South China continental region [J]. Acta Geologica Sinica, 2019, 93(3): 528-544.
[26] 姚琪. 杭州湾地区北西向断裂新构造运动特征[D]. 浙江大学, 2008.
YAO Qi. Neotectonics of NW-SE trending faults in Hangzhou Bay, China [D]. Zhejiang University, 2008.
[27] 谭忠福, 张启富, 袁正新, 等. 中国东部新华夏系[M]. 武汉: 中国地质大学出版社, 1988: 1-15.
TAN Zhongfu, ZHANG Qifu, YUAN Zhengxin, et al. Neocathaysian in Eastern China [M]. Wuhang: China University of Geosciences Press, 1988: 1-15.
[28] 李三忠, 索艳慧, 李玺瑶, 等. 西太平洋中生代板块俯冲过程与东亚洋陆过渡带构造-岩浆响应[J]. 科学通报, 2018, 63(16):1550-1593 doi: 10.1360/N972017-01113
LI Sanzhong, SUO Yanhui, LI Xiyao, et al. Mesozoic plate subduction in West Pacific and tectono-magmatic response in the East Asian ocean-continent connection zone [J]. Chinese Science Bulletin, 2018, 63(16): 1550-1593. doi: 10.1360/N972017-01113
[29] 环文林, 时振梁, 鄢家全. 中国东部及邻区中新生代构造演化与太平洋板块运动[J]. 地质科学, 1982(2):179-190
HUAN Wenlin, SHI Zhenliang, YAN Jiaquan. Meso-cenozoic tectonic evolution of eastern China and adjacent area and movement of the Pacific Plate [J]. Chinese Journal of Geology, 1982(2): 179-190.
[30] Morley C K, Nelson R A, Patton T L, et al. Transfer zones in the East African rift system and their relevance to hydrocarbon exploration in rifts [J]. AAPG Bulletin, 1990, 74(8): 1234-1253.
[31] 周心怀, 余一欣, 魏刚, 等. 渤海辽东湾海域JZ25-1S转换带与油气成藏的关系[J]. 石油学报, 2008(6):837-840 doi: 10.3321/j.issn:0253-2697.2008.06.009
ZHOU Xinhuai, YU Yixin, WEI Gang, et al. Relationship between JZ25-1S transfer zone and hydrocarbon accumulation in Liaodongwan offshore of Bohai Bay Basin [J]. Acta Petrolei Sinica, 2008(6): 837-840. doi: 10.3321/j.issn:0253-2697.2008.06.009
-
