Development characteristics of the unconformity on the bottom Paleogene in the northern Bozhong Sag and its relationship with hydrocarbon accumulation
-
摘要:
不整合是油气输导体系中的重要组成部分，也是油气成藏的有利场所。以渤海湾盆地渤中凹陷北部为例，综合利用三维地震资料、钻测井资料和岩心薄片资料，对古近系底部不整合发育特征及其对油气成藏影响进行分析。结果表明，渤中凹陷北部古近系底部不整合包括5种接触类型和7种结构类型。不整合通道类型划分为双运移通道I型、单运移通道Ⅱ1型和Ⅱ2型以及封堵型Ⅲ型，单运移通道Ⅱ1型是研究区主要的不整合油气成藏类型。运聚类型包括侧向型、圈闭+侧向型、垂向+侧向型和封堵型4种。不整合之上砂岩输导油气的能力与砂岩微观特征及裂缝倾角相关，半风化岩层对油气的输导储集能力受控于原始孔渗良好且不易形成风化黏土层的火山岩。
Abstract:Unconformity is an important part of hydrocarbon migration system and a favorable place for hydrocarbon accumulation. Taking the northern Bozhong Sag in Bohai Bay Basin as an example, we analyzed the characteristics of unconformity development on bottom Paleogene and its influence on hydrocarbon accumulation comprehensively by using the data from 3D seismic, drilling and logging, and core thin-section. Results show that there are five contact types and seven structural types of the Paleogene bottom unconformity in the northern Bozhong Sag. Unconformity channel types can be divided into double migration channel type Ⅰ, single migration channel type Ⅱ1 and Ⅱ2 and plugging type Ⅲ. The single migration channel type Ⅱ1 is the main type of unconformity hydrocarbon accumulation in the study area. The migration and accumulation types include lateral type, trap and lateral type, vertical and lateral type, and plugging type. The hydrocarbon migration capacity of sandstone above the unconformity is related to the microscopic characteristics of sandstone and the dip angle of fracture. The hydrocarbon migration and storage capacity of semi-weathered rock strata are controlled by the volcanic rocks with good original porosity and permeability and difficult to form weathered clay layer.
-
Key words:
- unconformity /
- hydrocarbon accumulation /
- volcanic rock /
- Bohai Bay Basin /
- northern Bozhong sag
-
-
表 1 渤中凹陷北部古近系底部不整合油气显示统计
Table 1. Oil and gas display in the unconformity at the bottom of the Paleogene in the northern Bozhong Sag
不整合结构 井号 含油性 不整合之上 半风化岩层 缺失风化
黏土层砂-火型 C2、C3、C4 油层 油层 泥-火型 A1 不含油 气层 A3 不含油 不含油 泥-砂型 A5、B1 不含油 油层 发育风化
黏土层砂-泥-火型 A4 不含油 不含油 砂-泥-灰型 D1 油斑 油斑 泥-泥-泥型 A2、B2 不含油 不含油 泥-泥-火型 A6、C1 不含油 不含油
下载: 导出CSV
-
[1] Rafini S, Mercier E. Forward modelling of foreland basins progressive unconformities [J]. Sedimentary Geology, 2002, 146(1-2): 75-89. doi: 10.1016/S0037-0738(01)00167-1
[2] Levorsen A I. The obscure and subtle trap [J]. AAPG Bulletin, 1966, 50(10): 2058-2067.
[3] 潘钟祥. 不整合对于油气运移聚集的重要性[J]. 石油学报, 1983, 4(4):1-10 doi: 10.7623/syxb198304001
PAN Zhongxiang. Significance of unconformity to oil and gas migration and accumulation [J]. Acta Petrolei Sinica, 1983, 4(4): 1-10. doi: 10.7623/syxb198304001
[4] 吴孔友, 查明, 柳广弟. 准噶尔盆地二叠系不整合面及其油气运聚特征[J]. 石油勘探与开发, 2002, 29(2):53-57 doi: 10.3321/j.issn:1000-0747.2002.02.013
WU Kongyou, ZHA Ming, LIU Guangdi. The unconformity surface in the Permian of Junggar Basin and the characters of oil-gas migration and accumulation [J]. Petroleum Exploration and Development, 2002, 29(2): 53-57. doi: 10.3321/j.issn:1000-0747.2002.02.013
[5] Wu K Y, Paton D, Zha M. Unconformity structures controlling stratigraphic reservoirs in the north-west margin of Junggar basin, North-west China [J]. Frontiers of Earth Science, 2013, 7(1): 55-64. doi: 10.1007/s11707-012-0344-9
[6] 陆克政. 关于不整合的分类和含油盆地不整合的分布[J]. 华东石油学院学报, 1980(3):10-19
LU Kezheng. On classification of unconformities and their distribution in oil-bearing basin [J]. Journal of East China Petroleum College, 1980(3): 10-19.
[7] 艾华国, 兰林英, 张克银, 等. 塔里木盆地前石炭系顶面不整合面特征及其控油作用[J]. 石油实验地质, 1996, 18(1):1-13 doi: 10.11781/sysydz199601001
AI Huaguo, LAN Linying, ZHANG Keyin, et al. The characteristics of the unconformity on the top of precarboniferous and its constraints on oil/gas behavionr in Tarim Basin [J]. Experimental Petroleum Geology, 1996, 18(1): 1-13. doi: 10.11781/sysydz199601001
[8] 郭维华, 牟中海, 赵卫军, 等. 准噶尔盆地不整合类型与油气运聚关系研究[J]. 西南石油学院学报, 2006, 28(2):1-3,5
GUO Weihua, MOU Zhonghai, ZHAO Weijun, et al. Research on the relation of unconformity type with oil and gas migration accumulation at Junggar basin [J]. Journal of Southwest Petroleum Institute, 2006, 28(2): 1-3,5.
[9] 吴亚军, 张守安, 艾华国. 塔里木盆地不整合类型及其与油气藏的关系[J]. 新疆石油地质, 1998, 19(2):101-105
WU Yajun, ZHANG Shou’an, AI Huaguo. The unconformity types and their relations with oil/gas reservoirs in Tarim Basin [J]. Xinjiang Petroleum Geology, 1998, 19(2): 101-105.
[10] 周瑶琪, 陆永潮, 李思田, 等. 间断面缺失时间的计算问题: 以贵州紫云上二叠统台地边缘礁剖面为例[J]. 地质学报, 1997, 71(1):7-17
ZHOU Yaoqi, LU Yongchao, LI Sitian, et al. The missing time calculation of the hiatus surface: a case stude of the upper Permian reefs section at the platform margin, Ziyun, Guizhou [J]. Acta Geologica Sinica, 1997, 71(1): 7-17.
[11] Strand K. Sequence stratigraphy of the Karelian formations (2.4-2.0 Ga) of the Fennoscandian Shield-Significance of major unconformities [J]. Marine and Petroleum Geology, 2012, 33(1): 117-126. doi: 10.1016/j.marpetgeo.2011.10.004
[12] 常波涛. 陆相盆地中不整合体系与油气的不均一性运移[J]. 石油学报, 2006, 27(5):19-23 doi: 10.3321/j.issn:0253-2697.2006.05.003
CHANG Botao. Relationship between unconformity system and heterogeneous migration of petroleum in continental basins [J]. Acta Petrolei Sinica, 2006, 27(5): 19-23. doi: 10.3321/j.issn:0253-2697.2006.05.003
[13] 高长海, 彭浦, 李本琼. 不整合类型及其控油特征[J]. 岩性油气藏, 2013, 25(6):1-7 doi: 10.3969/j.issn.1673-8926.2013.06.001
GAO Changhai, PENG Pu, LI Benqiong. Unconformity types and their constraints on hydrocarbon behavior [J]. Lithologic Reservoirs, 2013, 25(6): 1-7. doi: 10.3969/j.issn.1673-8926.2013.06.001
[14] Young G M, Caldwell W G E. A new look at an old unconformity: field and geochemical data from James Hutton's original unconformity on the Isle of Arran, Scotland [J]. Proceedings of the Geologists' Association, 2009, 120(1): 65-75. doi: 10.1016/j.pgeola.2009.03.004
[15] 高长海, 查明, 曲江秀, 等. 柴达木盆地东部不整合结构的地球物理响应及油气地质意义[J]. 石油学报, 2007, 28(6):32-36 doi: 10.3321/j.issn:0253-2697.2007.06.007
GAO Changhai, ZHA Ming, QU Jiangxiu, et al. Geophysical response of unconformities and petroleum geological significance in the eastern Qaidam Basin [J]. Acta Petrolei Sinica, 2007, 28(6): 32-36. doi: 10.3321/j.issn:0253-2697.2007.06.007
[16] 侯连华, 罗霞, 王京红, 等. 火山岩风化壳及油气地质意义: 以新疆北部石炭系火山岩风化壳为例[J]. 石油勘探与开发, 2013, 40(3):257-265,274 doi: 10.11698/PED.2013.03.01
HOU Lianhua, LUO Xia, WANG Jinghong, et al. Weathered volcanic crust and its petroleum geologic significance: a case study of the Carboniferous volcanic crust in northern Xinjiang [J]. Petroleum Exploration and Development, 2013, 40(3): 257-265,274. doi: 10.11698/PED.2013.03.01
[17] 邹才能, 侯连华, 杨帆, 等. 碎屑岩风化壳结构及油气地质意义[J]. 中国科学:地球科学, 2014, 57(12):3015-3026 doi: 10.1007/s11430-014-4983-4
ZOU Caineng, HOU Lianhua, YANG Fan, et al. Structure of weathered clastic crust and its petroleum potential [J]. Science China Earth Sciences, 2014, 57(12): 3015-3026. doi: 10.1007/s11430-014-4983-4
[18] 何登发. 塔里木盆地的地层不整合面与油气聚集[J]. 石油学报, 1995, 16(3):14-21 doi: 10.3321/j.issn:0253-2697.1995.03.019
HE Dengfa. Unconformities and oil and gas accumulation in Tarim Basin [J]. Acta Petrolei Sinica, 1995, 16(3): 14-21. doi: 10.3321/j.issn:0253-2697.1995.03.019
[19] Prather B E. Controls on reservoir distribution, architecture and stratigraphic trapping in slope settings [J]. Marine and Petroleum Geology, 2003, 20(6-8): 529-545. doi: 10.1016/j.marpetgeo.2003.03.009
[20] 李军, 刘丽峰, 赵玉合, 等. 古潜山油气藏研究综述[J]. 地球物理学进展, 2006, 21(3):879-887 doi: 10.3969/j.issn.1004-2903.2006.03.028
LI Jun, LIU Lifeng, ZHAO Yuhe, et al. A review of study on ancient buried hill reservoir [J]. Progress in Geophysics, 2006, 21(3): 879-887. doi: 10.3969/j.issn.1004-2903.2006.03.028
[21] 徐长贵, 于海波, 王军, 等. 渤海海域渤中19-6大型凝析气田形成条件与成藏特征[J]. 石油勘探与开发, 2019, 46(1):25-38 doi: 10.11698/PED.2019.01.03
XU Changgui, YU Haibo, WANG Jun, et al. Formation conditions and accumulation characteristics of Bozhong 19-6 large condensate gas field in offshore Bohai Bay Basin [J]. Petroleum Exploration and Development, 2019, 46(1): 25-38. doi: 10.11698/PED.2019.01.03
[22] Araibi A, Stow D, Lever H, et al. The role of the Mid-Cimmerian unconformity on the quality of the underlying Skagerrak sandstone reservoir in the Kittiwake Field, central North Sea [J]. Energy Geoscience, 2021, 2(4): 254-273. doi: 10.1016/j.engeos.2021.07.003
[23] 何登发. 不整合面的结构与油气聚集[J]. 石油勘探与开发, 2007, 34(2):142-149,201 doi: 10.3321/j.issn:1000-0747.2007.02.003
HE Dengfa. Structure of unconformity and its control on hydrocarbon accumulation [J]. Petroleum Exploration and Development, 2007, 34(2): 142-149,201. doi: 10.3321/j.issn:1000-0747.2007.02.003
[24] 吴孔友, 查明, 洪梅. 准噶尔盆地不整合结构模式及半风化岩石的再成岩作用[J]. 大地构造与成矿学, 2003, 27(3):270-276 doi: 10.3969/j.issn.1001-1552.2003.03.009
WU Kongyou, ZHA Ming, HONG Mei. Structural models of unconformity and recurrent diagenesis of semi-weathering rock in Junggar Basin [J]. Geotectonica et Metallogenia, 2003, 27(3): 270-276. doi: 10.3969/j.issn.1001-1552.2003.03.009
[25] 李晓燕, 蒋有录, 陈涛. 风化粘土层-半风化岩石型不整合的矿物学、地球化学特征[J]. 地球科学—中国地质大学学报, 2009, 34(3):428-434 doi: 10.3799/dqkx.2009.048
LI Xiaoyan, JIANG Youlu, CHEN Tao. Mineralogical and geochemical characteristics of unconformity structure with weathered clay and sapropelic rock [J]. Earth Science—Journal of China University of Geosciences, 2009, 34(3): 428-434. doi: 10.3799/dqkx.2009.048
[26] 宋明水, 赵乐强, 吴春文, 等. 准噶尔盆地车排子地区石炭系顶部风化壳结构及其控藏作用[J]. 石油与天然气地质, 2016, 37(3):313-321 doi: 10.11743/ogg20160303
SONG Mingshui, ZHAO Leqiang, WU Chunwen, et al. Structure and reservoir-controlling of top Carboniferous weathering crust in Chepaizi area, Junggar Basin [J]. Oil & Gas Geology, 2016, 37(3): 313-321. doi: 10.11743/ogg20160303
[27] 杨德相, 李振明, 田建章, 等. 廊固凹陷奥陶系潜山不整合输导特征与油气优势运聚方向[J]. 地质学报, 2021, 95(8):2575-2589 doi: 10.3969/j.issn.0001-5717.2021.08.020
YANG Dexiang, LI Zhenming, TIAN Jianzhang, et al. Unconformity characteristics and the dominant migration and accumulation direction of the Ordovician buried hill in the Langgu depression [J]. Acta Geologica Sinica, 2021, 95(8): 2575-2589. doi: 10.3969/j.issn.0001-5717.2021.08.020
[28] 王晨杰, 张新涛, 徐春强, 等. 渤中凹陷北部中生界火山岩储层发育特征及主控因素[J]. 中国海上油气, 2021, 33(3):48-57
WANG Chenjie, ZHANG Xintao, XU Chunqiang, et al. Development characteristics and main controlling factors of Mesozoic volcanic reservoirs in northern Bozhong sag [J]. China Offshore Oil and Gas, 2021, 33(3): 48-57.
-
