Mineralogical Characteristics of Spodumene in No. VIII Pegmatite Vein of Dangba Spodumene Deposit, Sichuan
-
摘要:
采用显微镜下观察、电子探针（EPMA）、激光剥蚀等离子质谱（LA-ICP-MS）和X射线衍射分析（XRD）等测试手段对四川党坝锂辉石矿床VIII号脉锂辉石的矿物学特征开展了详细研究。结果显示，锂辉石是主要的矿石矿物，锂辉石晶体粒度较粗大，锂主要赋存于锂辉石中，伴生有铌、钽等有益组分。XRD和LA-ICP-MS分析显示，锂辉石的纯度很高（Li2O平均含量7.84%），晶胞参数略小于标准卡片的晶胞参数。电子探针分析结果显示，锂辉石中SiO2含量较高（65.62%~65.82%），含有少量的Fe和Mn等杂质。矿石中Li2O含量达到1.33%。综合分析该锂矿具有重要的开发利用价值。
Abstract:Systematic research of mineralogical characteristics of spodumene of VIII pegmatite vein in Dangba spodumene deposit are studied by microscopic observation, electron probe micro analysis (EPMA), Laser ablation plasma mass spectrometry（LA-ICP-MS）and X-ray diffraction analysis (XRD). The results show that the main ore mineral is spodumene. The spodumene crystal partical is large, lithium mainly occurs in spodumene, accompanied by niobium and tantalum beneficial components. XRD and LA-ICP-MS analysis show that the purity of spodumene is very high（the average contentof Li2O is 7.84%）and the cell parameters are slightly lower than those of standard cards. The EPMA results show that the content of SiO2 in spodumene was high (65.62%~65.82%), with a small amount of impurities such as Fe and Mn. The contents of Li2O in the pegmatite ore is up to 1.33%. To sum up, the lithium ore has important development and utilization value.
-
Key words:
- Mineralogy /
- Spodumene /
- Comprehensive utilization /
- Dangba /
- Sichuan Province
-
-
表 1 锂辉石单矿物电子探针成分分析/%
Table 1. Monomineral chemical analysis of spodumene by EPMA
Na2O MgO K2O CaO P2O5 SiO2 Al2O3 FeO MnO Cr2O3 Li2O* 合计 0.147 0.006 0.018 0.031 0.058 65.62 27.479 0.299 0.051 0.019 8.29 102.0 0.143 0.005 0.011 0.017 0.021 65.83 27.412 0.54 0.127 0.009 8.29 102.4 0.161 0.02 0.031 0.044 0 65.73 27.73 0.298 0.09 0.027 8.25 102.4
下载: 导出CSV
表 2 锂辉石单矿物LA-ICP-MS分析/%
Table 2. Monomineral chemical analysis of spodumene by LA-ICP-MS
Na2O MgO Al2O3 SiO2 P2O5 K2O CaO TiO2 FeO MnO Li2O 合计 0.073 0.0053 27.4 64.0 0.054 — 0.029 0.0019 0.075 0.32 8.02 99.97 0.11 0.0045 27.2 64.2 0.032 0.0019 0.043 0.0027 0.083 0.33 7.95 99.96 0.12 0.0003 27.3 64.6 0.0014 0.0036 0.041 0.012 0.063 0.30 7.54 99.97
下载: 导出CSV
表 3 党坝锂辉石晶胞参数与各地锂辉石晶胞参数的对比
Table 3. Lattice parameters of spodumene from the Dangba Deposit and the comparision to other spodumenes
下载: 导出CSV
表 4 伟晶岩矿石多元素分析结果%
Table 4. Chemical analysis of multi-elements of pegmatite ore samples
Li2O Nb2O5 Ta2O5 SnO2 BeO Rb2O Cs2O SiO2 Al2O3 TFe MnO MgO CaO Na2O K2O P2O5 1.33 0.009 0.004 0.01 0.04 0.106 0.02 75.43 15.56 0.51 0.13 0.03 0.25 4.23 2.19 0.22
下载: 导出CSV
-
[1] 翟明国, 吴福元, 胡瑞忠, 等. 战略性关键金属矿产资源: 现状与问题[J]. 中国科学基金, 2019, 2:106-111. ZHAI M G, WU F Y, HU R Z, et al. Critical metal mineral resources: current research status and scientific issues[J]. Science Foundation in China, 2019, 2:106-111.
[2] 王登红, 刘丽君, 代鸿章, 等. 试论国内外大型超大型锂辉石矿床的特殊性与找矿方向[J]. 地球科学, 2017, 42(12):2243-2257. WANG D H, LIU L J, DAI H Z, et al. Discussion on particularity and prospecting direction of large and super-large spodumene deposits[J]. Earth Science, 2017, 42(12):2243-2257.
[3] 古城会. 四川省可尔因伟晶岩田东南密集区锂辉石矿床成矿规律[J]. 地质找矿论丛, 2014, 29(1):59-65. GU C H. Metallogenic regularity of spodumene deposits in the closely spaced pegmatite area in the southeastern Ke’eryin pegmatite field, Sichuan province[J]. Contributions to Geology and Mineral Resources Research, 2014, 29(1):59-65. doi: 10.6053/j.issn.1001-1412.2014.01.007
[4] 李建康. 川西典型伟晶岩型矿床的形成机理及其大陆动力学背景[D]. 北京: 中国地质大学, 2006.
LI J K. Mineralizing mechanism and continental geodynamics of typical pegmatite deposits in Western Sichuan, China[D]. Beijing: China University of Geosciences, 2006.
[5] 季根源, 江思宏, 夏浩东, 等. 四川阿坝州党坝伟晶岩型锂辉石矿床流体包裹体特征及地质意义[J]. 地质找矿论丛, 2020, 35(1):33-41. JI G Y, JIANG S H, XIA H D, et al. Characteristics and geological significance of fluid inclusions in Dangba pegmatite spodumene deposit in Aba Prefecture, Sichuan Province[J]. Contributions to Geology and Mineral Resources Research, 2020, 35(1):33-41. doi: 10.6053/j.issn.1001-1412.2020.01.005
[6] 王子平, 刘善宝, 马圣钞, 等. 四川阿坝州党坝超大型锂辉石矿床成矿规律及深部和外围找矿方向[J]. 地球科学, 2018, 43(6):2029-2041. WANG Z P, LIU S B, MA S C, et al. Metallogenic regularity, deep and periphery prospecting of Dangba Superlarge spodumene deposit in Aba, Sichuan Province[J]. Earth Science, 2018, 43(6):2029-2041.
[7] 费光春, 杨峥, 杨继忆, 等. 四川马尔康党坝花岗伟晶岩型稀有金属矿床成矿时代的限定: 来自LA-MC-ICP-MS锡石U-Pb定年的证据[J]. 地质学报, 2020, 94(3):836-849. FEI G C, YANG Z, YANG J Y, et al. New precise timing constraint for the Dangba granitic pegmatite type rare-metal deposit, Markam, Sichuan Province, evidence from cassiterite LA-MC-ICP-MS U-Pb dating[J]. Acta Geologica Sinica, 2020, 94(3):836-849. doi: 10.3969/j.issn.0001-5717.2020.03.012
[8] 马圣钞, 王登红, 刘善宝, 等. 川西可尔因锂矿田云母矿物化学及稀有金属成矿和找矿指示[J]. 矿床地质, 2019, 38(4):877-897. MA S C, WANG D H, LIU S B, et al. Mineral chemistry of micas from Ke'eryin pegmatite type lithium orefield in western Sichuan and its indication for rare metal mineralization and prospecting[J]. Mineral Deposits, 2019, 38(4):877-897. doi: 10.16111/j.0258-7106.2019.04.013
[9] 许志琴, 王汝成, 赵中宝, 等. 试论中国大陆“硬岩型”大型锂矿带的构造背景[J]. 地质学报, 2018, 92(6):1091-1106. XU Z Q, WANG R C, ZHAO Z B, et al. On the structural backgrounds of the large-scale “hard-rock type” lithium ore belts in China[J]. Acta Geologica Sinica, 2018, 92(6):1091-1106. doi: 10.3969/j.issn.0001-5717.2018.06.001
[10] CHEN H H, XU J, HU Z C, et al. In situ analysis of major and trace elements of anhydrous minerals by LA-ICP-MS without applying an internal standard[J]. Chemical Geology, 2009, 257(1-2):34-43.
[11] 周雄, 张贻, 赵开乐, 等. 四川甲基卡锂辉石矿134矿脉工艺矿物学特性[J]. 矿产综合利用, 2018(3):104-108. ZHOU X, ZHANG Y, ZHAO K L, et al. Technological mineralogy characteristics of 134 Vein in spodumene mine at Jiajika, Sichuan Province[J]. Multipurpose Utilization of Mineral Resources, 2018(3):104-108. doi: 10.3969/j.issn.1000-6532.2018.03.022
[12] 周雄, 周玉, 谭洪旗, 等. 四川措拉锂多金属矿的矿物学特征研究[J]. 矿产综合利用, 2020(6):148-152. ZHOU X, ZHOU Y, TAN H Q, et al. Mineralogical study on cuola lithium polymetallic mining area, Western Jiajika, Sichuan[J]. Multipurpose Utilization of Mineral Resources, 2020(6):148-152. doi: 10.3969/j.issn.1000-6532.2020.06.025
[13] 冯恒毅. 河南官坡伟晶岩中锂辉石的矿物学及提锂工艺研究[D]. 北京: 中国地质大学, 2009.
FENG H Y. Study on mineralogy and preparationof lithium carbonate of spodumene from pegmatite deposits in Guanpo, Henan Province[D]. Beijing: China University of Geoscience, 2009.
[14] 杨岳清, 王文瑛, 倪云祥, 等. 南平花岗伟晶岩中锂辉石的研究[J]. 福建地质, 1995, 14(2):95-108. YANG Y Q, WANG W Y, NI Y X, et al. A study on the spodumene in the granitic pegmatite in Nanping, Fujian Province[J]. Geology of Fujian, 1995, 14(2):95-108.
-
