Recovery of Flake Graphite from KR Desulfurization Slag
-
摘要:
铁水脱硫过程中溶于铁水中的过饱和碳会以石墨的形式析出，本文针对铁水脱硫渣中含有石墨的特点，以煤油为捕收剂，2#油为起泡剂，采用浮选法进行回收，同时采用球磨、磁选对回收的石墨进行物理除杂，然后用盐酸、氢氟酸混酸进行化学提纯，制备得高纯鳞片石墨。研究表明：石墨回收率随着浮选剂投加量的增加先增加后减小，在煤油和2#油总投加量为1200 g/t、煤油∶2#油= 4∶1时，回收率超过97%；球磨使杂质从石墨表面剥离，磁选则降低石墨中的含铁物质，“球磨+磁选”处理可以使显著降低石墨中杂质含量，通过三次“球磨+磁选”后，石墨中的固定碳含量由58%提高到88%以上。混酸处理在较佳条件下可以将石墨的灰分降至0.03%，达到高纯石墨标准。扫描电镜分析表明回收的鳞片石墨与天然鳞片石墨在外形和结构上均无明显差异。
Abstract:In the desulfurization process of molten iron, the supersaturated carbon dissolved in molten iron precipitates in the form of graphite. In this paper, according to the characteristics of graphite contained in molten iron desulfurization slag, the flotation method was firstly used to recover the graphite with kerosene used as collector and No.2 oil used as foaming agent, and then the ball milling and magnetic separation process was used to physically remove the impurities of the recovered graphite, and finally the hydrochloric acid and hydrofluoric acid were used for chemically purification. With the result, high purity flake graphite was prepared. The results show that the graphite recovery firstly increases and then decreases with the increase of flotation agent dosage. When the total dosage of kerosene and No.2 oil is 1200 g/t and w (kerosene: No.2 oil) = 4:1, the recovery is more than 97%. The ball milling treatment separated the impurities from the graphite surface, while the magnetic separation reduced iron content in graphite. After three times of the ball milling and magnetic separation treatment, the fixed carbon content in graphite increases from 58% to more than 88%. Under the optimum conditions, the ash content of graphite can be reduced to 0.03% by mixed acid treatment, reaching the standard of high purity graphite. SEM analysis also showed no significant difference in shape between the recovered flake graphite and the natural flake graphite.
-
Key words:
- Desulfurization slag /
- Flake graphite /
- Recycle /
- Flotation /
- Waste treatment
-
-
表 1 KR脱硫渣的化学成分/%
Table 1. Chemical composition of KR desulfurization slag
TFe* FeO CaO f-CaO** SiO2 MgO Al2O3 LOI*** 6.85 1.48 44.93 4.98 9.66 2.26 4.51 23.13 注：*表示渣铁元素单质形式的含量；**为游离氧化钙；***为950℃时的煅烧损失量。
下载: 导出CSV
表 2 “球磨+磁选”回收石墨的灰分的化学成分/%
Table 2. "Ball mill + water scrub + magnetic separation" to recover the chemical composition of impurities
组份 SiO2 Al2O3 Fe2O3 CaO MgO K2O Na2O “球磨+磁选”一次 6.51 3.13 68.55 11.50 1.61 0.30 0.20 “球磨+磁选”三次 13.09 4.50 43.51 25.56 4.21 0.30 0.20
下载: 导出CSV
-
[1] 张莉, 丁瑶, 刁杰, 等. 高铁脱硫渣制备高纯度草酸亚铁的研究[J]. 武汉工程大学学报, 2010(7):62-64. doi: 10.3969/j.issn.1674-2869.2010.07.016
ZHANG L, DING Y, DIAO J, et al. Study on the mechanics parameters of the covering rock in mining with sublevel caving method[J]. Journal of Wuhan Institute of Technology, 2010(7):62-64. doi: 10.3969/j.issn.1674-2869.2010.07.016
[2] 黄鹏. KR脱硫渣特性及在处理酸性废水上应用的研究[D]. 马鞍山: 安徽工业大学, 2012.
HUANG P. Study on characteristics of KR desulfurization slag and its application in treatment of acid wastewater[D]. Ma’anshan: Anhui University of Technology, 2012.
[3] 郭兴敏, 韩其勇, 刘浏, 等. 铁酸钙渣系脱磷的研究[J]. 钢铁, 1998, 33(5):20-23.
GUO X M, HAN Q Y, LIU L, et al. Study of dephosphorization by calcium Ferrite fluxes[J]. Iron and Steel, 1998, 33(5):20-23.
[4] 张健. 铁水脱硫渣超细微粉基础性能及应用研究[J]. 四川建材, 2018, 44(10):18-19. doi: 10.3969/j.issn.1672-4011.2018.10.010
ZHANG J. Study on basic properties and application of ultrafine powder of hot metal desulfurization slag[J]. Sichuan Building Materials, 2018, 44(10):18-19. doi: 10.3969/j.issn.1672-4011.2018.10.010
[5] 顾恒星, 李辉, 金强, 等. 铁水脱硫渣代炭黑对丁苯橡胶的性能影响[J]. 建筑材料学报, 2017, 20(6):925-930. doi: 10.3969/j.issn.1007-9629.2017.06.016
GU H X, LI H, JIN Q, et al. Effect of molten iron desulphurization slag instead of carbon black on the properties of styrene butadiene rubber[J]. Journal of Building Materials, 2017, 20(6):925-930. doi: 10.3969/j.issn.1007-9629.2017.06.016
[6] 李金伟. 炼铁炉渣中集结石墨回收试验和工业利用探讨[J]. 江苏冶金, 1996(3):12-14.
LI J W. Discussion on the recovery test and industrial utilization of aggregate graphite in ironmaking slag[J]. Jiangsu Metallurgy, 1996(3):12-14.
[7] 张韬, 程飞飞, 于阳辉. 内蒙古某低品位大鳞片石墨矿选矿试验研究[J]. 矿产综合利用, 2019(1):57-60. doi: 10.3969/j.issn.1000-6532.2019.01.012
ZHANG T, CHENG F F, YU Y H. Experimental research on beneficiation of a low-grade and large flake graphite ore in inner mongolia[J]. Multipurpose Utilization of Mineral Resources, 2019(1):57-60. doi: 10.3969/j.issn.1000-6532.2019.01.012
[8] 李哲. 鳞片石墨浮选特性及工艺研究[D]. 北京: 中国矿业大学, 2010.
LI Z. Research on the floatation characteristics and flotation intensification of flake graohite[D]. Beijing: China University of Mining and Technology, 2010.
[9] 沈笑君, 刘元晖. 浮选捕收剂与起泡剂的相互作用研究[J]. 洁净煤技术, 2009(1):14-16. doi: 10.3969/j.issn.1006-6772.2009.01.003
SHEN X J, LIU Y H. Study on the interaction between the collectors and the frothers in flotation[J]. Clean Coal Technology, 2009(1):14-16. doi: 10.3969/j.issn.1006-6772.2009.01.003
[10] 翁孝卿, 李洪强, 程润, 等. 低品位隐晶质石墨浮选提纯实验研究[J]. 矿产综合利用, 2018(5):84-88. doi: 10.3969/j.issn.1000-6532.2018.05.018
WENG X Q, LI H Q, CHENG R, et al. Study on the purification of a low-grade microcrystalline graphite by flotation[J]. Multipurpose Utilization of Mineral Resources, 2018(5):84-88. doi: 10.3969/j.issn.1000-6532.2018.05.018
[11] 唐维. 隐晶质石墨的混合酸法纯化及吸波性能研究[D]. 长沙: 长沙理工大学, 2013.
TANG W. Studies on aphanitic graphite purified by mixed-acid method and microwave absorbing properties[D]. Changsha: Changsha University of Science & Technology, 2013.
[12] 唐维, 匡加才, 谢炜, 等. 混合酸纯化对隐晶质石墨固定碳含量的影响[J]. 炭素技术, 2013, 32(1):9-12.
TANG W, KHUANG J C, XIE W, et al. The effect of mixed-acid purification on the fixed carbon content of aphanitic graphite[J]. Carbon Techniques, 2013, 32(1):9-12.
[13] 盛广宏, 汪忠宇, 朱双, 等. 利用回收石墨制备的氧化石墨烯及其吸附性能[J]. 环境工程学报, 2016, 10(9):5179-5184. doi: 10.12030/j.cjee.201504194
SHENG G H, WANG Z Y, ZHU S, et al. Preparation and adsorption characteristics of graphene oxide from recycled graphite[J]. Chinese Journal of Environmental Engineering, 2016, 10(9):5179-5184. doi: 10.12030/j.cjee.201504194
-
