Discussion about the Application of Separation Process in the Middling of a Copper-Nickel Sulfide Ore
-
摘要:
本文通过对金川硫化铜镍矿矿石性质的分析以及中矿单独再磨再选流程、两磨两选流程、两磨两选+中矿再磨流程应用前后指标的对比和流程分析，结合现场生产实际情况，分析其流程的特点、存在的问题，其分析结果认为，两磨两选工艺流程不论在总精矿镍品位还是在回收率指标上都优于中矿单独再磨再选流程。前者总精矿镍品位达到7.96%，比后者提高0.26%，镍回收率达到83.65%，比后者提高0.25%。两磨两选流程和两磨两选+中矿再磨流程对比后发现后者能使低精矿镍品位有较大幅度的提升，由实施前的3.95%提高到实施后的4.45%，同时总精矿镍品位由原来的8.061%提升到8.28%。
Abstract:Based on the analysis of copper-nickel sulfide ore, the comparison of indexes before and after the application of middling separate regrinding and reseparation process, two grinding and two separation process, two grinding and two separation + middling regrinding process and the analysis of the process. Combined with the actual production situation on site, the paper analyzes the problems existing in the characteristics of the process. The analysis results show that, two grinding and two separation process in both the total nickel concentrate grade and recovery index were superior to the middling separate regrinding and reseparation process. The former general nickel concentrate grade of 7.96%, 0.26% higher than that of the latter, nickel recovery rate reached 83.65%, 0.25% higher than the latter. Two grinding and two separation process and two grinding and two separation + middling regrinding process shows that the latter can make low nickel concentrate grade is greatly ascend, rose from 3.95% before the implementation to 4.45% after implementation, at the same time the total nickel concentrate grade from 8.061% to 8.28%
-
Key words:
- Copper-nickel sulfide ore /
- Beneficiation /
- Middling /
- Regrinding and reconcentration
-
-
表 1 两种流程指标对比分析结果
Table 1. Comparative analysis results of two processes
流程特点 原矿/
%总精矿镍
品位/%低精镍
品位/%总精镍回
收率/%中矿再磨单独
再选流程1.26 7.70 3.64 83.4 两段磨矿两段选别 1.21 7.96 4.18 83.65
下载: 导出CSV
表 2 两种流程指标数据情况
Table 2. Index data of two processes
项目 原矿品
位/%低精品
位/%总精品
位/%总回收
率/%两磨两选流程 1.363 3.95 8.061 85.68 两磨两选+中矿再磨 1.333 4.45 8.280 85.72
下载: 导出CSV
表 3 两种流程镍品位对比结果分析
Table 3. Comparison results analysis of two processes
产品二段粗选
泡沫/%二段一次
扫选泡沫/%二段二次扫选泡沫/% 二段二次
精选泡沫/%二段一次
尾矿/%两磨两选流程 1.7 1.18 1.41 3.4 1.41 两磨两选+中矿再磨 1.97 1.37 1.1 4.4 1.35
下载: 导出CSV
表 4 中矿再磨给料粒度组成及Ni金属含量分布
Table 4. Particle size composition and Ni content distribution of middlings regrinding feed
粒度/μm 产率/% 品位/% 金属分布率/% 累计金属分布率/% +96 3.00 1.32 2.98 2.98 −96+80 9.17 1.64 11.31 14.29 −80+74 2.17 1.67 2.72 17.02 −74+44.6 8.43 2.49 15.78 32.79 −44.6+28.8 34.11 1.48 37.96 70.75 −28.8+21.2 26.27 0.96 18.96 89.72 −21.2+15.0 10.59 0.92 7.33 97.04 −15+11.3 2.17 0.89 1.45 98.49 −11.3 4.09 0.49 1.51 100.00 合计 100.00 1.33 100.00 /
下载: 导出CSV
表 5 中矿再磨后产品粒度组成及Ni金属含量分布/%
Table 5. Particle size composition and Ni metal content distribution of middling products after regrinding
粒度/μm 产率/% 品位/% 金属分布率/% 累计金属分布率/% +96 2.29 1.37 2.39 2.39 −96+80 6.69 1.66 8.48 10.88 −80+74 1.78 1.60 2.17 13.05 −74+44.6 6.28 2.55 12.21 25.26 −44.6+28.8 30.42 1.56 36.23 61.48 −28.8+21.2 26.19 1.10 21.99 83.47 −21.2+15.0 9.83 1.08 8.10 91.57 −15+11.3 2.88 0.99 2.18 93.75 −11.3 13.64 0.60 6.25 100.00 合计 100.00 1.31 100.00 /
下载: 导出CSV
-
[1] 杨文彪, 张永梅. 粗精再磨工艺在某高铜镍比矿石选矿中的研究及应用[J]. 矿产综合利用, 2020(3):121-125. doi: 10.3969/j.issn.1000-6532.2020.03.020
YANG W B, ZHANG Y M. Research and application of rough concentrate and regrinding technology in beneficiation of a high copper nickel ratio ore[J]. Multipurpose Utilization of Mineral Resources, 2020(3):121-125. doi: 10.3969/j.issn.1000-6532.2020.03.020
[2] 来庆腾, 廖寅飞. 铜镍硫化矿浮选精矿降镁研究进展[J]. 矿产综合利用, 2017(5):7-11. doi: 10.3969/j.issn.1000-6532.2017.05.002
LAI Q T, LIAO Y F. Research progresser on reducing magnesium about flotation concentrate of copper-nickel sulfide ore[J]. Multipurpose Utilization of Mineral Resources, 2017(5):7-11. doi: 10.3969/j.issn.1000-6532.2017.05.002
[3] 邓伟, 王昌良, 韩跃新. 新型抑制剂用于铜镍矿选矿的工业实践[J]. 矿产综合利用, 2017(6):35-37.
DENG W, WANG C L, HAN Y X. Industrial practice of copper-nickel ore flotation by new depressant[J]. Multipurpose Utilization of Mineral Resources, 2017(6):35-37.
[4] 徐莺, 杨磊, 刘飞燕. 金川铜镍矿贫矿石选矿产品的工艺矿物学研究[J]. 矿产综合利用, 2013(3):53-55.
XU Y, YANG L, LIU F Y. Study on process mineralogy of mineral processing products in the low-grade ore at jinchuan[J]. Multipurpose Utilization of Mineral Resources, 2013(3):53-55.
[5] 张国范, 卢毅屏, 冯其明. 金川二矿区富矿石选矿新药剂应用研究[J]. 湖南有色金属, 2001, 17(5):6-7. doi: 10.3969/j.issn.1003-5540.2001.05.003
ZHANG G F, LU Y P, FENG Q M. Study on application of new reagent for beneficiation of Jinchuan rich ore in mining area No. 2[J]. Hunan Nonferrous Metals, 2001, 17(5):6-7. doi: 10.3969/j.issn.1003-5540.2001.05.003
[6] 曾新民. 金川镍铜矿选矿降镁工艺研究与生产实践[J]. 有色金属:选矿部分, 1996(1):1-5.
ZENG X M. Research and progresser on removal MgO from the flotation concentrate of jinchuan copper-nickel sulfide[J]. Nonferrous Metals(Mineral Processing Section), 1996(1):1-5.
[7] 吕晋芳, 童雄, 崔毅琦. 云南低品位铜镍矿选矿试验研究[J]. 矿产综合利用, 2011(3):26-28.
LV J F, TONG X, CUI Y Q. Experimental study on mineral processing technology for a low-grade copper-nicel ore from Yunnan[J]. Multipurpose Utilization of Mineral Resources, 2011(3):26-28.
-
