Experimental Study on Suspension Magnetization Roasting-Magnetic Separation of an Iron Ore
-
摘要:
某铁矿石铁品位是56.36%，主要以赤褐铁矿的形式存在，脉石矿物主要是石英和铝土矿。对该铁矿石采用了悬浮磁化焙烧—磁选工艺实验研究，在给料粒度为-0.074 mm 56.11%，焙烧温度为560℃，总气量为500 mL/min、CO浓度为30%，还原时间为15 min的条件下进行焙烧实验，然后将焙烧产品磨至-0.074 mm 95%，在磁场强度90 kA/m，选别时间5 min的条件下进行弱磁选实验，获得了铁品位64.42%，铁回收率94.49%的高品位铁精矿，为处理难选铁矿石提供了解决办法。
Abstract:The iron grade of a certain iron ore was 56.36%. The iron of raw ore mainly existed in the forms of hematite and limonite. The gangue minerals were chiefly quartz and bauxite. Therefore, a suspensionmagnetization roasting-magnetic separation process test was conducted on the ore. The results indicated that the optimum conditions for reducing roasting are as follows: The size of feed is -0.074 mm 56.11%, with roasting temperature 560℃, concentration of CO 30%, and roasting time 15 min. Under the optimum roasting conditions, the roasted products were ground to -0.074 mm 95%, and then magnetic separation was carried out to produce aniron concentrate with iron grade of 64.42% and iron recovery of 94.49%. It also provides a solution for other refractory iron ores.
-
Key words:
- Iron ore /
- Suspension magnetization roasting /
- Magnetic separation /
- Hematite /
- Magnetite
-
-
表 1 原矿的化学多元素分析/%
Table 1. Multi-element analysis of the raw ore
TFe FeO SiO2 Al2O3 MgO P S 烧失 56.36 1.13 3.38 7.00 0.68 0.082 0.047 8.59
下载: 导出CSV
表 2 铁物相分析结果
Table 2. Analysis results of irons phase
名称 磁性铁
中的铁碳酸铁
中的铁赤（褐、镜）
铁矿中的铁硫化铁
中的铁硅酸铁
中的铁总铁 含量/% 2.35 0.16 53.36 0.66 0.14 56.67 分布率/% 5.38 0.28 92.93 1.16 0.25 100.00
下载: 导出CSV
表 3 焙烧产品化学多元素分析/%
Table 3. Multi-element analysis of the roasted ore
TFe FeO SiO2 Al2O3 MgO P S 58.16 25.29 3.70 7.69 0.18 0.082 0.093
下载: 导出CSV
表 4 焙烧后铁物相分析
Table 4. Iron phase analysis after roasting
名称 磁性铁
中的铁碳酸铁
中的铁赤（褐、镜）
铁矿中的铁硫化铁
中的铁硅酸铁
中的铁总铁 含量/% 51.68 0.10 5.87 0.40 0.13 58.20 分布率/% 86.25 1.95 10.84 0.74 0.22 100.00
下载: 导出CSV
表 5 磁选精矿产品化学多元素分析/%
Table 5. Multi-element analysis of magnetic separation concentrate
TFe FeO SiO2 Al2O3 MgO P S 64.54 22.29 1.64 5.65 0.26 0.10 0.037
下载: 导出CSV
-
[1] 汪民, 彭齐鸣, 许大纯, 等. 中国矿产资源报告[R]. 北京: 地质出版社, 2015.
WANG M, PENG Q M, XU D C , et al. China mineral resources[R]. Beijing: Geological Publishing House, 2015.
[2] 李凤久, 尚新月, 李国峰, 等. 河北某铁矿铁精矿制备超级铁精矿试验[J]. 矿产综合利用, 2019(6):33-36. doi: 10.3969/j.issn.1000-6532.2019.06.007
LI F J, SHANG X Y, LI G F, et al. Experimental study on preparation of the super iron concentrate from an iron concentrate of an iron mine in Hebei province[J]. Multipurpose Utilization of Mineral Resources, 2019(6):33-36. doi: 10.3969/j.issn.1000-6532.2019.06.007
[3] 丁湛, 文书明, 李春龙, 等. 铁矿石脱磷硫工艺现状及同步脱除新方法[J]. 矿产综合利用, 2020(3):56-62. doi: 10.3969/j.issn.1000-6532.2020.03.009
DING Z,WEN S M,LI C L,et al. Current status of iron ore dephosphorization and desulphurization process and a new method for simultaneous removal[J]. Multipurpose Utilization of Mineral Resources, 2020(3):56-62. doi: 10.3969/j.issn.1000-6532.2020.03.009
[4] 袁帅, 韩跃新, 高鹏, 等. 难选铁矿石悬浮磁化焙烧技术研究现状及进展[J]. 金属矿山, 2016, 45(12):4-7. doi: 10.3969/j.issn.1001-1250.2016.12.003
YUAN S, HAN Y X, GAO P, et al. Research status and development of suspension roasting for refractory iron ore[J]. Metal Mine, 2016, 45(12):4-7. doi: 10.3969/j.issn.1001-1250.2016.12.003
[5] 李二垒, 刘杰, 杨晓峰, 等. 鞍山某复杂难选铁矿石预选-磁化焙烧-弱磁选试验[J]. 金属矿山, 2017(7):78-81. doi: 10.3969/j.issn.1001-1250.2017.07.016
LI E L, LIU J, YANG X F, et al. Research on preconcentration magnetic roasting-low intensity magnetic separation of refractory iron ore from Anshan[J]. Metal Mine, 2017(7):78-81. doi: 10.3969/j.issn.1001-1250.2017.07.016
[6] 王星亮. 悬浮磁化焙烧技术工业应用简介[J]. 矿业工程, 2020, 18(1):19-22. doi: 10.16672/j.cnki.kygc.2020.01.008
WANG X L. Introduction to the industrial application of suspension magnetization roasting technology[J]. Mining Engineering, 2020, 18(1):19-22. doi: 10.16672/j.cnki.kygc.2020.01.008
[7] 唐晓玲, 陈毅琳, 韩跃新, 等. 酒钢粉矿悬浮磁化焙烧扩大试验研究[J]. 金属矿山, 2019(2):29-33. doi: 10.19614/j.cnki.jsks.201902005
TANG X L, CHEN Y L, HAN Y X, et al. Expansion experimen‐tal study for suspension magnetization roasting in Jiugang powder ore[J]. Metal Mine, 2019(2):29-33. doi: 10.19614/j.cnki.jsks.201902005
[8] 陈毅琳, 唐晓玲, 李艳军, 等. 酒钢尾矿悬浮磁化焙烧扩大连续试验研究[J]. 金属矿山, 2020(5):178-184. doi: 10.19614/j.cnki.jsks.202005026
CHEN Y L, TANG X L, LI Y J, et al. Extended continuous test study on suspension magnetization roasting of JISCO tailings[J]. Metal Mine, 2020(5):178-184. doi: 10.19614/j.cnki.jsks.202005026
[9] 袁帅, 韩跃新, 李艳军, 等. 国外某赤铁矿石悬浮磁化焙烧-磁选试验[J]. 金属矿山, 2018(8):70-72.
YUAN S, HAN Y X, LI Y J, et al. Suspension magnetization roasting-magnetic separation test of a certain hematite ore abroad[J]. Metal Mine, 2018(8):70-72.
[10] 余建文, 韩跃新, 李艳军, 等. 鞍山式赤铁矿预选粗精矿悬浮态磁化焙烧—磁选试验研究[J]. 中南大学学报:自然科学版, 2018, 49(4):771.
YU J W, HAN Y X, LI Y J, et al. Experimental study on utilization of crude concentrate from an Anshan-type hematite ore by suspension magnetization roasting-magnetic separation[J]. Journal of Central South University:Science and Technology, 2018, 49(4):771.
[11] 柳林, 王威, 刘红召, 等. 磁化焙烧—磁选回收某褐铁矿中铁的试验研究[J]. 矿产综合利用, 2019(4):33-37. doi: 10.3969/j.issn.1000-6532.2019.04.006
LIU L, WANG W, LIU H S, et al. Research on recovery of iron from limonite by magnetization roasting and magnetic separation[J]. Multipurpose Utilization of Mineral Resources, 2019(4):33-37. doi: 10.3969/j.issn.1000-6532.2019.04.006
[12] 罗宿星, 陈华仕, 牟青松, 等. 黄铁矿的吸附性能研究现状及进展[J]. 矿产综合利用, 2020(5):26-33. doi: 10.3969/j.issn.1000-6532.2020.05.003
LUO S X, CHEN H S, MU Q S, et al. Research situation and progress of adsorption properties of pyrite[J]. Multipurpose Utilization of Mineral Resources, 2020(5):26-33. doi: 10.3969/j.issn.1000-6532.2020.05.003
[13] 柳晓, 韩跃新, 李艳军, 等. 山东某赤泥磁化焙烧—磁选提铁初探[J]. 金属矿山, 2019(2):60-65. doi: 10.19614/j.cnki.jsks.201902011
LIU X, HAN Y X, LI Y J, et al. Magnetized roasting of a red mud in Shandong-a preliminary study on iron extraction by magnetic separation[J]. Metal Mine, 2019(2):60-65. doi: 10.19614/j.cnki.jsks.201902011
-
