加瓜海脊铁锰结壳的年龄及其定年方法适用性比较

罗顺开; 周怀阳; 赵国庆; 袁伟

doi:10.16562/j.cnki.0256-1492.2021070502

加瓜海脊铁锰结壳的年龄及其定年方法适用性比较

1.
同济大学海洋地质国家重点实验室，上海 200092

2.
中国科学院地球环境研究所，西安 710061

基金项目: 国家自然科学基金项目“南海深部计划重点项目”（91428207）

详细信息

作者简介: 罗顺开（1995—），男，硕士研究生，海洋科学专业，E-mail：1176298753@qq.com

通讯作者: 周怀阳（1961—），男，博导，教授，从事海洋化学研究，E-mail：Zhouhy@tongji.edu.cn

中图分类号: P736.4

收稿日期: 2021-07-05

修回日期: 2021-08-08

刊出日期: 2022-02-28

Age of a Fe-Mn crust on the Gagua Ridge and applicability studies of dating methods

1.
State Key Laboratory of Marine Geology, Tongji University, Shanghai 200092, China

2.
Institute of Earth Environment, Chinese Academy of Science, Xi'an 710061, China

More Information

Corresponding author: ZHOU Huaiyang, Zhouhy@tongji.edu.cn

Received Date: 05 July 2021

Revised Date: 08 August 2021

Publish Date: 28 February 2022

摘要

摘要:
深海铁锰结壳的定年对其记录的百万年尺度古海洋环境变化研究至为关键。综合运用¹⁰Be/⁹Be、Co经验公式、²³⁰Th_ex/²³²Th和磁性地层学，对采自加瓜海脊的铁锰结壳样品开展了系统的年代学对比研究。结果表明：相对于开阔大洋的铁锰结壳，较多的陆源物质输入造成了不同定年方法获得的年龄或生长速率的明显差异。其中，因为大量陆源物质携带的²³²Th以及对Co含量的稀释，铁锰结壳表层的²³⁰Th_ex/²³²Th初始通量以及样品部分层位的Co通量出现显著变化，²³⁰Th_ex/²³²Th定年方法与Co经验公式获得的结果受到碎屑物质的影响最为显著。尽管¹⁰Be/⁹Be初始通量也受到了陆源物质输入的影响，但是¹⁰Be/⁹Be初始通量变化很小，应该是本研究中最为可信的结果。而古地磁地层学定年法需要参考其他定年结果，最后也只能得到几个年龄控制点。最终得出加瓜海脊该铁锰结壳样品的年龄为7.09 Ma，而不同核素在铁锰结壳中的赋存状态应该是今后值得深入研究的一个重要方向。
- 铁锰结壳 /
- 定年方法 /
- 古地磁 /
- 同位素地球化学 /
- 加瓜海脊
Abstract:
Precise dating of deep-sea Fe-Mn crust is crucial to the research of paleoceanographic changes. In this paper, dating methods of ¹⁰Be/⁹Be, Co empirical formula, ²³⁰Th_ex/²³²Th and paleomagnetic stratigraphy are comparatively used for systematical chronological studies of a Fe-Mn crust sample collected from the Gagua Ridge. Different growth rate or different age figures are observed as different dating methods are adopted due to large inputs of terrigenous materials. Co content is diluted by the excessive amounts of ²³²Th brought in by the terrigenous inputs, and the Co flux in certain layers and initial ²³⁰Th_ex/²³²Th flux at the surface layer are both greatly fluctuated, which will render greatly influence onto the dating results of the two methods. Although the ¹⁰Be/⁹Be initial flux is also influenced by terrigenous inputs, it remains relatively stable. Therefore, ¹⁰Be/⁹Be can be regarded as the most precise dating method in the case. Paleomagnetic stratigraphy dating results may provide several age controlling points after referring to other dating results. Finally, the initial growth age of the Fe-Mn crust is confirmed as 7.09 Ma. For more precise age figure, further studies are required on the occurrence of nuclides in the Fe-Mn crust.
- Fe-Mn crust /
- dating methods /
- paleomagnetism /
- isotopic geochemistry /
- the Gagua Ridge

HTML全文

图 1 结壳样品同位素测量值随深度变化

Figure 1.

下载: 全尺寸图片幻灯片

图 2 三种测年法（Co经验公式、¹⁰Be/⁹Be、古地磁地层学）得到的铁锰结壳生长速率与Al含量进行比较

Figure 2.

下载: 全尺寸图片幻灯片

图 3 古地磁测试结果

Figure 3.

下载: 全尺寸图片幻灯片

表 1 铁锰结壳的¹⁰Be/⁹Be测试结果以及¹⁰Be/⁹Be初始通量

Table 1. ¹⁰Be/⁹Be testing results of Fe-Mn crust and initial flux of ¹⁰Be/⁹Be

序号	矫正深度/mm	¹⁰Be/⁹Be/10⁻¹⁰	年龄/Ma	(¹⁰Be/⁹Be)_初始通量/10⁻¹⁰
Dive08-1	0.50	1.535	0.080	1.598
Dive08-2	3.50	1.208	0.560	1.598
Dive08-3	6.50	0.564	2.085	1.599
Dive08-4	11.75	0.439	2.589	1.601
Dive08-5	16.25	0.273	3.544	1.604
Dive08-6	20.75	0.239	3.814	1.605
Dive08-7	25.00	0.187	4.299	1.606
Dive08-8	28.25	0.137	4.923	1.606
Dive08-9	32.50	0.125	5.110	1.607
Dive08-10	36.00	0.113	5.306	1.609
Dive08-11	39.25	0.081	5.989	1.608
空白样		0.002

下载: 导出CSV

表 2 结壳表层²³⁰Th_ex/²³²Th测试结果以及²³⁰Th_ex/²³²Th初始通量

Table 2. Experimental results of ²³⁰Th_ex/²³²Th and initial flux of ²³⁰Th_ex/²³²Th

序号	深度/mm	质量/g	²³⁸U /(μg/kg)	²³⁰Th / ²³²Th/原子数×10⁻⁶	²³⁰Th / ²³⁸U	²³⁰Th_ex/²³²Th	年龄/Ma	(²³⁰Th_ex/²³²Th)₀
D08-1	0.08	0.023100	7684.3±36.7	159.015159±3.348	46.7555±0.3114	30.01	0.01	32.25
D08-2	0.27	0.033700	7459.7±31.2	87.168225±1.812	31.1138±0.1780	16.60	0.03	21.29
D08-3	0.47	0.024700	7467.8±29.3	65.836530±1.362	22.5662±0.1255	12.67	0.05	19.49
D08-4	0.64	0.026800	7715.4±29.0	66.634394±1.405	21.3219±0.1441	12.85	0.06	23.20
D08-5	0.81	0.023200	7891.3±35.2	60.799142±1.278	17.5236±0.1188	11.83	0.08	24.95
D08-6	0.98	0.027800	7358.8±41.0	23.237013±3.394	8.7137±1.1560	4.74	0.10	11.71
D08-7	1.14	0.021000	8267.8±35.7	45.847210±0.963	13.5603±0.0882	9.05	0.12	26.03
D08-8	1.28	0.020000	6918.1±34.2	35.667330±0.779	11.4776±0.1039	7.12	0.13	23.27
D08-9	1.41	0.019300	6830.7±22.5	37.542399±0.865	12.3548±0.1423	7.45	0.14	27.53
D08-10	1.53	0.014500	6557.2±42.6	30.485152±0.682	9.8458±0.1022	6.16	0.15	25.28
D08-11	1.62	0.014000	10020.1±71.8	24.628982±0.533	7.5091±0.0642	5.10	0.16	22.89
D08-12	1.75	0.023800	7926.5±44.1	21.876682±0.489	6.3202±0.0604	4.63	0.18	23.34
D08-13	1.87	0.011200	8203.9±48.0	19.038096±0.428	5.5576±0.0583	4.10	0.19	23.05
D08-14	1.95	0.013800	6689.5±36.2	18.846383±0.411	5.5571±0.0508	4.05	0.20	24.62
D08-14R			6171.4±46.5	16.099030±0.356	4.5886±0.0463	3.56
注：(²³⁰Th_ex/²³²Th)₀代表初始通量，D08-14R为重复样。

下载: 导出CSV

表 3 南海和太平洋深层水¹⁰Be/⁹Be初始通量

Table 3. Initial flux of ¹⁰Be/⁹Be in SCS and Pacific

序号	年龄/Ma	¹⁰Be/⁹Be/10⁻⁹	(¹⁰Be/⁹Be)_初始通量/10⁻⁹
J158-1	0.390	5.160	6.270
J158-2	1.330	3.230	6.279
J158-3	2.170	2.130	6.300
J158-4	3.170	1.290	6.289
J158-5	4.520	0.660	6.318
05E-1	0.250	5.420	6.141
05E-2	0.550	4.650	6.121
05E-3	1.060	3.610	6.131
05E-4	1.870	2.400	6.110
05E-5	2.340	1.900	6.118
05E-6	2.71	1.58	6.121
MDD46-1-1	0.96	65.48	106
MDD46-1-5	1.370	68.32	135
MDD46-1-10	1.750	60.89	146
MDD46-1-15	2.320	47.56	152
MDD46-1-20	2.750	24.31	96
MDD46-1-25	3.190	19.79	97
MDD46-1-30	3.680	7.93	50
MDD46-1-35	4.150	11.10	88
MDD46-1-40	4.560	14.99	147
MDD46-1-41	4.650	14.29	146
注：J158^[41]和05E^[42]记录南海深层水¹⁰Be/⁹Be初始通量，结壳 MDD46-1^[40]记录太平洋深层水¹⁰Be/⁹Be初始通量。

下载: 导出CSV

表 4 全球大洋、边缘海结壳主微量元素平均含量

Table 4. Major and trace elements content of Fe-Mn crust from oceans and marginal seas

元素		大西洋	印度洋	南大洋	Non-Prime Zone	北太平洋Prime Zone	加瓜海脊*	菲律宾海盆	加利福利亚湾	南海**
主量元素/%	Fe	20.9	22.3	18.1	22.5	16.8	23.92	21.16	23.8	16.01
	Mn	14.5	17	21.7	23.4	22.8	18.59	5.08	19.5	15.43
	Al	2.2	1.83	1.28	1.8	1.01	5.80	4	1.79	2.02
微量元素/(mg/kg)	Co	3608	3291	6167	3733	6655	2258.95	1450	3131	1639.25
	Cu	861	1105	1082	1074	982	1077.06	815.3	383	484.88
	Ni	2581	2563	4643	3495	4216	2286.86	886.15	2269	2992.88
	Th	52	56	15	36	12	63.03	31.66	48	8.68
注：数据来自Chen^[28]以及本研究，*数据来自Guan^[54]，其他数据来自Hein^[1]。

下载: 导出CSV
