Structural and sedimentary evolution of passive continental margin basins around the Indian Ocean and its effects on hydrocarbon accumulation
-
摘要:
环印度洋周缘被动陆缘盆地油气资源潜力巨大，是当前世界油气勘探的热点地区之一。本文基于IHS商业数据库和前人研究成果等资料，厘定了环印度洋地区被动陆缘盆地构造演化史，分析了构造演化对盆地充填结构和成藏要素的影响，并利用蒙特卡洛模拟法评估了盆地油气资源潜力，优选了有利勘探区带。研究结果表明，环印度洋地区被动陆缘盆地经历了3期构造演化阶段，依次为裂前期、同裂谷期和被动陆缘期。根据盆地演化的主导阶段，研究区内被动陆缘盆地可分为拉张边缘裂前发育型、拉张边缘断坳叠置型、拉张边缘坳陷发育型和转换边缘断坳叠置型。盆地内烃源岩主要发育于裂前期—被动陆缘早期，不同地区的主力烃源岩层系不同；储集岩主要发育于裂前期—被动陆缘晚期；区域盖层则主要发育于被动陆缘期。资源评价结果显示，研究区内重点被动陆缘盆地待发现石油、天然气和凝析油可采资源量（均值）分别为4.49×108 t，15.86×1012 m3和5.23×108 t，折合成油当量137.69×108 t。澳大利亚西北陆架北卡那封盆地裂前中—上三叠统区带、东非地区鲁伍马盆地北部和坦桑尼亚盆地南部中白垩统—新近系三角洲-深水扇区带是最有潜力的勘探区带。
Abstract:The passive continental margin basins around the Indian Ocean have huge exploration potential for oil and gas resources, and they are becoming hotspots for current global oil and gas exploration. With IHS commercial data and previous research results, this study defined the tectonic evolution history of passive continental margin basins around the Indian Ocean, analyzed the influence of tectonic evolution on filling structure and hydrocarbon accumulation in the basins, evaluated the resource potential by Monte Carlo statistical methodology and predicted favorable exploration zones. The results show that the passive continental margin basins around the Indian Ocean have experienced three stages of tectonic evolution, which are pre-rift, syn-rift, and passive continental margin stages. According to the dominant stage of evolution, the passive continental margin basins can be divided into four types: extensional marginal pre-rift, extensional marginal fault depression superimposition, extensional marginal depression and transform marginal fault depression superimposition. The source rocks in the passive continental margin basins are mainly developed from the pre-rift to the early passive continental margin stages, and the main source rocks vary by region. Reservoirs are mainly developed between the pre-rift and late passive continental margin stages; regional seals were mainly developed in the passive continental margin stage. The resource evaluation indicates that the undiscovered oil and gas resources (mean value) in the main passive continental margin basins around the Indian Ocean are 4.49×108 t of oil, 15.86×1012 m3 of natural gas, and 5.23×108 t of condensate, amounting to 137.69×108 t. The pre-rift Middle-Upper Triassic zone in North Carnarvon Basin, Northwest Shelf of Australia, the Middle Cretaceous-Neogene delta-deep water fan zone in northern Ruvuma Basin and southern Tanzania Basin, East Africa, are the most promising exploration zones.
-
-
图 1 中二叠世以来东冈瓦纳大陆板块重塑图（据Reeves et al., 2016修改）
Figure 1.
图 2 环印度洋地区重点被动陆缘盆地不同演化阶段地层对比图（修改自朱伟林等, 2012; IHS, 2015a, 2015b, 2017a, 2017b）
Figure 2.
图 4 环印度洋地区不同演化阶段古地理图（据Cao et al., 2017修改）
Figure 4.
图 8 东非地区被动陆缘晚期沉积相图（据IHS, 2017a修改）
Figure 8.
表 1 环印度洋地区重点被动陆缘盆地石油地质特征一览表（据朱伟林等, 2012; 刘铁树等, 2015; IHS, 2015a, 2015b, 2017a, 2017b; 秦雁群等, 2017; Boote et al., 2019；崔哿等, 2020整理总结）
Table 1. Geological characteristics of oil and gas in main passive continental margin basins around the Indian Ocean
地区 盆地 烃源岩 储集岩 盖层 时代 岩性 TOC/% Ro/% 干酪根类型 时代 岩性 孔隙度/% 渗透率/mD 沉积相 岩性 澳大利亚西北陆架 北卡那封 三叠系—
白垩系泥岩、页岩 1.0～5.0 0.3～6.0 Ⅱ/Ⅲ 三叠系—
白垩系砂岩 平均值>25 介于几十
到几百河流-三角洲沉积 泥岩、页岩 布劳斯 侏罗系—
白垩系泥岩、页岩 1.0～2.0 0.5～1.1 Ⅱ/Ⅲ 侏罗系、
白垩系砂岩 河流-三角洲沉积 泥岩、页岩 波拿巴 石炭系—
二叠系、
侏罗系页岩 0.1～13.9 0.35～1.5 Ⅱ/Ⅲ 三叠系—
白垩系砂岩 4.2～7.3 最大不超过
1 000，大多
数小于6河流-三角洲沉积 页岩 东非地区 索马里 二叠系—
古近系泥岩、页岩和碳酸盐岩 0.3～17.4 1.0～1.3 Ⅱ/Ⅲ 石炭系—
二叠系、侏罗系、古近系砂岩、
碳酸盐岩7～19.4 <10 三角洲和深水浊积扇沉积 泥岩、页岩 坦桑尼亚 二叠系—
白垩系碳酸盐岩、
页岩0.2～27 0.50～1.5 Ⅱ/Ⅲ 侏罗系—
新近系砂岩、
碳酸盐岩5～30 最大400 三角洲、浅海相沉积 页岩 鲁伍马 二叠系、侏罗系—古近系 页岩 1.34～12 0.5～2.13 Ⅱ/Ⅲ 二叠系—
新近系砂岩、
碳酸盐岩12～25 20～4 000 三角洲、浅海-深海相沉积 页岩 马任加 三叠系—
白垩系碳酸盐岩、
页岩1.2～7.1 Ⅱ/Ⅲ 石炭系—
白垩系砂岩、
碳酸盐岩三角洲和深水浊积扇沉积 页岩 穆龙达瓦 二叠系—
白垩系泥岩、页岩和碳酸盐岩 0.6～7.65 Ⅱ/Ⅲ 二叠系—
白垩系砂岩、
碳酸盐岩平均值23 100～5 000 三角洲和深水浊积扇沉积 页岩 南亚地区 克里希纳-
戈达瓦里石炭系—
二叠系、白垩系—古近系页岩 1.28～26 0.51～1.46 Ⅱ/Ⅲ 二叠系—
新近系砂岩、
碳酸盐岩9～23 20～10 000 三角洲和深水浊积扇沉积 页岩 孟加拉 古新统—
渐新统页岩 0.2～1.6 约0.65 Ⅱ/Ⅲ 二叠系、渐新统—中新统 砂岩、
碳酸盐岩10～35 5～1 500 三角洲、浅海相沉积 泥岩、页岩 孟买 古新统—
始新统泥岩、页岩 1～2 Ⅰ/Ⅱ 始新统—
中新统砂岩、碳酸盐岩、粉砂岩 14～22 60～370 三角洲、浅海相沉积 页岩
下载: 导出CSV
-
[1] 白国平, 邓超, 陶崇智, 等. 2013. 澳大利亚西北陆架油气分布规律与主控因素研究[J]. 现代地质, 27（05）: 1225−1232
Bai G P, Deng C, Tao C Z, et al., Hydrocarbon distribution patterns and controlling factors in North West Shelf, Australia[J]. Geoscience, 27（05）: 1225−1232（in Chinese with English abstract）.
[2] 白国平, 殷进垠. 2007. 澳大利亚北卡那封盆地油气地质特征及勘探潜力分析[J]. 石油实验地质, 29（3）: 253−257
Bai G P, Yin J Y. 2007. Petroleum geology features and exploration potential analyses of North Carnavon Basin, Australia[J]. Petroleum geology and experiment, 29（3）: 253−257（in Chinese with English abstract）.
[3] Bastia R, Radhakrishna M. 2012. Basin evolution and petroleum prospectivity of the continental margins of India[M]. Amsterdam: Elsevier.
[4] Boote D, Mike R, Andy C, et al., 2019. Using basin modelling to examine the origin of the hydrocarbons within the deepwater Rovuma Basin of Tanzania, Mozambique and the Comoros[C] // PESGB−HGS Africa E&P Conference, London, 1st−2nd October （Extended Abstract）.
[5] Burke K, Macgregor D S, Cameron N R. 2003. Africa’s petroleum systems: four tectonic ‘Aces’ in the past 600 million years[J]. Geological Society, London, Special Publications, 207（1）: 21−60.
[6] Catuneanu O, Wopfner H, Eriksson P G, et al., 2005. The Karoo Basins of south−central Africa[J]. Journal of African Earth Sciences, 43（1−3）: 211−253.
[7] Cao W C, Zahirovic S, Flament N, et al., 2017. Improving global paleogeography since the late Paleozoic using paleobiology[J]. Biogeosciences Discussions, 14（23）: 1−24.
[8] 崔志骅. 2016. 东非海岸重点盆地油气地质特征及勘探潜力分析[D]. 浙江大学.
Cui Z H. 2016. Evaluation on characteristics of petroleum geology and exploration potential of coastal key basin in East Africa[D]. Zhejiang University.
[9] 崔哿, 金爱民, 邬长武, 等. 2020. 东非海岸构造演化及其对南、北主要富油气盆地控藏作用对比[J]. 海洋地质与第四纪地质, 40（01）: 104−113
Cui G, Jin A M, Wu C W, et al., 2020. Tectonic evolution of East Africa coast and comparison of hydrocarbon accumulation conditions in the north and south petroliferous basins[J]. Marine Geology & Quaternary Geology, 40（01）: 104−113（in Chinese with English abstract）.
[10] Emmel B, Kumar R, Ueda K, et al., 2011. Thermochronological history of an orogen−passive margin system: an example from Northern Mozambique[J]. Tectonics, 30（2）: 58−66.
[11] 冯杨伟, 屈红军, 张功成, 等. 2011. 澳大利亚西北陆架深水盆地油气地质特征[J]. 海洋地质与第四纪地质, 31（04）: 131−140.
Feng Y W, Qu H J, Zhang G C, et al., 2011. Hydrocarbon distribution of deep−water basins in Northwest Shelf of Australia[J]. Geological Science and Technology Information, 30（6）: 99−104（in Chinese with English abstract）.
[12] 冯杨伟, 屈红军, 张瑾爱, 等. 2016. 印度东部大陆边缘克里希纳—戈达瓦里盆地油气分布规律[J]. 西北大学学报（自然科学版）, 46（03）: 408−414
Feng Y W, Qu H J, Zhang J A, et al., 2016. Distribution of hydrocarbon fields in Krishna−Godavari Basin, East India margin[J]. Journal of Northwest University （Natural Science Edition）, 46（03）: 408−414（in Chinese with English abstract）.
[13] 高济稷, 白国平, 秦养珍, 等. 2010. 蒙特卡洛模拟法在也门马里卜—夏布瓦盆地中的应用[J]. 石油实验地质, 32（3）: 305−308
Gao J J, Bai G P, Qin Y Z, et al., 2010. Monte carlo simulation − a case study of Marib−Shabwa Basin in Yemen[J]. Petroleum Geology & Experiment, 32（3）: 305−308（in Chinese with English abstract）.
[14] Gupta S K. 2006. Basin architecture and petroleum system of Krishna Godavari Basin, east coast of India[J]. The Leading Edge, 25（7）: 830−837.
[15] IHS Energy Group. 2015a. Krishna−Godavari Basin, India[DB]. Basin Monitor. Commercial database available from IHS Energy Group, 15 Inverness Way East, Englewood, Colorado, 80112, USA.
[16] IHS Energy Group. 2015b. Bombay Basin, India[DB]. Basin Monitor. Commercial database available from IHS Energy Group, 15 Inverness Way East, Englewood, Colorado, 80112, USA.
[17] IHS Energy Group. 2017a. Passive margin basins of East Africa[DB]. Basin Monitor. Commercial database available from IHS Markit, 15 Inverness Way East, Englewood, Colorado, 80112, USA.
[18] IHS Energy Group. 2017b. North West Shelf, Australia, Indian Ocean Region[DB]. Basin Monitor. Commercial database available from IHS Energy Group, 15 Inverness Way East, Englewood, Colorado, 80112, U. S. A.
[19] 康洪全, 逄林安, 贾怀存, 等. 2018. 澳大利亚西北陆架北卡那封盆地资源潜力评价[J]. 石油实验地质, 40（06）: 808−817
Kang H Q, Pang L A, Jia H C, et al., 2018. Resource assessment of North Carnarvon Basin on the Northwest Shelf of Australia[J]. Petroleum Geology & Experiment, 40（06）: 808−817（in Chinese with English abstract）.
[20] Khan M S R, Sharma A K, Sahota S K, et al., 2000. Generation and hydrocarbon entrapment within Gondwanan sediments of the Mandapeta area, Krishna−Godavari Basin, India[J]. Organic Geochemistry, 31: 1495−1507.
[21] 刘伟, 何登发, 王兆明, 等. 2011. 澳大利亚西北大陆架大气田的形成条件与分布特征[J]. 中国石油勘探, 16（03）: 68−75+8
Liu W, He D F, Wang Z M, et al., 2011. Formation and distribution of giant gas fields in Northwest Shelf of Australia[J]. China Petroleum Exploration, 16（03）: 68−75+8（in Chinese with English abstract）.
[22] 刘铁树, 袭著纲, 骆宗强. 2015. 孟加拉盆地油气分布特征及主控因素[J]. 石油实验地质, 37（03）: 361−366+401.
Liu T S, Xi Z G, Luo Z Q. 2015. Hydrocarbon distribution and major controlling actors of Bengal Basin, Bangladesh[J]. Petroleum Geology & Experiment, 37（03）: 361−366+401（in Chinese with English abstract）.
[23] Maende A, Mpanju F. 2003. Geochemistry and source rock potential of East African passive margin[R]. East African Petroleum Conference, 5−7 March, Nairobi, Kenya, 1−35.
[24] 秦雁群, 张光亚, 计智峰, 等. 2017. 印度东部盆地群地质特征、油气成藏与深水区勘探潜力[J]. 石油勘探与开发, 44（05）: 691 − 703
Qin Y Q, Zhang G Y, Ji Z F, et al., 2017. Geological features, hydrocarbon accumulation and deep−water potential of East Indian basins[J]. Petroleum Exploration and Development, 44（05）: 691 − 703（in Chinese with English abstract）.
[25] Preston J C, Edwards D S. 2000.The petroleum geochemistry of oils and source rocks from the Northern Bonaparte Basin, offshore Northern Australia[J]. APPEA Journal, 40（6）: 257−282.
[26] Reeves C. 2014. The position of Madagascar within Gondwana and its movements during Gondwana dispersal[J]. Journal of African Earth Sciences, 94: 45−57.
[27] Reeves J M, Chivas A R, Garcia A, et al., 2016. Palaeoenvironmental change in the Gulf of Carpentaria （Australia） since the last interglacial based on Ostracoda[J]. Palaeogeography, Palaeoclimatology, Palaeoecology, 246: 163−187.
[28] Rollet N, Grosjean E, Edwards D, et al., 2019. Triassic petroleum systems on the central North West Shelf – Learnings from the greater Phoenix area seismic mapping and geochemical studies[J]. ASEG Extended Abstracts, （1）, 1−7.
[29] Rao G N. 2001. Sedimentation, stratigraphy and petroleum potential of Krishna−Godavari basin, East Coast of India[J]. AAPG Bulletin, 85（9）: 1623−1643.
[30] Spry T B, Ward I. 1997. The Gwydion discovery: a new play fairway in the Browse basin[J]. APPEA Journal, 37（1）: 87−104.
[31] 孙丰楠, 张凯逊, 韩淑琴, 等. 2020. 北乌斯丘尔特盆地成藏组合分析与油气资源潜力评价[J]. 东北石油大学学报, 44（06）: 43 − 52+7 − 8
Sun F N, Zhang K X, Han S Q, et al., 2020. Analysis of petroleum play and resources evaluation in the North Ustyurt Basin[J]. Journal of Northeast Petroleum University, 44（06）: 43 − 52+7 − 8（in Chinese with English abstract）.
[32] 谭富文, 杨平, 王正和, 等. 2020. 尼泊尔西部代莱克（Dailekh）地区石油地质条件分析[J]. 沉积与特提斯地质, 40（03）: 87 − 95
Tan F W, Yang P, Wang Z H, et al., 2020. Petroleum geological conditions in Dailekh area, western Nepal[J]. Sedimentary Geology and Tethyan Geology, 40（03）: 87 − 95（in Chinese with English abstract）.
[33] 田纳新, 殷进垠, 陶崇智, 等. 2017. 中东—中亚地区重点盆地油气地质特征及资源评价[J]. 石油与天然气地质, 38（3）: 582 − 591
Tian N X, Yin J Y, Tao C Z, et al., 2017. Petroleum geology and resources assessment of major basins in Middle East and Central Asia[J]. Oil & Gas Geology, 38（3）: 582 − 591（in Chinese with English abstract）.
[34] Torsvik T H, Cocks L. 2013. Gondwana from top to base in space and time[J]. Gondwana Research, 24（3−4）: 999−1030.
[35] Walker T R. 2007. Deepwater and frontier exploration in Australia: Historical perspectives, present environment and likely future trends[J]. The APPEA Journal, 47（1）: 15−38.
[36] 汪伟光, 童晓光, 喻莲, 等. 2013. 澳大利亚西北大陆架油气分布及成藏主控因素[J]. 西南石油大学学报（自然科学版）, 35（01）: 10−18
Wang W G, Tong X G, Yu L, et al., 2013. Oil and gas distribution features and main controlling factors of northwest shelf, Australia[J]. Journal of Southwest Petroleum University (Science & Technology Edition), 35（01）: 10−18（in Chinese with English abstract）.
[37] 王正和, 谭富文, Sudhir R, 等. 2022. 尼泊尔及南侧邻区元古宙以来的构造−沉积演化[J]. 地球科学, 47（02）: 405−417
Wang Z H, Tan F W, Sudhir R, et al., 2022. The tectonosedimentary evolution since Proterozoic in Nepal and its southern adjacent areas[J]. Earth Science, 47（02）: 405−417（in Chinese with English abstract）.
[38] 温志新, 王兆明, 胡湘瑜, 等. 2011. 澳大利亚西北大陆架被动大陆边缘盆地群大气田分布与主控因素[J]. 海洋地质前沿, 27（12）: 41−47
Wen Z X, Wang Z M, Hu X Y, et al., 2011. Distribution and key controlling factors of giant gas fields in passive marginal basins of Northwest Australia[J]. Marine Geology Frontiers, 27（12）: 41−47（in Chinese with English abstract）.
[39] 汪焰, 申本科. 2012. 澳大利亚北卡那封盆地Rankin台地天然气富集原因初探[J]. 中国石油勘探, 17（03）: 77−82+8
Wang Y, Shen B K. 2012. Study on causes of gas accumulation in Rankin Platform, North Carnarvon Basin in Australia[J]. China Petroleum Exploration, 17（03）: 77−82+8（in Chinese with English abstract）.
[40] 王大鹏, 白国平, 陆红梅, 等. 2016. 扎格罗斯盆地含油气系统分析与资源潜力评价[J]. 现代地质, 30（02）: 361−372
Wang D P, Bai G P, Lu H M, et al., 2016. Analysis of petroleum systems and resources evaluation in the Zagros Foreland Basin[J]. Geoscience, 30（02）: 361−372（in Chinese with English abstract）.
[41] 王大鹏, 殷进垠, 田纳新, 等. 2017. 塞内加尔盆地成藏组合划分与资源潜力评价[J]. 现代地质, 31（06）: 1201−1213
Wang D P, Yin J Y, Tian N X, et al., 2017. Division and resource evaluation of hydrocarbon plays in the Senegal Basin, West Africa[J]. Geoscience, 31（06）: 1201−1213（in Chinese with English abstract）.
[42] 许晓明, 于水, 骆宗强, 等. 2013. 澳大利亚西北陆架天然气富集的主控因素[J]. 海洋地质前沿, 29（09）: 32−36
Xu X M, Yu S, Luo Z Q, et al., 2013. Main factors for gas accumulation on North West Shelf of Australia[J]. Marine Geology Frontiers, 29（09）: 32−36（in Chinese with English abstract）.
[43] 杨平, 谭富文, 施美凤, 等. 2021. 尼泊尔低喜马拉雅推覆带油源对比及油气成藏[J]. 地质学报, 95（11）: 3426−3441
Yang P, Tan F W, Shi M F, et al., 2021. Oil−source correlation and hydrocarbon accumulation in the Lesser Himalayan belt of Nepal[J]. Acta Geologica Sinica, 95(11): 3426−3441（in Chinese with English abstract）.
[44] 杨婷, 康洪全, 刘东旭, 等. 2017. 北卡那封盆地沉积演化规律与烃源岩发育特征[J]. 西南石油大学学报（自然科学版）, 39（05）: 81−91
Yang T, Kang H Q, Liu D X, et al., 2017. The sedimentary facies evolution and the development characteristics of source rocks in North Carnarvon Basin, Australia[J]. Journal of Southwest Petroleum University (Science & Technology Edition), 39（05）: 81−91（in Chinese with English abstract）.
[45] 于璇, 侯贵廷, 代双河, 等. 2015. 东非大陆边缘构造演化与油气成藏模式探析[J]. 地质科技情报, 34（06）: 147−154+158
Yu X, Hou G T, Dai S H, et al., 2015. Tectonic evolution and hydrocarbon pooling patterns analysis in East Africa continental margin[J]. Geological Science and Technology Information, 34（06）: 147−154+158（in Chinese with English abstract）.
[46] 余一欣, 殷进垠, 郑俊章, 等. 2015. 阿姆河盆地成藏组合划分与资源潜力评价[J]. 石油勘探与开发, 42（06）: 750−756
Yu Y X, Yin J Y, Zheng J Z, et al., 2015. Division and resources evaluation of hydrocarbon plays in the Amu Darya Basin, Central Asia[J]. Petroleum Exploration and Development, 42（06）: 750−756（in Chinese with English abstract）.
[47] 朱伟林, 胡平, 江文荣. 等. 2012. 南亚−东南亚含油气盆地[M]. 北京: 科学出版社.
Zhu W L, Hu P, Jiang W R, et al., 2012. South Asia and southeast Asia petroliferous basin[M]. Beijing: Science Press.
[48] 朱伟林, 崔旱云, 吴培康, 等. 2017. 被动大陆边缘盆地油气勘探新进展与展望[J]. 石油学报, 38（10）: 1099−1109
Zhu W L, Cui H Y, Wu P K, et al., 2017. New development and outlook for oil and gas exploration in passive continental margin basins[J]. Acta Petrolei Sinica, 38（10）: 1099−1109（in Chinese with English abstract）.
[49] 张光亚, 刘小兵, 温志新, 等. 2015. 东非被动大陆边缘盆地构造—沉积特征及其对大气田富集的控制作用[J]. 中国石油勘探, 20（04）: 71−80
Zhang G Y, Liu X B, Wen Z X, et al., 2015. Structural and sedimentary characteristics of passive continental margin basins in East Africa and their effect on the formation of giant gas fields[J]. China Petroleum Exploration, 20（04）: 71−80（in Chinese with English abstract）.
[50] 张可宝, 史卜庆, 徐志强, 等. 2007. 东非地区沉积盆地油气潜力浅析[J]. 天然气地球科学, 18（6）: 869−874
Zhang K B, Shi B Q, Xu Z Q, et al., 2007. A study on petroleum geology and hydrocarbon potential in eastern Africa[J]. Natural Gas Geoscience, 18（6）: 869−874（in Chinese with English abstract）.
-
