南海北部陆架早—中中新世古珠江河道发育特征及汇流冲刷模式

林理娥, 卓海腾, 冯进, 李智高, 苏明, 王英民, 雷亚平, 林智轩, 杨荣南. 南海北部陆架早—中中新世古珠江河道发育特征及汇流冲刷模式[J]. 海洋地质与第四纪地质, 2023, 43(2): 31-44. doi: 10.16562/j.cnki.0256-1492.2022090601
引用本文: 林理娥, 卓海腾, 冯进, 李智高, 苏明, 王英民, 雷亚平, 林智轩, 杨荣南. 南海北部陆架早—中中新世古珠江河道发育特征及汇流冲刷模式[J]. 海洋地质与第四纪地质, 2023, 43(2): 31-44. doi: 10.16562/j.cnki.0256-1492.2022090601
LIN Li’e, ZHUO Haiteng, FENG Jin, LI Zhigao, SU Ming, WANG Yingmin, LEI Yaping, LIN Zhixuan, YANG Rongnan. Seismic sedimentary characteristics of the Ancient Pearl River system and its depositional model of confluence scours, northern shelf of the South China Sea in Early-Mid Miocene[J]. Marine Geology & Quaternary Geology, 2023, 43(2): 31-44. doi: 10.16562/j.cnki.0256-1492.2022090601
Citation: LIN Li’e, ZHUO Haiteng, FENG Jin, LI Zhigao, SU Ming, WANG Yingmin, LEI Yaping, LIN Zhixuan, YANG Rongnan. Seismic sedimentary characteristics of the Ancient Pearl River system and its depositional model of confluence scours, northern shelf of the South China Sea in Early-Mid Miocene[J]. Marine Geology & Quaternary Geology, 2023, 43(2): 31-44. doi: 10.16562/j.cnki.0256-1492.2022090601

南海北部陆架早—中中新世古珠江河道发育特征及汇流冲刷模式

  • 基金项目: 广东省自然科学基金“南海珠江口陆坡区上新世以来富砂质深水沉积体系及其水合物储层潜力”(2019A151501078);中海石油(中国)有限公司科研项目“珠江口盆地(东部)浅水区早-中中新世精细沉积相及多成因岩性圈闭潜力”(CCL2021SZPS0113);国家自然科学基金“南海珠江口陆架区第四纪高精度层序地层构型、时空差异及控制因素”(41706050)
详细信息
    作者简介: 林理娥(1999—),女,硕士研究生,海洋地质专业, E-mail:linle3@mail2.sysu.edu.cn
    通讯作者: 卓海腾(1986—),男,博士,副教授,主要从事层序地层学、沉积学和海洋地质学的教学和科研工作,E-mail:zhuoht3@mail.sysu.edu.cn
  • 中图分类号: P736

Seismic sedimentary characteristics of the Ancient Pearl River system and its depositional model of confluence scours, northern shelf of the South China Sea in Early-Mid Miocene

More Information
  • 河道体系是侵蚀和沉积物搬运的重要通道,控制了大陆边缘源汇体系中砂体总体的输送和分布格局,并可有效指示古代构造活动、物源供给、气候变迁和海平面变化等丰富地质信息。研究基于高分辨率的三维地震、钻测井资料,结合层序划分方法和地震沉积学综合分析手段,揭示了南海北部珠一坳陷早—中中新世古珠江分流河道体系的类型和展布特征,并且以典型层序为例精细揭示了海平面变化控制下河道类型由辫状向曲流的转换。同时,在研究区地震剖面上识别到多处异常下切现象,经研究可解释为辫状河道内的汇流冲刷,其典型特征为:① 下切深度局部增大;② 平面近似圆形或椭圆形;③ 内部为砂质充填。虽然汇流冲刷结构在地震剖面特征上与“传统”意义的下切谷极易混淆,但在沉积特征和成因上存在较大差别,因此,对它的识别有助于避免层序界面的错误判别,并且其后期充填的河道砂体具有局限分布的特点,易于在后期海侵泥岩的覆盖下形成潜在的岩性圈闭新类型。

  • 加载中
  • 图 1  珠江口盆地珠一坳陷构造区划图[3]

    Figure 1.

    图 2  珠江口盆地珠一坳陷地层柱状图[2]

    Figure 2.

    图 3  研究区NW-SE向地震剖面图及其层序地层界面划分

    Figure 3.

    图 4  珠一坳陷NE-SW向早—中中新世的连井剖面图

    Figure 4.

    图 5  研究区不同沉积相的岩芯照片

    Figure 5.

    图 6  层序SQ17.1低位体系域发育的大型辫状河道体系

    Figure 6.

    图 7  层序SQ15.0低位体系域发育的中型河道体系

    Figure 7.

    图 8  层序SQ17.1高位体系域发育的小型河道体系

    Figure 8.

    图 9  异常下切现象示意图

    Figure 9.

    图 10  层序SQ17.1发育的大型辫状河道体系的异常下切作用的细节刻画

    Figure 10.

    图 11  辫状河道汇流冲刷沉积模式图[31]

    Figure 11.

    表 1  河道体系类型的划分

    Table 1.  Classification of the river system types

    河道类型河流宽度弯曲度地震反射特征地震地貌特征
    大型辫状分流河道平均宽度>10 km
    最大宽度可达30 km
    较低强-中振幅、好-中等连续、
    平行-亚平行反射
    内部河道交切明显,呈现“辫状”
    中型河道0.5~7 km中等强-中振幅、中等连续性辫状河道体系末端分支河;下切谷:
    延伸较远且地震剖面见明显下切
    小型曲流河道100~300 m较高单点状的强振幅且连续性较好单支河道孤立发育
    下载: 导出CSV

    表 2  汇流冲刷和下切谷的识别特征

    Table 2.  The distinctive features between confluence scour and incised valley

    平面形态特征下切深度充填特征岩性特征层序意义
    汇流冲刷近似圆形或椭圆形,分布局限,宽度约0.5~5 km中等单期充填中-粗河道砂岩无明显层序意义
    下切谷明显河道状,延伸距离远较大多期充填中-粗河道砂岩至海相泥岩,岩性多样层序边界标志
    下载: 导出CSV
